Victorinox Dive Master 500M Bedienungsanleitung

VICTO INOX SWISS A MY WATCH SA

Chemin des Grillons 4 – P.O. Box 1840 – 2501 Biel-Bienne – Switzerland

www.victorinoxswissarmy.com

USA

VICTO INOX SWISS A MY, INC.

7 Victoria Drive – P.O. Box 1212 – Monroe CT 06468-1212

Consumer Service: 800 442 2706

www.swissarmy.com

VICTO INOX SWISS A MY CANADA

904 Magnetic Drive – North York, ON – M3J 2C4

Consumer Service: 800 665 4095 ext 4127

www.swissarmy.com

V.03036.3

(North America, Asia/Paciﬁc, Middle East, Africa, Central and South America)

I N S T R U C T I O N S A N D WA R R A N T Y

F O R

CHRONOGRAPHS

Couv Chrono III USA u form t:couv Victorinox 30.9.2009 16:27 P ge 1

English 2-30

rançais 31-61

Español 62-91

Brasileiro 92-117

118-141

142-165

166-190

191-214

215-239

Authorized service centers 240-249

USA and Canada Repair Coupon 251-252

English USA Chrono VSA USA 30.9.2009 10:35 Page 1

I. GENERAL IN ORMATION 3

Disposal of used batteries 3

How to ﬁnd the calibre of your

timepiece 4

Special recommendations 4

II. CHRONOGRAPH UNCTIONS

Use of the chronograph 5

III. INSTRUCTIONS OR USE

QUARTZ CHRONOGRAPHS

Calibre ETA 251.262 6

Calibre ETA 251.262 INVERSE 7

Visual Countdown 8

Calibre ETA 251.272 10

Calibre ETA 251.471 12

Calibre ETA G10.211 14

IV. INSTRUCTIONS OR USE

MECHANICAL CHRONOGRAPHS

Calibre ETA A07.211 16

Calibre ETA 7750 17

Calibre ETA 7753 19

V. SPECI IC SECTION

Rotating bezel with countup

function 20

Rotating bezel with countdown

function 21

Tachymeter feature 21

Telemeter feature 22

Water resistance 23

VI. INTERNATIONAL WARRANTY 24

VII. NORTH AMERICAN WARRANTY

Three-year limited warranty 27

Repair coupon 251

VIII. AUTHORIZED SERVICE CENTERS

240

English Summary

VICTORI OX SWISS ARMY

I STRUCTIO S FOR USE A D LIMITED WARRA TY

English USA Chrono VSA USA 30.9.2009 10:35 Page 2

General in ormation English

I. GENERAL INFORMATION

Congratulations on having chosen a Victorinox Swiss Army timepiece. To ensure

your timepiece operates per ectly, we recommend that you ollow the advice given

in these instructions (All instruction manuals are also available on our website:

www.victorinoxswissarmy.com – Customer Service – User Manuals. For U.S. and

Canada: www.swissarmy.com).

Your chronograph is ﬁtted with either a screw-down or a “pull-out” crown. In order

to establish which, gently try to pull out the crown to position 2, i that works, your

timepiece is ﬁtted with a “pull-out” crown. I not, use your thumb and oreﬁnger to

apply mild pressure on the crown, while rotating towards you to release it. I it does

so, you have a screw-down crown.

After use, push the crown back n or screw t down unt l t s secure n

order to ma nta n the water res stance of your t mep ece.

Quartz timepieces are battery-operated. When the battery is exhausted, we

recommend that you have it replaced immediately at an authorized Victorinox Swiss

Army Service Center where the water resistance o your timepiece will also be

checked. The battery is not covered by the warranty.

COLLECTION AND DISPOSAL OF QUARTZ TIMEPIECE BATTERIES*

This symbol indicates that this product must not be thrown away with

household rubbish. It must be disposed o at an authorized battery

disposal point. By doing so you will be protecting the environment and

human health. Recycling conserves natural resources.

*Applicable in EU member countries and countries with similar

legislation.

English USA Chrono VSA USA 1.10.2009 9:12 Page 3

English General information

HOW TO FI D THE CALIBRE OF YOUR TIMEPIECE

To determine the calibre of your Victorinox Swiss Army Timepiece, please look at the

reference number engraved on the caseback and ﬁnd the corresponding calibre in

the Calibre Table in the annex or download it from our website:

www.victorinoxswissarmy.com / Customer Service.

or U.S. and Canada: www.swissarmy.com.

SPECIAL RECOMME DATIO S

– To avoid any errors, do not perform the DATE SETTI G between 9:00 p.m. and

3:00 a.m. when the date mechanism is in action. Be careful not to confuse noon

and midnight.

–ever operate chronographs pushers or crown when your timepiece is

under water or if it is wet and ensure that the crown and pushers are

properly pushed back or screwed down after each use.

– We recommend that you have the water resistance of your timepiece checked

at an authorized Victorinox Swiss Army Service Center every 18 months or

whenever the timepiece case is opened.

English USA Chrono VSA USA 30.9.2009 10:35 Page 4

Chronograph functions English

II. CHRO OGRAPH FU CTIO S

USE OF THE CHRO OGRAPH

Single Event:

1. Press pusher A to start the chronograph.

2 Press pusher A again to stop the chronograph.

3. Press pusher B to reset to zero.

ADD function (additional timings: each time you

stop the counter, the time is stopped and does not

take into consideration the elapsed time):

1. Press pusher A to start the chronograph.

2. Press pusher A to stop the chronograph and read the time.

3. Press pusher A again and read the additional timing... and so on.

4. Press pusher B to reset to zero.

SPLIT function (the split time function is used to display an intermediate time while

continuing timing). This function is not available for mechanical chronographs:

1. Press pusher A to start the chronograph.

2. Press pusher B to display an intermediate time, the chronograph will continue

timing.

3. Press pusher B again to catch up with timing.

4. Press pusher A to end the timing.

5. Press pusher B to reset to zero.

English USA Chrono VSA USA 30.9.2009 10:35 Page 5

English Quartz chronographs

III. I STRUCTIO S FOR USE

III. QUARTZ CHRO OGRAPHS

CALIBRE ETA 251.262

Pushers:

A Chronograph start/stop

B Split timing, zero reset

Timepiece indication:

C Hours

D Minutes

E Seconds

Date

Chronograph indication:

G 1/10th of a second counter

H 60-second counter

I 60-minute counter

J 12-hour counter

The crown has 3 positions:

1 Normal position

2 Time zone adjustment back and forth, date setting

3 Hour and minute setting, stop second

English USA Chrono VSA USA 30.9.2009 10:35 Page 6

Quartz chronographs English

CALIBRE ETA 251.262 I VERSE

Pushers:

A Chronograph start/stop

B Chronograph zero/reset

Crowns:

C Time setting crown

D Countdown setting crown

Timepiece indication:

E Hours

Minutes

G Date

H Visual Countdown ring with 60-minute scale

Chronograph indication:

I 1/10th of a second counter

J 60-second counter

K 60-minute counter

L 12-hour counter

The crown has 3 positions:

1 Normal position

2 Time zone adjustment back and forth, date setting

3 Hour and minute setting, stop second

English USA Chrono VSA USA 30.9.2009 10:35 Page 7

English Quartz chronographs

VISUAL COU TDOW

When rotating the countdown setting crown, simply align

minutes on the inner bezel to be counted down with the

minute hand (i.e. 20 minutes).

When the minute hand reaches the triangle (0 minute),

20 minutes will have been counted down.

ote: the countdown feature works for a duration between

1 and 60 minutes.

FOR CALIBRE ETA 251.262

A D CALIBRE ETA 251.262 I VERSE

SETTI G THE TIME

1. Pull out the crown to position 3. The seconds hand will stop.

Remember the date advances at 12:00 midnight, not 12:00 noon.

2. Turn the crown to position hands to the desired time.

3. Push the crown back to position 1.

SETTI G THE TIME ZO E

1. Pull out the crown to position 2.

2. Turn the crown back or forth to reach a new time zone.

3. Push the crown back to position 1.

English USA Chrono VSA USA 30.9.2009 10:35 Page 8

Quartz chronographs English

SETTI G THE DATE

1. Pull out the crown to position 2.

2. Turn the crown and the hour hand back or forth until the desired date is reached.

3. Push the crown back to position 1.

SETTI G THE COU TERS TO ZERO

12-hour counter:

1. Pull out the crown to position 2.

2. Press pusher A to adjust 12-hour hand to zero.

60-minute counter:

1. Pull out the crown to position 2.

2. Press pusher B to adjust 60-minute hand to zero.

60-second counter:

1. Pull out the crown to position 3.

2. Press pusher A to adjust the second hand to zero.

1/10th of a second counter:

1. Pull out the crown to position 3.

2. Press pusher B to adjust 1/10th of a second hand to zero.

English USA Chrono VSA USA 30.9.2009 10:35 Page 9
