VXI BlueParrott B250-XT Bedienungsanleitung

Compatible with most Bluetooth phones & Bluetooth enabled computers (Windows®or Macintosh®)

USER GUIDE

TABLE OF CONTENTS

VXi BlueParrott®B250-XT+ User Guide

4Package Contents

5Safety Instructions/

Glossary

6Charging the Headset

7Battery Power Indicators

8Headset Controls

9On/Off/Standby

10 Pairing with a Phone

11 Pairing with a Computer

12 Multiple Device Pairing

13 Multipoint Mode

15 Proximity Pairing

16 Microphone Positioning

17 Making a Call

18 Answering a Call

19 Operation While Using the

Charger/Adapter

20 Additional Functions

Last Number Redial

Rejecting a Call

Voice Dial

Transfer Audio

Turn Indicator Lights

On/Off

Automatic Bluetooth

Connection

22 Reset Paired Devices List

23 Call Waiting/

Rejecting a Call

24 Specifications

25 Functions & Indicators

29 Warranty

30 FCC Notice to Users

31 IC Notice to

Canadian Users

VXi BlueParrott®B250-XT+ User Guide

PACKAGE CONTENTS

4 5

1. B250-XT+ Wireless Headset

with Leatherette Ear Cushion

2. Windscreen

3. Foam Ear Cushion

4. Auto (DC) Charger

5. AC Charger

6. User Guide (not shown)

VXi BlueParrott®B250-XT+ User Guide

SAFETY INSTRUCTIONS / GLOSSARY

SAFETY INSTRUCTIONS

• Avoidhearingdamage.Setvolumeatlowestcomfortablelevel.Ifyouexperienceringinginyourearsorvoices

sound muffled, stop using the headset. Avoid turning up volume to block noisy surroundings (it’s possible to

adapt to volume that is too high).

• Checkwithlocalandstatelawsregardingcellphone/headsetusagewhileoperatingamotorvehicle.

• Donotimmerseanypartofthisproductinwater.

• Plasticbagsandsmallpartsmaycausechokingifingested.Keepthemawayfromsmallchildrenandpets.

• Useonlythepowercordsincludedwiththisproduct.

• Avoidtemperaturesexceeding140°F(willcauseequipmentfailure).

GLOSSARY OF TERMS

On: Headset is on, but there is no connection to the phone (red light will flash).

MFB: Abbreviation for “Multifunction Button.”

Multipoint Mode: Multipoint Mode allows you to pair and switch between two Bluetooth devices.

Paired: Two Bluetooth devices agree to communicate with one another.

Standby Mode: Headset is on, Bluetooth link is active, and the user is not on a call (blue light will flash).

Talk Mode: Headset is in use with the cell phone while the cell phone is on an active call (blue light will flash).

VXi BlueParrott®B250-XT+ User Guide

CHARGING THE HEADSET

Connect charger cord into the headset’s

charging port. The MFB’s indicator light

may turn green for several seconds while

the headset determines the level of charge

the battery is holding. Do not remove the

headset from the charger. If the headset is

not fully charged, the indicator will turn RED

within a short period (less than 3 minutes).

When the indicator turns green—and stays

green—the unit is fully charged. A fully

discharged battery will need approximately

3.5 hours to achieve a complete charge.

AC Charger

Headset Charging Port

Auto (DC) Charger

BATTERY POWER INDICATORS

While charging, the MFB’s indicator light shows the

level of battery power on your B250-XT+ as follows:

Green light: Fully charged. Over 20 hours’ talk

time.

Red light: Less than a full charge.

For best performance, keep charging headset when

not in use.

VXi BlueParrott®B250-XT+ User Guide

Indicator Light

8VXi BlueParrott®B250-XT+ User Guide

HEADSET CONTROLS

Volume Increase: Quickly press and release

the Volume Up/Mute button. Repeat until

desired volume is attained.

Volume Decrease: Quickly press and release

the Volume Down button. Repeat until desired

volume is attained.

Microphone Mute/Un-Mute: While in

standby or on a call, hold down the Volume

Up/Mute button for 2 seconds until you hear a

beep. A mute reminder will be heard every 10

seconds. Repeat button press to un-mute.

Multifunction Button (MFB) &

Indicator Lights

Volume Up / Mute

Volume Down

ON / STANDBY / OFF

VXi BlueParrott®B250-XT+ User Guide

Turn Headset On: Hold down the MFB for approximately 2–3 seconds until you hear a voice

prompt, “Power on.” The red light will flash once every second.

Standby Mode: Once the headset is turned on (after the initial pairing), it will attempt to connect

to the last device that it was paired with, putting itself into standby mode. (The headset can also

beputintostandbymodewithaquickpressandreleaseoftheMFB).Thebluelightwillflashindi-

cating an active Bluetooth link. The headset will have a voice prompt, “Your headset is connected.”

Turn Headset Off (conserves battery power): Hold down the MFB for approximately 4–5 seconds

until you hear a voice prompt, “Power off.” A red light will flash 4 times and the headset will turn off.

VXi BlueParrott®B250-XT+ User Guide

PAIRING WITH A PHONE

Keepheadsetandphonenolessthan3inchesandnomorethan3feetapartwhilepairing.Keep

other Bluetooth devices at least 50 feet away, or turn them off. NOTE: The headset can be paired

with up to 8 different devices but can only be connected to one at a time. It can only switch back

and forth between 2 devices in Multipoint Mode.

1. Turn headset off (page 9).

2. Hold down the headset’s MFB until the lights alternate red and blue or you hear the audio

prompts “Power On” and then “Discovering.” IMPORTANT: Wait for both audio prompts or the

alternating blue and red lights. This may take up to 10 seconds. Then release the MFB.

3. Put your cellular phone into Bluetooth Search/Scan Mode per the manufacturer’s instructions.

4. Wait while the devices discover each other: This could take up to 2 minutes. Once the phone

discovers the headset, select “Pair” on the phone and enter a pass code of “0000” if in-

structed. Once pairing is complete the alternating lights will stop flashing and the phone may

prompt you to connect to the headset. Select “Yes” on the phone to connect to the headset.

When connected, you will hear the voice prompt, “Your headset is connected,” and the blue

light will flash indicating that the headset is in Standby Mode and is ready to make or receive

calls.
