Manual

Handleiding

Manuel

Anleitung

Manual

Appendix

EasyPlus

12 | 1600 | 70-16 230V

Copyrights 2008 Victron Energy B.V.

This publication or parts thereof may not be reproduced in any form, by any method, for any

purpose.

For conditions of use and permission to use this manual for publication in other than the

English language, contact Victron Energy B.V.

VICTRON ENERGY B.V. MAKES NO WARRANTY, EITHER EXPRESSED OR IMPLIED, INCLUDING

BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE, REGARDING THESE VICTRON ENERGY PRODUCTS AND MAKES SUCH

VICTRON ENERGY PRODUCTS AVAILABLE SOLELY ON AN ‘AS IS’ BASIS.

IN NO EVENT SHALL VICTRON ENERGY B.V. BE LIABLE TO ANYONE FOR SPECIAL, COLLATERAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH OR ARISING OUT OF

PURCHASE OR USE OF THESE VICTRON ENERGY PRODUCTS. THE SOLE AND EXCLUSIVE

LIABILITY TO VICTRON ENERGY B.V., REGARDLESS OF THE FORM OF ACTION, SHALL NOT

EXCEED THE PURCHASE PRICE OF THE VICTRON ENERGY PRODUCTS DESCRIBED HERE IN.

Victron Energy B.V. reserves the right to revise and improve its products as it sees fit. This

publication describes the state of this product at the time of its publication and may not

reflect the product at all times in the future

EN NL FR DE ES Appendix

1. SAFETY INSTRUCTIONS

General

Please familiarize yourself with the safety features and instructions by first reading the

documentation supplied with this product before using the equipment. This product has been

designed and tested in accordance with international standards. The equipment must be used

exclusively for the purpose for which it was designed.

WARNING: ELECTRIC SHOCK HAZARD.

The product is used in conjunction with a permanent energy source (battery). Input and/or

output terminals may still be dangerously energized, even when the equipment is switched off.

Always switch off the AC supply and the battery before carrying out maintenance or servicing

the product.

The product has no internal user-serviceable components. Do not remove the front plate or

operate the product if any panels have been removed. All servicing must be undertaken by

qualified personnel.

Never use the product where there is a risk of gas or dust explosions. Consult the battery

manufacturer's information to ascertain that the product is intended for use in conjunction with

the battery. Always comply with the battery manufacturer's safety instructions.

WARNING: Do not lift heavy loads without assistance.

Installation

Read the installation instructions in the installation manual before installing the equipment.

This is a Safety Class I product (supplied with a protective grounding terminal).

Uninterruptible

protective grounding must be provided at the AC input and/or output terminals. Alternatively

the grounding point located externally on the product may be used.

Whenever it is likely that

the grounding protection has been damaged, the product must be turned off and secured against

unintended operation; please contact qualified service staff.

Ensure that the DC and AC input cables are fused and fitted with circuit breakers. Never replace a

safety component with a different type. Consult the manual to determine the correct component.

Before applying power, ensure that the available power source matches the configuration settings

of the product as described in the manual.

Ensure that the equipment is used under the correct ambient conditions. Never operate the product

in a wet or dusty environment. Ensure there is adequate free space for ventilation around the

product and check that the ventilation vents are not blocked.

Ensure that the required system voltage does not exceed the product's capacity.

Transport and Storage

Ensure that the mains power and battery cables have been disconnected before storing or

transporting the product.

No liability can be accepted for any transport damage if the equipment is shipped in non-original

packaging.

Store the product in a dry environment; the storage temperature must be between -40°C and 60°C.

Consult the battery manufacturer's manual in respect of transport, storage, charging, recharging

and disposal of the battery.

EN NL FR DE ES Appendix

2. DESCRIPTION

2.1 General

EasyPlus-functional

The EasyPlus is a powerful true sine wave inverter, a sophisticated battery charger that features

adaptive charge technology and a high-speed AC transfer switch in a single compact enclosure.

Beside these primary functions, however, the EasyPlus has several advanced features that

provide a range of new applications as outlined below.

Uninterrupted AC power

In the event of a grid failure, or shore or generator power being disconnected, the inverter

within the EasyPlus is automatically activated and takes over supply to the connected loads.

This happens so fast (less than 20 milliseconds) that computers and other electronic equipment

will continue to operate without disruption.

PowerControl – Dealing with limited generator or shore side power

With a Multi Control Panel a maximum generator or shore current can be set. The EasyPlus will

then take account of other AC loads and use whatever is extra for charging, thus preventing the

generator or shore supply from being overloaded.

PowerAssist – Boosting the capacity of shore or generator power

This feature takes the principle of PowerControl to a further dimension allowing the EasyPlus to

supplement the capacity of the alternative source. Where peak power is so often required only for a

limited period, it is possible to reduce the size of generator needed or conversely enable more to be

achieved from the typically limited shore connection. When the load reduces, the spare power is

used to recharge the battery.

Programmable relay

The EasyPlus is equipped with a programmable relay that by default is set as an alarm relay. The

relay can be programmed for all kinds of other applications, for example as a starter relay for a

generator.

2.2 Battery Charger

Adaptive 4-stage charge characteristic: bulk – absorption – float – storage

The EasyPlus features a microprocessor controlled ‘adaptive’ battery management system that can

be preset to suit different types of batteries. The ‘adaptive’ feature will automatically optimize the

process relative to the way the battery is being used.

The right amount of charge: variable absorption time

When only shallow discharges occur (a yacht connected to shore power for example) the absorption

time is kept short in order to prevent overcharging of the battery. After a deep discharge the

absorption time is automatically increased to make sure that the battery is completely recharged.

Preventing damage due to excessive gassing: the BatterySafe mode

If, in order to quickly charge a battery, a high charge current in combination with a high absorption

voltage has been chosen, the EasyPlus will prevent damage due to excessive gassing by

automatically limiting the rate of voltage increase once the gassing voltage has been reached.

Less maintenance and aging when the battery is not in use: the Storage mode

The storage mode kicks in whenever the battery has not been subjected to discharge during 24

hours. In the storage mode float voltage is reduced to 2,2V/cell (13,2V for a 12V battery) to minimize

gassing and corrosion of the positive plates. Once a week the voltage is raised back to the

absorption level to ‘equalize’ the battery. This feature prevents stratification of the electrolyte and

sulphation, a major cause of early battery failure.

Two outputs to charge 2 battery banks

The EasyPlus features 2 outputs, of which 1 can carry the full output current. The second output,

limited to approximately 4A and with a slightly lower output voltage, is intended to top up a starter

battery.

To increase battery life: temperature compensation

Every EasyPlus comes with a battery temperature sensor. When connected, charge voltage will

automatically decrease with increasing battery temperature. This feature is especially

recommended for sealed batteries and/or when important fluctuations of battery temperature are

expected.

Learn more about batteries and battery charging

To learn more about batteries and charging batteries, please refer to our book ‘Electricity on Board’

(available free of charge from Victron Energy and downloadable from www.victronenergy.com). For

more information about adaptive charging please look under Technical Briefs on our website.

EN NL FR DE ES Appendix

3. OPERATION

3.1 On/Off/Charger Only Switch

When switched to ‘on’, the product is fully functional. The inverter will come into operation and

the LED ‘inverter on’ will light up.

An AC voltage connected to the ‘AC in’ terminal will be switched through to the ‘AC out’

terminal, if within specifications. The inverter will switch off, the ‘mains on’ LED will light up and

the charger commences charging. The ‘bulk’, ‘absorption’ or ‘float’ LEDs will light up,

depending on the charger mode.

If the voltage at the ‘AC-in’ terminal is not within specifications, the inverter will switch on.

When the switch is switched to ‘charger only’, only the battery charger of the EasyPlus will

operate (if mains voltage is present). In this mode input voltage also is switched through to the

‘AC out’ terminal.

NOTE: When only the charger function is required, ensure that the switch is switched to

‘charger only’. This prevents the inverter from being switched on if the mains voltage is lost,

thus preventing your batteries from running flat.

3.2 Remote control

Remote control is possible with a 3-way switch, with a Digital Multi Control panel.

The Control panel has a simple rotary knob with which the maximum current of the AC input can be

set: see PowerControl and PowerAssist in Section 2.

For the appropriate DIP switch settings, see sect. 5.5.1.

3.3 Equalisation and forced absorption

3.3.1 Equalisation

Traction batteries may require regular equalisation charging. In the equalisation mode, the EasyPlus

will charge with increased voltage for one hour (1V above the absorption voltage for a 12V battery,

2V for a 24V battery). The charging current is then limited to 1/4 of the set value. The ‘bulk’ and

‘absorption’ LEDs flash intermittently.

Equalisation mode supplies a higher charging voltage than most DC consuming

devices can cope with. These devices must be disconnected before additional

charging takes place.

3.3.2 Forced absorption

Under certain circumstances, it can be desirable to charge the battery for a fixed time at absorption

voltage level. In Forced Absorption mode, the EasyPlus will charge at the normal absorption voltage

level during the set maximum absorption time. The ‘absorption’ LED will be ‘on’.

3.3.3 Activating equalisation or forced absorption

The EasyPlus can be put into both these states from the remote panel as well as with the front panel

switch, provided that all switches (front, remote and panel) are set to ‘on’ and no switches are set to

‘charger only’.

In order to put the EasyPlus in this state, the procedure below should be followed.

If the switch is not in the required position after following this procedure, it can be switched over

quickly once. This will not change the charging state.

NOTE: Switching from ‘on’ to ‘charger only’ and vice versa, as described below, must be done quickly. The switch

must be toggled such that the intermediate position is 'skipped', as it were. If the switch remains in the ‘off’

position even for a short time, the device may be turned off. In that case, the procedure must be restarted at step

1. A certain degree of familiarisation is required when using the front switch on the EasyPlus in particular. When

using the remote panel, this is less critical.

Procedure:

1. Check whether all switches (i.e. front switch, remote switch or remote panel switch if present) are

in the ‘on’ position.

2. Activating equalisation or forced absorption is only meaningful if the normal charging cycle is

completed (charger is in 'Float').

3. To activate:

a. Switch rapidly from ‘on’ to ‘charger only’ and leave the switch in this position for ½ to 2 seconds.

b. Switch rapidly back from ‘charger only’ to ‘on’ and leave the switch in this position for ½ to 2

seconds.

c. Switch once more rapidly from ‘on’ to ‘charger only’ and leave the switch in this position.

4. On the EasyPlus the three LEDs ‘Inverter’, ‘Charger’ and ‘Alarm’ will now flash 5 times.

If a MultiControl panel is connected, on the panel the LEDs ‘bulk’, ‘absorption’ and ‘float’ will also

flash 5 times.

5. Subsequently, on the EasyPlus the LEDs ‘Bulk’, ‘Absorption’ and ‘Float’ will each light during 2

seconds.

If a MultiControl panel is connected, on the panel the LEDs ‘bulk’, ‘absorption’ and ‘float’ will also

each light during 2 seconds.

a. If the switch on the EasyPlus is set to ‘on’ while the ‘Bulk’ LED lights, the charger will switch to

equalisation.

Similarly, if the switch on the MultiControl panel is set to ‘on’ while the ‘Bulk’ LED lights, the charger

will switch to equalisation.

b. If the switch on the EasyPlus is set to ‘on’ while the ‘Absorption’ LED lights, the charger will switch

to forced absorption.

Similarly, if the switch on the MultiControl panel is set to ‘on’ while the ‘Absorption’ LED lights, the

charger will switch to forced absorption.

c. If the switch on the EasyPlus is set to ‘on’ after the three LED sequence has finished, the charger

will switch to ‘Float’.

Similarly, if the switch on the MultiControl panel is set to ‘on’ after the three LED sequence has

finished, the charger will switch to ‘float’.

d. If the switch has not been moved, the EasyPlus will remain in ‘charger only’ mode and switch to

‘Float’.

Inhaltsverzeichnis

Andere Victron energy Wechselrichter Handbücher

Victron energy

Victron energy MultiPlus 12 Bedienungsanleitung

Victron energy

Victron energy MultiPlus 12/1600/70 Bedienungsanleitung

Victron energy

Victron energy BlueSolar MPPT 75/10 Bedienungsanleitung

Victron energy

Victron energy Inverter RS Smart Bedienungsanleitung

Victron energy

Victron energy Color Control GX Bedienungsanleitung

Victron energy

Victron energy EasySolar 12/1600/70 Bedienungsanleitung

Victron energy

Victron energy PIN121800300 Bedienungsanleitung

Victron energy

Victron energy MultiPlus 12/500/20-120V Bedienungsanleitung

Victron energy

Victron energy Phoenix Inverter Smart 12/1600 Bedienungsanleitung

Victron energy

Victron energy Phoenix 12/800 Bedienungsanleitung

Victron energy

Victron energy MultiPlus 12 1600 70 230V Bedienungsanleitung

Victron energy

Victron energy QUA488024000 Bedienungsanleitung

Victron energy

Victron energy MultiPlus Compact 12/2000/80-50 120V Bedienungsanleitung

Victron energy

Victron energy MultiPlus-II 24/3000/70-50 Bedienungsanleitung

Victron energy

Victron energy MultiPlus-II 48/5000/70-50 230V GX Bedienungsanleitung

Victron energy

Victron energy RS Smart Solar 48/6000 Bedienungsanleitung

Victron energy

Victron energy Phoenix 12/250 Bedienungsanleitung

Victron energy

Victron energy MultiPlus 12/800/35 Bedienungsanleitung

Victron energy

Victron energy MultiPlus-II 12|3000|120-50 Bedienungsanleitung

Victron energy

Victron energy Phoenix 12/300 Bedienungsanleitung

Victron energy

Victron energy Quattro 24/5000/120-100/100 Bedienungsanleitung

Victron energy

Victron energy MultiPlus 48/3000/35-50 Bedienungsanleitung

Victron energy

Victron energy VE.Direct 12-250 Bedienungsanleitung

Victron energy

Victron energy ECOmulti Bedienungsanleitung

Beliebte Wechselrichter Handbücher anderer Marken

Fourgroup

Fourgroup Easy Bedienungsanleitung

Velleman

Velleman PI300M Bedienungsanleitung

Sungrow

Sungrow SG350HX-US Bedienungsanleitung

WilTec

WilTec 61897 Bedienungsanleitung

SMA

SMA SUNNY BOY STORAGE 2.5 Bedienungsanleitung

Simplicity

Simplicity LANDLORD 316 Bedienungsanleitung

Santak

Santak SMAX 3000 Bedienungsanleitung

ATON

ATON RA.Store-3 Bedienungsanleitung

ZIEHL-ABEGG

ZIEHL-ABEGG FXET4AMQ Bedienungsanleitung

Tektronix

Tektronix CFG250 Bedienungsanleitung

Champion

Champion 200989 Bedienungsanleitung

Vanner

Vanner 20-500 Series Bedienungsanleitung

GE GEP Bedienungsanleitung

Astrel Group

Astrel Group Power Reducer Kurzanleitung

MULTIQUIP

MULTIQUIP GDP-5H Leitfaden

GoWISE

GoWISE PS1007 Bedienungsanleitung

Promate

Promate PM13500D ES Bedienungsanleitung

Mastervolt

Mastervolt WHISPER 3.5M3000 RPM Bedienungsanleitung
