Watts Bar PZDS Betriebshandbuch

bar-gmbh.de

2/2-way automatic butterﬂy valve

PZDS (with bar-agturn or actubar)

EZDS

IMPORTANT: This manual is only valid in conjunction

with the manufacturer documentation of the actuator

Translation of the original operating manual

2PZDS/EZDS-IM-DE-B-EN-01-23 Rev.0

Table of Contents

1. General information ...................................................................5

1.1 Reference documents.........................................................................................5

1.2 Validity of the operating manual......................................................................... 5

1.3 Notes to operating manual .................................................................................6

1.3.1 Signal words and symbols ......................................................................6

1.3.2 Explanation of the structure of the safety instructions..........................7

1.3.3 Descriptions in figures.............................................................................7

1.4 Responsibility of the operating company ..........................................................7

2. Safety ..........................................................................................8

2.1 General Safety Instructions ................................................................................8

2.2 Intended use........................................................................................................8

2.3 Reasonable foreseeable use ..............................................................................8

2.4 Organizational measures ....................................................................................8

2.4.1 Subsequent retrofitting or changes ........................................................8

2.4.2 Replacement of defective parts..............................................................8

2.5 Protective equipment..........................................................................................9

2.6 Personnel qualification .......................................................................................9

2.7 Dangers when handling the automatic butterfly valve....................................11

2.7.1 Dangers during assembly, maintenance and disassembly ................. 11

2.7.2 Dangers during functional checks, commissioning and operation..... 14

3. Product description .................................................................16

3.1 Butterfly valve ...................................................................................................16

3.2 Rotary actuator .................................................................................................16

3.3 Type plate..........................................................................................................17

PZDS/EZDS-IM-DE-B-EN-01-23 Rev.0 3

4. Transport and storage .............................................................18

4.1 Scope of delivery ..............................................................................................18

4.2 Incoming goods inspection ..............................................................................18

4.3 Transport, packaging and storage...................................................................18

5. Installation ................................................................................20

5.1 Installation conditions.......................................................................................20

5.2 Before installation .............................................................................................20

5.3 Installation of butterfly valve ............................................................................ 20

5.4 Mounting the rotary actuator............................................................................ 22

5.5 Pressure test of the pipe section .....................................................................22

6. Commissioning and operation ................................................23

7. Maintenance and repair ...........................................................23

7.1 Maintenance of the actuator ............................................................................23

7.2 Maintenance of butterfly valve .........................................................................23

8. Troubleshooting .......................................................................23

9. Repair and spare parts ............................................................24

10. Disassembly .............................................................................25

10.1 Disassembly of the actuator.............................................................................25

10.2 Dismantling the butterfly valve from the pipeline............................................25

11. Disposal ....................................................................................25

4PZDS/EZDS-IM-DE-B-EN-01-23 Rev.0

12. EU Declaration of Incorporation Type P... .............................26

13. EU Declaration of Incorporation Type E... .............................27

14. EU Declaration of Conformity Type E... .................................28

15. Annex / Technical data ............................................................29

15.1 Technical data of rotary actuator .....................................................................29

15.2 Technical data of the shut-off valve Type ZDS ...............................................29

15.3 Dimensional tables and dimensional drawings Type PZDS with bar-agturn.30

15.3.1 Dimensional drawing Type PZDS with bar-agturn...............................30

15.3.2 Dimensional table Type PZDS with bar-agturn....................................32

15.3.3 Actuator assignment ............................................................................. 36

15.4 Dimensional tables and dimensional drawings Type PZDS with actubar......37

15.4.1 Dimensional drawing Type PZDS with actubar.................................... 37

15.4.2 Dimensional table PZDS with actubar..................................................39

15.4.3 Actuator assignment ............................................................................. 43

15.5 Dimensional tables and dimensional drawings Type EZDS ...........................44

15.5.1 Dimensional drawing Type EZDS ......................................................... 44

15.5.2 Dimensional table Type EZDS...............................................................45

PZDS/EZDS-IM-DE-B-EN-01-23 Rev.0 5

1. General information

This operating manual is a part of the prod-

uct. The operating manual must be kept for

the entire life of the product and must be

passed on to each subsequent owner of the

product.

The operating manual must always be avail-

able at the place of operation.

1.1 Reference documents

This manual, the data mentioned and de-

sign data sheets, additional assembly and

maintenance instructions as well as further

information – also in other language ver-

sions, can be obtained from:

bar pneumatische

Steuerungssysteme GmbH

Auf der Hohl 1

53547 Dattenberg

Tel.: +49 (0)2644-9607-0

Fax: +49 (0)2644-960735

Email: bar-info@wattswater.com

www.bar-gmbh.de

IMPORTANT

This manual is only valid in conjunction

with the manufacturer documentation of

the rotary actuator.

bar pneumatische

Steuerungssysteme GmbH

Auf der Hohl 1

53547 Dattenberg

Tel.: +49 (0)2644-9607-0

Fax: +49 (0)2644-960735

Email: bar-info@wattswater.com

www.bar-gmbh.de

Valpes

Z.I. Centr‘alp

89 rue des étangs

F - 38430 Moirans

Tel. +33 (0) 4 76 35 06 06

Fax +33 (0) 4 76 35 14 34

valpes-info@wattswater.com

www.valpes.com

1.2 Validity of the operating

manual

This operating manual is valid for the 2/2-

way automatic butterﬂy valve of PZDS /

EZDS type since year of manufacture 2019

with one of the following rotary actuators:

bar-agturn

• agturn Type GD-032 till 040

• agturn Type GD/GS-052 till 400

actubar

• actubar Type AD-001

• actubar Type AD/AS-002 till 1200

Electric rotary actuator of company

Valpes

6PZDS/EZDS-IM-DE-B-EN-01-23 Rev.0

1.3 Notes to operating manual

The safety and hazard statements in the

document are intended for your protec-

tion, the protection of third parties and the

protection of the product. The instructions

must therefore be observed.

1.3.1 Signal words and symbols

DANGER

... indicates a hazard that, if not avoided,

will result in death or serious injury.

WARNING

... indicates a hazard that, if not avoided,

could result in death or serious injury.

CAUTION

... indicates a hazard which, if not avoid-

ed, could result in minor or moderate in-

jury.

NOTE

... indicates important information (e.g.

Material damage) but not hazards.

Electric voltage!

The text passages marked with

this symbol inform you about

dangerous situations with danger to life

and health of persons due to electrical

voltage.

Corrosive substances!

The text passages marked with

this symbol inform you about

dangerous situations caused by corrosive

substances.

Hot surface!

The text passages marked with

this symbol inform you about

dangerous situations with a risk of burns

due to hot surfaces.

Cold surface!

The text passages marked with

this symbol inform you about

dangerous situations with a risk due to

cold surfaces.

Suspended load!

The text passages marked with

this symbol inform you about

dangerous situations with a risks due to

suspended load.

Hand injuries!

The text passages marked with

this symbol inform you about

dangerous situations resulting in hand

injuries caused by bruising or punching.

The activities described in the relevant

text passage must be performed with the

utmost care to avoid dangerous situations

and resulting injuries such as loss of limbs.

PZDS/EZDS-IM-DE-B-EN-01-23 Rev.0 7

Use head protection!

Notes with this symbol indicate

that a head protection must be

worn.

Use protective clothing!

Notes with this symbol indicate

that a protective clothing must

be worn.

Use hand protection!

Notes with this symbol indicate

that a hand protection must be

worn.

1.3.2 Explanation of the structure of

the safety instructions

A safety instruction is initiated with a signal

word describing the severity of the danger

(

„Chapter 1.3.1 Signal words and symbols“

WARNING

Type or source of danger (possibly

with warning signs according to DIN

EN ISO 7010)

Consequences in case of not following

the instruction

• Avoidance of danger

1.3.3 Descriptions in figures

The ﬁgures in this operating manual are

intended to help you understand the facts

and procedures.

The descriptions in the ﬁgures are exem-

plary and may differ slightly from the actual

appearance of your product.

1.4 Responsibility of the operating company

• The installation, electrical and pneumatic connection as well as the commissioning of

the product may only be carried out by qualiﬁed personnel in accordance with the in-

structions described in this operating manual.

• The product may only be operated and maintained by personnel of the legal minimum

age and the corresponding personnel qualiﬁcation.

• This operating manual is an integral part of the product and must be available to the

personnel at all times. This operating manual must be read and understood before the

ﬁrst commissioning.

• The operating and technical personnel must be instructed about safety devices of the

product as well as safe working methods.

• The product may only be operated in perfect condition. No safety devices may be re-

moved or disconnected.

8PZDS/EZDS-IM-DE-B-EN-01-23 Rev.0

2. Safety

2.1 General Safety Instructions

Personnel assigned to work on the auto-

matic butterﬂy valve must read the operat-

ing instructions before starting work and, in

particular, understand the chapter “Safety”

before starting work. This is particularly valid

for personnel working only occasionally on

the rotary actuator.

2.2 Intended use

• The automatic butterﬂy valve is used

for the automatic shut-off of liquids and

gases in pipelines.

• The automatic valve is designed for use

in process engineering plants.

• The operating values, limit values and

setting data speciﬁed in the operating

manual and the corresponding data

sheet must be observed.

• Intended use also includes the obser-

vance of these operating instructions.

2.3 Reasonable foreseeable use

Any use other than that described in

„Chap-

ter 2.2 Intended use“

and any use not ap-

proved by the manufacturer is considered

as unintended.

DANGER

Danger of explosion!

The automatic valve is not intended for

use in potentially explosive atmospheres.

• Do not use the automatic valve in po-

tentially explosive atmospheres.

2.4 Organizational measures

2.4.1 Subsequent retrofitting or

changes

The operator must make a corresponding

assessment of the hazards when dealing

with subsequently integrated components

and retroﬁtting.

If you want to use a different medium or use

the butterﬂy valve for a different purpose,

contact our customer service. We can help

you with any possible necessary conﬁgura-

tions.

2.4.2 Replacement of defective

parts

Replace parts of the rotary actuator that are

not in perfect condition immediately with

original spare parts.

Please note that only original spare and

wear parts of bar GmbH are to be used.

In the case of usage of the third-party parts,

it is not ensured that they are designed and

manufactured to suit the requirements.

PZDS/EZDS-IM-DE-B-EN-01-23 Rev.0 9

2.5 Protective equipment

If necessary, the protective equipment shall

be used. Keep your hair and clothing away

from moving parts. If necessary, wear a

hairnet and do not wear jewelery such as

necklaces and rings!

Use head protection!

Wear suitable head protection

during transport.

Use protective clothing!

Wear suitable protective clothing

during commissioning, mainte-

nance and troubleshooting.

Use hand protection!

Wear suitable hand protection

during transport, commissioning,

maintenance and troubleshooting.

2.6 Personnel qualification

Only trained or instructed personnel who

has known and understood the operating

instructions as well as the possible dangers

of the rotary actuator is allowed to work with

the rotary actuator. The responsibility of the

personnel for operation, maintenance and

repair must be clearly deﬁned by the oper-

ator.

Personnel to be trained, instructed or un-

dergoing training may work on the rotary

actuator only under the constant supervi-

sion of an experienced person.

The individual activities on the rotary actua-

tor require different personnel qualiﬁcations

which are listed in the following table. The

different qualiﬁcations are characterized by

the following skills and knowledge:

• Instructed persons must operate the rotary actuator and be able to detect possible

damage and dangers on the rotary actuator.

• Instructed persons with technical training must also be aware of the dangers of han-

dling pressurized equipment, hot and cold surfaces, harmful and hazardous materials

and the process of installing and removing the valves in a process line, the speciﬁc and

potential risks of the process and the most important safety regulations.

• Trained electricians must read and understand electrical circuit diagrams, commission,

put electric machines into operation, service and maintain them, wire switch and control

cabinets, install control software, ensure the functionality of electrical components and

identify potential hazards in handling electrical and electronic systems.

• Trained pneumatic specialists must read and understand pneumatic circuit diagrams,

put pneumatic systems into operation, service and maintain them, disconnect and

connect pneumatic hoses, ensure the proper functioning of pneumatic components,

assess the work performed on the pneumatic system and identify potential hazards.

10 PZDS/EZDS-IM-DE-B-EN-01-23 Rev.0

Read this table as follows:

“The electrical installation requires the qualiﬁcation of a qualiﬁed electrician.”

Activities Instructed

persons

Instructed persons with

technical training

Electri-

cians

Pneumatic

specialists

Installation X

Electrical installation X

Pneumatic installation X

Setting and equipping X

Commissioning X

Troubleshooting X

Cleaning X

Troubleshooting, repair and

maintenance of mechanics X

Troubleshooting, repair and

maintenance of electrics X

Troubleshooting, repair and

maintenance of pneumatics X

Functional checks X

Shutdown X X

Transport X

Disposal X

Tab. 2-1 Overview of the required personnel qualiﬁcations

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Watts Steuereinheit Handbücher

Watts

Watts AMES 910GD Montage- und Bedienungsanleitung

Watts

Watts AMES 910GD-11 Montage- und Bedienungsanleitung

Watts

Watts LFM110-13 Betriebsanleitung

Watts

Watts 757 Series Einrichtungshandbuch

Watts

Watts LFM114-2 Bedienungsanleitung

Watts

Watts LFMMV Series Bedienungsanleitung

Watts

Watts LF1170C-M2 Series Bedienungsanleitung

Watts

Watts IntelliFlow A2C-M1 Bedienungsanleitung

Watts

Watts AMES LF981GD Series Bedienungsanleitung

Watts

Watts AMES 985GD Handbuch

Watts

Watts LFM127-11 Montage- und Bedienungsanleitung

Watts

Watts AMES 960GD-17 Montage- und Bedienungsanleitung

Watts

Watts SOCLA BA BM Bedienungsanleitung

Watts

Watts USG-P-M1 Bedienungsanleitung

Watts

Watts AMES LF985GD-20 Series Bedienungsanleitung

Watts

Watts iDROSET CF Series Bedienungsanleitung

Watts

Watts 800 Series Bedienungsanleitung

Watts

Watts Ames 912GD Betriebsanleitung

Watts

Watts AMES 920GD-01-15 Bedienungsanleitung

Watts

Watts WFC-03 HCM RF 230 Bedienungsanleitung

Watts

Watts LFM115-3 Betriebsanleitung

Watts

Watts AMES Deringer 20G Bedienungsanleitung

Watts

Watts FEBCO 860 Small Series Betriebsanleitung

Watts

Watts DRV Series Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung

Watts bar PZDS Betriebshandbuch

Beliebte Steuereinheit Handbücher anderer Marken
