DU6693Z

Remote Communicaton

Manual

DU6693Z DLP Projecto

Remote Communication Manual

RC66930718EN01

Table of Contents

The Serial Interface RS-232 Command ........................................................................................2

Communication parameter.........................................................................................................2

Operation commands.................................................................................................................2

Operation command syntax .................................................................................................2

List of operation commands .................................................................................................3

Simulated IR remote controller commands ..............................................................................14

List of simulated IR remote controller commands ....................................................................14

Control the Projector Through a Network..................................................................................15

Cable connection .....................................................................................................................15

Set up the projector for networking ..........................................................................................16

Control the projector through a network ...................................................................................17

Control the projector through a web browser .....................................................................17

Control projector with TCP/IP communication protocol ......................................................20

About Vivitek Support .................................................................................................................21

DU6693Z DLP Projecto

Remote Communication Manual

RC66930718EN01

The Serial Interface RS-232 Command

This projector supports to control by RS-232 command, there exists two types of RS-232 serial commands:

Operation command: The commands are listed by the OSD menus structure as PICTURE,SIGNAL, SETUP,

INSTALLATION and SERVICE.

Simulated IR remote controller commands: Controls projector via RS-232 command, the commands simulate IR

remote controller and its control keys.

Communication parameter

You can use the serial control command to input commands for projector control or retrieve its operational data

through Windows client terminal software, e.g. Hyper Terminal, with ASCII characters. You need to set up the following

communication parameters in advance:

Item Parameter:

Bit per Second 9600, 19200, 38400 bps

Data Bit 8-bit

Parity None

Stop Bit 1

Flow Control None

Port 7000

The terminal software does not return every command input character.

The transmission performance varies with the length of RS-232 cable, please set the baud rate per

the cable length.

Operation commands

Operation command syntax

An operation command is prefixed by character "op", followed by control commands and settings separated by

space blank [SP], and ended by carriage return pair "CR" and "ASCII hex 0D".Syntax of serial control

commands:

op[SP]<operation command>[SP]<Setting Value>[CR]

op :

A constant indicating this is an operation command.

[SP] :

Indicate one blank space.

[CR] :

Indicate the command ending carriage return pair "CR" and "ASCII hex 0D".

Setting value : Settings of operation command

Types of setup strings Characters of settings Description

Query current setup ? Question mark "?" indicates querying current setup

Setup = <settings> Syntax: Symbol "=" suffixed with setup values

Increase the value + Some settings are changed in steps. Symbol "+"

indicates changing one step up

Decrease the value - Some settings are changed in steps. Symbol "-"

indicates changing one step down

Execute operation command None Certain operation commands execute after input

without further setting or regulators.

Examples:

Control items Input command Projector return message

Query current brightness op bright ? [CR] OP BRIGHT = 101

Set brightness op bright = 127 [CR] OP BRIGHT = 127

Set input signal source to HDMI op input.sel = 0 [CR] OP INPUT.SEL = 0

Reset projection lens to

center position

lens.center

When sending the multiple commands, make sure the return message of the last command is

received before sending out the next one.

DU6693Z DLP Projecto

Remote Communication Manual

RC66930718EN01

List of operation commands


OSD Function Operation

command

Settings/Return Values Available when

Picture Mode pic.mode ?

0 = High Bright

1 = Presentation

2 = Video

3 = User 1

4 = User 2

Projector is turned on.

Input signal is detected

3D mode is turned off.

Brightness Bright ?

0-200

Projector is turned on.

Input signal is detected

Contrast contrast ?

0-200

Projector is turned on.

Input signal is detected

Saturation saturat ?

0-200

Projector is turned on.

Input signal is detected

Input signal is YUV.

Hue tint ?

0-200

Projector is turned on.

Input signal is detected

Input signal is YUV.

Sharpness sharp ?

0-31

Projector is turned on.

Input signal is detected.　

Noise Reduction nr ?

0-15

Projector is turned on.

Input signal is detected.

Color Temperature color.temp ?

0 = 5400K

1 = 6500K

2 = 7500K

3 = 9300K

4 = Native

Projector is turned on.

Input signal is detected

3D Mode is turned off.

Gamma gamma ?

0 = 1.0

1 = 1.8

2 = 2.0

3 = 2.2

4 = 2.35

5 = 2.5

6 = S-Curve

7 = DICOM

Projector is turned on.

Input signal is detected.

Advance/Input Balance

/Red Offset

red.offset ?

0-200

Projector is turned on.

Input signal is detected.

DU6693Z DLP Projecto

Remote Communication Manual

RC66930718EN01

Advance/Input Balance

/Green Offset

green.offset ?

0-200

Projector is turned on.

Input signal is detected.

Advance/Input Balance

/Blue Offset

blue.gain ?

0-200

Projector is turned on.

Input signal is detected.

Advance/Input Balance

/Red Gain

red.gain ?

0-200

Projector is turned on.

Input signal is detected.

Advance/Input Balance

/Green Gain

green.gain ?

0-200

Projector is turned on.

Input signal is detected.

Advance/Input Balance

/Blue Gain

blue.gain ?

0-200

Projector is turned on.

Input signal is detected.

Advance/ HSG

/Red Gain

hsg.r.gain ?

0-200

Projector is turned on.

Input signal is detected.

Advance/ HSG

/Green Gain

hsg.g.gain ?

0-200

Projector is turned on.

Input signal is detected.

Advance/ HSG

/Blue Gain

Hsg.b.gain ?

0-200

Projector is turned on.

Input signal is detected.

Advance/ HSG

/Cyan Gain

hsg.c.gain ?

0-200

Projector is turned on.

Input signal is detected.

Advance/ HSG/

Magenta Gain

hsg.m.gain ?

0-200

Projector is turned on.

Input signal is detected.

Advance/ HSG

/Yellow Gain

Hsg.y.gain ?

0-200

Projector is turned on.

Input signal is detected.

Advance/ HSG

/Red/Saturation

hsg.r.sat ?

0-200

Projector is turned on.

Input signal is detected.

Advance/ HSG

/Green/Saturation

hsg.g.sat ?

0-200

Projector is turned on.

Input signal is detected.

Advance/ HSG

/Blue/Saturation

Hsg.b.sat ?

0-200

Projector is turned on.

Input signal is detected.

DU6693Z DLP Projecto

Remote Communication Manual

RC66930718EN01

Advance/ HSG

/Cyan/Saturation

hsg.c.sat ?

0-200

Projector is turned on.

Input signal is detected.

Advance/ HSG

/Magenta/Saturati on

hsg.m.sat ?

0-200

Projector is turned on.

Input signal is detected

OSD Function Operation

command

Settings/Return Values Note

Advance/ HSG

/Yellow/Saturation

Hsg.y.sat ?

0-200

Projector is turned on.

Input signal is detected

Advance/ HSG

/Red/Hue

hsg.r.hue ?

0-200

Projector is turned on.

Input signal is detected

Advance/ HSG

/Green/Hue

hsg.g.hue ?

0-200

Projector is turned on.

Input signal is detected

Advance/ HSG

/Blue/Hue

Hsg.b. hue ?

0-200

Projector is turned on.

Input signal is detected

Advance/ HSG

/Cyan/Hue

hsg.c. hue ?

0-200

Projector is turned on.

Input signal is detected

Advance/ HSG

/Magenta/Hue

hsg.m. hue ?

0-200

Projector is turned on.

Input signal is detected

Advance/ HSG

/Yellow/Hue

Hsg.y. hue ?

0-200

Projector is turned on.

Input signal is detected

Advance/ HSG

White/Red Gain

hsg.wr.gain ?

0-200

Projector is turned on.

Input signal is detected

Advance/ HSG

/White/Green Gain

hsg.wg.gain ?

0-200

Projector is turned on.

Input signal is detected

Advance/ HSG

/White/Blue Gain

Hsg.wb.gain ?

0-200

Projector is turned on.

Input signal is detected

Advance/ HSG

Reset

hsg.reset (execute) Projector is turned on.

Input signal is detected

DU6693Z DLP Projecto

Remote Communication Manual

RC66930718EN01

SIGNAL

OSD Function Operation

command Settings/Return Values Note

Input Select input.sel ?

0 = HDMI I

1 = DisplayPort

2 = DVI-D

3 = VGA

4 = Component / BNC

5 = HDBaseT

Projector is turned on.

EDID Mode

HDMI

Edid.mode.hdmi ?

0 = Default

1 = 1024x768@60

2 = 1280x720@60

3 = 1280x800@60

4 = 1280x1024@60

5 = 1600x1200@60

6 = 1680x1050@60

7 = 1920x1080@60

Projector is turned on.

Adjustment is for current input

source.

EDID Mode

DisplayPort

Edid.mode.dp ?

0 = Default

1 = 1024x768@60

2 = 1280x720@60

3 = 1280x800@60

4 = 1280x1024@60

5 = 1600x1200@60

6 = 1680x1050@60

7 = 1920x1080@60

Projector is turned on.

Adjustment is for current input

source.

EDID Mode

DVI-D

Edid.mode.dvi ?

0 = Default

1 = 1024x768@60

2 = 1280x720@60

3 = 1280x800@60

4 = 1280x1024@60

5 = 1600x1200@60

6 = 1680x1050@60

7 = 1920x1080@60

Projector is turned on.

Adjustment is for current input

source.

EDID Mode

VGA

Edid.mode.vga ?

0 = Default

1 = 1024x768@60

2 = 1280x720@60

3 = 1280x800@60

4 = 1280x1024@60

5 = 1600x1200@60

6 = 1680x1050@60

7 = 1920x1080@60

Projector is turned on.

Adjustment is for current input

source.

EDID Mode

HDBaseT

Edid.mode.hdbt ?

0 = Default

1 = 1024x768@60

2 = 1280x720@60

3 = 1280x800@60

4 = 1280x1024@60

5 = 1600x1200@60

6 = 1680x1050@60

7 = 1920x1080@60

Projector is turned on.

Adjustment is for current input

source.

Auto Source auto.src ?

0 = Off

1 = On

Projector is turned on.

DU6693Z DLP Projecto

Remote Communication Manual

RC66930718EN01

OSD Function Operation

command Settings/Return Values Note

Color Space color.space ?

0 = Auto

1 = YPbPr (Rec 709)

2 = YcbCr (Rec 601)

3 = RGB-PC (0-255)

4 = RGB-Video (16-

35)

Projector is turned on.

The source is detected.

Aspect Ratio aspect ?

0 = 5:4

1 = 4:3

2 = 16:10

3 = 16:9

4 = 1.88

5 = 2.35

6 = LetterBox

7 = Source

8 = Native

Projector is turned on.

The source is detected.

Overscan zoom ?

0 = Off

1 = On

Projector is turned on.

The source is detected.

Background background ?

0 = Logo

1 = Black

2 = Blue

Projector is turned on.

Test Pattern pattern ?

0 = Off

1 = CrossHatch

2 = Color Bar

3 = Checkboard

4 = H Burst

5 = V Burst

6 = White

7 = Red

8 = Green

9 = Blue

10 = Black

Projector is turned on.

3D model is not enabled.

VGA Setup/H Total h.total ?

0-200

Projector is turned on.

The source is detected.

The source is from VGA or

Component/BNC Input.

VGA Setup/H Start h.pos ?

0-200

Projector is turned on.

The source is detected.

The source is from VGA or

Component/BNC Input.

VGA Setup/H Phase h.phase ?

0-31

Projector is turned on.

The source is detected.

The source is from VGA or

Component/BNC Input.

VGA Setup/V Start v.pos ?

0-200

Projector is turned on.

The source is detected.

The source is from VGA or

Component/BNC Input.

Auto Sync auto.img (execute) Projector is turned on.

The source is detected.

DU6693Z DLP Projecto

Remote Communication Manual

RC66930718EN01

SETUP

OSD Function Operation

command Settings/Return Values Note

Language lang ?

0 = English

1 = French

2 = Spanish

3 = German

4 = Portuguese

5 = Chinese Simplified

6 = Chinese Traditional

7 = Japanese

8 = Korean

Projector is turned on.

Laser Mode laser.mode ?

0 = ECO

1 = Normal

2 = Power Level

Projector is turned on.

Custom Power Level laser.power ?

35 - 100

Projector is turned on.

Laser mode is set to Power

Level.

Custom Power Level is set to Off

Constant Brightness Laser.cbc.enable ?

0 = Off

1 = On

Laser model is set to Power Level

Startup Logo Startup.logo ?

0 = Off

1 = On

Projector is turned on.

Projector is not at ECO standby

mode.

Dynamic Black dblack ?

0 = Off

1 = On

Projector is turned on.

Projector is not at 3D mode.

Constant Brightness is set to Off.

Laser Off Timer laser.off.timer ?

0 = Disable

1 = 0.5 seconds

2 = 1.0 seconds

3 = 1.5 seconds

4 = 2.0 seconds

5 = 3.0 seconds

6 = 4.0 seconds

Projector is not at 3D mode

Constant Brightness is set to Off

3D Format

3d.format = ? 0 = Off

1 = Auto

2 = Side-By-Side (Half)

3 = Top-And-Bottom

4 = Frame Sequential

Projector is turned on.

DLP Link

3d.dlplink ?

0 = Off

1 = On

Projector is turned on.

3D Format is not set to Off or

uto.

Eye Swap

3d.swap ?

0 = Normal

1 = Reverse

Projector is turned on.

3D Format is enabled.

3D 24Hz Display

3d.144hz ?

0 = 96Hz

1 = 144Hz

Projector is turned on.

3D Format is enabled.

The option is for 24Hz 3D timing

only

Sync Reference

3d.syncref ?

0 = Internal

1 = External

Projector is turned on.

3D Format is enabled.

sync delay

3d.syncdelay ?

0 – 100 Projector is turned on.

3D Format is enabled.

DU6693Z DLP Projecto

Remote Communication Manual

RC66930718EN01

OSD Function Operation

command Settings/Return Values Note

Trigger1 trig.1 ?

0 = Off

1 = On

Projector is turned on.

Trigger2 trig.2 ?

0 = Off

1 = On

Projector is turned on.

Control Panel Lock keypad.lock ?

0 = Off

1 = On

Projector is turned on.

Security Lock security.lock ?

Password is composed of

four characters, U, D, L

and R as cursor.

U: Up

D: Down

L: Left

R: Right

Projector is turned on.

Disable Security Lock security.unlock (execute) Projector is turned on.

Projector ID Control control.id ?

0 = Disable ID Control

1 - 99 = Enable ID control

and set Control ID

Projector is turned on.

Menu Position osd.menupos ?

0 = Center

1 = Top Left

2 = Top Right

3 = Bottom Left

4 = Bottom Right

Projector is turned on.

INSTALLATION

OSD Function Operation

command Settings/Return Values Note

Projection Mode proj.mode ?

0 = Front

1 = Rear

2 = Ceiling + Front

3 = Ceiling + Rear

4 = Auto-Front

Projector is turned on.

High Altitude altitude ?

0 = Sea Level

1 = A1(4000ft/1219m)

2 = A2(8000ft//2438m)

Projector is turned on.

Standby Mode Standby.mode ?

0 = Network Standby

1 = Eco

Projector is turned on.

Remote sensor is not set to

HDBaseT

RS-232 Channel is not set to

HDBaseT

Remote Sensor ir.enable =

0 = Front / Back

1 = Front

2 = Back

3 = HDBaseT

4 = Off

Projector is turned on.

Front and rear IR receivers are

disabled when the option is set to

HDBasT or Off.

Andere Handbücher für DU6693Z

Inhaltsverzeichnis

Andere Vivitek Projektor Handbücher

Vivitek

Vivitek DS262 Bedienungsanleitung

Vivitek

Vivitek D-530MX Bedienungsanleitung

Vivitek

Vivitek DX813 Series Bedienungsanleitung

Vivitek

Vivitek D6510 Bedienungsanleitung

Vivitek

Vivitek DW866 series Bedienungsanleitung

Vivitek

Vivitek DU9900Z Bedienungsanleitung

Vivitek

Vivitek D86x Series Bedienungsanleitung

Vivitek

Vivitek DU8190Z Bedienungsanleitung

Vivitek

Vivitek Qumi Q2-L Series Bedienungsanleitung

Vivitek

Vivitek D9 Series Bedienungsanleitung

Vivitek

Vivitek D755WT SERIES Bedienungsanleitung

Vivitek

Vivitek D36 Series Bedienungsanleitung

Vivitek

Vivitek D7 Series Bedienungsanleitung

Vivitek

Vivitek D965 Series Bedienungsanleitung

Vivitek

Vivitek D8 Series Bedienungsanleitung

Vivitek

Vivitek DH758USTIR series Gebrauchsanweisung

Vivitek

Vivitek DH559 SERIES Bedienungsanleitung

Vivitek

Vivitek D5I80HD Bedienungsanleitung

Vivitek

Vivitek Qumi Z1H Bedienungsanleitung

Vivitek

Vivitek D950HD Bedienungsanleitung

Vivitek

Vivitek DU72x Series Bedienungsanleitung

Vivitek

Vivitek DU4771Z-WH Bedienungsanleitung

Vivitek

Vivitek H1082 Bedienungsanleitung

Vivitek

Vivitek D8300ST Bedienungsanleitung

Beliebte Projektor Handbücher anderer Marken

iEmmet

iEmmet MP-312 Bedienungsanleitung

Epson

Epson VS400 Bedienungsanleitung

Sony

Sony VPL-HS10 Marketing Specifications & Features Bedienungsanleitung

Sony

Sony VPL-HW65ES Service-Handbuch

Toshiba

Toshiba TLP-791U Bedienungsanleitung

Philips

Philips LC1341 Referenzhandbuch

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Bedienungsanleitung

NEC

NEC NP600S EDU Bedienungsanleitung

BenQ

BenQ SH753P Bedienungsanleitung

Eiki

Eiki EK-623U series Bedienungsanleitung

Epson

Epson PowerLite Pro Cinema 6020UB Bedienungsanleitung

Epson

Epson PowerLite Home Cinema 705HD Bedienungsanleitung

Christie

Christie LHD700 Bedienungsanleitung

Navitar

Navitar FX Bedienungsanleitung

InFocus

InFocus LitePro 560 Bedienungsanleitung

Sony

Sony SRX-R815P Bedienungsanleitung

Vivitar

Vivitar DP1500 X Bedienungsanleitung

Acer

Acer C20 Series Bedienungsanleitung
