WAC Lighting 6011 Bedienungsanleitung

WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. 1

waclighting.com

Phone (800) 526.2588

Fax (800) 526.2585

Headquarters/Eastern Distribution Center

44 Harbor Park Drive

Port Washington, NY 11050

Central Distribution Center

1600 Distribution Ct

Lithia Springs, GA 30122

Western Distribution Center

1750 Archibald Avenue

Ontario, CA 91760

INSTALLATION INSTRUCTION

PATH LIGHT

6011 / 6021 / 6031 / 6041 / 6051 / 6061 / 6071 / 6081 / 6091 / 6321 / 6311

SAFETY INSTRUCTION

IMPORTANT: NEVER attempt any work without shutting o the electricity.

• Read all instructions before installing.

• System is intended for installation by a qualied electrician in accordance with the National Electrical Code and local regulations.

• Place the wall switch in the“OFF”position.

• Go to the main fuse box, or circuit breaker. Unscrew the fuse(s) or switch ”OFF”the circuit breaker switch(es) that control the power to the

space that you are working on.

WARNING: Risk of electric shock. Install all luminaires 10 feet (3.05 m) or more from a pool, spa, or fountain.

CAUTION:

All parts must be used as indicated in these instructions. Do not substitute any parts, leave parts out, or use any parts that are worn out

or broken. Failure to follow this instruction could invalidate the ETL/cETL listing of this xture.

AVERTISSEMENT

IMPORTANT : COUPEZ L’ÉLECTRICITÉ AVANT TOUTE MANIPULATION.

• Lisez toutes les instructions avant d’installer.

• Système est destiné à être installé par un électricien qualié en conformité avec le code national de l’électricité et les règlements locaux.

• Placez l’interrupteur mural en position d’arrêt (« OFF »).

• Accédez au panneau central de disjoncteurs ou de fusibles de votre demeure et placez l’interrupteur principal en position d’arrêt (« OFF »).

MISE EN GARDE

Toutes les pièces doivent être utilisées tel qu’il est indiqué dans ces instructions. Ne remplacez pas les pièces, n’en laissez pas de côté et ne les

utilisez pas si elles sont usées ou brisées. Le non-respect de ces instructions peut annuler l’homologation ETL/cETL du luminaire.

THIS INSTRUCTIONS APPLY TO THE MODELS BELOW:

6031

Mounting Accessories (included in box)

6021

Mounting Stake

Qty: 1pc

7TVD207001BW

Outdoor Rated Wire Nut

Qty: 2pcs

7EAC352401

Guardian Mount 9000-SP9-BZ

Qty: 1pcs

(Included in 6031-BBR nish only)

6011 6041 6051 6061

6071 6081 6091 6321 6311

*Note: Transformer is required to power the xture. (sold separately)

WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. 2

waclighting.com

Phone (800) 526.2588

Fax (800) 526.2585

Headquarters/Eastern Distribution Center

44 Harbor Park Drive

Port Washington, NY 11050

Central Distribution Center

1600 Distribution Ct

Lithia Springs, GA 30122

Western Distribution Center

1750 Archibald Avenue

Ontario, CA 91760

INSTALLATION

STEP 1:

1. Make sure your main power is o.

2. At the point of installation, mount the stake by placing

a piece of wood on the stake and hammering the wood.

Hammer till the bottom of the ring is ush with the ground.

3. In the case of hard soil, dig a hole and place the stake in

so that the bottom of the ring is ush with the ground.

Fill the rest of the hole with the removed soil and pack it

tight to secure the stake.

4. Screw the xture onto the stake provided, leading the wire

from the xture through the wire slot in the stake.

STEP 2:

5. Cut the power supply wire from the transformer at the

location of the xture.

6. Separate the power supply wire into two individual wires

by lightly pulling on each side so that a couple inches is

separated.

7. Strip o ½ inch of the insulating material from each wire and

connect one to each of the wires from the xture using the

outdoor rated direct burial wire nuts provided.

STEP 3:

8. Screw the xture onto the stake provided, leading the wire

from the xture through the wire slot in the stake.

9. If desired, bury your wire by digging a small trench. Close the

trench by applying an inward force to both sides of the trench.

10. Repeat steps for other xtures in the same electrical circuit.

11. Turn the main power supply back on and make sure the

xtures light up.

Hammer

Wood

Mounting Stake

Soil

Transformer

To Next Fixture

Mounting Stake

Fixture Wires

Supply Wire between Fixtures

Wire Slot

Path Lighting

Fixture

Path LightingFixture

Note: To install multiple xtures, also connect the power supply wire of each

additional xture to the connection described in 7 of the previous xture.

INSTALLATION INSTRUCTION

PATH LIGHT

6011 / 6021 / 6031 / 6041 / 6051 / 6061 / 6071 / 6081 / 6091 / 6321 / 6311

WAC Lighting retains the right to modify the design of our products at any time as part of the company's continuous improvement program. 3

waclighting.com

Phone (800) 526.2588

Fax (800) 526.2585

Headquarters/Eastern Distribution Center

44 Harbor Park Drive

Port Washington, NY 11050

Central Distribution Center

1600 Distribution Ct

Lithia Springs, GA 30122

Western Distribution Center

1750 Archibald Avenue

Ontario, CA 91760

INSTALLING THE SURFACE MOUNT ACCESSORY

Softscape Installation:

1. Attach the three removable spikes to the surface mount

accessory by screwing them in.

2. Using a piece of wood to buer the impact, hammer the

assembled mount into the soil till the bottom of the surface

mount accessory is ush with the ground.

3. Lead your wire through the wire slot and screw in your xture.

4. Connect xture wires to power supply wires as normal using

the outdoor rated direct burial wire nuts provided.

Hardscape Installation:

1. Mount the accessory to the surface using No. 10 Philips head

screws that are at least half an inch long.

2. If mounting on concrete or something similar, rst use

plastic anchors sized for No. 10 screws.

3. Create a route underneath the accessory for your wire to

travel through.

4. Lead your wire through the created route and screw your

xture onto the surface mount accessory.

Installing Fixture Caps:

Thread the xture cap into the stem body by rotating it clockwise.

Fixture

Surface Mount

Accessory

Wire Slot

Removable Spike

No.10 Mounting Screw

Surface Mount

6011

Threaded Stem Cap Threaded Stud Cap

6041

Threaded Stud Cap

6051

INSTALLATION INSTRUCTION

PATH LIGHT

6011 / 6021 / 6031 / 6041 / 6051 / 6061 / 6071 / 6081 / 6091 / 6321 / 6311
