E. Quick Programming Features
A one or two digit door strike code can be entered by
programming position #41. When in programming, enter the
one or two digit code followed by “#41”. Note: “Q” and “#”
can be entered as valid characters of the door strike code by
substituting “#20” and #21” (respectively) when programming
the door strike code (see section D). To disable the door
strike relay, enter “#41” without any preceding numbers.
Examples of door strike code entries are shown to the right.
H. Door Strike Code
Description Enter Digits + Location
Speed dial numbers ................................................................................................................. 0-46 digits** + #01 - #12
Door strike time in sec (factory 05, 00 =.5 sec)*........................................................................ 2 digits + #40
Door strike code (factory 6, no digits disables) ......................................................................... 1-2 digits + #41
Maximum call time in min (factory 3, 0 = .5 min, no digits disables)* ...................................... 1 digit + #42
Maximum ring time in sec (factory 20, 00 disables)* ............................................................... 2 digits + #43
Silence Time Out in sec (factory 10, 00 disables)* ................................................................. 2 digits + #44
Talk/listen delay time in .1 sec (factory 2)* .............................................................................. 1 digit + #45
Security code (factory 845464)* ............................................................................................... 6 digits + #47
Access code (factory set to 123456)* ....................................................................................... 1-6 digits + #48
Keyless entry codes .................................................................................................................. 1-6 digits + #50 - #99
Dial a (Q) .................................................................................................................................. #20
Dial a (#) ................................................................................................................................... #21
Add a 4 second pause ............................................................................................................. #22
Add a 1 second pause ............................................................................................................. #23
Second phone number selector ............................................................................................... #24
Normal dialing speed (factory setting) ..................................................................................... #30
Fast dialing speed ..................................................................................................................... #31
Hang up on dial tone enable (factory setting) .......................................................................... #32
Hang up on dial tone disable ................................................................................................... #33
Disable tenant initiated entry (factory setting) ........................................................................... #37
Enable tenant initiated entry ..................................................................................................... #38
Reset all programming to factory default settings ................................................................... ###
Hang up from programming ..................................................................................................... ##7
* Cannot contain “Q“ or “#“ (see #20 and #21) ** 45 digits maximum if two numbers are programmed in one memory location
Notes: 1. A single or double beep indicates a valid entry, three beeps indicate an error.
2. “Q“ or “#“, pauses or second phone number selector occupy one digit of memory.
The K-1270 is programmed through the incoming phone line. The programming commands are structured so
that they do not interfere with the commands of a C-1000B controller.
The K-1270 Entry Controller can be programmed with up to twelve 46 digit numbers. Each number can also be
programmed with special features such as pauses, and the Touch Tones “Q” and “#”. Each of the special characters count
as a single digit. Each of the speed dial positions #01 to #12 pertain to the corresponding button on the front of the K-
1270. The button “0” uses position #10, the “Q” uses position #11 and the “#” uses position #12. To program a speed dial
position, enter programming (see section A) then enter the desired number followed by the selected position. To clear a
position, only enter a “#“ followed by the position number with out any preceding number.
The K-1270 also has the capability to dial a second phone number if there is no answer or busy at the first number. This
can be used if the tenant wants the visitor to call their cell phone if they are not at home. To program a second number, be
sure that position #43 is programmed with the desired maximum ring time, then enter the first number to be dialed, followed
by “#24”. A single beep should be heard. Next enter the second number to be dialed followed by “#“ plus the memory
location. The total number of digits cannot exceed 46 for each position (45 digits if two numbers are programmed). The
following are examples of speed dial number entries:
F. Speed Dial Numbers
To Program the K-1270 to... Step 1 (see section A) Step 2 - Enter Digits
...store 555-1234 at the first button position Enter programming 5551234#01
...store a 9, a 1 second pause, then 333-4444 in the seventh button position Enter programming 9#233334444#07
...store a 23Q# in the eight position Enter programming 23#20#21#08
...store a first number of 22 and a second number of 33 in the “#“
button position Enter programming 22#24 (beep) 33#12
The actual time the door strike relay is energized is controlled by location #40. The time can be set from 00 to 99 seconds,
(an entry of “00” gives 0.5 seconds). In order to use this feature, be sure the relay door strike code is set (see section H).
G. Door Strike Time
To Program the
Door Strike Code to...
Step 1
(see section A)
Step 2
Enter Digits
“99” Enter programming 99#41
“3” Enter programming 3#41
“QQ”Enter programming #20#20#41
“#1” Enter programming #211#41
“Q”Enter programming #20#41
