West Bend Studio Toaster Bedienungsanleitung
Instruction Manual
201 West Bend a Brand of Focus
SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE
Products Group International, LLC.
TM
,3
TOASTER OVEN
2
Important Safeguards..................................................................................................................
...........................................................................................................................4
One Year Limited Warranty......................................................................................................
Control Settings
How To Use..................................................................................................................................5
Care And Cleaning.......................................................................................................................9
.
Before First Use...........................................................................................................................3
Manufactured and Distributed by Midea America Corp., Authorized Licensee,
Parsippany, NJ 07054
10
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed,
including the following:
. Read all instructions before using.
To protect against any electrical hazards, Do not place unit or cord in water or
any other liquids.
Do not touch any hot surfaces. Use oven mitts for removing or touching any hot
parts. Always place Toaster Oven on heat protected surface.
Unplug the unit from outlet when not in use and before cleaning. Always allow to
cool before attaching or removing any parts.
The use of accessory attachments not recommended by the appliance manufacturer
may cause injuries.
Always pull the plug out from the wall – never pull the cord. Remove the plug from
the wall before moving the appliance. Use both hands to move the appliance.
Do not let cord hang over edge of table or counter, or touch hot surface.
Do not place the toaster oven inside a heated oven or near a hot flame or electric
burner.
Do not use outdoors
If the electric circuit is overloaded with other appliances, this appliance may not
operate properly. The toaster oven should be operated on a separate electrical
circuit from other operating appliances.
The temperature of accessible surfaces may be high when the appliance is operating.
If the supply cord is damaged, it must be replaced by the manufacturer. Do not
attempt to repair this product yourself. See warranty page for information.
Store only the accessories provided with this unit inside the oven when not in use.
Do not store any other materials.
A fire may occur if the appliance is covered or touching flammable material, including
curtains, draperies, walls, and the like, when in operation. Do not put any items
on top of the appliance when in operation.
Do not place any cardboard, paper or plastic inside the oven.
All containers placed inside the oven must not be airtight. Also, they need to have
enough room to allow for expansion of fluids.
Clean this appliance regularly as build – up of grease may cause a fire. Make
sure that this appliance is not placed near curtains, any drapery, or other flammable
material.
Do not clean with metal scouring pads. Pieces can break off the pad and touch
electrical parts involving a risk of electric shock.
In order to prevent accidental burns, always use the handle and knobs to operate
this appliance.
The temperature of the door or outer surface may be high when the appliance
operating.
CAUTION
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
English-2
. Oversize foods or metal utensils must not be inserted in a toast oven as they
may create a fire or risk of electric shock.
Do not cover crumb tray or any part of the oven with metal foil. This will cause
overheating of the oven.
Extreme caution should be exercised when using containers constructed of
other than metal or glass.
This appliance is not intended for use by persons (including children ) with
reduced physical, sensory or mental capabilities. Or lack of experience and
knowledge unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
The appliance is not intended to be operated by means of an external timer or
separate remote-control system.
The rear surface of appliance should not be placed against a wall.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
BEFORE FIRST USE
1. Remove all accessories and shipping materials packed inside the oven.
2. Wash the racks and pan in warm soapy water. Wipe the inside of the oven with a
damp cloth or sponge. Blot dry with paper towels to be sure the unit is dry before
using.
3. Place oven on a flat counter or other stable surface with at least 6" clearance from
ANOTHER APPLIANCE.
4. Make sure the crumb tray is properly installed before using. Place crumb tray in the
, set the temperature knob to 450, and the timer control
minutes. This will burn off any oils still on the oven.
NOTE: The oven may smoke during this process. This is normal for a new oven and
will not last more than 10-15 minutes.
walls, curtains or cabinets. DO NOT OPERATE ON THE SAME CIRCUIT WITH
Before using for the first time
to 15
.
.
.
.
.
.
bottom o the oven, under the heating elements.f
English-3
CONTROL SETTINGS
TIME SETTING
0-120 MINUTES: The timer can be set up to 120 minutes.
The oven will not turn on without the timer being set.
When the timer control is in the “OFF” position, the
oven will not operate. To set the time, turn the timer
Indicator light is lit only when time has been set.
When the timer has reached the "OFF" position, a bell
sound and the oven will turn off automatically.
ADJUSTING TIME
Time can be changed during the cooking cycle.
urn the timer to the desired time and continue
cooking.
NOTE: To select a cooking time less than 40 mins,
back to the time you require.
TEMPERATURE SETTING
Turn the temperature control clockwise to the desired
temperature setting. The temperature can be set
from 150 F to 450 F
o
o
NAME OF PARTS
Baking racks (2)
Baking tray/drip pan
Rotisserie fork
elper handle
TEMP °F
FUNCTION
TIME(Min) Off
20
40
60
80
100
120
Stay on
150
250350
450
POWER
OFF
H
1
2
3
4
1. Temperature control
2. Indicator light
3. Function control
4. Timer control
5.
6.
7.
8.
9. Crumb tray (not pictured)
5678
control clockwise to the desired time.
T control
turn the timer control to 40 mins, and then turn the
control counter clockwise
.
STAY ON
NOTE: Bread may catch fire if the time is set too long.
uring toasting.
To use the oven without time control, turn the timer
will work until the timer control is set to "OFF" position.
control to position "Stay On". In this position, the oven
Close supervision is necessary d
English-4
FUNCTION SETTINGS
This oven offers four different functions for versatile cooking all in one appliance.
Bake: The heating elements are working during this function.
Broil: The upper heating elements are working during this cycle.
Toast: The upper and lower heating elements are working during this function.
Rotisserie: The upper heating elements, rotisserie, and convection feature are
working during this function.
HOW TO USE
CAUTION: THE OVEN SURFACES ARE HOT DURING AND AFTER USE
GENERAL INSTRUCTIONS
1. Place the Baking Rack in position that will accommodate the height of the food to be
cooked. Place the in the bottom of the oven, under the heating ele
2. Set the food on the Rack. Make sure that you always use an ovenproof container in
the oven, never use plastic or cardboard containers in the oven.
3. Never use glass or ceramic pans or lids.
4. DO NOT let juices run to the bottom of the oven. Use the drip tray and crumb tray
when cooking.
5. Set the temperature as suggested by the recipe or as desired.
6. Securely close the door and set the function and cooking time to begin operating
the oven.
ments.
lower
crumb tray
English-5
TOAST FUNCTION:
Use the Toast Function for foods such as pizza, toasting, bread, cookies and reheating food.
1. Place the baking rack to the desired height.
2. Set the function control to " ".
BROIL FUNCTION:
The Broil Function is ideal for fish, beef, steak, vegetables, etc.
1. Place the baking rack to the desired height.
2. Set the function control to " ".
3. Select the length of time you want to broil the food.
4. Set the temperature control to the 450 F, for best broiling performance.
BAKE FUNCTION:
Use the bake function for foods such as less tender cuts of meat, cakes and casseroles.
1. Place the baking rack to the desired height.
2. Set the function control to " ".
3. Select the length of time you want to bake the food.
4. Set the temperature control to desired temperature.
NOTE: Maximum length of time for toasting bread is 7 minutes. Bread may catch fire if the
toasting time is set longer. Close supervision is necessary.
3. Set the temperature control to the desired temperature.
NOTE: Always check food temperature to ensure proper internal temperatures have been
have been reached. Remove food with oven mitts. Food and oven surfaces are hot.
1. Remove both baking racks from the oven.
Do Not attempt
then place baking pan on the baking rack.
CONVECTION/ROTISSERIE FUNCTION:
Place one baking rack upside down in the
lowest position of the oven,
ook the food.
. Set the temperature control to desired temperature.
to rotisserie cook without using the baking pan on the baking rack.
o
c
2. Set the function knob to " ".
3. Select the length of time you want to
4
English-6
ROTISSERIE FUNCTION USING THE ROTISSERIE FORKS:
1. Insert the pointed end of the spit through one of the forks, making sure the points of
towards the square end of the spit and secure with the thumbscrew.
2. Place the food to be cooked onto the spit by inserting the spit (pointed away from you)
directly through the center of the food embedding it completely.
3. Slide the second fork onto the spit at the other end of the roast or poultry. Continue to
slide the fork until it is securely embedded in the food. Secure the fork with the
Note: Foods may change shape during cooking. Check to make sure there is at least a
5. Set the temperature and the time controls to begin operating the oven.
6. Once the cooking time has been complete, and you have checked the internal
temperature of the food to ensure that it has cooked properly, remove the
otisserie s with the elper andle.
you.
10. Place the food on a heat safe plate or dish when you have removed from the oven.
Let it cool slightly before attempting to remove the holding forks and spit from the
food.
11. To remove the holding forks, turn the screws counterclockwise.
12. Carefully slide the food off of one side of the spit onto a heat safe plate or dish.
the fork face in the same direction as the pointed end of the spit. Slide the fork
thumbscrew. Ensure the food is centered on the spit.
1" clearance between food and heating elements at all times during the cooking cycle.
4. Insert the pointed end of the spit in to the drive socket located on the right-hand side of
the oven wall. Make sure the square end of the spit rests in the spit.
r pit h h
7. Place the hooks on the helper hander underneath the rotisserie spit.
8. Lift the left side of the spit out of the bracket first and pull slightly toward
9. Gently remove the right side of the spit Forks from the socket.
English-7
BAKING RACK LEVELS
There are 4 rack levels. The baking rack can be slid into the groove for either level.
12
34
BAKING TRAY
The tray must be put on the grill rack.
It can not be put on the bottom heating element.
ROTISSERIE LEVELS
PIZZA LEVELS
Place the grill racks like the picture on the right
when baking two pizzas.
English-8
When using the rotisserie, the grill rack should be
placed in the lowest position, upside down.
CARE AND CLEANING
cool completely.
CAUTION: Before cleaning any part of the oven, always set the timer and function
controls to ''OFF,'' unplug the cord from the electrical outlet and allow the oven to
To keep your countertop oven clean, wipe away food spills, spatters, and crumbs
after each use.
1. The oven rack, bake/drip pan, and crumb tray may be washed in warm, soapy
water with a dishcloth, rinsed and dried or in an automatic dishwasher. Do not
use any metal or abrasive scouring pads or cleansers on these parts as damage
to the finish may occur.
Do not use any type of scouring pad or cleaner on the exterior surfaces or the
glass door as scratching will occur. If glass is scratched, it can weaken and shatter.
. Wipe the interior of the oven with a damp cloth, wipe clean and dry. Do not use
any metal or abrasive scouring pads, cleansers, or oven cleaner on the inside of
oven, as damage will occur. Be careful when wiping around the heating elements
to prevent damage.
2. Wipe the exterior of the oven and glass door with a soft, damp cloth and dry.
3
English-9
This product carries a warranty that it will be free from defects in material and
workmanship for a period of one year from the date of purchase. This warranty is valid
for the original retail purchaser from the date of initial retail purchase and is not
transferable. Keep your original sales receipt.
IMPORTANT: This warranty does not cover damages resulting from accident, misuse or
abuse, lack of reasonable care, the affixing of any attachments not provided with the
product, loss of parts, or subjecting the appliance to any but the specified voltage.
(Read directions carefully ).
If service is required during the warranty period, properly pack your unit. We
recommend using the original carton and packing materials. Please call customer
800-842-1289
Some states do not allow this exclusion
quential losses so the foregoing disclaimer may not
rights which may vary from state to state.
SAVE THIS MANUAL AND YOUR ORIGINAL RECEIPT FOR YOUR RECORDS
Made in China
apply to you. This warranty gives you specific legal rights, and you may also have other
expressly disclaims all responsibility for consequential damages orMidea America Corp.
incidental losses caused by use of the appliance.
or limitation of incidental or conse
The serial number can be found on the back cabinet. We suggest that you record the
serial number of your unit in the space below for future reference
Model Number:_______________________
Serial Number:________________________
ONE YEAR LIMITED WARRANTY
L5 Printed in China
Midea America Corp
4 Campus drive 1st floor South
Parsippany NJ 07054
900
service number below to get the exact shipping address before sending out the unit.
8/130
English-10
Andere Handbücher für Studio Toaster
1
Inhaltsverzeichnis
Sprachen:
Andere West Bend Ofen Handbücher
West Bend
West Bend 74766 Bedienungsanleitung
West Bend
West Bend QUIKSERVE 76026 Bedienungsanleitung
West Bend
West Bend AFWB15BK13 Bedienungsanleitung
West Bend
West Bend Rotisserie Oven Bedienungsanleitung
West Bend
West Bend Chris Freytag Countertop Oven Bedienungsanleitung
West Bend
West Bend L5659B Bedienungsanleitung
West Bend
West Bend Rotary Oven Bedienungsanleitung
West Bend
West Bend Soho L5704 Bedienungsanleitung
West Bend
West Bend L5658B Bedienungsanleitung
