Vigilant Vision 9.7" Bedienungsanleitung
9.7” LED MONITOR
Contents
1. Safety instruction
2. Contents in the products
3. Safety tips
4. Installation
5. Product Specification
6. Signal connection
7. How to control OSD (On screen display) key
1) Input signal : Video, HDMI
2) Input signal : PC (for DVR or PC usage)
8. FAQ
2
3
4
5
6
7
8
9
12
16
- 1 -
1. Safety Instructions
Thank you for purchasing our security LCD monitor.
For the best performance of our product, please take a few minutes to
read the user’s manual and follow relevant guides and directions.
■ Please read the instructions carefully, and keep it for later use.
■ Please comply with all warnings and instruction signs marked on the product.
■ Always keep the product under normal temperature and humidity, avoiding
heavy moisture and high temperature.
■ Keep the product stable conditions at any time, otherwise the product may fail,
causing serious loss and damage.
■ Do not install this product without any proper ventilation system, and keep the
product away from all heat sources, humid and dusty surroundings.
■ When cleaning, cut off the electrical supply at any times, and keep away from any
liquid sources. Use damp rag to clean product when necessary instead of liquid
or aerosol detergent
■ Do not crash and convulse the product when move it because the product as
glasswork is easily scratched.
■ Do not attempt to repair the product by yourself or remove the casting, if may
expose you to electronic shock hazard. Please contact a dealer near you for the
service.
- 2 -
2. Contents in the product
Inspect all the items inside the box. If any item is damaged or miss-
ing, notify your dealer immediately.
- 3 -
LED monitor
3. Safety Tips
■ Place the monitor on a flat and stable surface
■ Ensure that the power to the monitor, the computer, and other connected devices
should be off before making any connections.
■ Plug the DC cord of the AC adapter to the 12V power connector of the monitor.
■ Plug power cord to the AC adapter, and plug the other side to the power socket.
■ Please use the enclosed power cord and connect to the standard power outlet of
your country.
■ For viewing clarify, you can tilt the LCD forward or backward.
■ Ensure the LCD will not fall or be damaged.
■ Do not tilt the LCD beyond the allowed angles forward up to 5 degrees or
backward up to 25 degrees.
- 4 -
4. Installation
■ Connect power cord and power adaptor
■ Connect video cable
- Make sure both the LCD display and computer are turned off.
- Connect the video cable from the LCD display to the computer.
■ Turn on LCD display and computer.
■ Select input source (video, PC, HDMI) pushing ‘SELECT’ button of OSD.
- 5 -
AV OUT AV IN VGA HDMI DC IN
5. Product Specification
※ Technical details may be subject change without further notice.
Features
Model
LCD
Resolution
Viewing angle
Brightness
Contrast
Input signals
Output signal
Power
Size (WxHxD)
Weight (set)
Weight (Packed)
9.7inch
9.7″LED monitor(4:3)
1024 x 768@60Hz
178/178 (degree)
200 cd/㎡
600:1
PC (RGB), Video (BNC),
HDMI
Video(BNC)
DC 12V 2A
235mm x 195mm x
320mm
1.7Kgs
2.5 Kgs
Specification
- 6 -
6. Signal connection
Parameter
PC input
HDMI input 480P/576P/720P
1080I/1080P
Composite video input Vp-p
Vp-p
1
1
Composite video output
Input signal
Input level
Input Resolution
H-Frequency
V-Frequency
Max, input resolution
Analogue R,G,B Separate
0.7
31 ~ 80
60 ~ 75
1280 x 1024@75Hz
Vp-p
KHz
Hz
75Ω
Pal / NTSC / Secam
With HDCP
Specification Unit Remark
VGA plug Pin PinFunction Function
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Red
Green
Blue
Unconnected
Grounded
Red grounded
Green grounded
Blue grounded
VGA_5V
Synchronization grounded
Unconnected
SDA (DDC Data)
Horizon synchronization
Vertical synchronization
SCL (DDC clock)
VGA Connector
Various input/output signal specifications are supported.
The following table shows the input/output signal specifications.
- 7 -
7. How to control OSD (on screen display) Key
To choose input signal : Video, PC, HDMI
To enter the sub-menu
To view the next function in the OSD main menu
To activate the OSD main menu
To view the previous function in the OSD main menu
To exit from the OSD main menu
Auto adjust (hot key) in the PC mode
OSD item UP
To increase the value of the specific function which has been selected
To adjust contrast / Brightness (Direct menu)
OSD item DOWN
To decrease the value of the specific function which has been selected
To turn on / off the monitor
Key function
Select
Menu
Up
Down
Power
Up Down Select Menu Power
OSD Key function
LED color status
Mode
LED color
ON
Green
Stand by
Orange
OFF
Orange
- 8 -
7-1. Input Signal : Video / HDMI
(Choose‘Select’button from OSD key)
(1) Menu : PICTURE
■ Contrast : To adjust the brightness and darkness of the object and backgrounds
■ Brightness : To adjust the brightness of the entire picture.
■ Hue : To adjust colors naturally. This function is activated at NTSC video signal.
■ Saturation : To adjust colors to deeper or lighter color
■ Sharpness : To adjust the sharpness of video image.
■ Color temp
- Normal : For a general color tone
- Warm : For warm colors with reddish tone
- Cool : For cool colors with bluish tone.
- 9 -
