QUICKGUIDE
VOLVO S80
WELCOME TO YOUR NEW VOLVO!
Getting to know your new car is an exciting experience.
Please browse through this Quick Guide to enjoy your new Volvo
even more. For detailed information, please refer to your Owner´s
Manual.
Warning texts and other important information are only provided in
the regular Owner's Manual - not in this folder. The Owner's Manual
contains the most up-to-date information.
Optional features are marked with an asterisk (*).
Trip odometer. To measure distance the car
has two independent trip odometers T1 & T2
always running.
Press (A) for 2 seconds to reset displayed
odometer.
Quickly press (A) to toggle T1/T2.
1
123456
12.3
12:34
P_3 C
o
01
1000km
to empty tank
T2
3 A2 41 5
Push the control.
POWER PARKING BRAKE, PPB (V8, AWD & RHD)
TRIP ODOMETER AND TRIP COMPUTER
2
1
Light flashes until the brake is fully applied
and then glows continuously.
To release
Ignition mode 0 or higher.
Depress clutch or brake.
To apply
Pull the control.
Automatic release
Engage gear and drive away. (Automatic trans-
mission cars require seatbelt buckled).
With a gear selected and accelerator pedal de-
pressed the brake releases when you start driv-
ing.
Fuel gauge. Fuel filler lid location arrow.
2
Fuel warning symbol. Lights in display
when 8 litres fuel remain
(diesel models: 7 litres).
3
Driving range on current fuel reserve
Twist control (7) to display.
4
Driving range on current fuel reserve is not a
fuel gauge but an approximation of available
range based on driving conditions.
Clock.Turn control (A) clockwise or anti-
clockwise to adjust clock.
5
READ Push to access messages.
Push again to confirm message.
6
Trip computer control.
Twist control to display functions.
7
Reset current function
8
Multi control button.
Push to control trip odometer.
Turn L/R to adjust clock.
A
7 8
6
NOTE
POWER/VOLUME
Press ON/OFF.
Turn to adjust volume. Radio, TP, hands-
free* and RTI volume are stored individually
until next time they are used.
1
2
6
3
4
157
2
RADIO
Select a station by turning
3
Pull release handles separately to fold left
and/or right backrest.
Make sure rear head restraints are in upright po-
sition. Fold backrests.
AUDIO
FOLDING THE REAR SEAT BACKREST
1
Adjust sound
Adjust BASS, TREBLE, FADER, BALANCE,
Dolby Pro Logic II* and SUB-WOOFER* by
pressing button.
Set by turning button.
3
CD
Change CD track with left or right arrow.
Select CD* with up or down arrow.
4
Eject
Press to eject current CD.
Press and hold to eject all CDs in CD chang-
er*.
6
CD changer.* Select CD 1-6.
7
Search stations with left or right arrow.
Store up to 20 stations by press & hold 0-9 in
FM1 and 0-9 in FM2, confirmed in display.
4
Autostore the 10 strongest stations.
Press AUTO for 2 seconds. AUTOSTORE is
displayed during search.
Select 0-9 to play a radio station after
storing.
5
Select AM, FM1, FM2, CD or MODE. Use
MODE to activate AUX and adjust AUX
source volume.
2
1
3
STOP & REMOVE REMOTE
Depress clutch or brake.
Locks door/boot and activates alarm.
Unlocks doors/boot and deactivates alarm.
Unlocks the boot.
Lights up sideview mirrors/approach lights and interior,
foot, number plate, indicator and parking lights.
“Panic” button. Press for 3 seconds in an emergency
situation.
START
Place the remote in the ignition slot.
Park the car and push Start/Stop button to
stop the engine.
1
When cold starting, your engine will idle at a higher speed for a short time.
Gently push the remote. The remote ejects.
Automatic transmission must be in position P.
2
Simply press START/STOP button to start the
engine.
4
2
Gently push the remote. The remote is pulled
into position.
KEY & REMOTE
Automatic relock occurs if no door/boot is opened within 2 minutes after unlock.
KEYLESS DRIVE START
STOP
Enter the car with the PCC e.g. in your pocket.
Depress clutch or brake.
1
2
1
2
Monitor the car within range by pressing the but-
ton and wait for only 5 seconds. Press when out of
range, the PCC remembers if the car is locked or
unlocked.
Green light: The car is locked.
Yellow light: The car is unlocked.
Red light: The alarm has been triggered.
Flashing alternating red lights: Someone might
be in the car.
WARNING! Do not adjust steering wheel while
driving.
When cold starting, your engine will idle at a higher speed for a short time.
ADJUSTING THE STEERING WHEEL REFUELLING
Push to open fuel filler lid.
Park the car and push Start/Stop button to
stop the engine.
With keyless drive the PCC just needs to be
in the car. Keep the PCC e.g. in your pocket
all the time. The car unlocks automatically
when you open the door.
When you have parked the car just close the
door and press the outside door handle but-
ton to lock the car.
Simply press START/STOP button to start the
engine.
2
PERSONAL CAR COMMUNICATOR, PCC* WITH KEYLESS DRIVE
NOTE
AUTOMATIC CONTROL
AUTO mode maintains all controls and makes
driving easy with optimised air quality.
1
2
The power outlets in front/rear centre console
operate in ignition mode I. The power outlet on
the right-hand side in the boot* is always ac-
tive.
Use of the 12 V outlet in the boot with engine
off can drain the battery.
STORAGE COMPARTMENTS. 12 V POWER OUTLETS & AUX
ELECTRONIC CLIMATE CONTROL, ECC*
MANUAL CONTROL
Blower speed.
Air distribution.
Defroster to quickly remove mist on wind-
screen and side windows.
Air quality. OFF/AUT/Recirculation.
Air Conditioner ON/OFF.
Adjust the temperature by turning. The set
temperature is displayed.
1
Press AUTO for automatic temperature
control.
2
NOTE
2
1
2
2
1
2
+
-
3
2
1
5 4 4352
The controls for Road Traffic Information are
easy to reach behind the steering wheel while
driving. The RTI also comes with a remote.
Press ENTER to start the system.
REMOTE
Clutch or brake must not be depressed.
PCC & KEYLESS DRIVE
MODE I
0Instrument & clock light, steering wheel
unlocks.
I
Moon roof, power windows, fan, ECC,
wipers, power outlets and RTI.
MODE I MODE 0
TP 8373 (Swedish). AT 0605. Printed in Sweden, Elanders Infologistics Väst AB, Mölnlycke 2006. Copyright © Volvo Car Corporation.
ROAD TRAFFIC INFORMATION, RTI*
DRIVER DOOR PANEL
Lumbar support
Backrest tilt
Seat cushion Raise/Lower
Seat cushion front Raise/Lower
Forward/Rearward
1
2
3
4
5
IGNITION MODES ADJUSTING THE SEATS
Lock/unlock all doors.
Fold side mirrors* by pushing both
L&R.
Sideview mirror controls.
Manual window control.
Automatic window control.
Locks rear windows and doors*
(Child safe).
L R
2
Audio/interior lights operate without ignition
modes.
AB
C
0
D
E
F
G
Display & instrument panel
lighting
Front fog lamps
Rear fog lamp
Automatic headlamps. Flash
works but main beam does not
operate.
Parking lights
Headlamps
Headlamp height adjustment
The Active Bi-Xenon lights follow the steering
wheel movements.
Headlamp main beam flash.
Toggle between main/dipped beams.
RAIN SENSOR* AND WINDSCREEN WIPERS
RAIN SENSOR
Single wiper sweep
Intermittent wipers. Turn (B) to adjust in-
terval.
Normal speed
High speed
Windscreen and headlamp washer
#
$
%
F
G
Deactivate/Activate by pressing the button.
ACTIVE BI-XENON LIGHTS, ABL*
LIGHT CONTROLS
Press to activate rain sensor with wiper lever
in position 0.
A
Turn to adjust sensitivity.
B
Indicator rain sensor ON.
