Watchguard ALM-D1-RC Bedienungsanleitung
V1.1.2
Wireless Keyfob
User’s Manual
Foreword
General
This manual introduces the installation, functions and operations of the wireless keyfob (hereinafter
referred to as the "keyfob"). Read carefully before using the device, and keep the manual safe for
future reference.
Safety Instructions
The following signal words might appear in the manual.
Signal Words Meaning
Indicates a high potential hazard which, if not avoided, will result in
death or serious injury.
Indicates a medium or low potential hazard which, if not avoided,
could result in slight or moderate injury.
Indicates a potential risk which, if not avoided, could result in
property damage, data loss, lower performance, or unpredictable
result.
Provides methods to help you solve a problem or save you time.
Provides additional information as the emphasis and supplement to
the text.
Revision History
Version Revision Content Release Time
V1.1.2 Added battery description. August 2023
V1.1.1 Revised battery life. June 2023
V1.1.0
●Added technical specications and eld of
view.
●Updated descriptions of parameters.
●Updated images.
January 2022
V1.0.0 First release. October 2021
Privacy Protection Notice
As the device user or data controller, you might collect the personal data of others such as their
face, ngerprints, and license plate number. You need to be in compliance with your local privacy
protection laws and regulations to protect the legitimate rights and interests of other people by
implementing measures which include but are not limited: Providing clear and visible identication
to inform people of the existence of the surveillance area and provide required contact information.
User’s Manual
I
About the Manual
●The manual is for reference only. Slight dierences might be found between the manual and the
product.
●We are not liable for losses incurred due to operating the product in ways that are not in
compliance with the manual.
●The manual will be updated according to the latest laws and regulations of related jurisdictions.
For detailed information, see the paper user’s manual, use our CD-ROM, scan the QR code or
visit our ocial website. The manual is for reference only. Slight dierences might be found
between the electronic version and the paper version.
●All designs and software are subject to change without prior written notice. Product updates
might result in some dierences appearing between the actual product and the manual. Please
contact customer service for the latest program and supplementary documentation.
●There might be errors in the print or deviations in the description of the functions, operations
and technical data. If there is any doubt or dispute, we reserve the right of nal explanation.
●Upgrade the reader software or try other mainstream reader software if the manual (in PDF
format) cannot be opened.
●All trademarks, registered trademarks and company names in the manual are properties of their
respective owners.
●Please visit our website, contact the supplier or customer service if any problems occur while
using the device.
●If there is any uncertainty or controversy, we reserve the right of nal explanation.
User’s Manual
II
Important Safeguards and Warnings
This section introduces content covering the proper handling of the keyfob, hazard prevention, and
prevention of property damage. Read carefully before using the keyfob, and comply with the
guidelines when using it.
Operation Requirements
●Make sure that the power supply of the device works properly before use.
●Do not pull out the power cable of the device while it is powered on.
●Only use the device within the rated power range.
●Transport, use and store the device under allowed humidity and temperature conditions.
●Prevent liquids from splashing or dripping on the device. Make sure that there are no objects
lled with liquid on top of the device to avoid liquids owing into it.
●Do not disassemble the device.
Installation Requirements
●Connect the device to the adapter before power on.
●Strictly abide by local electrical safety standards, and make sure that the voltage in the area is
steady and conforms to the power requirements of the device.
●Do not connect the device to more than one power supply. Otherwise, the device might
become damaged.
●Observe all safety procedures and wear required protective equipment provided for your use
while working at heights.
●Do not expose the device to direct sunlight or heat sources.
●Do not install the device in humid, dusty or smoky places.
●Install the device in a well-ventilated place, and do not block the ventilator of the device.
●Use the power adapter or case power supply provided by the device manufacturer.
●The power supply must conform to the requirements of ES1 in IEC 62368-1 standard and be no
higher than PS2. Note that the power supply requirements are subject to the device label.
●Connect class I electrical appliances to a power socket with protective earthing.
User’s Manual
III
Table of Contents
Foreword.............................................................................................................................................................. I
Important Safeguards and Warnings.............................................................................................................. III
1 Introduction..................................................................................................................................................... 1
1.1 Overview........................................................................................................................................................................................1
1.2 Technical Specications........................................................................................................................................................... 1
2 Checklist........................................................................................................................................................... 3
3 Design............................................................................................................................................................... 4
3.1 Appearance...................................................................................................................................................................................4
3.2 Function Key.................................................................................................................................................................................4
4 Adding the Keyfob to the Hub........................................................................................................................6
5 Keyfob Conguration......................................................................................................................................7
5.1 Viewing Status............................................................................................................................................................................. 7
5.2 Conguring the Keyfob............................................................................................................................................................ 8
6 Using the Keyfob........................................................................................................................................... 10
Appendix 1 Cybersecurity Recommendations............................................................................................. 11
User’s Manual
IV
1 Introduction
1.1 Overview
Wireless keyfob is a miniature remote that connects to the hub and controls the alarm system in
your home. It works by sending wireless communication signals to the alarm system, which will
recognize the signal and then perform the function that is assigned to the area.
1.2 Technical Specications
This section contains technical specications of the keyfob. Please refer to the ones that correspond
with your model.
Table 1-1 Technical specications
Type Parameter Description
Port Indicator Light 1 × two-color status indicator (green: normal,
red: abnormal)
Button 4 (Home, Away, Disarm, and SOS)
Function Remote Update Cloud update
Low Battery Alarm Yes
Wireless Parameters
Carrier Frequency ALM-D1-RC:
433.1 MHz–434.6 MHz
Communication
Distance
ALM-D1-RC: Up to
500 m (1,640.42 ft) in
an open space
Communication
Mechanism Two-way
Encryption Mode AES128
Frequency Hopping Yes
General
Power Supply CR2032 battery
Battery Voltage 3 VDC
Min. Voltage 1.8 VDC
Battery Low Threshold 2.6 VDC
Battery Restore
Threshold 2.65 VDC
Consumption Quiescent current 3 uA
Max current 50 mA
PS Type Type C
Battery Life 3 years
User’s Manual
1
Type Parameter Description
Power Consumption ALM-D1-RC:
Max. 85 mW
Operating
Environment
Indoor: –10 °C to +55 °C (+14 °F to +131 °F)
Certied temperature: –10°C to +40°C (+14°F to
+104 °F)
Operating Humidity 10%–90% (RH)
Product Dimensions 60.0 mm × 39.5 mm × 15.0 mm (2.36" × 1.56" ×
0.59") (L × W × H)
Packaging Dimensions 135.0 mm × 98.5 mm × 27.8 mm (5.31" × 3.88" ×
1.09")
Net Weight 20 g (0.04 lb)
Gross Weight 65 g (0.14 lb)
Casing PC + ABS
ACE Type Type B
Certications
ALM-D1-RC:
CE
FCC
User’s Manual
2
2 Checklist
Figure 2-1 Checklist
Table 2-1 Checklist
No. Item Name Quantity
1 Wireless keyfob 1
2 String 1
3 User's manual 1
4 Legal and regulatory information 1
User’s Manual
3
3 Design
3.1 Appearance
Figure 3-1 Appearance
3.2 Function Key
Figure 3-2 Function key
Table 3-1 Description of function button
No. Name Description
1 Disarming button Press the button once to disarm the system.
2 SOS Press the panic button, and then the keyfob will
send alarm signal to the alarm system.
User’s Manual
4
No. Name Description
3 Arming button Press the button once to arm the system.
4 Home mode Press the home mode, and then the selected
accessories will be armed.
5 Indicator
●Flashes green quickly: Pairing mode.
●Solid green: Normal.
●Solid red: The keyfob is oine.
●Flashes green rst, and then turns to red:
Connection with the hub failed.
User’s Manual
5
