Western Digital 2U24 Bedienungsanleitung

EcoDesign

Disclosures

2U24 Flash Storage Platform

Regulatory Model: G224-J-12

1ET2163

Version 1.0

February 2020

EcoDesign Disclosures Table of Contents

Table of Contents

Notices........................................................................................................................................................................................ ii

Chapter 1. EU EcoDesign Disclosures............................................................................................................................................ 1

EcoDesign Overview................................................................................................................................................................. 2

2U24 Flash Storage Platform EcoDesign Specifications.........................................................................................................2

Instant Secure Erase / Secure Erase........................................................................................................................................3

2U24 Flash Storage Platform Disassembly...............................................................................................................................5

EcoDesign Disclosures Notices

Notices

Western Digital Technologies, Inc. or its affiliates' (collectively “Western Digital”) general policy does not

recommend the use of its products in life support applications wherein a failure or malfunction of the product

may directly threaten life or injury. Per Western Digital Terms and Conditions of Sale, the user of Western

Digital products in life support applications assumes all risk of such use and indemnifies Western Digital

against all damages.

This document is for information use only and is subject to change without prior notice. Western Digital

assumes no responsibility for any errors that may appear in this document, nor for incidental or consequential

damages resulting from the furnishing, performance or use of this material.

Absent a written agreement signed by Western Digital or its authorized representative to the contrary,

Western Digital explicitly disclaims any express and implied warranties and indemnities of any kind that may,

or could, be associated with this document and related material, and any user of this document or related

material agrees to such disclaimer as a precondition to receipt and usage hereof.

Each user of this document or any product referred to herein expressly waives all guaranties and warranties

of any kind associated with this document any related materials or such product, whether expressed or

implied, including without limitation, any implied warranty of merchantability or fitness for a particular

purpose or non-infringement. Each user of this document or any product referred to herein also expressly

agrees Western Digital shall not be liable for any incidental, punitive, indirect, special, or consequential

damages, including without limitation physical injury or death, property damage, lost data, loss of profits or

costs of procurement of substitute goods, technology, or services, arising out of or related to this document,

any related materials or any product referred to herein, regardless of whether such damages are based on

tort, warranty, contract, or any other legal theory, even if advised of the possibility of such damages.

This document and its contents, including diagrams, schematics, methodology, work product, and

intellectual property rights described in, associated with, or implied by this document, are the sole and

exclusive property of Western Digital. No intellectual property license, express or implied, is granted by

Western Digital associated with the document recipient's receipt, access and/or use of this document or the

products referred to herein; Western Digital retains all rights hereto.

Western Digital, the Western Digital logo, and Ultrastar are registered trademarks or trademarks of Western

Digital Corporation or its affiliates in the US and/or other countries. Linux® is the registered trademark of

Linus Torvalds in the U.S. and other countries. All other marks are the property of their respective owners.

Product specifications subject to change without notice. Pictures shown may vary from actual products. Not

all products are available in all regions of the world.

Western Digital

5601 Great Oaks Parkway

San Jose, CA 95119

Western Digital

EU EcoDesign

Disclosures

This document provides information and instructions related

to the 2U24 Flash Storage Platform's disclosures for the EU's

ecodesign requirements.

In This Chapter:

- EcoDesign Overview......................................2

- 2U24 Flash Storage Platform EcoDesign

Specifications...................................................2

- Instant Secure Erase / Secure Erase............ 3

- 2U24 Flash Storage Platform

Disassembly......................................................5

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.1 EcoDesign Overview

This document provides information about the 2U24 Flash Storage Platform related to its manufacturing and

operation, and instructions for secure data deletion and disassembly.

1.2 2U24 Flash Storage Platform EcoDesign Specifications

Product Type Data Storage

Manufacturer's Name Western Digital

Manufacturer's Registered Trade Name Western Digital®

Manufacturer's Registered Trade Address 5601 Great Oaks Parkway

San Jose, CA 95119

USA

Product Model Number G224-J-12

Starting Year of Manufacture 2016

PSU efficiency at 20%, 50%, 100%

of rated output power

20% load = 88%

50% load = 92%

100% load = 88%

Power Factor at 50% Rated Load Level Minimum Power Factor = 0.95

Declared Operating Condition Class A2

Neodymium Content in HDDs N/A (no HDDs)

Cobalt Content in Batteries N/A (no batteries)

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.3 Instant Secure Erase / Secure Erase

This section provides conceptual information and instructions for using the Instant Secure Erase (ISE) or

Secure Erase (SE) features included with Western Digital drives.

Data Erasure Options

Western Digital provides several options for securely erasing data from its drives. The appropriate method

depends upon many factors, including the following:

•Erase Configuration (ISE or SE)

•Drive Type (HDD or SSD)

•Interface Type (SAS, SATA)

•Encryption (none, TCG, or FIPS)

For more information on the sanitize command for specific drive models, please see the drive model's

specification, contact Western Digital technical support, or download the following whitepaper for details:

https://documents.westerndigital.com/content/dam/doc-library/en_us/assets/public/western-digital/

collateral/tech-brief/tech-brief-instant-secure-erase....

ISE / SE Overview

Instant Secure Erase (ISE) is Western Digital’s implementation of the industry standard T10 (SAS)/T13 (SATA)

sanitize command, allowing users to instantly erase both user-accesible data and hidden user data from

Western Digital drives.

The sanitize command supports three options:

1. Crypto Scramble (SATA) / Crypto Erase (SAS): deletes the encryption key of a self-encrypting drive.

2. Overwrite (HDDs): overwrites the data on the drive with a supplied value.

3. Block Erase (SSDs): electrically erases each storage element by modifying their voltage levels.

Secure Erase (SE) is a subset of ISE, where the Crypto Scramble / Erase option has been disabled, allowing

only the Overwrite or Block Erase options.

Requirements

To perform secure deletion, the following versions are the minimal recommended/supported utilities for

each drive interface required on the host. For other versions, please verify the arguments/parameters in the

appropriate man pages.

•SAS: sg_sanitize version 1.00 20151219 (included in sg3_utils 1.42 *)

•SATA: hdparm version 9.58

Erase Methods

The following methods cover all erasure options and storage technologies for Western Digital drives.

For more information on the sanitize command for specific drive models, please see the drive model's

specification.

Note: If a RAID adapter or software is in use, remove the drives from a RAID set before erasure.

* For details on how to use the sg3_utils v1.42 utility, visit http://sg.danny.cz/

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.3 Instant Secure Erase / Secure Erase

Note: If a drive is encrypted (TCG or FIPS), unlock the drive before executing any sanitize

commands.

Note: In the following commands, replace the generic reference of <dev> with the specific

device reference appropriate for your operating system (i.e. sgX for Linux, SCSIX:X,X,X for

Windows).

SAS

Note: In the following sg_sanitize commands, the --quick option starts the deletion

immediately. If the --quick option is not specified, the drive's inquiry response strings are

printed in case the wrong device has been specified, and the user is given 15 seconds to

reconsider whether they wish to erase all the data on the drive.

•ISE - Crypto Erase - HDD/SSD:

# sg_sanitize --crypto --quick <dev>

•SE - Overwrite - HDD:

# sg_sanitize --overwrite --quick --zero <dev>

•Block Erase - SSD:

# sg_sanitize --block --quick <dev>

SATA

•ISE - Crypto Erase - HDD/SSD:

# hdparm --yes-i-know-what-i-am-doing --sanitize-crypto-scramble <dev>

•SE - Overwrite - HDD:

# hdparm --yes-i-know-what-i-am-doing --sanitize-overwrite hex:11111111 <dev>

•Block Erase SSD:

# hdparm --yes-i-know-what-i-am-doing --sanitize-block-erase <dev>

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.4 2U24 Flash Storage Platform Disassembly

This task provides instructions for disassembling a 2U24 Flash Storage Platform to meet the EU's ecodesign

requirements.

Table 1: Procedure Info

Required Tools # of People Required Time

Required

Replacement

Window

#2 Phillips-Head Screwdriver 2 * 1 hours N/A

Powering Down the Enclosure

Step 1 : At the rear of the enclosure, locate the power cable connected to each PSU:

Step 2 : Detach the cable retention clip from the power cable:

Step 3 : Remove the power cable by pulling its plug away from the receptacle on the PSU.

Caution: To reduce the potential for damaging equipment, do not jerk the cable

out of the PSU.

Step 4 : Repeat these steps to remove the remaining power cable.

Removing the SAS Cables

Step 5 : At the rear of the enclosure, locate the three (3) HD Mini-SAS cables attached to each ESM:

* 2 people required for lifting enclosure; only 1 required for disassembly

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.4 2U24 Flash Storage Platform Disassembly

Step 6 : If the HD Mini-SAS cables will be reinstalled at a later time, ensure each is labeled or removed in

an organized manner such that it can be returned to the same port from which it was removed.

Step 7 : To remove an HD Mini-SAS cable, pull on the blue tab extending from beneath the connector.

This will free the cable from the port.

Caution: To reduce the potential for damaging equipment, do not jerk the cable

out of the ESM.

Step 8 : Repeat these steps to remove the remaining HD Mini-SAS cables.

Removing the Drives

Step 9 : At the front of the enclosure, locate the twenty-four (24) drives.

Step 10 : If the drives will be reinstalled at a later time, ensure each is labeled or removed in an organized

manner such that it can be returned to the same bay from which it was removed.

Step 11 : To remove a drive assembly, press the release button to unlatch the drive carrier from the

enclosure.

The carrier's handle should extend out of the enclosure:

Step 12 : Grasp the handle and pull the drive carrier out of the enclosure with even pressure:

EcoDesign Disclosures 1. EU EcoDesign Disclosures

1.4 2U24 Flash Storage Platform Disassembly

Step 13 : Repeat these steps to remove the remaining drives from the enclosure. Store each drive

assembly in an ESD-safe environment. Do not stack them on top of one another.

Disassembling Drive Assemblies

Step 14 : Lay a drive assembly (drive & carrier) on its side.

Step 15 : Using a #2 Phillips screwdriver, remove the four (4) M3 6mm screws from the edges of the drive

carrier:

Step 16 : Pull the drive upward to remove it from the carrier:

Andere Handbücher für 2U24

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Western Digital Lagerung Handbücher

Western Digital

Western Digital WD3001HKHGSP Bedienungsanleitung

Western Digital

Western Digital WD1000FYYG - RE SAS Montageanleitung

Western Digital

Western Digital WD Elements WDE1UBK10000 Bedienungsanleitung

Western Digital

Western Digital WDXUB3200JB - Dual-Option USB Bedienungsanleitung

Western Digital

Western Digital WD10EVCS Bedienungsanleitung

Western Digital

Western Digital WDH2Q20000 - My Book Studio Edition II Hard Drive... Bedienungsanleitung

Western Digital

Western Digital WD10000H1NC - World Edition Bedienungsanleitung

Western Digital

Western Digital caviar blue xl500s Produkthandbuch

Western Digital

Western Digital Scorpio Black WD1200BEKT Bedienungsanleitung

Western Digital

Western Digital wd Cloud Bedienungsanleitung

Western Digital

Western Digital WD3200AAJB - Caviar 320 GB Hard Drive Bedienungsanleitung

Western Digital

Western Digital Scorpio Blue WD1200BEVE Bedienungsanleitung

Western Digital

Western Digital WDG1SU3200N - My Book Premium ES Edition 320 GB External Hard... Montageanleitung

Western Digital

Western Digital MY PASSPORT WDBYNN0010BWT Bedienungsanleitung

Western Digital

Western Digital Caviar WD2000JD Bedienungsanleitung

Western Digital

Western Digital WDBMWV0020BBK Bedienungsanleitung

Western Digital

Western Digital My DVR Expander Bedienungsanleitung

Western Digital

Western Digital My Book Studio Bedienungsanleitung

Western Digital

Western Digital WDBAAF6400EBK - My Book Essential Bedienungsanleitung

Western Digital

Western Digital My Passport Ultra Bedienungsanleitung

Western Digital

Western Digital My Passport Pro Bedienungsanleitung

Western Digital

Western Digital WDBAAH0015HCH - My Book Elite Bedienungsanleitung

Western Digital

Western Digital WD1600AVBB Bedienungsanleitung

Western Digital

Western Digital WD1500AHFD - Raptor X 150 GB Hard Drive Montageanleitung

Beliebte Lagerung Handbücher anderer Marken

QNAP

QNAP TS 32PXU Series Bedienungsanleitung

LaCie

LaCie RUGGED RAID Bedienungsanleitung

Freecom

Freecom CLS DOCK Bedienungsanleitung

PNY

PNY Attache P-FD64MBATT3 Bedienungsanleitung

HP StorageWorks MSL2024 Bedienungsanleitung

OLT

OLT 6x6 Maximizer Bedienungsanleitung

Transcend

Transcend JetFlash 160 Bedienungsanleitung

LaCie

LaCie RUGGED MINI Bedienungsanleitung

Thunderbolt

Thunderbolt 600 Bedienungsanleitung

Panasonic

Panasonic LB-DH8 series Handbuch

Intel

Intel RAID High Availability Bedienungsanleitung

LaCie

LaCie 12big Thunderbolt 3 Bedienungsanleitung

Spectra Logic

Spectra Logic T-Series Spectra T50e Bedienungsanleitung

Panasonic

Panasonic LKM-F931-1 Bedienungsanleitung

Tabernus

Tabernus Enterprise Erase E2400 Bedienungsanleitung

Rocstor

Rocstor COMMANDER 3F series Bedienungsanleitung

HP P9000 Bedienungsanleitung

Dell

Dell PowerVault MD3600f Series Bedienungsanleitung
