Volkswagen Passat 1995 Betriebsanleitung
Heating & Air Conditioning
80 - Heating, Ventilation
Heating and ventilation system
Heating and ventilation system, assembly
Heating and ventilation unit, assembly
Heating and ventilation cables, installing and adjusting
Heating and ventilation controls, assembly
87 - Air conditioning
A/C refrigerant system, notes
Safetymeasures
A/C refrigerant R-134a, properties
Basics when working on A/C refrigerant system R-134a
Manual A/C
Heating and A/C components in passenger compartment, servicing
Heating and A/C cables, installing and adjusting
Heating and A/C components in engine compartment, servicing
Vacuum hose layout
A/C clutch -N25- (Sanden), servicing (compressor removed)
Compressor bracket, removing and installing
4-cyl. gasoline engine
4-cyl. TDI engine
6-cyl. engine
A/C refrigerant system
A/C refrigerant system, identification
A/C refrigerant system, component overview
A/C refrigerant system, servicing
Expansion valve, removing
Condensor, removing
Heating and A/C unit, removing and assembly
A/C refrigerant system, replacing components
A/C refrigerant system pressures and temperatures, checking
A/C refrigerant system, testing with pressure gauges
A/C refrigerant system, discharging
A/C refrigerant system, flushing with compressed air and nitrogen
A/C refrigerant system, evacuating and recharging
A/C refrigerant system, troubleshooting
Compressor noisy
A/C refrigerant system pressures, checking
A/C refrigerant system cooling performance, checking
A/C refrigerant system, checking for leaks
A/C refrigerant system, capacities
Refrigerant R-134a, capacity
Refrigerant (PAG) oil R-134a, capacity
Refrigerant (PAG) oil R-134a, identification
Refrigerant (PAG) oil R-134a, distribution
80-1
Heating and
ventilation system
Heating and ventilation
system, assembly
CAUTION!
Obtain the anti-theft radio
security code.
Switch the ignition off.
Disconnect the battery
Ground(GND) strap.
After reconnecting
battery, re-
code andcheck
operation of anti-theft
radio. Also check
operation of clock and
power windows according
to Repair Manual and/or
Owner's Manual.
1-
Plenum chamber cover
2-
Dust and pollenfilter
Removing Fig. 5
3-
Hex screw with shank
M6x22
5 Nm (44 in lb)
4-
Gasket
Page
1
of
21
Heating and ventilation system
12/7/2004
http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.HA01.80.1
80-2
5-
Fresh Air Blower
Series Resistance with
Fuse -N24-
Removing and
installing Fig. 1
6-
Fresh air blower -V2-
Removing Fig. 2
7-
Footwell outlet
Replacing: Remove
shelf on drivers' and
passenger side, center
console, instrument
panel bracket and
pedal cluster cover -
23 -
8-
Airduct
9-
Airdistribution duct
Replacing center outlet
-12-
, heating and fresh
air controls -22-,
remove shelf on
passenger side;
Loosen instrument
panel -20- and lift
Page
2
of
21
Heating and ventilation system
12/7/2004
http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.HA01.80.1
80-3
10 -
Right air outlet
Removing Fig. 8
11 -
Grille
For right air outlet
12 -
Center air outlet
Removing Fig. 7
13 -
Control panel trim
14 -
Grilles
For center outlet
15 -
Instrument panel trim
Removing Fig. 4
16 -
Grille
For left air outlet
17 -
Left air outlet
Removing Fig. 6
Page
3
of
21
Heating and ventilation system
12/7/2004
http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.HA01.80.1
80-4
Repair Manual, Body
Exterior, Interior, Repair Group
70; Removing and installing
instrument panel
18 -
Rear duct
Replacing: Remove
console, instrument
panel bracket, pedal
cluster cover - 23 -,
footwell outlet - 7 -
19 -
Rear duct seal
Replacing: Remove
console, instrument
panel bracket, pedal
cluster cover - 23 -,
footwell outlet - 7 -
20 -
Instrument panel
Removing and
installing
21 -
Left air duct
22 -
Heating and ventilation
controls
Removing and
installing Fig. 3
Assembly Page 80-
21
Installing and adjusting
cables Page 80-15
Page
4
of
21
Heating and ventilation system
12/7/2004
http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.HA01.80.1
80-5
23 -
Pedal cluster cover
24 -
Heating and ventilation
cables
Replacing: First
remove pedal cluster
cover - 23 - and foot
well outlet - 7 -
Removing and
installing Page 80-
15
25 -
Intermediate duct
With gasket
Replacing - remove
instrument panel first
26 -
Heating and ventilation
unit
Contains:
Heater core
Temperature flap
Center flap
Footwell/defrost flap
Do not disassemble
further
Assembly Page 80-
12
Removing: Remove
instrument panel
&items -22- to 28-
Fig. 9
Page
5
of
21
Heating and ventilation system
12/7/2004
http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.HA01.80.1
80-6
27 -
Heater core
Replacing Page 80-
12
Always replace coolant
after
removal/replacement.
28 -
Airduct with main
shut-off flap
Replacing: Remove
instrument panel and
items -22- to 28-
Fig. 9
Installing: Page 80-
12
29 -
Hex nut M6
5 Nm (44 in lb)
Page
6
of
21
Heating and ventilation system
12/7/2004
http://ebahn.bentleypublishers.com/vw/servlet/Display?action=Goto&type=repair&id=VW.B4.HA01.80.1
