How to make the HDMI Daisy-Chain Setting
VZ-UNBS SERIES VIDEO WALL MONITORS
2User ManualVisit the ViewZ USA website at https://www.viewzusa.com
• There are two ways to set up the daisy-chained video wall.
1. Use the IR remote controller
2. Use the Serial Control Program
How to make the HDMI daisy-chain setting
SETUP DAISY CHAIN
Input Source
Before the daisy chain setup, the monitor will be shown as above
3User Manual Visit the ViewZ USA website at https://www.viewzusa.com
qwe
r
o
t
i
y
u
Cat 5 Cable
Input
Source
q-o Connecon order of monitors Cable Type HDMI Cable
1. Physical Connecons
Special note: Use the short HDMI cables (less than 6feet) for the daisy-chain connecon. For 4K video, use the
18Gbps 4K graded HDMI cables.
In accordance with the following gure, please connect the cables.
qConnect the Video source at the HDMI IN of 1st monitor.
Using IR Remote Controller
SETUP DAISY CHAIN
wConnect the HDMI cable at HDMI OUT of 1st monitor and HDMI IN of 2nd monitor. And connect 2nd and 3rd
monitors repeatedly unl the last of monitor.
eConnect the IR Receiver at the RJ45 IN of 1st monitor.
rConnect the CAT5/6 cable at RJ45 Out of 1st monitor and RJ45 IN of 2nd monitor. And connect 2nd and 3rd
monitors repeatedly unl the last of monitor.
4User ManualVisit the ViewZ USA website at https://www.viewzusa.com
Using IR Remote Controller
SETUP DAISY CHAIN
2. Power on and ID Seng
qPower on the video source and the video wall monitors.
wPress SOURCE on the IR Remote Controller (be sure to display input source on all of monitors) and select HDMI.
e Disconnect all CAT5/6 cables aer rst monitor to set the ID of 1st monitor.
rPress ID on the IR Remote Controller to display the following window.
t Move cursor to Generate ID and select it to display the Idener AAA - BBB.
AAA is Idener 1 and BBB is Idener 2.
yMove cursor to the box of Idener 1 and enter the 3 digit number - Ex. 238 (see below picture)
uMove cursor to the box of Idener 2 and enter the 3 digit number - Ex. 54 (see below picture)
iMove cursor to the box of H_Addr and enter a number of 1.
oMove cursor to the box of V_Addr and enter a number of 1.
aMove cursor to Applicaons and then press ENTER buon on the IR Remote Controller.
AAA BBB
5User Manual Visit the ViewZ USA website at https://www.viewzusa.com
Aer the process of '2-qto 2-a', disconnect IR Remote Cable from the 1st monitor and connect it to RJ45 IN of 2nd
monitor. Repeat above steps ( 2-rto 2-a ) unl you nish the ID seng of all monitors.
H_Addr and V_Addr should refer to the following numbers
Using IR Remote Controller
SETUP DAISY CHAIN
3. Video Wall Seng
qConnect the IR Receiver at the RJ45 IN of 1st monitor.
wConnect the CAT5/6 cable at RJ45 OUT of 1st monitor and RJ45 IN of 2nd monitor. And connect 2nd and 3rd
monitors repeatedly unl the last of monitor.
ePress MENU on the IR Remote Controller.
rMove Cursor to Video Wall Set and select to display the following menu.
tMove Cursor to Video Wall Set and press ENTER to nish the Daisy-Chained Video Wall Seng.
IR Receiver
H_Addr : 1
V_Addr : 1
H_Addr : 2
V_Addr : 1
H_Addr : 3
V_Addr : 1
H_Addr : 1
V_Addr : 2
H_Addr : 1
V_Addr : 3
H_Addr : 2
V_Addr : 2
H_Addr : 2
V_Addr : 3
H_Addr : 3
V_Addr : 2
H_Addr : 3
V_Addr : 3
6User ManualVisit the ViewZ USA website at https://www.viewzusa.com
1. Physical Connecons
Special note: Use the short HDMI cables (less than 6 ) for the daisy-chain connecon. For 4K video, use the
18G-bps 4K graded HDMI cables. Before making connecon, be sure to install the Serial Control Program in your
PC and prepare a proper serial cable with the RJ45 connector for the monitor.
In accordance with the following gure, please connect the cables.
qConnect the Video source at the HDMI IN of 1st monitor.
wConnect the HDMI cable at HDMI OUT of 1st monitor and HDMI IN of 2nd monitor. And connect 2nd and 3rd
monitors repeatedly unl the last of monitor.
eConnect the IR Receiver at the RJ45 IN of 1st monitor.
rConnect the CAT5/6 cable at RJ45 OUT of 1st monitor and RJ45 IN of 2nd monitor. And connect 2nd and 3rd
monitors repeatedly unl the last of monitor.
Using Serial Control Program
SETUP DAISY CHAIN
• Before the setup of daisy-chain, user needs to conrm the connecon between the computer (which has Screen-
Control program) and monitors
Caution
qwe
r
o
t
i
y
u
Cat 5 Cable
Input
Source
q-o Connecon order of monitors Cable Type HDMI Cable
7User Manual Visit the ViewZ USA website at https://www.viewzusa.com
Please refer " VZ-UNBS-VideoWall-SW-Manual"
Using Serial Control Program
SETUP DAISY CHAIN
2. Power and ID Seng
qPower on the video source and the video wall monitors.
wPress SOURCE on the IR Remote Controller (be sure to display input source on all of monitors) and select HDMI.
eDisconnect the IR Receiver and connect the Serial Control Cable at the RJ45 IN of 1st monitor.
3. Video Wall Seng
qDisconnect a Serial Control Cable and connect the IR Receiver at the RJ45 IN of 1st monitor.
wConnect the CAT5/6 cable at RJ45 OUT of 1st monitor and RJ45 IN of 2nd monitor. And connect 2nd and 3rd
monitors repeatedly unl the last of monitor.
ePress MENU on the IR Remote Controller.
rMove Cursor to Video Wall Set and select to display the following menu.
tMove Cursor to Video Wall Set and press ENTER to nish the Daisy-Chained Video Wall Seng.
8User ManualVisit the ViewZ USA website at https://www.viewzusa.com
qwe
r
o
t
i
y
u
Cat 5 Cable
Input
Source
q-o Connecon order of monitors Cable Type HDMI Cable
Using Serial Control Program
SETUP DAISY CHAIN
• If your setup is successfully done, you will see the image like below picture.
Input Source
q w e
r
o
t
i
y
u
