USER'S MANUAL

VIA P4M900 Chipset

VIA VT8237R Plus Chipset

M/B For LGA775 Conroe & Dual Core Ready

Intel Pentium-D Processor

No. G03-P900DMP-F

Rev:1.0

Release date: Dec 2006

Trademark:

* Specifications and Information contained in this documentation are furnished for information use only, and are

subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

CHAPTER 1 INTRODUCTIONOFVIA P4M900 MOTHERBOARDSERIES

1-1 FEATURES OF MOTHERBOARD.................................................................................... 1

1-1.1 SPECIAL FEATURES OF MOTHERBOARD.................................................... 2

1-2 SPECIFICATION................................................................................................................... 3

1-3 ITEM CHECKLIST..............................................................................................................4

1-4 LAYOUT DIAGRAM & JUMPER SETTING................................................................... 4

CHAPTER 2 HARDWARE INSTALLATION

2-1 INSTALL LGA 775 SUPPORTED INTEL PROCESSOR................................................ 5

2-2 INSTALL MEMORY............................................................................................................ 6

2-3 EXPANSION CARDS........................................................................................................... 7

CHAPTER 3 CONNCTORS, HEADERS & JUMPERS SETTING

3-1 CONNECTORS..................................................................................................................... 8

3-2 HEADERS.............................................................................................................................. 10

CHAPTER 4 USEFUL HELP

4-1 HOW TO UPDATE BIOS..................................................................................................... 12

4-2 TROUBLE SHOOTING....................................................................................................... 12

Environmental Protection Announcement

Do not dispose this electronic device into the trash while discarding. To minimize pollution

and ensure environment protection of mother earth, please recycle.

TABLE OF CONTENT

Chapter 1

Introduction of VIA P4M900 Chipset Motherboards

1-1 Feature of motherboard

The VIA P4M900 chipset motherboard series are designed for the innovative 65nm and 90nm

Dual-Core Intel® Pentium® D Processor 8 and 9 Series, Intel® Pentium® D Processor, and

Intel® Core 2 Duo® (Code Name: Conroe) Processor with Intel® Hyper-Threading

Technology. With the cost-effective VIA P4M900 chipset that delivers a high performance and

professional desktop platform solution.

The VIA P4M900 chipset motherboard series implement VIA P4M900 chipset which supports

400MHz/ 533MHz /800MHz/1066MHz system bus of data transfer rate and Hyper Threading

technology. The VIA P4M900 chipset motherboard series provide 333MHz/266MHz/200MHz

memory clock frequency for DDR2 667/533/400 system RAM Modules. The motherboard

series are embedded with VIA VT8237R PLUS South Bridge offers ULTRA ATA 133 and

Serial ATA with RAID 0, 1, JBOD functions to provide speedier HDD throughout that

boosts overall system performance. The VIA P4M900 Chipset motherboard series implement

the VIA VT6103L LAN PHY chip Support Fast Ethernet LAN function provide 10/100 Mb/s

data transfer rate.

The motherboard series also have an integrated 6-channel AC’97 CODEC on board which is

fully compatible with Sound Blaster Pro®that gives you the best sound quality and

compatibility.

.Featuring the VIA Chrome9™ HC IGP (Integrated Graphics Processor) core, the VIA

P4M900 delivers DirectX® 9 graphics support with hardware pixel shaders to meet the

requirements of the upcoming Windows® Vista™ operating system, and rising high

definition video requirements. The core of the VIA P4M900 North Bridge lies the VIA

Chrome9™ HC IGP, delivering a rich visual experience through the implementation of

innovative features such a 128 bit 2D/3D engine with dual pixel pipeline. The P4M900 also

features extensive display support for all HDTV output formats including 1920x1080p and

additional advanced graphics capabilities include the Chromotion Video Display Engine,

comprehensive de-interlace support, and DuoView™ for enhanced productivity and

presentation capabilities.

The VIA P4M900 chipset motherboard series provide one PCI-Express x16 graphics slot of

4Gbyte/sec data transfer rate at each relative direction which gets 3.5 times of bandwidth

more than AGP8X and it’s up to a peak concurrent bandwidth of 8Gbyte/sec at full speed to

guarantee the fully operational GPU graphics power; one PCI Express x1 I/O slot offers

512Mbyte/sec concurrently which is 3.5 times bandwidth more than PCI at 133Mbye/sec.Two

32-bit PCI slots guarantee the rich connectivity for the I/O peripherals.

With USB controller as well as capability of expanding to 8x USB2.0 function ports

delivering 480Mb/s bandwidth and rich connectivity, the motherboards meet future USB

demand also have built-in hardware monitor function to monitor and protect your computer.

The motherboards provide high performance & meet future specification demand of the next

generation operation system. It is a wise choice for your non-stop business computing.

Some special features---CPU Thermal Throttling/ CPU Vcore 7-shift ) in this motherboard are

designed for power user to use the over-clocking function in more flexible ways. But please be caution

that the over-clocking maybe cause the fails in system reliabilities. This motherboard provides the

guaranteed performance and meets the demands of the next generation computing. But if you insist to

gain more system performance with variety possibilities of the components you choose, please be

careful and make sure to read the detailed descriptions of these value added product features, please

get them in the coming section.

1-1.1 Special Features of Motherboard

CPU Thermal Throttling Technology---(The CPU Overheat Protection Technology)

To prevent the increasing heat from damage of CPU or accidental shutdown while at high workload,

the CPU Thermal Throttling Technology will force CPU to enter partially idle mode from 87.5% to

12.5% according to preset CPU operating temperature in BIOS (from 40℃to 90℃). When the

system senses the CPU operating temperature reaching the preset value, the CPU operating bandwidth

will be decreased to the preset idle percentage to cool down the processor. When at throttling mode the

beeper sound can be optionally selected to indicate it is in working.

CPU Smart Fan---( The Noise Management System(Not Support 3-pin CPU Fan) )

It’s never been a good idea to gain the performance of your system by sacrificing its acoustics. CPU

Smart Fan Noise Management System is the answer to control the noise level needed for now-a-day’s

high performance computing system. The system will automatically increase the fan speed when CPU

operating loading is high, after the CPU is in normal operating condition, the system will low down

the fan speed for the silent operating environment. The system can provide the much longer life cycle

for both CPU and the system fans for game use and business requirements.

CPU Vcore 7-Shift--- (Shift to Higher Performance)

The CPU voltage can be adjusted up by 7 steps for the precisely over-clocking of extra demanding

computing performance.

1-2 Specification

Spec Description

Design ∗Micro ATX form factor 4 layers PCB size: 24.4x21.0cm

Chipset ∗VIA P4M900 North Bridge Chipset

∗VIA VT8237R Plus South Bridge Chipset

CPU Socket

(LGA 775 Socket)

∗Support Intel Pentium 4, Celeron D, Pentium D, and Core 2 Duo

775-Land LGA Package utilizes Flip-Chip Land Grid Array

(FCLGA4) package processor

∗Support FSB Frequency 533MHz / 800 / 1066MHz

Memory Socket ∗240-pin DDRII Module socket x 2

∗Support 2pcs DDRII 667/553 / 400 system memory modules

which are expandable to 4.0GB

Expansion Slot ∗PCI-Express x16 slot 1pcs deliver up to 8GB/s concurrent bandwidth

∗PCI-Express x1 slot 1pcs delivers up to 512MB/s concurrent

bandwidth

∗32-bit PCI slot x 2pcs

Integrate IDE and

Serial ATA RAID

∗Two PCI IDE controllers support PCI Bus Mastering, ATA

PIO/DMA and the ULTRA DMA 33/66/100/133 functions that

deliver the data transfer rate up to 133 MB/s; Two Serial ATA

ports provide 150 MB/sec data transfer rate for two Serial ATA

Devices and offer RAID 0, 1, JBOD functions

VGA

∗Integrated Chrome9™ HC IGP

∗128 bit 2D/3D engine with dual pixel pipeline

∗250MHz engine clock speed.

LAN

∗Integrated VIA 6103L PCI-10 /100 LAN PHY

∗Supports Fast Ethernet LAN function provide 10Mb / 100Mb /

s data transfer rate

Audio ∗VIA VT1616B AC’97 Digital Audio controller integrated

∗6-channel AC’97 Audio CODEC onboard

∗Audio driver and utility included

BIOS ∗Award 4MB Flash ROM

Multi I/O ∗PS/2 keyboard and PS/2 mouse connectors

∗Floppy disk drive connector x1

∗Parallel port x1

∗Serial port x1

∗VGA port x1

∗USB2.0 port x 4 and headers x 4 (connecting cable option)

∗Audio connector (Line-in, Line-out, MIC)

1-3 Item Checklist

5VIA P900DMP Chipset motherboard

5Cable for IDE

5CD for motherboard utilities

5Cable for Serial ATA IDE Port

5VIA P900DMP Chipset motherboard User’s Manual

1-4 Layout Diagram & Jumper Setting

PC99 Back Panel

Front Panel Audio

CD Audio

PS2 KB/Mouse Port

K/B Power

ON Jumper (JP1)

USB Port

(USB2, USB3)

Fintek F71805F Chip

PCI Slo

6-CH AC’97

Codec

4MBit Flash ROM BIOS

SFAN1

ATA 133 IDE

Connector (IDE1, IDE2)

Clear CMOS (JBAT)

VIA VT8237R Plus Chip

Speaker / Power LED

Connector

VIA P4M900

Chi

set

CPU Socket

DDRII Socket X2

USB Port/

LAN Connector

USB Port

Audio Connector

Front Panel Connector

Optional VIA

VT6103 LAN PHY

USB Power

On Jumper (JP2)

ATX Powe

Connector

Serial-ATA

Connector (SATA1, 2)

CPU FAN

ATX 12V Connecto

16 lane PCI EXPRESS SFAN2

Floppy

Connector

PCI EXPRESSX1

Chapter 2

Hardware Installation

2-1 Install LGA775 Supported Intel CPU

This motherboard provides a 775-pin surface mount, LGA775 Land Grid Array socket, referred to as

the LGA775 socket supports Intel Pentium 4 processor in the 775 Pin package utilizes Flip-Chip Land

Grid Array (FC-LGA4) package technology.

The CPU that comes with the motherboard should have a cooling FAN attached to prevent

overheating. If this is not the case, then purchase a correct cooling FAN before you turn on your

system.

WARNING! Be sure that there is sufficient air circulation across the processor’s heatsink and CPU

cooling FAN is working correctly, otherwise it may cause the processor and motherboard

overheat and damage, you may install an auxiliary cooling FAN, if necessary.

To install a CPU, first turn off your system and remove its cover. Locate the LGA775 socket and

open it by first pulling the level sideways away from the socket then upward to a 90-degree angle.

Insert the CPU with the correct orientation as shown below. The notched corner should point toward

the end of the level. Because the CPU has a corner pin for two of the four corners, the CPU will only

fit in the orientation as shown.

CPU LGA775 Socket

Colden Arrow

LGA775

When you put the CPU into the LGA775 socket. No force require to insert of the CPU, then

press the level to Locate position slightly without any extra force.

2-2 Install Memory

This motherboard provides two 240-pin DDR DUAL INLINE MEMORY MODULES

(DIMM) sides for DDR memory expansion available from minimum memory size of 64MB

to maximum memory size of 4.0GB DDR SDRAM.

Valid Memory Configurations

Bank 240-pin DDR DIMM PCS Total Memory

Bank 0, 1（DIMM 1）DDRII667/DDRII533/DDRII400 DDR DRAM

Module X1 64MB∼2.0GB

Bank 2, 3 (DIMM 2) DDRII667/DDRII533/DDRII400 DDR DRAM

Module

X1 64MB∼2.0GB

Total System Memory (Max. 4.0GB) X2 64MB∼4.0GB

Recommend DIMM Module Combination

1. One DIMM Module ----Plug in DIMM1

2. Two DIMM Modules---Plug in DIMM1 and DIMM2

Install DDR2 SDRAM modules to your motherboard is not difficult, you can refer to figure

below to see how to install a 240-Pin DDR2 400 / DDR2 533 / DDR2 667 SDRAM module.

DIMM2 (BANK2+ BANK3)

DIMM1 (BANK0+ BANK1)

NOTE! When you install DIMM module fully into the DIMM socket the eject tab should

be locked into the DIMM module very firmly and fit into its indention on both

sides.

Figure 2-4

2-2 Expansion Cards

This motherboard provides one 16-lane PCI Express slot which offers 4Gbyte/sec data

transfer rate at each relative direction intended for Video Graphics Array, and one x1 PCI

Express Slot. Fully compliant to the PCI Express Base Specification revision 1.0a , support

PCI Express VGA card, and other PCI Express device.

IMPORTANT! To install the single PCI EXPRESS x16 interface supported VGA card to get the full

speed of x16 bandwidth in the PCI EXPRESS x16 slot as being marked above. If you

utilize the EXPRESS x16 slot to support the VGA card as the external display, please

disabled the integrated VGA card in BIOS.

PCI-E x16 for full bandwidth

VGA Signal Output

PCI-E x1 Slot

32-bit PCI slot

Chapter 3

Connectors, Headers & Jumpers Setting

3-1 Connectors

(1) Power Connector (24-pin block) : ATXPWR1

ATX Power Supply connector.

This is a new defined 24-pins

connector that usually comes with

ATX case. The ATX Power Supply

allows to use soft power on

momentary switch that connect from

the front panel switch to 2-pins

Power On jumper pole on the

motherboard. When the power

switch on the back of the ATX

power supply turned on, the full

power will not come into the system

board until the front panel switch is

momentarily pressed. Press this

switch again will turn off the power to the system board.

** We recommend that you use an ATX 12V Specification 2.0-compliant power supply

unit (PSU) with a minimum of 350W power rating. This type has 24-pin and 4-pin

power plugs.

** If you intend to use a PSU with 20-pin and 4-pin power plugs, make sure that the 20-pin

power plug can provide at least 15A on +12V and the power supply unit has a minimum

power rating of 350W. The system may become unstable or may not boot up if the

power is inadequate.

(2) ATX 12V Power Connector (8-pin block) : ATX12V1

This is a new defined 8-pins connector that usually comes

with ATX Power Supply. The ATX Power Supply which fully

supports AM2 processor must including this connector for

support extra 12V voltage to maintain system power

consumption. Without this connector might cause system unstable because the power

supply can not provide sufficient current for system.

(3) PS/2 Mouse & PS/2 Keyboard Connector: KB1

The connectors for PS/2 keyboard and PS/2 Mouse.

(4) USB Port connector: CN3

The connectors are 4-pin connector that connects USB devices to the system board.

(5) LAN Port connector: UL1

This connector is standard RJ45 connector for Network

The USB/LAN1 support 10M/100Mb s data transfer rate

Pin 1

ROW1 ROW2

24-Pin

ROW1 ROW2

Pin 1

20-Pin

PIN ROW1 ROW2

1 3.3V 3.3V

2 3.3V -12V

3 GND GND

4 5V Soft Power On

5 GND GND

6 5V GND

7 GND GND

8 Power OK -5V

9 +5V (for Soft Logic) +5V

10 +12V +5V

11 +12V +5V

12 +3V GND

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere VIA Technologies Computerhardware Handbücher

VIA Technologies

VIA Technologies SOM-9X35-STK Bedienungsanleitung

VIA Technologies

VIA Technologies EPIA-P720 Bedienungsanleitung

VIA Technologies

VIA Technologies ARTiGO A935 Bedienungsanleitung

VIA Technologies

VIA Technologies LPC-01 Bedienungsanleitung

VIA Technologies

VIA Technologies SOM-7000 Bedienungsanleitung

VIA Technologies

VIA Technologies IVT01 Bedienungsanleitung

VIA Technologies

VIA Technologies VT82C693A Bedienungsanleitung

VIA Technologies

VIA Technologies VAB-820 Bedienungsanleitung

VIA Technologies

VIA Technologies ENT-610M Bedienungsanleitung

VIA Technologies

VIA Technologies ARTiGO A950 Bedienungsanleitung

VIA Technologies

VIA Technologies Mobile360 FSS Bedienungsanleitung

VIA Technologies

VIA Technologies VAB-820 Bedienungsanleitung

VIA Technologies

VIA Technologies SOM-6X80 Bedienungsanleitung

VIA Technologies

VIA Technologies SOM-9X50-STK Bedienungsanleitung

VIA Technologies

VIA Technologies SOM-9X50-STK Bedienungsanleitung

VIA Technologies

VIA Technologies ARTiGO A820 Bedienungsanleitung

VIA Technologies

VIA Technologies VAB-3000 Bedienungsanleitung

VIA Technologies

VIA Technologies ARTiGO-A1200 Bedienungsanleitung

VIA Technologies

VIA Technologies ARTiGO A600 Bedienungsanleitung

VIA Technologies

VIA Technologies AMOS-820 SKU Bedienungsanleitung

VIA Technologies

VIA Technologies VAB-3000 Bedienungsanleitung

VIA Technologies

VIA Technologies AMOS-820 SKU Bedienungsanleitung

VIA Technologies

VIA Technologies VNT6656AU Bedienungsanleitung

VIA Technologies

VIA Technologies SOM-6X50 Bedienungsanleitung

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

Intel

Intel NUC 12 Pro Bedienungsanleitung

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Intel

Intel AXXRMFBU4 Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung
