WellGate 3232s

32 ports FXS Gateway

User Guide

Version: 1.0

Date: August 2016

Contents

CH1 Introduction.................................................................................... 4

1-1 Physical Interface ............................................................................. 4

1-2 IP Network connection ..................................................................... 4

1-3 Front Panel: LED Indicators............................................................. 5

1-4 Rear Panel: Phone cable connection................................................. 6

1-5 QUICK SETUP ................................................................................ 9

CH2 Device Settings............................................................................. 15

2-1 Network Configuration................................................................... 15

2-2 Device Time Setting ....................................................................... 16

2-3 Device Advance Setting.................................................................. 18

2-4 User Login Setting.......................................................................... 18

2-5 Debug Settings................................................................................ 19

2-6 Event Notice ................................................................................... 20

2-7 Auto Provision................................................................................ 21

2-8 SNMP ............................................................................................. 22

CH3 VoIP Setting.................................................................................. 23

3-1 SIP parameters setting .................................................................... 23

3-2 Audio .............................................................................................. 24

3-3 Tone ................................................................................................ 26

3-4 NAT Traversal................................................................................. 27

CH4 VOIP Advance .............................................................................. 28

4-1 SIP .................................................................................................. 28

4-2 Audio .............................................................................................. 30

4-3 Ring ................................................................................................ 31

CH5 Dialing Plan................................................................................. 32

5-1 General............................................................................................ 32

5-2 Dialing Rule.................................................................................... 33

5-3 Digit Manipulation ......................................................................... 34

5-4 Phone Book..................................................................................... 35

CH6 TEL Setting................................................................................... 36

6-1 FXS line.......................................................................................... 37

6-2 SIP Proxy........................................................................................ 38

6-3 Caller ID ......................................................................................... 40

6-4 Others.............................................................................................. 40

CH7 SIP Trunk...................................................................................... 42

7-1 Create SIP Trunk............................................................................. 43

CH8 Route Plan.................................................................................... 44

8-1 Create Route Plan........................................................................... 45

CH9 Status ............................................................................................ 46

9-1 Device Status .................................................................................. 47

9-2 Line Status...................................................................................... 47

9-3 SIP Trunk Status ............................................................................. 48

CH10 Maintenance............................................................................... 48

10-1 Firmware Update.......................................................................... 48

CH11 Logout......................................................................................... 49

Appendix A --- HTTP auto provision ................................................... 50

Appendix B --- SNMP.......................................................................... 52

WellGate 3232s

CH1 Introduction

WellGate 3232s Telephony Gateway

WellGate 3232s is a 32 ports FXS SIP gateway which includes 1-WAN/1-LAN

(management port) with 10/100 base-T network environment. Field-proven

quality of Voice communication and Fax transmission over IP broadband

access network to makes WellGate 3232s to be an excellent solution for

various VoIP applications.

The core firmware and webpage configuration is consistent with both 4-port

FXS gateway (WellGate 2504) and 24-port FXS gateway (WellGate 2424S). So,

there is not any difficulty to use WellGate 3232s if you are already using

WellGate 2504, 2808 or WellGate 2424S. Besides, if you have established

HTTP provision to manage WellGate 2504, it should be able to manage this

device as well.

1-1 Physical Interface

Ethernet port (RJ-45, 10/100 base-T)

1-WAN port, for connect to router, ADSL modem (ATU-R), or switch

hub directly. Connect to SIP IP network.

1-LAN port, connect to computer to configure this gateway.

Telephony port with RJ45 socket (include 4-pair FXS port each).

Two sockets of RJ-21 Telecom Female connector for telephony port.

Each FXS port are tied in parallel at corresponding RJ45 and RJ21

connector

32 FXS ports to connect to analog phone

Reset button to return Factory Default setting

AC power input with auto range 100 to 240Vac 50/60Hz.

19-inch, 1U rack mount metal case chassis.

Status indicated LED

Indicates Power, Ethernet, Line, SIP and system status

1-2 IP Network connection

IPv4 (RFC 791)/IPV6 (RFC 2460)

IPv6 Auto Configuration (RFC 4862)

MAC Address (IEEE 802.3)

Static IP

DHCP Client (RFC 2131) at WAN port

PPPoE at WAN port

DNS Client at WAN port

TCP/UDP (RFC 793/768)

RTP/RTCP (RFC 1889/1890)

IPV4 ICMP (RFC 792)/IPV6 ICMP (RFC 4443)

TFTP Client

VOIP VLAN Support (802.1q/802.1p)

HTTP/HTTPS Server

QoS Support

Support IPV4 only, IPV6 only or dual stack mode

1-3 Front Panel: LED Indicators

Figure 1-3-1 front panel of WellGate 3232s

LED

Description

Power

When AC power cable is connected and power switch is

ON, the LED will light up green.

Status

When the gateway is powered ON and is operated

normally, this LED keeps steady ON.

Ready

If one of 32 ports FXS isn’t registered successfully to a

Proxy, this LED will Flash.

Flash: At least one of 32 ports FXS doesn’t register

successfully.

ON: All FXS ports are registered successfully.

OFF: Peer to Peer mode or not configure properly.

WAN 10/100

speed, ACT

This will light up green when the gateway’s WAN port is

physically connected to the public internet. When data is

transmitted through this port, it will flash green.

The default IP of WAN port is 10.1.1.3.

LAN 10/100

speed, ACT

This will light up green when the gateway’s LAN port is

physically connected to a local network. When data is

transmitted through this port, it will flash green.

The default IP of LAN port is 192.168.123.123.

1 to 32

The status LED for FXS port 1-32. It will light up when the

connected phone is in busy, or when the connected phone

is engaged in a conversation. It will flash when there is an

incoming ring to this FXS port.

Connector

Description

Power Switch

This is AC power input switch. When it was turned ON, the

LED will light up green.

WAN

Provide RJ-45 Ethernet 10/100BaseT connection. Connect

SIP IP network to WAN port in operation.

LAN

Provide RJ-45 Ethernet 10/100BaseT connection. Only

provide configuration to this gateway locally via

computer’s IE Web Browser.

Reset

Press this Reset switch and hold on at least 5 seconds will

force this gateway’

s configuration resume factory default

setting.

COM

RS-232 DB 9-pin male console cable connection. It is only

used for professional engineer to debug this gateway

according to instructions

from supplier/vendor.

Unauthorized access to this console port may damage and

crash boot code and can’t be resumed normal operation.

1-4 Rear Panel: Phone cable connection

Figure 1-4 rear panel for FXS cable connection

Socket

Description

1 – 8, RJ-45

There are 32 FXS 2-wire loop start telephone ports to

connect with analog telephone set. Each RJ-45 socket

consists of four-pair FXS ports. Here are eight sockets of

RJ-45 to support 32 ports FXS.

1 – 2, RJ-21

Telecom

Connector

Here are two sockets of RJ-21 female telecom connector

to provide 32 FXS ports. Each RJ-21 socket comprises 16

FXS ports.

AC electric Socket

Electric AC voltage input socket.

Each FXS port number is tied together in parallel with that in RJ-21. That means each

FXS port can be accessed via RJ45 socket or RJ-21 telecom connector.

Eight lines of each RJ45 socket are separated into four pairs of FXS line sequences.

RJ45 position

RJ45 lines definition

Four-pair FXS line sequences

FXS port number

Signal

UTP Colour

Analog Line Pair

TX+

White Orange

Tip 1

1St Pair

TX-

Orange

Ring 1

RX+

White Green

Tip 2

2nd Pair

No Signal

Blue

Tip 3

3rd Pair

No Signal

White Blue

Ring 3

RX-

Green

Ring 2

2nd Pair

No Signal

White Brown

Tip 4

4th Pair

No Signal

Brown

Ring 4

TX+

White Orange

Tip 1

1St Pair

TX-

Orange

Ring 1

RX+

White Green

Tip 2

2nd Pair

No Signal

Blue

Tip 3

3rd Pair

No Signal

White Blue

Ring 3

RX-

Green

Ring 2

2nd Pair

No Signal

White Brown

Tip 4

4th Pair

No Signal

Brown

Ring 4

TX+

White Orange

Tip 1

1St Pair

TX-

Orange

Ring 1

RX+

White Green

Tip 2

2nd Pair

No Signal

Blue

Tip 3

3rd Pair

No Signal

White Blue

Ring 3

RX-

Green

Ring 2

2nd Pair

No Signal

White Brown

Tip 4

4th Pair

No Signal

Brown

Ring 4

TX+

White Orange

Tip 1

1St Pair

TX-

Orange

Ring 1

RX+

White Green

Tip 2

2nd Pair

No Signal

Blue

Tip 3

3rd Pair

No Signal

White Blue

Ring 3

RX-

Green

Ring 2

2nd Pair

No Signal

White Brown

Tip 4

4th Pair

No Signal

Brown

Ring 4

TX+

White Orange

Tip 1

1St Pair

TX-

Orange

Ring 1

RX+

White Green

Tip 2

2nd Pair

No Signal

Blue

Tip 3

3rd Pair

No Signal

White Blue

Ring 3

RX-

Green

Ring 2

2nd Pair

No Signal

White Brown

Tip 4

4th Pair

No Signal

Brown

Ring 4

TX+

White Orange

Tip 1

1St Pair

TX-

Orange

Ring 1

RX+

White Green

Tip 2

2nd Pair

No Signal

Blue

Tip 3

3rd Pair

No Signal

White Blue

Ring 3

RX-

Green

Ring 2

2nd Pair

No Signal

White Brown

Tip 4

4th Pair

No Signal

Brown

Ring 4

TX+

White Orange

Tip 1

1St Pair

TX-

Orange

Ring 1

RX+

White Green

Tip 2

2nd Pair

No Signal

Blue

Tip 3

3rd Pair

No Signal

White Blue

Ring 3

RX-

Green

Ring 2

2nd Pair

No Signal

White Brown

Tip 4

4th Pair

No Signal

Brown

Ring 4

TX+

White Orange

Tip 1

1St Pair

TX-

Orange

Ring 1

RX+

White Green

Tip 2

2nd Pair

No Signal

Blue

Tip 3

3rd Pair

No Signal

White Blue

Ring 3

RX-

Green

Ring 2

2nd Pair

No Signal

White Brown

Tip 4

4th Pair

No Signal

Brown

Ring 4

If you have RJ-11 phone cable connect to RJ45 Phone socket as above table, you will access 3rd pair of

phone cable. For example, if you plug-in RJ-11 cable to position 1 RJ45 socket, you will access to FXS

port 3. If you plug-in RJ11 to position 4 RJ45 socket, you will access to FXS port 15.

RJ-21 Position 1

Line

FXS port

T10

R10

T11

R11

RJ-21 Position 2

Line

FXS port

T10

R10

T11

R11

1-5 QUICK SETUP

Note:

Please use Windows IE 8.0 web browser or above version to

configure FXS gateway webpage setting. Welltech products

don’t support other Web Browser such as FireFox or Google

Chrome to configure. Otherwise, the configuration from

webpage can’t be saved successfully.

Setp1: Setup the administrative PC’s IP address to be the same as WellGate

3232s and connect the Ethernet cable into LAN port. Start IE8.0 (or later

version) to navigate Wellgate 3232s web management system by typing the

default URL which is http://192.168.123.123 (through LAN port) or

http://10.1.1.3 (through WAN port).The screen will display User Name and

Password (the default user ID is root and user password is root). (See figure

1-5-1 web access)

LAN port provides static IP address. If you want to use computer to configure

this gateway, your Computer need to set up Ethernet interface to static IP and

stay the same IP segment with LAN port. With factory default IP address of

LAN port at 192.168.123.123, please change your computer’s IP address to

192.168.123.100 to access this gateway.

Figure 1-5-1 web access

Step 2: After login, the screen shows the factory default setting at Home page

of WellGate 3232s. (See figure 1-5-2 Network configure-1)

Figure 1-5-2 Network configure-1

Change Default IP Network:

Step 3: After successfully login to the system, you need to change the

network configuration. Click Device Setting --> Network to setup the SIP

service network interface at WAN port parameters. Enter the desire IP

address, subnet mask and default gateway or selected to “DHCP” or “PPPoE”.

Apply the change by clicking Apply button as figure (See Figure 1-5-3

Network configure-2).

Figure 1-5-3 Network configure-2

Note: if you change WAN port IP address to DHCP, and do not install DHCP

Server to WAN port, this gateway will restart every 60 seconds periodically.

Inhaltsverzeichnis

Andere WELLTECH Tor Handbücher

WELLTECH

WELLTECH 2540 FXO Bedienungsanleitung

WELLTECH

WELLTECH WellGate 5250 Bedienungsanleitung

WELLTECH

WELLTECH Wellgate 26xx Series Bedienungsanleitung

WELLTECH

WELLTECH WellGate 2880 Bedienungsanleitung

WELLTECH

WELLTECH WILLGATE26XX - RELEASE NOTE V106C Bedienungsanleitung

WELLTECH

WELLTECH 3802 - RELEASE NOTE V106 Bedienungsanleitung

WELLTECH

WELLTECH FXO - RECORD NEW GREETING Bedienungsanleitung

WELLTECH

WELLTECH WILLGATE2626 - RELEASE NOTE V106A Bedienungsanleitung

WELLTECH

WELLTECH FXSO GATEWAY H.323 3701A - VERSION 2.1A Bedienungsanleitung

WELLTECH

WELLTECH 3701 - RELEASE NOTE V106 Bedienungsanleitung

WELLTECH

WELLTECH WELLGATE 2626 Bedienungsanleitung

WELLTECH

WELLTECH 2504 Bedienungsanleitung

WELLTECH

WELLTECH 2424s FXS Bedienungsanleitung

WELLTECH

WELLTECH WellGate M4 Bedienungsanleitung

WELLTECH

WELLTECH 3502 - RELEASE NOTE V114 Bedienungsanleitung

WELLTECH

WELLTECH FXO - ACHIEVE ONE-STAGE DIALING Bedienungsanleitung

WELLTECH

WELLTECH WILLGATE26XX - RELEASE NOTE V105B Bedienungsanleitung

WELLTECH

WELLTECH WellGate M1 Bedienungsanleitung

WELLTECH

WELLTECH WILLGATE26XX - RELEASE NOTE V106A Bedienungsanleitung

WELLTECH

WELLTECH FXO SIP GATEWAY - V105 Bedienungsanleitung

WELLTECH

WELLTECH 5290 - SS7 PARAMETERS REQUIREMENT Bedienungsanleitung

WELLTECH

WELLTECH 3502 - RELEASE NOTE V113 Bedienungsanleitung

WELLTECH

WELLTECH WELLGATE 2522 Bedienungsanleitung

WELLTECH

WELLTECH WILLGATE2626 - RELEASE NOTE V106B Bedienungsanleitung

Beliebte Tor Handbücher anderer Marken

LST

LST M500RFE-AS Bedienungsanleitung

Kinnex

Kinnex Media Gateway Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace 2N StarGate Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Bedienungsanleitung

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Bedienungsanleitung

Telsey

Telsey CPVA 500 - SIP Bedienungsanleitung

RTA

RTA 460A-NNA4 Technisches Datenblatt

Shaw

Shaw Gateway HDPVR Bedienungsanleitung

ABB

ABB VSN900 Kurzanleitung

Commander

Commander Pulse Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Bedienungsanleitung

NETGEAR

NETGEAR C6300BD Bedienungsanleitung

Amit

Amit CDW531AM Bedienungsanleitung

HMS

HMS Netbiter EasyConnect EC150 Bedienungsanleitung

Huawei

Huawei EchoLife HG620 Bedienungsanleitung

AT&T

AT&T U-verse 3801 Gebrauchs- und Pflegehandbuch

Logic IO

Logic IO RTCU MX2 turbo Bedienungsanleitung

Suttle

Suttle MediaMAX MXM-521 Bedienungsanleitung
