2013 CC Quick-Start Guide
At Volkswagen, we want to be sure
you get the most out of your time behind
the wheel, so we’ve created this guide to
take you through the finer points. And if
you still have questions, just turn to the
back of this guide and see how easy it
can be to contact us. You’ll see how fun
and easy it is to drive a VW, and soon
you’ll be speaking fluent Volkswagen.
LEARN MORE AT
vw.com/cc2013
The information within this guide must be used in conjunction with the information in the Volkswagen Owner’s Manuals. Refer to your vehicle’s Owner’s Manual for all information and warnings.
By using this guide, you acknowledge that you are aware of and have read the warnings and information provided in the Owner’s Manual on the topics in this guide and will use this information to
augment that material.
Answer an incoming call
The Bluetooth system will interrupt your car
stereo with a ringtone. Press the phone button
on the multi-function steering wheel.
The multi-function display (or your RNS 315 screen)
will then show a PIN.**
Make sure the same PIN is displayed on your
phone and press OK on the steering wheel
(or press YES on the RNS 315). Then press PAIR
on your phone.†
Bluetooth®
Technology
Bluetooth Voice Recognition
Text* PHONE to 50467
to watch the Bluetooth video.
Message and data rates may apply.
Text* VRECO to 50467 to watch
the Voice Recognition video.
Message and data rates may apply.
**Some phones may require entering a four-digit PIN (0000) to complete the pairing process. †Once the PIN is shown, pairing must be completed within 30 seconds. Otherwise the process will need to be repeated.
Reconnect Automatically
If your phone displays a prompt asking to
connect to VW PHONE, make sure to enable
future automatic connections.
Phone button
Microphone button
Pairing your phone
First, check your phone’s compatibility at
www.vw.com/bluetooth.
Start the ignition. Your car’s Bluetooth system will be
in “discovery” mode for the next three minutes. (If your
car is equipped with an RNS 315 touchscreen display,
power it on.)
From the Bluetooth menu on your phone, search for
new devices and select VW PHONE.
A connection request will appear on the
multi-function display (or on the RNS 315).
Press OK on the steering wheel (or PAIR on the RNS 315).
Important Warnings and Safety Information, which you must read, are listed on the last panel, under BLUETOOTH TECHNOLOGY WARNINGS.
Press the microphone button until you hear a chime. Your VW will say, “Main menu.” Then take the following steps.
Call by name
After you hear a beep, say, “Call” followed by the
name of the person you want to call. For example,
“Call Mike Brown.” The system will repeat your
request. Say, “Yes” if correct. The system will answer,
“Calling Mike Brown.”
LEARN MORE AT
vw.com/cc2013
Bluetooth
Phone Pairing
Redial
After the beep, say, “Redial.”
Help
After the beep, say, “Help.”
Then follow the prompts.
*Do not text while driving.
*Do not text while driving.
Premium VIII
Audio
Premium VIII Audio
Text* PREM8 to 50467 to
watch the Premium VIII video.
Message and data rates may apply.
Select and save a preset radio station
Press FM, AM or SAT to select a band.
Use the tuning knob at the lower right to select a station, then press
and hold any preset station soft key until you hear a confirmation beep.
The new station will appear in the display.
By pressing the Presets soft key, you can change through
additional presets.
Important Warnings and Safety Information, which you must read, are listed on the last panel, under PREMIUM VIII WARNINGS.
LEARN MORE AT
vw.com/cc2013
Streaming audio with Bluetooth® technology
First, pair your compatible Bluetooth equipped phone or
audio player. (Refer to the pairing instructions in this booklet.)
Press the MEDIA hard key.
Press the BT-Audio soft key.
To navigate through your music, press the PLAY/PAUSE,
PREVIOUS, and NEXT TRACK soft keys.
HD Radio® Programming. HD Radio is totally free programming,
offering crystal clear sound—FM stations have CD-quality sound,
while AM stations sound like FM stereo. HD Radio also offers more
variety, as many FM stations broadcast extra HD multicast channels.
HD Radio Signal Interruption. When leaving the HD coverage
area, HD1 channels will switch to the analog signal, while HD2/
HD3 channels will cut off completely, without gradual fading.
This is normal. The signal will refresh as you drive.
SiriusXM Satellite Radio. New Volkswagen vehicles come with
a three-month trial subscription to the Sirius Select package.
Infrequently, tall buildings and tunnels may interrupt the satellite
signal. This is normal. The signal will refresh as you drive. For more
information, please refer to the SiriusXM brochure in your glove box.
*Do not text while driving.
RNS 315
Navigation
Optional RNS 315 Navigation
Important Warnings and Safety Information, which you must read, are listed on the last panel, under NAVIGATION WARNINGS.
LEARN MORE AT
vw.com/cc2013
Enter a destination
Press the NAV hard key.
Tap the flag icon on the touchscreen. This will allow you to enter
the address.
Enter the state first, then the city, the street, and the number.
Not sure about the number of the address? You can just enter the state, the
city, and the street. Then press the List soft key to display the street.
Confirm the address. If the address is incorrect, press the back button to return
to the address entry screen.
Press the START soft key to begin your route.
Change the route settings
The system will automatically display the fastest route. You can also
have the most economical or shortest route displayed.
Within the Navigation screen, press the SETUP hard key.
Choose ROUTE OPTIONS.
Choose ROUTE CRITERIA.
Now you can change from the Fast default to Economic or Short.
Back button Back button
NAV hard key NAV hard key
iPod Adapter
iPod®
Adapter
Important Warnings and Safety Information, which you must read, are listed on the last panel, under iPOD ADAPTER WARNINGS.
To connect your device, here’s all you need to do.
LEARN MORE AT
vw.com/cc2013
RNS 315
First, note that your iPod music player
must be Generation Four or newer.*
Connect it to your car’s MDI cable.
Audio from your device will play
through your speaker system.
To choose a song, press the LIST
soft key, then the UP soft key.
To display the category list, press
the UP soft key again.
Premium VIII
First, note that your iPod music player must be Generation Four or newer.
Connect it to your car’s MDI cable.
Press the MEDIA hard key.
Press the MEDIA-IN soft key until the external audio device is shown in the display.
To choose a song, press the Selection soft key.
To display the category, press the key with the folder icon at the upper left of the screen.
To return to the main screen, press the Back soft key on the upper right corner of the screen.
First, plug in your media device to the auxiliary jack. Note that an auxiliary cable does not come standard.
Playing your media device with the auxiliary jack
Premium VIII
• Press the SETUP hard key.
• Press the MEDIA soft key.
• Press the Enable AUX Input soft key.
• Press the MEDIA hard key.
RNS 315
• To toggle between different media,
such as a CD or streaming audio
from your phone, press the MEDIA
hard key.
• Then press the media-specific soft key.
*For more information on iPhone 5, please visit vw.com/cc2013
Climatronic
Heating & Cooling
Climatronic®
Heating and Cooling
Important Warnings and Safety Information, which you must read, are listed on the last panel, under CLIMATRONIC SYSTEM WARNINGS.
LEARN MORE AT
vw.com/cc2013
To cool or heat the interior
Turn the temperature dial to 72.°
Press the AUTO button.
Like a thermostat, the system will maintain the temperature.
In extreme heat, press the MAX AC button.
When a comfortable temperature has been reached,
push the AUTO button again.
• Press the MAX defrost button.
• The AC function comes on automatically
to dry the air.
• When the windshield is clear, push the
AUTO button to return to your automatic
climate control settings.
Defrost the windshield
MAX
Set and synchronize temperatures
for driver and passenger
The driver turns the left dial until the desired temperature
is shown above the dial.
The passenger can choose a different temperature by
turning the right dial.
The passenger’s temperature can be synchronized with
the driver’s temperature by pressing the SYNC button.
When the light is on, SYNC is activated.
Cruise Control
Cruise Control
Important Warnings and Safety Information, which you must read, are listed on the last panel, under CRUISE CONTROL WARNINGS.
LEARN MORE AT
vw.com/cc2013
Cruise Control
Pull the cruise control stalk toward you.
The speedometer icon will appear in the
multi-function display.
Activate
Cancel and resume
• To cancel and resume cruise speed, press the brake
pedal or slightly push the stalk away from you.
• The CRUISE light will go off.
• To resume, pull the stalk towards you. You’ll resume
cruising at your saved speed.
Set cruising speed
mph
60
Your most recently set speed will appear as a small icon
in the multi-function display. It will remain in memory
until you turn your VW off.
When you get to your cruising speed, press the SET
button at the end of the stalk.
Your speed will appear next to the speedometer icon.
The green CRUISE light will appear in the
instrument cluster.
To increase/decrease your speed to the nearest
increment of 5, tap the stalk up or down.
Key Fob
Programming
Key Fob Programming
Important Warnings and Safety Information, which you must read, are listed on the last panel, under KEY FOB WARNINGS.
LEARN MORE AT
vw.com/cc2013
Menu button
Customize which doors lock or unlock
when you press the key fob
First, make sure your vehicle is parked.
Your car won’t let you do this while you’re driving.
Press the button with the menu icon located on
the steering wheel until you see the “Settings”
screen on the multi-function display.
Press the down arrow to scroll to “Convenience.” Press OK.
Scroll down to “Central Locking”—press OK.
Press “Unlock doors” to adjust which doors
lock or unlock when the key fob is pressed once.
“All doors” unlocks all doors.
“Single door” unlocks only the driver’s door.
“Vehicle side” unlocks the doors on the driver’s side
of the vehicle.
Press the up or down arrows to select an option.
Press OK to select your preference.
Program the doors to unlock when
you remove the keys from the ignition
First, make sure your vehicle is parked.
Press the menu button on your steering wheel until you see the
screen labeled “Settings” on the multi-function display.
Press the down arrow to scroll to “Convenience”—press OK.
Scroll down to “Central Locking”—press OK.
Select “Automatic”—press OK.
Select “Unlock,” press OK, and make sure the box is checked.
From now on, when you remove your keys from the ignition, the
doors will automatically unlock.
Seeing the TPMS light? Here’s what to do.
The correct tire pressure is displayed on the sticker on the driver’s door jamb.
Inflate your tires to those specifications, not to the number on your tires.
If you see the TPMS light on your instrument panel or the message “tire
pressure too low” in the multi-function display, use the right menu button on
your steering wheel to show Vehicle Status on the display. This will show the
current and recommended tire pressure.
Inflate the low tire(s) to the correct pressure as soon as possible.
Windshield Wipers
/ TPMS
Windshield Wipers
Tire Pressure Monitoring System
Important Warnings and Safety Information, which you must read, are listed on the last panel, under TPMS WARNINGS.
Important Warnings and Safety Information, which you must read, are listed on the last panel, under WINDSHIELD WIPER WARNINGS.
LEARN MORE AT
vw.com/cc2013
From the OFF position, move the wiper stalk one click up to activate the rain-sensing wipers. The
rain sensor automatically turns on the wipers when it begins to rain, adjusting the wiper frequency
in line with rainfall intensity.
NOTE: Be sure to turn off the rain-sensing wipers before going through a car wash.
Use the rain-sensing wipers
Continuous
LOW: From the OFF position, move the wiper stalk two clicks up.
HIGH: From the OFF position, move the wiper stalk three clicks up.
Pulsing/quick wipes
From the OFF position, press the wiper stalk down for a single wipe.
Press and hold the wiper stalk down for two seconds for a faster wipe.
Wash
Pull the stalk toward you to spray washer fluid.
Cooler temperatures may cause a warning to appear and then disappear as the tires warm up. This is a good reminder to check and adjust the tires to the proper inflation pressure.
Correct tire pressure
Andere Handbücher für 2011 CC
1
Inhaltsverzeichnis
Andere Volkswagen Automobil Handbücher
Volkswagen
Volkswagen SCIROCCO - Bedienungsanleitung
Volkswagen
Volkswagen 2014 Passat Bedienungsanleitung
Volkswagen
Volkswagen 2015 Golf GTI Betriebsanleitung
Volkswagen
Volkswagen PASSAT ESTATE Bedienungsanleitung
Volkswagen
Volkswagen ID.4 Bedienungsanleitung
Volkswagen
Volkswagen Phaeton 2003 Gebrauchsanweisung
Volkswagen
Volkswagen Golf 1998 Bedienungsanleitung
Volkswagen
Volkswagen Campmobile Betriebsanleitung
Volkswagen
Volkswagen Jetta Wagon 2004 Bedienungsanleitung
Volkswagen
Volkswagen Arteon 2021 Gebrauchsanweisung
Volkswagen
Volkswagen Amarok 2011 Installations- und Benutzerhandbuch
Volkswagen
Volkswagen TRANSPORTER 1963 Bedienungsanleitung
Volkswagen
Volkswagen 1980 Vanagon Westfalia Campmobile Bedienungsanleitung
Volkswagen
Volkswagen NEW BEETLE - Bedienungsanleitung
Volkswagen
Volkswagen Taigun 2022 Bedienungsanleitung
Volkswagen
Volkswagen Jetta 2000 Bedienungsanleitung
Volkswagen
Volkswagen 1998 Jetta Bedienungsanleitung
Volkswagen
Volkswagen 2011 Touareg Bedienungsanleitung
Volkswagen
Volkswagen FOX - Bedienungsanleitung
Volkswagen
Volkswagen california Bedienungsanleitung
