Vive LVA1074PGR Bedienungsanleitung
QUICK SET UP GUIDE
Step 1: Open the battery door of the pager and insert two AA
batteries as shown. Close the battery door.
Step 2: On the pager, press and hold both UP and DOWN arrows for
5 seconds. You will see the number “1” is blinking in red, indicating that
the pager is now in programming mode.
Step 3: There are 10 channels on the pager for programming up to
10 individual wireless devices. Select a number for programming by
pressing the UP or DOWN arrow on the front of the pager.
Step 4: While the pager is in pairing mode, a red light should ash
over the device number (#1-10) that you are attempting to pair
the alarm with. While this light is ashing, press the button on the
transmitter once to wake it up, then hold for 5 seconds until the alarm
light on the transmitter ashes orange. Then release the button on
the transmitter.
Step 5: The pager will beep to signal a successful connection. Then it
will re-enter programming mode in case you need to connect other
wireless devices. If you do not need to connect more devices press
and hold both the UP and DOWN arrows on the front of the pager to
exit programming mode.
Step 6: Test the connection by sitting down on the sensor pad
and standing up. The alarm should sound on the pager and the
connected channel number should ash in red while the alarm
sounds. To silence the alarm press the STOP button on the pager. If
this does not occur follow these steps again from the beginning or
contact us for help.
Note: This set up is only for the sensor pads with transmitters. If you
are trying to pair a call button or door alarm, please refer to those
specic instructions. All devices are sold separately.
Number
UP Button DOWN Button
Change Alarm
Time Delay
Cordless Pad Alarm
Alarm
05 25 45
Change Alarm Light
Number
© Copyright and Distributed by Vive Health
8955 Fontana Del Sol Way, Naples, FL 34109
All Rights Reserved. Made in China.
Email: [email protected]
WARNINGS
This device will not prevent a fall or injury. It is a
supplemental part of an overall fall management program.
Failure to follow all product instructions may result in the failure or
improper function of the product.
The WPG is able to communicate up to 150 feet away from the
patient in open eld. The actual communication distance or wireless
range will vary from building to building. Test the wireless range in your
building prior to putting the system into service. Always keep the pag-
er located within the wireless range.
The pad, transmitter and any other devices should be checked prior
to each use for proper functioning.
GUARANTEE
You are protected by Vive Health’s industry leading guarantees
and customer service.
If you did not purchase through vivehealth.com, please register
at vivehealth.com/register to validate your guarantee.
Product Code: LVA1074PGR
1-800-487-3808
Monday - Friday 9am - 5pm EST
Notification Mode Notification Sign
Audible notication Beeps
Vibration notication Vibration
Audible + Vibration
notication
Audible and
Vibration
Button
To set the notication modes, press and hold down both Button on
the front of the WPG for more than 5 seconds until the image is
blinking.
To select another notication mode, press and release the UP Button
or DOWN Button on the front of the WPG. The next notication light
will start blinking. Continue to press and release the Up or Down
buttons until the desired notication light is selected. Once you’ve
landed on your desired notication light, press and release
the Button, you will hear a 1 second beep and/or feel a 1 second
vibration. This means the current notication mode is recorded to the
WPG.
Step 2: Exit programming mode: Press and hold both the UP and
Down buttons on the WPG for more than three seconds until you see
the number light turn off. The WPG has now exited programming
mode.
NOTIFICATION MODES FOR THE WIRELESS PAGER
STEP 1: Set notication mode for the WPG.
The WPG has three notication modes.
