PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1-888-VIKING1

R E V I S E D 6 / 7 / 1 1

All models include

• Brass Acc nt Option (BR)—nam plat

and knob b z ls. Brass compon nts

hav a durabl prot ctiv coating for

maint nanc -fr normal us

FINISH DETAILS FOR ALL MODELS

• Stainl ss St l (SS)

o Stainl ss units hav black porc lain

grat s, black porc lain burn r caps,

black porc lain grat support and

stainl ss knobs.

Standard Features & Accessories

Model Options

COOKING

Professional Custom Series Built-In Gas 60”W.

Sealed Burner Rangetop

*Shown throughout with accessory 8” high backguard. See Installation Notes & Accessories for details.

ORDERING INSTRUCTIONS

First sp cify mod l numb r, and th n color cod (VGRT560-6GQSS). If ord ring brass acc nt option, sp cify cod at nd (VGRT560-

6GQSSBR).

If ord ring optional LP conv rsion, sp cify cod at nd (

VGRT560-6GQ

SSBRLP).

•Exclusive VSH™ Pro S al d Burn r

Syst m (VariSimm r™ to High)—

combination of pat nt d burn r and

top d sign provid as of cl aning

plus sup rior p rformanc at simm r

and high

•Exclusive VariSimm r s tting for all

burn rs

•Exclusive Sur Spark™ ignition syst m

for all burn rs

•Exclusive tool d and porc lainiz d

cooking surfac contains spills for asy

cl aning

• Brass s al d burn rs with

porc lain/cast iron caps and automatic

ignition/r -ignition

• Shipp d standard with h avy-duty

m tal knobs with stainl ss st l finish

• Shipp d standard with stainl ss st l

island trim

6GQ model includes

• On TruPow r Plus™ 18,500 BTU

burn r

•Fiv 15,000 BTU burn rs

• 12”W. th rmostatically controll d st l

griddl /simm r plat

• 12”W. grill with flavor g n rator

plat s and automatic ignition/

r -ignition

6G models include

• On TruPow r Plus™ 18,500 BTU

burn r

• Fiv 15,000 BTU burn rs

• 24”W. th rmostatically controll d st l

griddl /simm r plat

VGRT 60-6GQ*

Six-Burner/Griddle/

Grill Rangetop

VGRT 60-6G*

Six-Burner/

24”W. Griddle Rangetop

COOKING

Professional Custom Series Built-In Gas 60”W.

Sealed Burner Rangetop

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1-888-VIKING1

R E V I S E D 6 / 7 / 1 1

✪

Please see

Installation Notes &

Accessories

for important

installation

information,

including island

trim, backguard,

and high-shelf.

60”

(152.4cm)

All models

Overa width 60” (152.4 cm)

Overa height (from bottom)

To top of grate 9-1/4” (23.5 cm)

To top of island trim 9-1/ ” (23.2 cm)

Additions to bas h ight

To top of backguard Add ” (20.3 cm)

To top of high sh lf Add 23-1/2” (72.9 cm)

Overa depth (from rear)

To end of side pane 24-5/16” (61. cm)

To end of anding edge 2 -1/16” (71.3 cm)

To end of knobs 2 -9/16” (72.6cm)

Star-K Kosher

Certification for

use on the Jewish

Sabbath or Jewish

holidays

Dimensions & Specifications

PRODUCT DIMENSIONS

ALL MODELS

8-1/8”

(20.6 cm)

1-5/8” (4.1 cm)

8” (20.3 cm)

28-9/16” (72.6 cm)

24-5/16” (61.8 cm)

VGRT 60-6GQ

Six-Burner/Griddle/

Grill Rangetop

VGRT 60-6G

Six-Burner/

24”W. Griddle Rangetop

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1-888-VIKING1

R E V I S E D 6 / 7 / 1 1

COOKING

Professional Custom Series Built-In Gas 60”W.

Sealed Burner Rangetop

42” min.

(106.7cm)

13”max.

(

33.0cm)

6” min.

(15.2cm)

18”min.

(45.7cm)

3/8”

(0.95cm)

8-1/8”

(20.6cm)

25-3/4”

(65.4cm)

Minimum clearances from adjacent

combustible construction

• Cooking surfac and b low, i. .,

36” (91.4 cm) and b low

o Sid s—0”

o R ar—0” with backguard or

highsh lf; 0” with island trim

and non-combustibl r ar wall;

6” (15.2 cm) with island trim and

combustibl r ar wall.

• Abov cooking surfac , i. . abov

36" (91.4 cm)

o Sid s—6” (15.2 cm)

o Within 6” (15.2 cm) sid cl aranc ,

wall cabin ts no d p r than 13”

(33.0 cm) must b minimum 18”

(45.7 cm) abov cooking surfac .

o Wall cabin ts dir ctly abov product

must b minimum 42” (106.7 cm)

abov cooking surfac .

Dimensions & Specifications

CLEARANCE DIMENSIONS

COOKING

Professional Custom Series Built-In Gas 60”W.

Sealed Burner Rangetop

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1-888-VIKING1

R E V I S E D 6 / 7 / 1 1

UTILITY

REQUIREMENTS

GAS

o Shipp d natural or

propan gas; fi ld

conv rtibl with

conv rsion kit.

o Acc pts standard

r sid ntial 1/2”

(1.3 cm) ID gas

s rvic lin

o Gas manifold

pr ssur

o Natural gas 5.0”

W.C.P.

o LP/Propan

10.0" W.C.P.

ELECTRICAL

• Four-foot (121.9

cm) cord includ d

with rang top

• Thr -wir with

ground/thr -

prong plug

• 120 V/60 Hz

• Max. amp usag —

o 6GQ—0.5

o 6G—0.5

PLUMBING

Not applicabl

Installation Requirements

ACCESS REQUIREMENTS

VGRT560-6GQ VGRT560-6G

Cutout width 60-1/4” (153.0 cm)

Cutout h ight 7-5/ ” (19.4 cm)

Cutout depth 24” (61.0 cm) min. to 25-3/4” (65.4 cm) max.

Surface burner rating

Grated burners (each) 15,000 BTU Nat. (4.4 kW)/13,500 BTU LP (4.0 kW)

TruPower P us™ burner 1 ,500 BTU Nat. (5.4 kW)/

(front right) 16,600 BTU LP (4.9 kW)

Gridd e 15,000 BTU Nat. (4.4 kW)/ Two at 15,000 BTU Nat. (4.4 kW)/

12,500 BTU LP (3.7 kW) 12,500 BTU LP (3.7 kW)

Gri 18,000 BTU Nat. (5.3 kW)/

16,000 BTU LP (4.7 kW)

1-1/2”

(3.8cm)

24”min.

(

61.0cm)

25-3/4”max.

(

65.4cm)

3”

(7.6cm)

*Note: 120 VAC/50Hz within 48” (121.9 cm) of right rear of rangetop

VGRT 60-6GQ

Six-Burner/Griddle/

Grill Rangetop

VGRT 60-6G

Six-Burner/

24”W. Griddle Rangetop

R E V I S E D 6 / 7 / 1 1

Island Trim

• Stainl ss St l (SS)

•Coordinat s with all finish s

• For island/p ninsula installation

• Includ d and shipp d standard

”H. Backguard

• Stainl ss St l (SS)

• Coordinat s with all finish s

High-shelf

• Stainl ss St l (SS)

• Coordinat s with all finish s

• Sh lf com s attach d to a 24”H. backguard

Countertop Side Trim

• Stainl ss St l (SS)

• Coordinat s with all finish s

• Installs on sid of unit; ov rlaps count rtop

• On pair of trim

Countertop Rear Trim

• Stainl ss St l (SS)

LP/Propane Conversion Kit

• Allows for fi ld conv rsion of rang from natural gas to LP

Compliance Information

WARRANTY INFORMATION*

• Thr -y ar full warranty—compl t product

• Lif tim limit d—stainl ss st l xt rior

• Fiv -y ar limit d warranty—surfac burn rs, griddl burn rs and grill burn rs

• Nin ty-day limit d warranty—cosm tic parts such as glass, paint d, and d corativ it ms

* For compl t warranty s Use & Care Guide. Warranty valid on Viking products shipp d within th Unit d Stat s and Canada.

COOKING

Professional Custom Series Built-In Gas 60”W.

Sealed Burner Rangetop

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1-888-VIKING1

✪Installation Notes & Accessories

A backguard, high-sh lf, or island trim must b us d for all installations.
