VM Audio SRAT10-BK Bedienungsanleitung

SRAT10-BK

SHAKER SERIES

ACTIVE FLOORSTANDING

LOUDSPEAKERS

Thank you for your interest in VM Audio products. Our

goal is to enhance your listening experience. The Shaker

Series was designed as the economical solution for a

performance craving, casual consumer. The experts and

engineers at VM Audio have meticulously tested and

designed this product with a reasonable price tag to t any

budget. Let the Shaker Series maximize the value of your

investment.

Welcome!

About This Manual

This user guide describes the controls on the speaker

system. You can use the controls on the remote if they

have the same or similar names as those on the control

panel.

Specications

Loudspeaker Type

Cabinet Color

High Frequency

Midrange Driver

Bass Driver

Audio Input

Frequency Range

Power (RMS/Peak)

Dimensions (H x W x D)

Operating Voltage

Bluetooth Wireless Range

Microphone Input Jack

Full Range System

Phantom Black

1 1/2” Composite Soft Dome

4” Treated Composite Fiber

8” Dual Pulp Cone

Analog RCA, Bluetooth, USB, SD

40 Hz - 20 kHz

300W / 1000W

32.68” x 6.38” x 12.20”

120V

30 ft.

1/4” / 6.3mm

Table of Contents

Welcome

Specications

Table of Contents

Warning

Precautions

System Features

Included

Overview

Connections

Settings & Adjustments

Operation

Speaker Placement

Troubleshooting

Warranty

Warning!

To prevent re or electric shock:

• Do not expose the unit to rain or moisture.

• Do not open the cabinet.

• Do not use these speakers near water.

• Do not expose these speakers to dripping or

splashing liquids

• Do not set objects containing liquids on units.

• Do not spill liquids into any part of the speaker

system.

• Do not overload wall outlets and extension

cords.

• Do not run power cables and speaker wires

through sharp edges.

• Do not pinch power cables and speaker wires.

• Do not expose the bare wires from the power

cable and speaker wires.

• Do not remove the back amplier plate. No

user-serviceable parts inside.

• Refer servicing to qualied personnel only.

WARNING

RISK OF ELECTRIC

SHOCK

CAUTION:

Any change or modications not expressly

approved in this manual could void your warranty

for this equipment.

Precautions

On Safety

• Contact between bare speaker wires may result in a

short-circuit.

• Should any liquid or solid object fall into the speaker

system, unplug the system’s power cord and have the

system checked before operating it any further.

On Power Sources

• Before operating this speaker system, check that the

operating voltage of the speaker system is identical to the

wall outlet voltage where the speaker is being connected.

• If you are not going to use the speaker system for a long

period of time, be sure to disconnect the speaker system

from the wall outlet. To disconnect the AC power cord

(mains lead), grasp the plug itself and never pull the cord.

• AC power cord must be changed by qualied electrical

personnel.

On Placement

• Use good lifting practice when moving speakers to avoid

injury.

• Do not install the speakers in an inclined position.

On Operation

• Before making any connections, turn off your receiver

or audio source and unplug if from the AC (mains) power

outlet. Not doing this may result in damage to your system.

• The volume level should not be turned up to the point of

distortion.

On Adjusting Volume

• Do not turn up the volume while listening to a portion

with very low level inputs or no audio signals. If you do,

the speakers may be damaged when a peak level portion is

played.

On Cleaning

• Clean the cabinet, panel and controls with a soft cloth

slightly moistened with a mild detergent solution. Do not

use any type of abrasive pad, scouring powder or solvent

such as alcohol or benzine.

System Features

• High Performance With Smooth & Detailed Reproduction

• Phantom Black Wood Veneer Body

• Easy 1-2-3 Direct Play Setup

• All-In-One Home Audio Solution

• Wide Range 3-Way Soundstage Performance

• Fully Powered, Bi-amplied System

• Advanced Wireless Bluetooth Connectivity

• Internal, Magnetic Motor Shielding Protection

• Optimum Bass Reex Wood Enclosure Design

• CAD Energized Bass Port Design

• Soft Dome 1.5” High Frequency Driver

• High Performance 4” Midrange Driver

• Deep Note 8” Solid Bass Subwoofer

• Karaoke Function with Dual Mic Input & Echo Control

• USB Drive / SD Card Music Playback

• WMA / MP3 Music File Compatibility

• Bass, Treble, Mic, Echo & Volume Adjustments

• Built-In Digital Control POD

• High Clarity Class A/B Amplier Technology

• Low Distortion CMOS Signal Processing Technology

• Infrared Full Function Wireless Remote Control

Review the contents of the package and make sure the

following items are included:

Included

RemoteSpeaker Cabinets

RCA-to-RCA Cables 20ft Speaker Wire

RCA-to-3.5mm Cable User Guide

SRAT10-BK

SHAKER SERIES

ACTIVE FLOORSTANDING

LOUDSPEAKERS

Right SpeakerLeft Speaker

Front View

Overview

Rear View

Amplier

Back Plate Speaker

Connector

Right SpeakerLeft Speaker

Side View

Overview

Left Speaker

Side Panel

Control

Digital Control

Pod
