Waeco CoolFun CK40D Hybrid Bedienungsanleitung

CoolFun CK-40D

D 4 Kompressor-Kühlbox

Bedienungsanleitung

GB 12 Compressor Cooler

Instruction Manual

F 20 Glacière à compression

Notice d’emploi

E28Neveraporcompresor

Instrucciones de uso

I 36 Frigorifero a compressore

Istruzioni per l’uso

NL 44 Compressorkoelbox

Gebruiksaanwijzingen

DK 52 Kompressor-køleboks

Betjeningsanvisning

S 60 Kylbox med kompressor

Bruksanvisning

N 67 Kjøleboks med kompressor

Bruksanvisning

FIN 75 Kompressori-kylmälaatikko

Käyttöohjeet

CK-40D.book Seite 1 Dienstag, 25. Juli 2006 2:53 14

Fordern Sie weitere Informationen zur umfangreichen Produktpalette aus dem Hause

WAECO an. Bestellen Sie einfach unsere Kataloge kostenlos und unverbindlich unter

der Internetadresse: www.waeco.de

We will be happy to provide you with further information about WAECO products.

Please order our free catalogue with no obligation to buy on our homepage:

www.waeco.com

Demandez d’autres informations relatives à la large gamme de produits de la maison

WAECO. Commandez tout simplement notre catalogue gratuitement et sans

engagement à l’adresse internet suivante : www.waeco.com

Solicite más información sobre la amplia gama de productos de la empresa WAECO.

Solicite simplemente nuestros catálogos de forma gratuita y sin compromiso en la

dirección de Internet: www.waeco.com

Per ottenere maggiori informazioni sull’ampia gamma di prodotti WAECO è possibile

ordinare una copia gratuita e non vincolante del nostro Catalogo all’indirizzo Internet:

www.waeco.com

Maak kennis met het omvangrijke productscala van de firma WAECO. Bestel onze

catalogus gratis en vrijblijvend onder het internetadres: www.waeco.com

Bestil yderligere information om det omfattende produktudvalg fra WAECO.

Bestil vores katalog gratis og uforpligtende på internetadressen: www.waeco.com

Inhämta mer information om den omfattande produktpaletten från WAECO:

Beställ våra kataloger gratis och utan förpliktelser under vår Internetadress:

www.waeco.com

Be om mer informasjon om det rikholdige produktutvalget fra WAECO. Bestill vår

katalog gratis uforbindtlig på Internettadressen: www.waeco.com

FIN

Pyytäkää lisää tietoja WAECOn kattavista tuotevalikoimista. Tilatkaa tuotekuvastomme

maksutta ja sitoumuksetta internet-osoitteesta: www.waeco.com

CK-40D.book Seite 2 Dienstag, 25. Juli 2006 2:53 14

CK-40D

ON/OFF

TEMP TEMP

°C

2 3 4

CK-40D.book Seite 3 Dienstag, 25. Juli 2006 2:53 14

Notes on using the instruction manual CK-40D

Please read this manual carefully before starting the machine. Keep it

in a safe place for future reference. If the device is resold, this instruc-

tion manual must be handed over to the purchaser along with the de-

vice.

Contents

1 Notes on using the instruction manual. . . . . . . . . . . . . . . . . . . . . . . 12

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

4 Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

7 Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

8 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

9 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

11 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

1 Notes on using the instruction manual

The following symbols are used in this instruction manual:

Caution!

Safety instruction: failure to observe this instruction can cause

injury or damage the device.

Caution!

Safety instruction relating to a danger from electrical current or

voltage. Failure to observe this instruction can damage the device

and impair its function and cause injury.

Note

Supplementary information for operating the device.

CK-40D.book Seite 12 Dienstag, 25. Juli 2006 2:53 14

CK-40D Safety instructions

➤Action: this symbol indicates that you need to do something.

The required action is described step-by-step.

✓This symbol indicates the result of an action.

1 5, page 3: This refers to an element in an illustration. In this case, item 5

in figure 1 on page 3.

Please observe the following safety instructions.

2 Safety instructions

2.1 General safety

zUse only the connection cable to connect the device to the AC mains.

zNever pull the plug out of the socket by the cable.

zIf the cable is damaged, it must be replaced to prevent possible electrical

hazards.

zDo not operate the device if it is visibly damaged.

zThis device may only be repaired by specialist personnel. Inadequate re-

pairs can lead to considerable hazards.

Should your device need to be repaired, please contact WAECO custo-

mer services.

zPull out the plug:

– Before cleaning and care

– After use

zEnsure that the ventilation slots are not covered.

zCheck that the voltage specification on the type plate corresponds to that

of the energy supply.

zThe cooling device is not suitable for transporting caustic materials or ma-

terials containing solvents.

zElectronic devices are not toys!

Do not let children play with this appliance. Children and infirmed persons

should be supervised when using the appliance.

CK-40D.book Seite 13 Dienstag, 25. Juli 2006 2:53 14

Scope of delivery CK-40D

2.2 Operating the device safely

zBefore starting the device ensure that the power supply line and the plug

are dry.

zDo not place the device near flames or other heat sources (heaters, direct

sunlight, gas ovens etc.).

zDo not fill the inner container with ice or fluid.

zDo not immerse the device in water.

zNever expose the device to rain or moisture.

zProtect the device and the cable against heat and moisture.

zDo not touch exposed cables with your bare hands. This especially ap-

plies to when operating the device with the AC mains: mortal danger!

zWAECO cannot be held liable for damage resulting from improper usage

or incorrect operation.

3 Scope of delivery

4 Proper use

The coolbox is suitable for cooling and freezing foodstuffs. The device is also

suitable for camping.

If you wish to cool medicines, please check if the cooling capacity of the de-

vice is suitable for the medicine in question.

Quantity Description

1Coolbox

1 Instruction manual

CK-40D.book Seite 14 Dienstag, 25. Juli 2006 2:53 14

CK-40D Technical description

5 Technical description

The coolbox is suitable for use when camping, on a terrace, in the backyard,

or anywhere where a 220-240 V power connection is available. The device

can cool goods down and keep them cool or freeze them.

A maintenance-free, CFC-free refrigerant circuit with compressor provides

the cooling. The extra strong CFC-free insulation and powerful compressor

ensure especially fast cooling.

You can use the digital display to set the temperature you require.

The lid is sealed all round and has a magnetic lock.

The cooler has the following control elements:

6 Operation

Before starting your new coolbox for the first time, you should

clean it inside and outside with a damp cloth for hygienic reasons

(please also refer to the Kapitel „Cleaning and care“ auf Seite 17).

6.1 Energy saving tips

zChoose a well ventilated installation location which is protected against di-

rect sunlight.

zAllow food to cool down first before placing it in the device.

zDo not open the coolbox more often than necessary.

zDo not leave the lid open for longer than necessary.

No. in 2,

Seite 3 Description Explanation

1 Display Shows the current or required temperature.

2ON/OFF Switches the cooler on or off.

3 TEMP – Decreases the desired cooling temperature

by 1 °C.

4TEMP + Increases the desired cooling temperature by

1 °C.

CK-40D.book Seite 15 Dienstag, 25. Juli 2006 2:53 14

Operation CK-40D

6.2 Using the cooler

Food may only be stored in its original packaging or in suitable

containers.

➤Place the cooler on a firm foundation.

➤Use the cable to connect the cooler to a

220-240 V AC socket.

➤Switch the cooler on by pressing the “ON/OFF” button (22, Seite 3).

✓

The display switches on and shows the current cooling temperature in °C.

✓The cooler starts cooling the interior.

➤To switch the cooler off, press the “ON/OFF” button (22, Seite 3).

➤The display switches off.

Ensure that the objects placed in the cooler are suitable for cool-

ing to the selected temperature.

Ensure that food or liquids in glass containers are not excessively

refrigerated. Liquids expand when they freeze and can thus

destroy the glass containers.

Setting the temperature

The cooling capacity can be influenced by:

– The ambient temperature

– The quantity of goods to be cooled

– The frequency with which the door is opened.

➤Press the “TEMP –” (23, Seite 3) button to decrease the desired cool-

ing temperature by 1 °C, or press the “TEMP +” (24, Seite 3) button to

increase the desired cooling temperature by 1 °C.

✓The cooling temperature set in °C then appears in the display for a few

seconds.

✓The display flashes to confirm that the selected temperature has been set.

CK-40D.book Seite 16 Dienstag, 25. Juli 2006 2:53 14

CK-40D Cleaning and care

6.3 Defrosting the cooler

Humidity can form frost in the interior of the cooling device or on the vaporis-

er. This reduces the cooling capacity. Defrost the device in good time to avoid

this.

Caution - Danger of damaging the device!

Never use hard or pointed tools to remove ice or to loosen objects

which have frozen in place.

To defrost the cooler, proceed as follows:

➤Take out the contents of the cooling device.

➤If necessary, place them in another cooling device to keep them cool.

➤Switch off the device.

➤Leave the cover open.

➤Wipe off the defrosted water.

7 Cleaning and care

Caution!

Before cleaning the coolbox, pull the cable out of the socket.

Caution!

Do not clean the coolbox under flowing water or in dish water.

Caution!

Do not use abrasive cleaning agents or hard objects during clea-

ning as these can damage the coolbox.

➤Clean the interior of the coolbox with a damp cloth from time to time.

➤Clean the exterior of the device with a damp cloth.

CK-40D.book Seite 17 Dienstag, 25. Juli 2006 2:53 14

Guarantee CK-40D

8 Guarantee

Our general guarantee conditions apply. If the product is defective, please re-

turn it to the WAECO distributor in your county (addresses on the back on the

instruction manual). The following documents must be included with the de-

vice when it it sent in for repair:

zCopy of the receipt with purchase date

zA reason for the guarantee claim or description of the fault

9 Disposal

➤Place the packaging material in the appropriate recycling waste bins

wherever possible.

If you wish to finally dispose of the device, ask your local

recycling centre or specialist dealer for details about how to

do this in accordance with the applicable disposal regulations.

10 Troubleshooting

Fault Possible cause Suggested remedy

The coolbox does not

work.

The coolbox is not

properly connected.

Check whether the connection cable and

any extension cables are correctly

plugged in.

If you are using an extension cable,

check it and replace if defective.

The refrigerant cir-

cuit is defective.

This can only be repaired by an authori-

sed customer services unit.

CK-40D.book Seite 18 Dienstag, 25. Juli 2006 2:53 14

Andere Handbücher für CoolFun CK40D Hybrid

Inhaltsverzeichnis

Andere Waeco Gefrierschrank Handbücher

Waeco

Waeco TC-21FL-ISO Bedienungsanleitung

Waeco

Waeco CoolMatic CB-36 Bedienungsanleitung

Waeco

Waeco CA-45 Bedienungsanleitung

Waeco

Waeco TropiCool TC-14FL-AC Bedienungsanleitung

Waeco

Waeco TropiCool TC07DC Bedienungsanleitung

Waeco

Waeco CoolFun CK40D Hybrid Bedienungsanleitung

Waeco

Waeco COOLFUN CD 28 Bedienungsanleitung

Waeco

Waeco CF-32UP Bedienungsanleitung

Waeco

Waeco CoolAir SP950T Bedienungsanleitung

Waeco

Waeco BordBar TF08 Bedienungsanleitung

Waeco

Waeco CoolFun CD-22-AC Bedienungsanleitung

Waeco

Waeco COOLFREEZE CDF 11 Bedienungsanleitung

Waeco

Waeco BordBar AS25 Bedienungsanleitung

Waeco

Waeco TropiCool TC-14FL-AC Bedienungsanleitung

Waeco

Waeco CoolPro TC-14FL-AC Bedienungsanleitung

Waeco

Waeco CoolMatic CRF-50 Bedienungsanleitung

Waeco

Waeco CoolFreeze CDF-18 Bedienungsanleitung

Waeco

Waeco CoolFreeze CFX95DZ2 Bedienungsanleitung

Waeco

Waeco CoolFun CK40D Hybrid Bedienungsanleitung

Waeco

Waeco BordBar TB-08 Bedienungsanleitung

Waeco

Waeco CoolFreeze CF11 Bedienungsanleitung

Waeco

Waeco BordBar AS25 Bedienungsanleitung

Waeco

Waeco Coolfreeze CF-35 Bedienungsanleitung

Waeco

Waeco CF-80 Bedienungsanleitung

Beliebte Gefrierschrank Handbücher anderer Marken

Siemens

Siemens GU..D SERIES Bedienungsanleitung

Omcan

Omcan FR-CN-0155 Bedienungsanleitung

Beko

Beko FNE290E24W Bedienungsanleitung

Electrolux

Electrolux ARCTIS G 8 60 50-6I Bedienungsanleitung

Electrolux

Electrolux EUF2042AOX Bedienungsanleitung

Dometic

Dometic CoolFreeze CFX95DZ Bedienungsanleitung

Electrolux

Electrolux EUF7000W1 Bedienungsanleitung

Polar Electro

Polar Electro CT330 Bedienungsanleitung

MPM

MPM MPM-145-SK Series Bedienungsanleitung

SAF

SAF PRESTOTIG 200AC/DC Kurzanleitung

Zanussi

Zanussi ZFT11407WA Bedienungsanleitung

AEG

AEG A63190GT Bedienungsanleitung

AEG

AEG A81000TNW0 Bedienungsanleitung

Matsui

Matsui MUC50S15E Bedienungsanleitung

NEFF

NEFF G4344X8 Bedienungsanleitung

Frigidaire

Frigidaire FV 1246 H Bedienungsanleitung

Frigidaire

Frigidaire FFC13K1AW Bedienungsanleitung

Electrolux

Electrolux EU 2400C Bedienungsanleitung
