Welker RV-1 Bedienungsanleitung

INSTALLATION, OPERATION, ANDMAINTENANCEMANUAL

WELKER RELIEFVALVE

MODELS

RV-1

RV-2

RV-2CP

RV-3



DRAWING NUMBERS

AD017A[ ]

AD018A[ ]

AD020A[ ]

AD282BO



MANUAL NUMBER

IOM-033



REVISION

Rev. F, 7/23/2019

TABLEOFCONTENTS

2IOM-033 MODELS: RV-1, RV-2, RV-2CP, and RV-3 REV: F 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department 281.491.2331



 SAFETY 3

1. PRODUCT INFORMATION 4

1.1 Introduction 4

1.2 Product Description 4

1.3 Specifications 4

1.4 Equipment Diagrams 5

  

2. INSTALLATION & OPERATION 7

2.1 Before You Begin 7

2.2 Setting and Installing the Relief: RV-1, RV-2, and RV-3 7

2.3 Installing and Setting the Relief: RV-2CP 8

  

3. MAINTENANCE 9

3.1 Before You Begin 9

3.2 Maintenance: RV-1 10

3.3 Maintenance: RV-2 11

3.4 Maintenance: RV-2CP 12

3.5 Maintenance: RV-3 13

  

 APPENDIX 14

 A: Referenced or Attached Documents 14



IMPORTANTSAFETYINFORMATION

READALLINSTRUCTIONS

Notes emphasize information and/or provide additional information to assist the user.

Caution messages appear before procedures that could result in damage to equipment if not observed.

Warning messages appear before procedures that could result in personal injury if not observed.

This manual is intended to be used as a basic installation and operation guide for the Welker Relief Valves, RV-1, RV-2, RV-2CP, and RV-3. For comprehensive

instructions, please refer to the IOM Manuals for each individual component. A list of relevant component IOM Manuals is provided in Appendix A of this manual.

The information in this manual has been carefully checked for accuracy and is intended to be used as a guide for the installation, operation, and maintenance of

the Welker equipment described in this manual. Correct installation and operation, however, are the responsibility of the end user. Welker reserves the right to make

changes to this manual and all products in order to improve performance and reliability.

BEFOREYOUBEGIN

Read these instructions completely and carefully.

IMPORTANT- Save these instructions for local inspector's use.

IMPORTANT- Observe all governing codes and ordinances.

Note to Installer - Leave these instructions with the end user.

Note to End User - Keep these instructions for future reference.

Installation of this Relief Valve is of a mechanical nature.

Proper installation is the responsibility of the installer. Product failure due to improper installation is not covered under the warranty.

If you received a damaged Relief Valve, please contact a Welker representative immediately.

Phone: 281.491.2331

Address: 13839 West Bellfort Street

Sugar Land, TX 77498

SAFETY

3IOM-033 MODELS: RV-1, RV-2, RV-2CP, and RV-3 REV: F 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department 281.491.2331

1.1 Introduction

We appreciate your business and your choice of Welker products. The installation, operation, and maintenance liability for this

equipment becomes that of the purchaser at the time of receipt. Reading the applicable Installation, Operation, and

Maintenance (IOM) Manuals prior to installation and operation of this equipment is required for a full understanding of its

application and performance prior to use.*

If you have any questions, please call Welker at 1-281-491-2331.

*The following procedures have been written for use with standard Welker parts and equipment. Assemblies that have been modified may have additional

requirements and specifications that are not listed in this manual.

1.2 Product Description

The Welker RV-1, RV-2, and RV-3 Relief Valves are designed to protect instruments and regulators from overpressurization. The

RV-2CP is designed to be used in place of a rupture disc to protect cylinders from overpressurization. Unlike a rupture disc, the

RV-2CP will only relieve enough pressure required for it to reseat, thus limiting the amount of product discharged. As an added

safety feature, the RV-2CP outlet can be vented to a safe location.

lThe RV-1 is specifically designed to relieve moderate capacity instruments in the 0–200 psig range.

lThe RV-2 is specifically designed to relieve low capacity instruments in the 0–1900 psig range.

lThe RV-2CP is specifically designed to relieve low capacity cylinders in the 0–1900 psig range.

lThe RV-3 is specifically designed to relieve high capacity instruments in the 0–200 psig range.

Welker may custom design the RV-1, RV-2, RV-2CP, and RV-3 to suit the particular application and specifications of each customer.

1.3 Specifications



The specifications listed in this section are generalized for this equipment. Welker can modify the equipment according to your

company's needs. Please note that the specifications may vary depending on the customization of your equipment.

Table 1: RV-1 Specifications

Materials of Construction 316/316L Stainless Steel, PTFE, and Viton®

Others Available

Maximum Allowable Inlet Pressure

2500 psig (172 barg)

5000 psig (344 barg) [Standard]

6000 psig (413 barg)

Connections Inlet: ¼" MNPT (Standard) or ¹⁄₈" MNPT

Outlet: Atmospheric, ¼" FNPT, or ½" FNPT

Spring Range

0–50 psig (0–3 barg)

0–100 psig (0–6 barg)

0–200 psig (0–13 barg)

Options

Pre-Set Relief

Sulfinert®-Treated Wetted Parts

CECompliance

CRNCertification

NACE Compliance



SECTION 1: PRODUCTINFORMATION

4IOM-033 MODELS: RV-1, RV-2, RV-2CP, and RV-3 REV: F 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department 281.491.2331

Table 2: RV-2 Specifications

Materials of Construction 316/316L Stainless Steel, PTFE, and Viton®

Others Available

Maximum Allowable Inlet Pressure 5000 psig (344 barg)

Connections Inlet: ¼" MNPT (Standard) or ¹⁄₈" MNPT

Outlet: Atmospheric or ¼" MNPT

Spring Range

100–300 psig (6–20 barg)

150–800 psig (10–55 barg)

500–1000 psig (34–68 barg)

900–1500 psig (62–103 barg)

1900+ psig (131+ barg)

Option Pre-Set Relief



Table 3: RV-2CP Specifications

Materials of Construction 316/316L Stainless Steel, PTFE, and Viton®

Others Available

Maximum Allowable Inlet Pressure 5000 psig (344 barg)

Connections Inlet: ½" – 20 UNF

Outlet: ¼" FNPT

Spring Range

100–300 psig (6–20 barg)

150–800 psig (10–55 barg)

500–1000 psig (34–68 barg)

900–1500 psig (62–103 barg)

1900+ psig (131+ barg) [Standard]

Options Pre-Set Relief

NACECompliance



Table 4: RV-3 Specifications

Materials of Construction 316/316L Stainless Steel, PTFE, and Viton®

Others Available

Maximum Allowable Inlet Pressure 3600 psig (248 barg)

Connections Inlet: ¼" MNPT (Standard) or ³⁄₈" MNPT

Outlet: ¼" FNPT, ³⁄₈" FNPT, ½" FNPT, ¾" FNPT, or 1" FNPT (Standard)

Spring Range 0–50 psig (0–3 barg)

0–200 psig (0–13 barg)

Option Pre-Set Relief

1.4 Equipment Diagrams

Figure 1: RV-1 Diagram

5IOM-033 MODELS: RV-1, RV-2, RV-2CP, and RV-3 REV: F 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department 281.491.2331

Figure 2: RV-2 Diagram

Figure 3: RV-2CP Diagram

Figure 4: RV-3 Diagram

6IOM-033 MODELS: RV-1, RV-2, RV-2CP, and RV-3 REV: F 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department 281.491.2331

2.1 Before You Begin



After unpacking the unit, check the equipment for compliance and any damage that may have occurred during shipment.

Immediately contact a Welker representative if you received damaged equipment.



When sealing fittings with PTFE tape, refer to the proper sealing instructions for the brand used.

2.2 Setting and Installing the Relief: RV-1, RV-2, and RV-3



If installing and setting an RV-2CP, see Section 2.3, Installing and Setting the Relief: RV-2CP.



To accurately set the relief, a safe gas source, regulator, and pressure gauge are needed.

Setting the Relief Valve

1. Connect the regulator to a safe gas source.

2. Screw the spring adjuster of the relief valve clockwise to fully close the relief valve.

3. Install the relief valve to the regulator.

4. Set the regulator to the desired pressure, and then apply auxiliary gas through the regulator to the relief valve.

5. Screw the spring adjuster of the relief valve counterclockwise until pressure starts to relieve. A hissing sound will be

audible.



For the RV-1 and RV-2, use a hex key to screw the spring adjuster.

For the RV-3, use a Phillips head screwdriver to screw the spring adjuster.



6. Screw the spring adjuster of the relief valve clockwise until the hissing sound stops and the relief valve obtains a

positive shutoff.

Testing the Relief Valve

7. Set the regulator to a pressure slightly below the relief valve set point, and then slowly increase the pressure of the

regulator until it is slightly higher than the relief valve set point. A hissing sound should be audible.

8. Slowly decrease the pressure of the regulator until it is slightly below the relief valve set point. The hissing sound should

stop as the relief valve reseats.

9. If the relief valve does not begin to relieve pressure or does not reseat, it may be necessary to repeat steps 4–6 to reset

the relief valve.

10. If the relief valve is to be used with the regulator it was set with, reset the regulator to the desired point.

SECTION 2: INSTALLATION&OPERATION

7IOM-033 MODELS: RV-1, RV-2, RV-2CP, and RV-3 REV: F 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department 281.491.2331

Installing the Relief Valve

11. Either wrap the threads of the relief valve with PTFE tape or apply pipe dope to the threads.

12. Using a wrench, install the relief valve to the correct port on the instrument it will be relieving.

13. Installation is complete, and the relief valve is now operational.

2.3 Installing and Setting the Relief: RV-2CP



If setting and installing an RV-1, RV-2, or RV-3, see Section 2.2, Setting and Installing the Relief: RV-1, RV-2, and RV-3.

Installing the RV-2CP



Prior to being set, the RV-2CP must be installed to the cylinder it will be relieving.



1. Install the seat of the RV-2CP to the cylinder the RV-2CP will be relieving (Figure 3). The O-ring side of the seat must face

away from the RV-2CP.

2. Either wrap the threads of the RV-2CP with PTFE tape or apply pipe dope to the threads.

3. Install the RV-2CP on top of the seat.

4. Using a torque wrench, tighten the RV-2CP to 30 ft•lb. The RV-2CP may now be set.

Setting the RV-2CP



To accurately set the relief, a safe gas source, regulator, and pressure gauge are needed.



5. Connect the regulator to a safe gas source.

6. Using a hex key, screw the spring adjuster of the RV-2CP clockwise to fully close the RV-2CP.

7. Connect from the regulator to the cylinder end cap to which the RV-2CP is installed.

8. Set the regulator to the desired pressure, and then apply auxiliary gas through the regulator to the RV-2CP.

9. Using a hex key, screw the spring adjuster of the RV-2CP counterclockwise until pressure starts to relieve. A hissing

sound will be audible.

10. Screw the spring adjuster of the RV-2CP clockwise until the hissing sound stops and the RV-2CP obtains a positive

shutoff.

Testing the RV-2CP

11. Set the regulator to a pressure slightly below the RV-2CP set point, and then slowly increase the pressure of the

regulator until it is slightly higher than the RV-2CP set point. A hissing sound should be audible.

12. Slowly decrease the pressure of the regulator until it is slightly below the RV-2CP set point. The hissing sound should

stop as the RV-2CP reseats.

13. If the RV-2CP does not begin to relieve pressure or does not reseat, it may be necessary to repeat steps 8–10 to reset

the RV-2CP.

14. Disconnect the regulator from the cylinder end cap.

15. The RV-2CP is now operational.

8IOM-033 MODELS: RV-1, RV-2, RV-2CP, and RV-3 REV: F 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department 281.491.2331

3.1 Before You Begin

1. Welker recommends that the unit have standard maintenance under normal operating conditions: for gas

every six (6) months; and for liquid every twelve (12) months. In cases of severe service, dirty conditions, excessive

usage, or other unique applications that may lead to excess wear on the unit, a more frequent maintenance schedule

may be appropriate.

2. Prior to maintenance or disassembly of the unit, it is advisable to have a repair kit available for repairs of the system in

case of unexpected wear or faulty seals.



New seals supplied in spare parts kits should be lightly lubricated before being installed to ease the installation of the seals and

reduce the risk of damage when positioning them on parts. Wipe excess lubricant from the seals, as it may adversely affect

analytical instrument results.



For sample-exposed seals, Welker recommends non-hydrocarbon-based lubricants, such as Krytox®.

For non-sample-exposed seals, Welker recommends either non-hydrocarbon-based lubricants or silicone-based lubricants, such

as Molykote® 111.



After the seals are installed, the outer diameter of shafts and inner diameter of cylinders may be lubricated to allow smooth

transition of parts.



3. All maintenance and cleaning of the unit should be performed on a smooth, clean surface.

4. Welker recommends having the following tools available for maintenance. Please note that the exact tools required may

vary by model.

a. Adjustable Wrench

b. Channel Lock Pliers

c. Flat Head Screwdriver

d. Hex Key Set

e. Phillips Head Screwdriver

SECTION 3: MAINTENANCE

9IOM-033 MODELS: RV-1, RV-2, RV-2CP, and RV-3 REV: F 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department 281.491.2331

10 IOM-033 MODELS: RV-1, RV-2, RV-2CP, and RV-3 REV: F 13839 West Bellfort Street, Sugar Land, TX 77498 welker.com Service Department 281.491.2331

3.2 Maintenance: RV-1

Figure 5: RV-1 Maintenance Diagram

1. Isolate and depressurize the RV-1 from the supply source.

2. Remove the RV-1 from the supply.

3. Using a hex key, remove the spring adjuster, spring, and ball.

4. Inspect the spring. If the spring is in good condition, it can be reused.

5. Inspect the ball for nicks and scratches. Replace as necessary.

6. Unscrew the base from the spring housing, and then replace the O-ring on the base.

7. Remove and replace the O-ring in the spring housing side of the base.



DONOT lubricate the O-ring on which the ball seals (Figure 5, #1).



8. Screw the base into the spring housing.

9. Return the ball and spring to the spring housing.



The ball must rest on the O-ring. If the ball rests on the metal trim, the relief will not seat.



10. Screw the spring adjuster into the spring body.

11. The RV-1 is now ready to be reset and reinstalled. See Section 2.2, Setting and Installing the Relief: RV-1, RV-2, and RV-3,

for instructions on setting and installing the relief.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Welker Steuereinheit Handbücher

Welker

Welker IRM-4SS Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
