V-Series Refrigerators

Cabinet:

Victory’s Value Packed V-Series refrigerators

are constructed of heavy gauge, polished

stainless steel and aluminum to maintain

an attractive appearance and maximum

durability for years to come.

Interiors feature coved corners that are easy

to clean and maintain. An average of over

21/2 inches of foamed-in-place polyurethane

insulation throughout the cabinet assures

the food storage compartment remains well

insulated promoting energy efficiency. The

bottom of the storage compartment is made

of heavy gauge metal with 31/2 inches of

polyurethane insulation for exceptional

strength. Interior lighting is recessed.

Doors:

The self-closing doors stay open at 110°

facilitating loading. Each door has a cylinder

lock.

Shelving:

Heavy-duty, epoxy coated steel shelves are

mounted on pilaster strips and are adjustable

on 1” increments. Wide door openings

accommodate two 12” x 20”, or one 18” x 26”,

or one 14” x 18” pans/trays per level.

Refrigeration:

All components of the self-contained refrigeration

system are mounted on top of the cabinet.

The air circulating fans and the forced

convection cooling coil are contained in an

insulated housing separate from the

product zone allowing for maximum food

storage capacity. All condensate water is

disposed of automatically by the energy

efficient nonelectric condensate evaporator,

no plumbing is required.

The R-134a refrigerant used is environmentally

friendly.

Standard Features

• Stainless Steel Fronts for Durability

• Polished Aluminum Sides

• Energy Efficient ABS Thermal Breakers

Around Door Jamb

• Heavy-Duty Swivel Casters with Brakes

• Recessed Interior Lighting

• Exterior Dial Thermometer

• Lifetime Self-Closing Camlift Hinges with

110° Stay-Open Feature

• Self-Adjusting Magnetic Door Gaskets

• Heavy-Duty Cylinder Locks

• Durable and Energy Efficient ABS Interior

Door Liners

• Field Reversible Door Swing

• Door Opening Accepts 20” Wide Pan(s)

• Epoxy Coated Shelves Adjustable on 1”

Centers

• Automatic Non-Electric Condensate Disposal

System

• Environmentally Friendly R-134a Refrigerant

• Anti-Corrosion Coated Evaporator Coil

• Cord Connected

Optional Features:

• Rod Type Pan Slides

• Stainless Steel Angle Type Pan Slides

• Adjustable 6” Legs

• Two Half Doors in Place of One Full Length

Door

• Change Door Swing

• Solar Digital Thermometer

VR-22

Victory Refrigeration, Inc. I 110 Woodcrest Road I Cherry Hill, NJ 08003 USA I Phone: 856.428.4200 I Fax: 856.428.7299 I E-mail: sales@victory-refrig.com

Victory Refrigeration specification sheets

are available online at www.victory-refrig.com.

Approvals:

Project:

Location:

Item #:

Quantity:

VR-1

VR-2

VR-3

VR MODELS —

Stainless steel front.

Aluminum sides and interior.

Victory participates in the KCL CADalog, the most current source of CAD symbols for foodservice designers worldwide. Symbols include

standard equipment in plan, side, front and 3-D views, layered for FEDA/FCSI recommended guidelines.

Continuous product development may necessitate specification changes and design without notice.

Victory

Refrigeration,

Inc. V-SSeries

Refrigerators

CHARACTERISTICS ONE SECTION TWO SECTION THREE SECTION

Reach-In Reach-In Reach-In

Width, Overall 26 1/252 1/877 3/4

Depth, Overall (incl. handles) 33 1/433 1/434 1/2

Height, Overall (incl. adj. legs) 83 5/883 5/883 3/4

Depth, Open Door 90° 56 1/256 1/256 1/2

Clear Door Opening, Width 21 1/421 1/421 1/4

Clear Full Door Opening, Height 54 54 54

Clear Half Door Opening, Height 25 1/425 1/425 1/4

Capacity Net (cubic feet) 21.0 45.4 69.0

No. of Full Doors 1 2 3

No. of Half Doors 2 4 6

No. of Shelves 3 6 9

Shelf Area (square feet) 17.1 36.0 54.2

Cabinet Voltage 115/60/1 115/60/1 115/60/1

Feed Wires 2 2 2

Condensing Unit Voltage 115/60/1 115/60/1 115/60/1

Condensing Unit Size (HP) 1/31/31/2

Total Amperes 5.5 8.2 10.6

Plug, NEMA 5-15P 5-15P 5-15P

Crated dim. & wts.

Ht. Width Depth Cu. Ft. Lbs.

One Section 83 34 43 82.2 305

Two Section 83 59 43 143.3 435

Three Section 83 86 43 204.4 585

Dimensional tolerance ± 1/4” Metric dimensions (MM)

Printed in U.S.A. 010405

PART OF AGA FOODSERVICE GROUP

56.00

(1422)

33.25

(844)

31.00

(787)

2.25

(57)

13.88 (352)

6.00 (152)

VR-1, VR-2, VR-3 SIDE VIEW

26.50

(673)

83.62

(2124)

23.88 (606) TYP. DOOR

TYP. OPENING

VR-1 FRONT VIEW

26.00

(660)

22.50

(571)

33.25

(844)

VR-1 TOP VIEW

26.00

(660)

47.75 (1212)

33.25

(844)

52.12 (1323)

VR-2 TOP VIEW

33.25

(844)

77.75(1974)

73.25 (1860)

26.00

(660)

VR-3 TOP VIEW

52.12 (1323)

21.25

(539)

TYP. OPENING

23.88

(606)

TYP. DOOR

VR-2 FRONT VIEW

83.62

(2124)

77.75 (1974)

VR-3 FRONT VIEW

21.25

(539)

TYP. OPENING

23.88

(606)

TYP. DOOR

83.62

(2124)

21.25

(539)

NOTE: If cabinet is located directly against

wall and/or under low ceiling, a minimum

clearance of 2” is required.

We reserve the right to change

specifications and product design

without notice. Such revisions do not

entitle the buyer to corresponding

changes, improvements, additions or

replacements for previously purchased

equipment.
