WebDT 133
ENGLISH 23ENGLISH
THE WebDT 133
Rear ViewFront View
Powering ON and OFF
The Power Buon is located in the front of the WebDT 133. The Power Buon may be configured to
funcon differently depending on the power opons of the operang system. In general, to turn the
WebDT 133 on, push and release the Power Buon on the front bezel. The adjacent power LED will
be lit (blue) and the corresponding interface will be displayed on the display monitor.
To turn offthe device, again depending on soware operang system, push and release the Power
Buon or use a soware shutdown interface. In the event of system lockup, the Power Buon may
be used to perform a reset on the device. To do that, push and hold the Power Buon for at least 4
seconds. The system will shut down and all unsaved work may be lost. Pushing on the Power Buon
again will restart the device.
Device Ports
The WebDT 133 features an opmal set of I/O ports while preserving the compact size of the
system. The HDMI connector, Network (10/100/1000 BaseT Ethernet), and Power ports are
supplemented by a set of four USB 2.0 and two Audio ports. Through its USB ports, the WebDT 133
supports a wide range of USB-based peripherals. These peripherals are applicable in providing the
means for soware installaon, applicaon storage, data storage, and system soware recovery
and updates.
Memory and Storage
The WebDT 133 may be available in storage configuraons 8GB of fash memory or 32GB to 64GB
SSD. Depending on base soware configuraon, the user may use the internal memory of the
WebDT 133 for user’s installed soware and storage. The user may also supplement storage space
with USB-based peripherals such as fash disks, disk drives, etc. RAM capacity is 2GB.
VESA Mounng Bracket Installaon for WebDT 133
Precauons
•Always exercise care when operang and handling the WebDT 133.
•Never disassemble any poron of the enclosure. It will void any product warranty on
the WebDT 133.
•Do not use any AC/DC adapter other than the one provided with the device or
acquired from the manufacturer or its partners.
•In the unlikely event that smoke, abnormal noise, or strange odor is present,
immediately power down the WebDT 133 and disconnect all power sources.
•Please report the problem to your device provider immediately.
A B C D E F G H I
Ethernet port
USB 2.0 (2)
DVI-I port
DC-in
A F
B G
C H
D I
E
Audio jacks
HDMI port
RS232 COM port
USB 2.0 (2)
Power buon
Step1:
Locate the exisng mounng holes•
on the monitor.
Line the bracket holes up with the•
holes on the back of the monitor,
as shown to the right.
Place the screws to hold the•
mounng bracket in place and
ghten the screws (do not over-
ghten).
Step2:
Remove the two M3 screws (3)•
originally on the WebDT 133
signage appliance.
Place the WebDT 133 (2) on the•
bracket rail with the interface
ports side facing downwards so
that the two mounng holes on
the appliance are aligned with
the exisng holes on the rail (see
picture).
Step3:
Apply and ghten the screws•
into their original locaons and
make sure that the bracket and
the WebDT 133 are properly
secured.
