DU9900ZDLP Projector Remote CommunicationManual

CM8X900217EN00

Table of Contents

The Serial Interface RS-232 Command ........................................................................................2

Communication parameter.........................................................................................................2

Operation commands.................................................................................................................2

Operation command syntax .................................................................................................2

List of operation commands .................................................................................................3

Simulated IR remote controller commands ..............................................................................14

List of simulated IR remote controller commands ....................................................................14

Control the Projector Through a Network..................................................................................15

Cable connection .....................................................................................................................15

Set up the projector for networking ..........................................................................................16

Control the projector through a network...................................................................................17

Control the projector through a web browser .....................................................................17

Control projector with TCP/IP communication protocol ......................................................21

About Vivitek Support .................................................................................................................22

DU9900Z DLP Projector Remote Communication Manual

CM8X900217EN00

The Serial Interface RS-232 Command

This projector supports to control by RS-232 command, there exist two types of RS-232 serial commands:

Operation command: Available menu options are INPUT, PICTURE, ALIGNMENT, CONTROL and SERVICE.

Simulated IR remote controller commands: Controls projector via RS-232 command, the commands simulate IR

remote controller and its control keys.

Communication parameter

You can use the serial control command to input commands for projector control or retrieve its operational data

through Windows client terminal software, e.g. Hyper Terminal, with ASCII characters. You need to set up the following

communication parameters in advance:

Item

Parameter:

Bit per Second

9600 bps

Data Bit

8-bit

Parity

None

Stop Bit

Flow Control

None

Port

7000

Note:

The terminal software does not return every command input character

The transmission performance varies with the length of RS-232 cable

Operation commands

Operation command syntax

An operation command is prefixed by character "op", followed by control commands and settings separated by

space blank [SP], and ended by carriage return pair "CR" and "ASCII hex 0D".Syntax of serial control

commands:

op[SP]<operation command>[SP]<Setting Value>[CR]

A constant indicating this is an operation command.

[SP]

Indicate one blank space.

[CR]

Indicate the command ending carriage return pair "CR" and "ASCII hex 0D".

Setting value

Settings of operation command

Types of setup strings

Characters of settings

Description

Query current setup

Question mark "?" indicates querying current setup

Setup

= <settings>

Syntax: Symbol "=" suffixed with setup values

Increase setup order of

adjustment items

Some settings are changed in steps. Symbol "+"

indicates changing one step up

Decrease setup order of

adjustment items

Some settings are changed in steps. Symbol "-"

indicates changing one step down

Execute operation command

None

Certain operation commands execute after input

without further setting or regulators.

Examples:

Control items

Input command

Projector return message

Query current brightness

op bright ? [CR]

OP BRIGHT = 101

Set up brightness

op bright = 127 [CR]

OP BRIGHT = 127

Set up input signal source to

HDMI

op input.sel = 0 [CR]

OP INPUT.SEL = 0

Reset projection lens to

center position

lens.center

Note:

When sending the multiple commands, make sure the return message of the last command is received

before sending out the next one.

CM8X900217EN00

List of operation commands

INPUT

OSD Function

Operation

command

Settings/Return Values

Note

Input Select

input.sel

0 = HDMI 1

1 = HDMI 2

2 = VGA

3 = Component / BNC

4 = DVI

5 = 3G-SDI

6 = HDBaseT

Not applicable when the project is at

below status.

Standby mode

When the blank function is activated

PIP/PIP Option

pip.mode

0 = Off

1 = On

Not applicable when the project is at

below status.

Standby mode

When PIP is off

PIP/PIP Input

pip.sel

0 = HDMI 1

1 = HDMI 2

2 = VGA

3 = Component / BNC

4 = DVI

5 = 3G-SDI

6 = HDBaseT

Not applicable when the project is at

below status.

Standby mode

When PIP is off

PIP/ Position

pip.pos

0 = Top Left

1 = Top Right

2 = Bottom Left

3 = Bottom Right

4 = PBP

Not applicable when the project is at

below status.

Standby mode

When PIP is off

Auto Source

auto.src

0 = Off

1 = On

Not applicable when the projector is in

standby mode.

Color Space

color.space

0 = Auto

1 = YPbPr (Rec. 709)

2 = YcbCr (Rec. 601)

3 = RGB-PC (0-255)

4 = RGB-Video (16-235)

Not applicable when the project is in

standby mode or the input signal is not

yet locked.

Aspect Ratio

aspect

0 = 5:4

1 = 4:3

2 = 16:10

3 = 16:9

4 = 1.88

5 = 2.35

6 = LetterBox

7 = Source

8 = Native

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

When the Zoom function is set to

Zoom in, the Unscaled function is

disabled.

Overscan

zoom

0 = Off

1 = Crop

2 = Zoom

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

When the Zoom function is set to

Zoom in, the Unscaled function is

disabled.

DU9900ZDLP Projector Remote CommunicationManual

DU9900Z DLP Projector Remote Communication Manual

CM8X900217EN00

OSD Function

Operation

command

Settings/Return Values

Note

VGA Setup/H Total

h.total

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Apply for VGA and Component signal

input.

VGA Setup/H Start

h.pos

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Apply for VGA and Component signal

input.

VGA Setup/H Phase

h.phase

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Apply for VGA and Component signal

input.

VGA Setup/V Start

v.pos

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Apply for VGA and Component signal

input.

Test Pattern

pattern

0 = Off

1 = White

2 = Black

3 = Red

4 = Green

5 = Blue

6 = Checkboard

7 = CrossHatch

8 = V Burst

9 = H Burst

10 = Color Bar

Not applicable when the project is in

standby mode.

3D/3D Format

3d.format

= ?

0 = Off

1 = Auto

2 = Side-By-Side (Half)

3 = Top-And-Bottom

4 = Frame Sequential

Not applicable when the project is at

below status.

Standby mode

3D/Eye Swap

3d.swap

= ?

0 = Normal

1 = Reverse

Not applicable when the project is at

below status.

Standby mode

3D/DLP Link

3d.dlplink

= ?

0 = Off

1 = On

Not applicable when the project is at

below status.

Standby mode

3D/Dark Time

3d.darktime

= ?

0 = 0.65 ms

1 = 1.3 ms

2 = 1.95 ms

Not applicable when the project is at

below status.

Standby mode

3D/sync delay

3d.syncdelay

= ?

1 – 60

Not applicable when the project is at

below status.

Standby mode

3D/Sync Reference

3d.syncref

= ?

0 = External

1 = Internal

2 = Auto

Not applicable when the project is at

below status.

Standby mode

DU9900Z DLP Projector Remote Communication Manual

CM8X900217EN00


OSD Function

Operation

command

Settings/Return Values

Note

Picture Mode

pic.mode

0 = High Bright

1 = Presentation

2 = Video

Not applicable when the project is in

standby mode.

Brightness

bright

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Contrast

contrast

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Saturation

saturat

0-200

Apply for YUV signal input

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Hue

tint

0-200

Apply for YUV signal input

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Sharpness

sharp

0-20

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Color Temperature

color.temp

0 = 5400K

1 = 6500K

2 = 7500K

3 = 9300K

4 = Native

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Gamma

gamma

0 = 1.0

1 = 1.8

2 = 2.0

3 = 2.2

4 = 2.35

5 = 2.5

6 = S-Curve

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Input Balance /Red

Offset

red.offset

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Input Balance /Green

Offset

green.offset

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Input Balance /Blue

Offset

blue.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

DU9900Z DLP Projector Remote CommunicationManual

CM8X900217EN00

OSD Function

Operation

command

Settings/Return Values

Note

Input Balance /Red

Gain

red.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Input Balance /Green

Gain

green.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Input Balance /Blue

Gain

blue.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Red Gain

hsg.r.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Green Gain

hsg.g.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Blue Gain

Hsg.b.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Cyan Gain

hsg.c.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Magenta Gain

hsg.m.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Yellow Gain

Hsg.y.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Red/Saturation

hsg.r.sat

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Green/Saturation

hsg.g.sat

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Blue/Saturation

Hsg.b.sat

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Cyan/Saturation

hsg.c.sat

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Magenta/Satura

ti on

hsg.m.sat

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

DU9900Z DLP Projector Remote Communication Manual

CM8X900217EN00

OSD Function

Operation

command

Settings/Return Values

Note

HSG/Yellow/Saturation

Hsg.y.sat

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Red/Hue

hsg.r.hue

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Green/Hue

hsg.g.hue

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Blue/Hue

Hsg.b. hue

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Cyan/Hue

hsg.c. hue

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Magenta/Hue

hsg.m. hue

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/Yellow/Hue

Hsg.y. hue

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/White/Red Gain

hsg.wr.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/White/Green Gain

hsg.wg.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG/White/Blue Gain

Hsg.wb.gain

0-200

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

HSG Reset

hsg.reset

(execute)

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Noise Reduction

0-3 (Noise Reduction)

Not applicable when the project is in

standby mode or the input signal is

not locked yet.

Dynamic Black

dblack

0 = Off

1 = On

Not applicable when the projector is

in standby mode.

Freeze

freeze

0 = Off

1 = On

Not applicable when the projector is

in standby mode

DU9900Z DLP Projector Remote Communication Manual

CM8X900217EN00

Alignment

OSD Function

Operation

command

Settings/Return Value

Note

Lens control

zoom.in

(execute)

The Lens control command does not

apply when the projector is in standby

mode.

Lens control

zoom.out

(execute)

The Lens control command does not

apply when the projector is in standby

mode.

Lens control

focus.near

(execute)

The Lens control command does not

apply when the projector is in standby

mode.

Lens control

focus.far

(execute)

The Lens control command does not

apply when the projector is in standby

mode.

Lens control

lens.up

(execute)

The Lens control command does not

apply when the projector is in standby

mode.

Lens control

lens.down

(execute)

The Lens control command does not

apply when the projector is in standby

mode.

Lens control

lens.left

(execute)

The Lens control command does not

apply when the projector is in standby

mode.

Lens control

lens.right

(execute)

The Lens control command does not

apply when the projector is in standby

mode.

Lens Type

lens.type

0 = non-UST

1 = UST lens

Not applicable when the project is at

below status.

Standby mode

Lens Memory /

Load Memory

lens.load

1-10 set of lens memory

(Load)

Not applicable when the project is at

below status.

Standby mode

Lens Memory /

Save Memory

lens.save

1-10 set of lens memory

(Save)

Not applicable when the project is at

below status.

Standby mode

Lens Memory /

Clear Memory

lens.clear

1-10 set of lens memory

(Save)

Not applicable when the project is at

below status.

Standby mode

Center Lens

lens.center

(execute)

The Lens control command does not

apply when the projector is in standby

mode.

Digital Zoom /

Digital Zoom

digi.zoom

0 - 100

Not applicable when the project is in

standby mode or the input signal is not

locked yet.

Digital Zoom /

Digital Pan

digi.pan

-320 - 320 (depend on

input timing;

use "op digi.pan ?" to

query current setting)

Not applicable when the project is in

standby mode or the input signal is not

locked yet.

Digital Zoom /

Digital Scan

digi.scan

-200 - 200

(depend on input timing;

use "op digi.scan.?" to

query current setting

Not applicable when the project is in

standby mode or the input signal is not

locked yet.

Digital Zoom /

Reset

digi.zoom.rst

(execute)

Not applicable when the project is in

standby mode or the input signal is not

locked yet.

DU9900Z DLP Projector Remote Communication Manual

CM8X900217EN00

OSD Function

Operation

command

Settings/Return Value

Note

Warp / Keystone H

h.keystone

Horizontal -600 ~ + 600

Not applicable when the project is at

below status.

Standby mode

Warp / Keystone V

v.keystone

Vertical -400 ~ + 400

Not applicable when the project is at

below status.

Standby mode

Warp / Rotation

rotation

-100 ~ +100

Not applicable when the project is at

below status.

Standby mode

Warp / H Pin/Barrel

h.pin.barrel

-150 ~ + 300

Not applicable when the project is at

below status.

Standby mode

Warp/ V Pin/Barrel

v.pin.barrel

-150 ~ + 300

Not applicable when the project is at

below status.

Standby mode

Warp/ Top Left

Corner/Horizontal

4corner.ulx

-192 ~+192

Not applicable when the project is at

below status.

Standby mode

Warp/ Top Left

Corner/Vertical

4corner.uly

-120 ~+120

Not applicable when the project is at

below status.

Standby mode

Warp/ Top Right

Corner/ Horizontal

4corner.urx

-192 ~+192

Not applicable when the project is at

below status.

Standby mode

Warp/ Top Right

Corner/ Vertical

4corner.ury

-120 ~+120

Not applicable when the project is at

below status.

Standby mode

Warp/Bottom left

Corner/ Horizontal

4corner.llx

-192 ~+192

Not applicable when the project is at

below status.

Standby mode

Warp/Bottom left

Corner/ Vertical

4corner.lly

-120 ~+120

Not applicable when the project is at

below status.

Standby mode

Warp/Bottom Right

Corner/ Horizontal

4corner.lrx

-192 ~+192

Not applicable when the project is at

below status.

Standby mode

Warp/Bottom Right

Corner/ Vertical

4corner.lry

-120 ~+120

Not applicable when the project is at

below status.

Standby mode

Blanking /

Top

blanking.top

0 ~ 360

Not applicable when the project is at

below status.

Standby mode

Blanking /

Bottom

blanking.bottom

0 ~ 360

Not applicable when the project is at

below status.

Standby mode

Blanking /

left

blanking.left

0 ~ 534

Not applicable when the project is at

below status.

Standby mode

Blanking /

Right

blanking.right

0 ~ 534

Not applicable when the project is at

below status.

Standby mode

Andere Handbücher für DU9900Z

Inhaltsverzeichnis

Andere Vivitek Projektor Handbücher

Vivitek

Vivitek DX977 Series Bedienungsanleitung

Vivitek

Vivitek DU6693Z Bedienungsanleitung

Vivitek

Vivitek D366 Series Bedienungsanleitung

Vivitek

Vivitek H1188 Series Bedienungsanleitung

Vivitek

Vivitek D5500 series Bedienungsanleitung

Vivitek

Vivitek H5095 series Bedienungsanleitung

Vivitek

Vivitek D-635MX Bedienungsanleitung

Vivitek

Vivitek DU70x Series Bedienungsanleitung

Vivitek

Vivitek DU8090Z-WH Gebrauchs- und Pflegehandbuch

Vivitek

Vivitek DX6731 Bedienungsanleitung

Vivitek

Vivitek DU8090Z Gebrauchs- und Pflegehandbuch

Vivitek

Vivitek DX864 series Bedienungsanleitung

Vivitek

Vivitek novopro Bedienungsanleitung

Vivitek

Vivitek D8 Series Bedienungsanleitung

Vivitek

Vivitek DU8090Z Bedienungsanleitung

Vivitek

Vivitek D863 Bedienungsanleitung

Vivitek

Vivitek QUMI Q9 Bedienungsanleitung

Vivitek

Vivitek Qumi Q5 Series Bedienungsanleitung

Vivitek

Vivitek D8 PointRacer Series Bedienungsanleitung

Vivitek

Vivitek D330MX Bedienungsanleitung

Vivitek

Vivitek D967 SERIES Bedienungsanleitung

Vivitek

Vivitek D5I8ZHDB Bedienungsanleitung

Vivitek

Vivitek DH758UST series Bedienungsanleitung

Vivitek

Vivitek D825MS Bedienungsanleitung

Beliebte Projektor Handbücher anderer Marken

iEmmet

iEmmet MP-312 Bedienungsanleitung

Epson

Epson VS400 Bedienungsanleitung

Sony

Sony VPL-HS10 Marketing Specifications & Features Bedienungsanleitung

Sony

Sony VPL-HW65ES Service-Handbuch

Toshiba

Toshiba TLP-791U Bedienungsanleitung

Philips

Philips LC1341 Referenzhandbuch

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Bedienungsanleitung

NEC

NEC NP600S EDU Bedienungsanleitung

BenQ

BenQ SH753P Bedienungsanleitung

Eiki

Eiki EK-623U series Bedienungsanleitung

Epson

Epson PowerLite Pro Cinema 6020UB Bedienungsanleitung

Epson

Epson PowerLite Home Cinema 705HD Bedienungsanleitung

Christie

Christie LHD700 Bedienungsanleitung

Navitar

Navitar FX Bedienungsanleitung

InFocus

InFocus LitePro 560 Bedienungsanleitung

Sony

Sony SRX-R815P Bedienungsanleitung

Vivitar

Vivitar DP1500 X Bedienungsanleitung

Acer

Acer C20 Series Bedienungsanleitung
