Notes on using the operating manual COOLMATIC MDC Series

Please read this operating manual carefully before starting the device.

Keep it in a safe place for future reference. If the device is resold, this

operating manual must be handed over to the purchaser along with it.

Contents

1 Notes on using the operating manual . . . . . . . . . . . . . . . . . . . . . . 22

2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

3 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

5 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

6 Setting up and connecting the cooling device . . . . . . . . . . . . . . . . 26

7 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

8 Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

9 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

10 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

12 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

1 Notes on using the operating manual

The following symbols are used in this operating manual:

Caution!

Safety instruction: failure to observe this instruction can cause

injury or damage the device.

Caution!

Safety instruction relating to a danger from an electrical current

or voltage. Failure to observe this instruction can damage the

device and impair its function and cause injury.

Note

Supplementary information for operating the device.

➤Action: this symbol indicates that action is required on your part.

The required action is described step-by-step.

✓This symbol indicates the result of an action.

MDC.book Seite 22 Montag, 27. September 2010 4:01 16

COOLMATIC MDC Series Safety instructions

fig. 21, page 3: this refers to an element in an illustration. In this case,

item 1 in figure 2on page 3.

Please observe the following safety instructions.

2 Safety instructions

Caution!

WAECO International will not be held liable for claims for damage

resulting from the following:

zDamage to the device resulting from mechanical influences and

overvoltage

zAlterations to the device made without the explicit permission of

WAECO International

zUse for purposes other than those described in the operating

manual

2.1 General safety

zHave a trained technician make installations in wet rooms.

zThis device may only be repaired by qualified personnel.

Inadequate repairs can lead to considerable hazards.

Should your device need to be repaired, please contact

WAECO customer services.

zDo not open the refrigerant circuit under any circumstances.

zSet up the device in a dry location where it is protected against

splashing water.

zDo not place the device near naked flames or other heat

sources (heaters, direct sunlight, gas ovens etc.)

zIf you connect your refrigerator to a battery, please remember

that the battery contains acid.

zEnsure that the ventilation slots are not covered.

zThe cooling device is not suitable for transporting caustic

materials or materials containing solvents.

zElectronic devices are not toys!

Always keep and use the device out of the reach of children.

zFood may only be stored in its original packaging or in suitable

containers.

MDC.book Seite 23 Montag, 27. September 2010 4:01 16

Intended use COOLMATIC MDC Series

zBefore starting up the device for the first time, check whether

the operating voltage and the battery voltage correspond

(see type plate).

zDanger of fatal injuries!

When using the device on boats: if the device is powered

by the mains, ensure that the power supply has a ground fault

interrupter circuit.

zIf the connection cable is damaged, it must be replaced to

prevent possible electrical hazards. Only replace a damaged

connection cable with a connection cable of the same type

and specifications.

2.2 Operating the device safely

zDo not place any electrical devices inside the refrigerator.

zDefrost the device in good time to save energy.

zIf you connect the device to a battery, make sure that food does

not come into contact with the battery acid.

zProtect the device against rain and moisture.

zDisconnect the cooling device and other power consuming

devices from the battery before connecting the battery to a quick

charging device.

Overvoltage can damage the electronics of the device.

zNote:

Disconnect the device if you are not going to use it for a long

time.

zDanger of fatal injuries!

Do not touch exposed cables with your bare hands. This especially

applies when operating the device with an AC mains power supply.

3 Intended use

The refrigerator is suitable for cooling and freezing foodstuffs.

The device is also suitable for use on boats.

If you wish to cool medicines, please check if the cooling capacity

of the device is suitable for the medicine in question.

MDC.book Seite 24 Montag, 27. September 2010 4:01 16

COOLMATIC MDC Series Scope of delivery

4 Scope of delivery

4.1 Accessory

If you wish to operate the cooling device with a 230 V AC mains supply,

please use one of the following rectifiers:

5 Technical description

COOLMATIC MDC series refrigerators are suitable for use with a 12 V or

24 V DC voltage and can therefore also be used for camping or on boats.

You can also use the MOBITRONIC EPS-100W and MPS-35 rectifiers to

connect them to a 230 V mains supply.

The refrigerator can chill products and keep them cool. Products can be

deep-frozen in the freezer compartment.

You can use the continuously variable thermostat to set the desired

temperature.

All materials used in the refrigerator are compatible for use with foodstuffs.

The refrigerant circuit is maintenance-free.

When used on boats the refrigerator can be subjected to a constant

inclination of 30°.

Quantity Description

1Refrigerator

1 Assembly kit for changing the door hinge

1 Operating manual

Description Item number

MOBITRONIC rectifier EPS-100W

MOBITRONIC rectifier MPS-35

MDC.book Seite 25 Montag, 27. September 2010 4:01 16

Setting up and connecting the cooling device COOLMATIC MDC Series

5.1 Operating and display elements

Error codes in the error code LED, see chapter “Troubleshooting” on

page 34.

On the MDC-90 and MDC-110 models the temperature control

and the error code LED are on the device operating panel. On the

MDC-50 and MDC-65 models, the temperature control and the

LED are integrated in the device.

6 Setting up and connecting the cooling

device

6.1 Setting up the cooling device

The device is designed for ambient temperatures between +16 °C and

+32 °C. In continuous operation, the air humidity may not exceed 90 %.

Set up the cooling device in a dry, sheltered place. Avoid placing it near heat

sources such as radiators, gas ovens or hot water pipes. Do not let it stand

in the direct, strong sunlight.

The cooling device must be positioned so that heated air can dissipate easily.

Therefore make sure there is adequate ventilation (fig. 2, page 4).

No. in

fig. 1,

page 3

Explanation

1 Temperature controller

2Error code LED

3 Operating panel with ventilation slots (only MDC-90 and

MDC-110)

No. in

fig. 2,

page 4

Explanation

1 Hot waste air

2Cold intake air

3 Condenser

4With cover panel 50 mm above

MDC.book Seite 26 Montag, 27. September 2010 4:01 16

Andere Handbücher für MDC-50

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Waeco Kühlschrank Handbücher

Waeco

Waeco Bordbar CDF-11 Bedienungsanleitung

Waeco

Waeco CR-110 Bedienungsanleitung

Waeco

Waeco MyFridge MF-6W Bedienungsanleitung

Waeco

Waeco MDC-50 Bedienungsanleitung

Waeco

Waeco CoolMatic HDC-150 Bedienungsanleitung

Waeco

Waeco CoolMatic CRP-40 Bedienungsanleitung

Waeco

Waeco CoolMatic HDC-150 Bedienungsanleitung

Waeco

Waeco MyFridge MF-6W Bedienungsanleitung

Waeco

Waeco CR SERIES Verdrahtungsschema

Waeco

Waeco CoolMatic CRX50 Bedienungsanleitung

Waeco

Waeco CR-65 Bedienungsanleitung

Waeco

Waeco CoolMatic HDC195 Bedienungsanleitung

Waeco

Waeco Adler/Barbour Bedienungsanleitung

Waeco

Waeco RPD190 Bedienungsanleitung

Waeco

Waeco MyFridge MF-05 Bedienungsanleitung

Waeco

Waeco CoolFreeze Series Bedienungsanleitung

Waeco

Waeco MyFridge MF-05 Bedienungsanleitung

Waeco

Waeco CoolMatic CD50 Bedienungsanleitung

Waeco

Waeco CoolMatic CD30 Bedienungsanleitung

Waeco

Waeco CoolMatic CRX50 Bedienungsanleitung

Waeco

Waeco COOL MATIC RPD/RPA Bedienungsanleitung

Waeco

Waeco CoolMatic CRP-40 Bedienungsanleitung

Waeco

Waeco MyFridge MF-05 Bedienungsanleitung

Waeco

Waeco MyFridge MF-5M Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
