Mounting instructionsPlease read the Operation Manual completely and retain for future reference AUTOMATIC SLATTED POOL COVERS MANUFACTURERSafety cover compliant with standard NFP 90-308 to be installed and used according this mounting user manual

ABOVE GROUND REEL SYSTEM

JUNIOR SILVERCompliant with standard NFP 90-308

SpecificationsPlease follow the instructions :- The owner or end user is responsible for the use and the security of his pool- The owner or end user must be cautious and aware of the risks- Never leave a child without supervision- Please follow the instructions of this operation manual- Please make sure that the cover is closed and locked after each use.- The pool should never have a lateral deviation higher than 70 mm- Please make sure that the quick fastening system on the width sides of the cover is properly fastened (in oder toprevent kids from slipping underneath)- Please make sure that the cover fits the standard NFP 90-308- Please maintain the key while opening and closing the cover, and more Importantly, remove this key after the coveris closed.2

The box must contain :Anodised aluminium axle + integrated motorShaft + rings, opposite to the motor - BElectrical box + drilling template - CQuick fastening system (qty depending on the width of the pool) - DPair of stands - ERolling straps to be fixed on the axle (qty depending of the width of the pool) - F50 cm slat strips (6 slats/strip) (qty depending of the length of the pool) - GKit of screws1 mounting intructions manualUpon receipt of the slatted automatic cover: WALTER Piscine can not be held responsible for losses or damages caused during the transport. It is clearly stated that the goods travel at recipient's risk.In case of missing or defective parts, it is essential to: - Record any reservations on the delivery note.- Address a registered letter with acknowledgement receipt to the transport manager within 2 days after the delivery and please noteprecisely the problems identified.- Send a copy of this letter to WALTER Piscine, for informationThe quality control of the original parcel must be done in presence of the delivery manThe containt of the box should be checked upon delivery. CHECK-LIST

The box must contain:

A - Anodised aluminium axle + integrated motor

B - Shaft + rings, opposite to the motor

C - Electrical box + drilling template

D - Quick fastening system (qty depending on the width of the pool)

E - Pair of stands

F - Rolling straps to be fixed on the axle (qty depending of the width of the pool)

G - 50 cm slat strips (6 slats/strip) (qty depending of the length of the pool)

Kit of screws

1 mounting intructions manual

Note: Pictures are not contractual. For information

Assembled cover

Strip of 6 slats

Junior Silver mechanism

Electrical box

Box content4

Distance electrical box against the pool.

Please follow standard NF C15-100

section 702

Cable section R02V recommended (from motor to

electrical box). Semi rigid copper FR-N05VV-R

2 x 10 mm²

15m<L<30m

2 x 6 mm²

0m<L<15m

Motor cable section

Distance electral box - motor

Electrical box 220V 24V

Differential

30mA

220V

24V ongoing

To cover motor

Common bridge

Commun (Noir)

Opening (blue)

Closing (white)

Motor cable

Black

Red

Push button

switch to adjust

the stroke end

Phase

(brown)

Neutral

(blue)

Terre

(Vert)

Stroke end

(brown)

Push button

switch (brown)

Push button

(black)

Commun (Noir)

Wago

165

74,50

Preparation of coping stones in order to place the cover :

1) Position the stands assembled with the axle on the coping stones axis

according the below indications:

A) Respect the parallelism between the axle of unrolling slats and one of

the pool's length, as well as the axle leveling.

B) Please center the the cover on the pool's width, with stands close to the

aluminium profile. (otherwise, please plan to tighten the ring to prevent any

lateral play)

C) Axle at the base:

- of the coping stone if straight angled pool and coping

- of the en of the radius if rounded pool and coping

)

Fix the brackets with M10 knock-in studs through the coping

stones.

)

Cutting of the coping stones in line with the axis over a length Dm

according to the table opposite:

)

After mounting the cover, make sure that there is no friction when

opening and closing it (rear curbstone, side curbstone, skimmer, etc.).

Option: Surface a flat surface for the supports. Minimum dimension:

235 x 155 mm

390mm

499mm

If coping stone right angled

If rounded coping stone

Width/2 Width/2

0° 0°

Pool lefthand side

Plan middle of pool cover

Pool righthand side

Width X

Width X = pool width + 440 mm

Axle: about 5 cm longer than the pool width

Coping stones

Pool length

6 m

260 mm

8 m

290 mm

10 m

320 mm

12 m

340 mm

Installation of the power reel system6

Motor shaft pin

Stands

Power cable and

stroke end

Alumimium axle + bearing

Bearing shaft pin

Aluminium axle with tubular motor

support hood

Assembly of the axle with the stands7

Key switch

(O) : Opening (blue)(F) : Closing (white)(C) : Common (black)Differential )

30mA

(not enclosed

SIREM COVEO motor above ground

Electrical box for above ground motor

220V

24V Continu

Wiring electrical box with above ground motor for Junior Silver

Push button (stroke end setting)

Push button (brown)

Push button (black)

Stroke end (brown)

Wago

Cable 2x6²

Reel wiring8

Electrical supply unitTechnical features:Power 230 VAC - 50/60 HzElectrical box 24VOn/Off buttonPresence of voltage output by LEDOvercharge fuse protectionFunction temperatureStorage temperatureRelative air humidity until 95%9

- Power supply- Dry contact for electrolizercontrol- Overcharge protectionHull:IP55Shock resistance IK06Easy connectionMounting brackets includedCompliant with electrical normsElectrical security EN60335Compliant with CEM norms:- Immunity according CN55014,EN61000-4-6, EN61000-4-2,EN61000- 4-8, EN61000-4-11, tightenedthresholds for EN61000-4-4 and4-5 to 4kV-Emissions according EN 55014-1and EN 61000-6-3PLUGS CONFIGURATION

Electronic card detailsOvervoltage protection will only be fully efficient if the grounding connection has a resistance <20ohm. If the grounding from the main building is far from the installation site, this can not be the case. It is then essential to install a proper differential to the pool which is compliant with Standard NF C15-100.The electro box must be installed by a qualified technician.The electro box must also be connected to switch differential 30mA compliant with NF EN/IEC 60947-3.Above ground electrical box10 Primary fuseCartridge 230VSecondary fuse type ATO 10ALed presence output voltageDry contact to drive the electrolyser. represented contact state is "set" state.The state is stored when the electrical box is not connected.These contacts should not directly drive a pump. switching off capacityPower supplyAbove ground motorisationAbove ground motorisation control-0 Vdc or+ 24 VdvRemote control interface box0 Vdc for COVEO and MH2+ 24 Vdc for C80230 vac 10% - 50/60 Hz
