VistaQuest VQ1100 Bedienungsanleitung

Quick Start Guide

020606

1. VQ1100 Names of Parts

1. Shutter Button

2. Viewfinder

3. Flash

4. Lens

5. USB Port

6. Indicator Lamp

7. LCD

8. MODE

9. ON/OFF

10. Strap Eyelet

11. Battery Compartment Cover

12. Tripod Socket

2. Operating The VQ1100

• Open the battery cover and insert batteries.

Step 1: Slide open the battery door by lifting the tab on the door.

Step 2: Insert three AAAbatteries with the polarity as shown:

Step 3: Slide close the battery cover.

• Press and hold the ON/OFF button for 2 second to start the camera. The camera will

beep once, indicating that it is ready. The LCD screen will display digits and symbols.

•

Aim the camera and compose the scene by looking through the viewfinder.

• Press the shutter button to take a picture. Buzzer will sound as the confirmation of the

taken picture. LCD will show number of pictures taken.

• Sleep mode: With the power ON, if you do not take another picture within 60 sec., camera

will turn to the "Sleep" mode to save batteries. The blank LCD screen identifies the "Sleep"

mode. (Press the ON/OFF button held 2 second can manual turn on/off the "Sleep" mode.)

• Re-activating camera from "Sleep" mode. Press the ON/OFF button held 2 second to

re-active the camera for taking next picture.

Please note, that when batteries disconnected or discharged, the memory, and all taken

pictures will be erased.

Power Consumption

• The batteries allow you to take, and store all pictures inside the memory for approximately

two weeks (camera stays in the "Sleep" mode)

• After that, LCD screen starts to blink, informing you that the batteries are low. You must

download the stored pictures into the computer within a day; otherwise all pictures will be

lost.

3. Using Camera's Modes

Press the mode button to select the function you want to set, and the press the shutter button

to confirm. Then press the mode button again to change the option, and then press the shutter

button to confirm and you will see the result on the LCD.

VQ1100 has sixteen modes, which can be selected by pressing the Mode button, Pressing

the Mode button to see the features options in the following sequence:

•Snapshot Mode

• Flash Off

• Auto Flash

• Force Flash

• Low Resolution Mode

• High Resolution Mode

• SXVGA

• XVGA

•Single Mode

• Continuous Capture Mode

• AVI Video Mode

• Self Timer Mode

• 60Hz Mode

• 50Hz Mode

• Delete One Picture Mode

• Delete All Pictures Mode

LCD screen displays flickering symbols related to the selected mode.

1. Snapshot Mode: The LCD displays the number of pictures taken. Press the

Shutter button to take a picture. The number will automatically increase.

2. Flash Off Mode: Flash never fires. (Default). Press the mode button once

and then press the shutter button to confirm. Press the mode button again to

select the icon , and then press the shutter button to confirm.

3. Auto Flash Mode: Flash fires when the lighting conditions require it. Press

the mode button once and then press the shutter button to confirm. Press the

mode button again to select the icon , and then press the shutter button

to confirm.

4. Force Flash Mode: Flash fires every time you take a picture, regardless of the

lighting conditions. Press the mode button once and then press the shutter

button to confirm. Press the mode button again to select the icon , and

then press the shutter button to confirm.

5. High Resolution Mode: Take few pictures but big picture size. Press the mode

button twice and then press the shutter button to confirm. Press the mode

button again to select the icon , and then press the shutter button to

confirm.

6. LOW Resolution Mode: Take more pictures but small picture size. Press the

mode button twice and then press the shutter button to confirm. Press the

mode button again to select the icon , and then press the shutter button

to confirm.

7. SXVGA Mode: Take pictures about 1.3M pixels. Press the mode button three

times and then press the shutter button to confirm. Press the mode button

again to select the icon SXVGA, and then press the shutter button to confirm.

8. VGA Mode: Take pictures about 0.3M pixels. Press the mode button three

times and then press the shutter button to confirm. Press the mode button

again to select the icon VGA, and then press the shutter button to confirm.

9. Single Mode: Press the mode button four times and then press the shutter

button to confirm. Press the mode button again to select the icon , and

then press the shutter button to confirm.

10. Continuous Capture Mode: Press the mode button four times and then

press the shutter button to confirm. Press the mode button again to select

the icon , and then press the shutter button to confirm. Press the

shutter button again and camera will take 3 pictures sequentially.

11. AVI Video Mode: Press the mode button four times and then press the

shutter button to confirm. Press the mode button again to select the

icon , and then press the shutter button to confirm. Press the shutter

button still to recording and the camera will beep during recording. The

recording is finished when you release the shutter button. [The video

resolution is QVGA (320x240) default and you cannot change the video

resolution; The capture mode return to single mode automatically when

finish recording.

9. Self-Timer Mode: Press the mode button five times and then press the

shutter button to confirm. Press the mode button again to select the icon on

(reactive the Self-Timer mode), and then press the shutter button to confirm.

Press the shutter button again and camera will take a picture automatically

after 10 seconds.

10. 60Hz Mode: Press the mode button six times and then press the shutter

button to confirm. Press the mode button again to select the icon 60H. You

should set up to this mode if you use 60Hz power.

11. 50Hz Mode: Press the mode button six times and then press the shutter button

to confirm. Press the mode button again to select the icon 50H. You should

set up to this mode if you use 50Hz power.

12. Delete One Picture Mode: Press the mode button seven times and then press

the shutter button to confirm. Press the mode button again to select the

icon , press the shutter button and the icon will blink, press the

shutter button again to confirm and camera will delete (erase) last stored picture

from the memory.

13. Delete All Pictures Mode: Press the mode button seven times and then press

the shutter button to confirm. Press the mode button again to select the

icon , press the shutter button and the icon will blink, press the

shutter button again to confirm and camera will delete (erase) all stored

pictures from the memory.

14. PC camera mode: Press the shutter button to turn on the camera, and then

connect the camera and the computer with the USB cable. You will see the

icon PC on the LCD. Then you can download the pictures.

Note: 1. The erased pictures cannot be recovered. Make sure you have selected the images

you want to erase.

2. If the battery low the camera will beep when you turn on the camera;“ ”

message appears on the LCD when the memory is full. Please download the

pictures to your computer.

The VistaQuest Corporation is proud that you have chosen its product

and hopes you will enjoy sharing “a clearer vision” of your memories and special

moments captured with your new camera with friends and family for many years.
