QUICK GUIDE

WEB EDITION

WELCOME TO YOUR NEW VOLVO!

This folder contains a selection of the most common functions in your particular car. The owner's manual and

other manuals contain important information with all warnings and safety instructions.

The following symbols mean:

Different parts are pointed out in the overview images.

Instructions step-by-step.

It is particularly important to read the owner's manual.

Important information, warnings and safety instructions that must be read are listed on the last

page.

Options are marked with an asterisk *.

In addition, learn more about your particular car at www.volvocars.com.

Remote control key

Keyless key system*

Starting and switching off the engine

Parking brake

Wipers

Climate system controls

Headlamp control

Combined instrument panel

Infotainment system

Phone*

Internet*

External audio device

Buttons in the centre console

Settings in the menu system

02 Starting and driving

Adjusting the seat

Adjusting the steering wheel

Drive mode

Charging

Preconditioning

Mobile application

01 Your hybrid car 04 Your driving environment

Refuelling

Car care

Storage spaces

AUX/USB* and 12 V sockets

05 Functions in your car

06 Tips

BLIS* and CTA*

Pedestrian protection*

03 Driver support in your car

Which drive modes can I select?

The car is powered by two motors - an electric motor and

a diesel engine. Different drive modes can be selected. It

is not possible to select the "wrong" drive mode - the car

returns to the HYBRID mode if certain conditions are not

met. The lamp in the hybrid button will then illuminate.

HYBRID

This is the car's preset drive mode. Both the motor

and the engine are used - alone or in parallel, and

a computer determines what is most appropriate in

each case.

PURE

The car is powered by the electric motor. Air condi-

tioning is switched off in order to obtain the longest

possible driving distance. The diesel engine starts

automatically when the battery needs to be charged

or when the driver requests more power than the

electric motor can supply. The diesel engine is also

used to provide all-wheel drive if required, e.g. when

starting and on slippery surfaces.

POWER

Provides the best response and performance by

means of both the electric motor and the diesel

engine being activated the whole time. Driving in

a lower gear is prioritised for active driving, which

results in delayed upshifting.

AWD

All-wheel drive is activated. Primarily intended for low

speed in slippery driving conditions when better grip

and traction are required. The drive mode also has a

stabilising effect at higher speeds.

SAVE

Maintains current energy level in the battery for later

needs. In the event of low charge level the battery

will also be charged to a level equivalent to approx.

20 km electric operation. Select PURE when electric

operation is required.

How do I open and close the hatch for the

charging input socket?

The charging cable is located in the storage compartment

under the cargo area's floor hatch.

Press in the rear section of the hatch and release.

Fold out the flap.

Pull away the cover for the charging input socket and

secure it to the inside of the hatch.

Close the hatch for the charging input socket in reverse

order.

Where is the charging cable located?

Illuminated symbol: Shows selected charging current.

Lit symbol: Cable connected to 230 V.

Increases the charging current.

Decreases the charging current.

Lit symbol: Cable connected to the car.

How does the control unit for the charging

cable work*? 01

How do I stop charging?

Unlock the car with the remote control key.

Detach the charging cable from the car.

Detach the charging cable from the 230 V electrical

socket.

Refit the charging cable in the storage space under

the cargo area's floor hatch.

The charging cable locks automatically into the charg-

ing input socket a little while after unlocking if it was not

removed. Open the lock/latch by unlocking the car again

with the remote control key.

What do the lamps for the charging input

socket show? 01

White constant: Guide light

Yellow constant: Waiting mode

Green short flashes: Charging of low charge battery

Green long flashes: Charging of well-charged battery

Green constant or off: Charging complete

Blue: Timer switched on

Red: Error

How do I start charging?

Connect the charging cable to the 230 V electrical

socket.

Increase/decrease the charging current on the con-

trol unit*. Affects charging time and preconditioning.

Connect the charging cable to the car - the cable

locks automatically into the charging input socket.

Press the button for Approach lighting on the remote

control key - the combined instrument panel then shows

the remaining charging time. Charge status indicated via

the charging input socket's lamps and the Volvo On Call*

mobile app.

Approach lighting must be activated in MY CAR –

see the owner's manual.

What can I do with the Volvo On Call* app?

The Volvo On Call mobile application can be used anytime

and anywhere. With a single touch of a button on the

mobile phone the car can be located and locked remotely,

amongst other things, the combined instrument panel and

charge status can be checked, and preconditioning can

be set.

The mobile application is updated continuously. For more

information – see the Volvo On Call manual*.

How do I activate preconditoning?

Preconditioning is mainly used to optimise the car's elec-

tric drive system prior to a planned departure. The function

heats/cools the passenger compartment and is activated

via direct start in the combined instrument panel, the

remote control key* or Volvo On Call* mobile app.

Activate via the combined instrument panel:

Press OK on the left-hand stalk switch.

Turn the thumbwheel to Preconditioning and press

OK.

Select between Direct start, Timer, Outdoor

parking or Parking inside (can only be activated

if the car is being charged with the charging cable).

Confirm with OK.

Activating via the remote control key*:

–Press the button for approach lighting for approx. 2

seconds. The car's direction indicators emit 5 short

flashes, followed by a constant glow when precondi-

tioning has been activated.

Check status via remote control key*: (see illustra-

tion)

–Press the button for information for approx. 2 seconds.

The indicator lamp emits 5 short flashes, followed by a

constant glow when preconditioning is active.

For more information on activation via mobile phone

– see the Volvo On Call manual*.

How does the remote control key work?

What do the remote control key indicator

lamps* show?

Green constant light: The car is locked.

Yellow constant light: The car is unlocked.

Red constant light: The alarm has been triggered.

Red light flashing alternately in both indicator lamps:

The alarm was triggered less than 5 minutes ago.

Unlocks doors and tailgate and disarms the alarm*.

Can be set in MY CAR.

Locks doors and tailgate and arms the alarm.

Approach light duration.

Only unlocks the tailgate.

Information* about the car.

Panic function.

The remote control key can store settings including

door mirrors and power driver's seat* – see the

owner's manual.

How does the Keyless key system* work?

The key can remain in your pocket for example the whole

time.

Lock and arm the alarm

–Touch the rear section of one of the outer door handles

or press lightly on the smaller of the tailgate's two rub-

berised buttons.

Unlock and disarm the alarm

–Grip a door handle and open the door in the usual way

or press lightly on the larger of the tailgate's two rub-

berised buttons.

How do I use the parking brake? 02

To apply

Depress the foot brake pedal.

Press the control PUSH LOCK/PULL RELEASE

– the combined instrument panel's warning symbol

starts to flash. Once there is a constant glow the

parking brake is applied.

Release the foot brake pedal.

To disengage

Depress the foot brake pedal.

Pull the control PUSH LOCK/PULL RELEASE.

How do I switch off the engine? 02

Briefly press the START/STOP ENGINE-button -

the engine stops. The electric motor is switched off

when the digits in the speedometer or tachometer

and side gauge have extinguished.

Take the remote control key out from the ignition

switch.

How do I start the engine?

Ensure that the charging cable has been removed before

starting the car.

Press the remote control key into the ignition switch.

Fully depress the brake pedal.

Briefly press the START/STOP ENGINE button

and release. The electric motor is running when the

figures in the speedometer or tachometer and side

gauge are illuminated.

How do I start the windscreen wipers and rain

sensor*?

Move the lever downward to start the windscreen wipers

and upward for a single sweep.

Rain sensor On/Off.

Regulates the sensor sensitivity or the intermittent

delay.

Wiper, rear window - intermittent/normal.

It is important to understand this function thor-

oughly – see the owner's manual.

The car has Collision Warning with Auto Brake and Cyclist

and Pedestrian Detection, which can warn, brake and/or

stop for vehicles, cyclists and pedestrians.

The function is only an aid and does not work in all situ-

ations – for example, it does not see cyclists from the

side, pedestrians who are shorter than 80 cm or who are

partially obscured.

How does the pedestrian protection work*? 03

What is the function of BLIS* and CTA*? 03

Blind Spot Information System advises about vehicles

in the blind spot and rapidly approaching vehicles.

Cross Traffic Alert warns of crossing traffic during

reversing.

BLIS and CTA are activated when the engine is started.

BLIS On/Off. BLIS can be deactivated/activated in

the menu system MY CAR under Settings > Driver

support systems.

CTA On/Off - operated with the same button that is

used for the parking sensors*.

Parking sensors – see the owner's manual.

How do I adjust the steering wheel?

Release the catch.

Adjust the steering wheel forward/backward and up/

down.

Activate the catch.

How do I adjust the seat?

Raise/lower the front of the seat cushion.

Raise/lower seat.

Move the seat forward/backward.

Tilt the backrest.

Store settings for power seat*.

Memory buttons for power seat.

Store setting:

Hold the button depressed to store settings while de-

pressing one of the memory buttons.

Seat settings for a power seat can also be stored

in the remote control key* – see the owner's

manual.

Andere Handbücher für V60

Inhaltsverzeichnis

Andere Volvo Automobil Handbücher

Volvo

Volvo V40 Bedienungsanleitung

Volvo

Volvo V60 Twin Engine Bedienungsanleitung

Volvo

Volvo V90 - ACCESSORY PANEL Bedienungsanleitung

Volvo

Volvo 940 Bedienungsanleitung

Volvo

Volvo XC60 2019 Bedienungsanleitung

Volvo

Volvo 164 1972 Bedienungsanleitung

Volvo

Volvo XC90 TWIN ENGINE Bedienungsanleitung

Volvo

Volvo FMX 400 6x4 T RSS Prime Mover Installationsanleitung

Volvo

Volvo XC60 - ANNEXE 541 Bedienungsanleitung

Volvo

Volvo XC60 - ANNEXE 541 Bedienungsanleitung

Volvo

Volvo XC 70 Bedienungsanleitung

Volvo

Volvo S60 2021 Bedienungsanleitung

Volvo

Volvo S 80 Bedienungsanleitung

Volvo

Volvo C30 - ANNEXE 798 Bedienungsanleitung

Volvo

Volvo 2010 V50 Bedienungsanleitung

Volvo

Volvo XC 90 Bedienungsanleitung

Volvo

Volvo XC90 RECHARGE Bedienungsanleitung

Volvo

Volvo XC90 TWIN ENGINE Bedienungsanleitung

Volvo

Volvo S90 2020 Bedienungsanleitung

Volvo

Volvo V60 CROSS COUNTRY 2018 Bedienungsanleitung

Volvo

Volvo V50 Bedienungsanleitung

Volvo

Volvo S80 - Bedienungsanleitung

Volvo

Volvo S80 - Bedienungsanleitung

Volvo

Volvo S80 - Handbuch

Beliebte Automobil Handbücher anderer Marken

Toyota

Toyota 2000 Tundra Bedienungsanleitung

CITROËN

CITROËN DS4 DSign Bedienungsanleitung

Lexus

Lexus 2015 CT 200h Bedienungsanleitung

Cadillac

Cadillac CTS 2008 Bedienungsanleitung

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Bedienungsanleitung

Porsche

Porsche Boxster S Bedienungsanleitung

GMC

GMC 2010 Savana 1500 Cargo Bedienungsanleitung

KIAM

KIAM SPORTAGE 2014 Stücklistenhandbuch

GMC

GMC 2013 Terrain Montageanleitung

GMC

GMC T-Series 1999 Bedienungsanleitung

Mercury

Mercury 1998 Mystique Bedienungsanleitung

Mercury

Mercury 2007 Mariner Bedienungsanleitung

Mazda

Mazda 2007 Mazdaspeed 3 Leitfaden

Mazda

Mazda 2014 CX-5 Bedienungsanleitung

GMC

GMC Chevrolet Express 2022 Bedienungsanleitung

GMC

GMC 1997 Jimmy Bedienungsanleitung

Chevrolet

Chevrolet 2012 Malibu Bedienungsanleitung

Cadillac

Cadillac 2010 Escalade Bedienungsanleitung
