Victory VUR-72-12 Bedienungsanleitung

Salad/Sandwich Refrigerators

Standard Features:

• Stainless Steel Doors, Tops and Interior Bottom Construction

Provides Durable Lasting Finish

• Durable Aluminum Interior Sides and Rear for Easy Cleaning

• Models are Front-Breathing and Recessible to Enable Zero

Clearance Placement or in Limited Access Areas

• Food Pans are Recessed into an Insulated 2" Top which

Surrounds Pans With an Insulated Airflow to Maintain Consistent

Temperature

• Holds Food Safely and Assures Fresher Food

• Exclusive Design Accepts 4" and 6" Pans which Maximize Airflow

and Maintain Temperature

• A Complete Set of 4" Deep Plastic Pans are Included

• Interior Thermometer Consistently Monitors Temperature

• Spacious Design With 10" Cutting Board Provides Maximum Work

Surface

• Removable Stainless Steel Insulated Telescoping Lid Offers Easy

Cleaning

• Self-Closing Door With Replaceable One-Piece Magnetic Gasket

Maintains Positive Seal

• Horizontal Recessed Heavy-Duty Handles Provide Quicker, Easier

Access to Cabinets

• Adjustable Shelves Provide Storage Flexibility

• Heavy-Duty, Epoxy Coated Steel Shelves Accept Heavy Loads and

Offer Easy Clean-up

• Energy Saving, High Density, Polyurethane Foam Insulation

Promotes Cold Retention

• Anti-Corrosion Coated Evaporator Coil Assures Lasting

Performance

• Automatic Condensation Evaporation System Eliminates the

Need for a Floor Drain

• Balanced Energy Efficient Refrigeration System

• Environmentally Friendly R-134a Refrigerant

• Plugs into Standard 115 V Outlets - Cord and Plug Attached for

Easy Installation

• 5" Heavy-Duty Swivel Casters with Brakes Provide Mobility

• Completely Finished and Enclosed Cabinet Back

• Meets Tough NSF Standard 7, 41° F

Optional Features and Accessories:

• 3" Heavy-Duty Swivel Casters with Brakes

• 6" Adjustable Stainless Steel Legs

• Single and Double Overshelf

• Stainless Steel Back Door Mounted Dial Thermometer

• Cylinder Locks

Three Section Model with Doors

Doors, tops and interior floor of stainless steel.

Aluminum ends and interior.

VUR-72-12

VUR-72-18

Victory Refrigeration, Inc. I 110 Woodcrest Road I Cherry Hill, NJ 08003 USA I Phone: 856.428.4200 I Fax: 856.428.7299 I E-mail: [email protected]

Victory Refrigeration specification sheets

are available online at www.victory-refrig.com.

Approvals:

Project:

Location:

Item #:

Quantity:

Victory participates in the KCL CADalog, the most current source of CAD symbols for foodservice designers worldwide. Symbols include

standard equipment in plan, side, front and 3-D views, layered for FEDA/FCSI recommended guidelines.

Continuous product development may necessitate specification changes and design without notice.

Victory Refrigeration, Inc. Salad/Sandwich Refrigerators

CHARACTERISTICS VUR-72-12 VUR-72-18

Width, Overall 72 72

Depth, Overall 30 30

Height, Overall 42 1/242 1/2

Height, Work Area 36 36

Capacity Net (cubic feet) 19.4 19.4

No. of Full Doors 3 3

No. of Shelves 6 6

No of 1/6Size Pans 12 18

Cabinet Voltage 115/60/1 115/60/1

Condensing Unit Voltage 115/60/1 115/60/1

Condensing Unit Size (HP) 1/31/3

Total Amperes 8.8 8.8

NEMA Receptacle Required 5-15R 5-15R

Crated dim. & wts.

Ht. Width Depth Lbs.

VUR-72-12 481/2771/2391/2440

VUR-72-18 481/2771/2391/2450

Dimensional tolerance ± 1/4” Metric dimensions (MM)

Printed in U.S.A. 063009

23.94

(608)

AIR FLOW

30.00

(762)

6.50

(165)

2.00

(50)

10.00

(254)

42.50

(1079)

36.50

(927)

36.50

(927) 14.12

(358)

8.50

(215)

72.12

(1831)

30.00

(762)

27.00

(685)

VUR-72-12, VUR-72-18 SIDE VIEW

VUR-72-12 FRONT VIEW VUR-72-12 TOP VIEW

19.75

(501)

18.75

(476)

18.75

(476)

18.75

(476)

30.00

(762)

72.12

(1831)

8.50

(215)

18.75

(476) 18.75

(476)

19.75

(501)

We reserve the right to

change specifications and

product design without

notice. Such revisions do

not entitle the buyer to

corresponding changes,

improvements, additions or

replacements for previously

purchased equipment.
