Western Digital Caviar WD1601ABYS Bedienungsanleitung

Enterprise Hard Drives

Interface

Width/Height

Rotational Speed

Capacities

Model Numbers

3.5-inch/1-inch

160 to 750 GB

WD1601ABYS

WD2502ABYS

WD3201ABYS

WD4000ABYS

WD4001ABYS

WD5000ABYS

WD5001ABYS

WD7500AYYS

Note: Not all products

may be available in all

regions of the world.

WD RE2 hard drives are the world’s most reliable server-class SATA drives in

the market. With 1.2 million hours MTBF, 5-year limited warranty, 3 Gb/s

SATA technology, and best-in-class vibration tolerance, WD RE2 drives offer

the best combination of superior reliability, high capacity, and optimum

performance for enterprise applications.

Product Benefits

Superior reliability - Designed and manufactured to server-class standards to provide

best-in-class enterprise reliability in high duty cycle environments. With 1.2 million hours

MTBF, these drives have the highest available reliability rating on a high-capacity drive.

High capacity - Up to 750 GB of storage packed with server-class features and low

cost-per-gigabyte value.

Fast - With a next-generation SATA interface, 3 Gb/s data transfer rate, Native Command

Queuing (NCQ), and 16 MB cache, these drives deliver optimum performance.

Low power - Active Power Save™delivers best-in-class seek mode power consumption

through an advanced WD firmware which conserves power in active seek modes without

degrading performance.

RAID-specific, Time-Limited Error Recovery (TLER) - A feature pioneered by WD,

significantly reduces drive fallout caused by the extended hard drive error-recovery processes

common to desktop drives.

Rotary Acceleration Feed Forward (RAFF™)- Provides best-in-class vibration tolerance

by optimizing operation and performance when the drives are used in vibration-prone,

multidrive systems such as rack-mounted servers or network storage.

5-year limited warranty

Applications

Servers, network attached storage, scientific computing, life sciences, video surveillance,

enterprise backup, software build systems, document and image management, audio/video

media applications, other demanding write-intensive applications.

The WD Promise

WD understands the importance of the information you save to your hard

drive and we are committed to protecting that data with exceptionally reliable

products, advanced data protection technology, and superior customer support.

No one does more to safeguard your data than WD.

7200 RPM

SATA

WD RE2

Enterprise Hard Drives

1.2 Million Hours MTBF

High Capacity

24 x 7 Reliability

Enterprise Hard Drives

For service and literature:

support.wdc.com

www.westerndigital.com

Western Digital, WD, and the WD logo are

registered trademarks in the U.S. and other

countries; and the FIT Lab logo, Active Power

Save, and RAFF are trademarks of Western

Digital Technologies, Inc. Other marks may

be mentioned herein that belong to other

companies. Product specifications subject to

change without notice.

Western Digital

20511 Lake Forest Drive

Lake Forest, California 92630

U.S.A

2879-701176-A10 Feb 2008

800.ASK.4WDC North America

949.672.7199 Spanish

+800.6008.6008 Asia Pacific

+31.20.4467651 EMEA

Drive Specifications

160 GB 250 GB 320 GB 400 GB 500 GB 750 GB

Formatted capacity1160,041 MB 250,059 MB 320,072 MB 400,088 MB 500,107 MB 750,156 MB

User sectors per drive 312,581,808 488,397,168 625,142,448 781,422,768 976,773,168 1,465,149,168

Model number WD1601ABYS WD2502ABYS WD3201ABYS WD4000ABYS WD5000ABYS WD7500AYYS

WD4001ABYS WD5001ABYS

Actuator latch/auto park Yes Yes Yes Yes Yes Yes

Bytes per sector (STD) 512 512 512 512 512 512

Dedicated landing zone Yes Yes Yes Yes Yes Yes

Form factor 3.5-inch 3.5-inch 3.5-inch 3.5-inch 3.5-inch 3.5-inch

Interface SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s

Native Command

Queuing Yes Yes Yes Yes Yes Yes

RoHS compliant2Yes Yes Yes Yes Yes Yes

1 One gigabyte (GB) = one billion bytes. One terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment.

2WD products manufactured and sold worldwide after August 1, 2005, meet or exceed Restriction of Hazardous Substances (RoHS) compliance requirements as

mandated by the European Union for electrical and electronic products. The RoHS Directive 2002/95/EC of the European Parliament, which is effective in the EU

beginning July 1, 2006, aims to protect human health and the environment by restricting the use of certain hazardous substances in new equipment, and consists of

restrictions on lead, mercury, cadmium, and other substances.

3Maximum drive capacity model.

4After 24 power-on hours.

5Average idle run current and power measured with power supply at nominal voltage and 35°C ambient.

6No non-recoverable errors during operating test or after non-operating tests.

720 KHz cutoff.

8Sound power level.

Power Requirements (ABYS models)3

Power Requirements (AYYS models)

Note: 3.3V Serial ATA power not used in this product.

Mode 12V (±10%) 5V (±5%) Power

Idle 5450 mA 600 mA 8.4W

Read/Write 470 mA 660 mA 8.9W

Sleep 6 mA 170 mA 0.9W

Standby 6 mA 170 mA 0.9W

Mode 12V (±10%) 5V (±5%) Power

Idle 5490 mA 535 mA 8.5W

Read/Write 545 mA 685 mA 10.0W

Sleep 6 mA 180 mA 0.97W

Standby 6 mA 180 mA 0.97W

WD RE2

Enterprise Hard Drives

Physical Dimensions

Environmental Specification6

Shock

Note: Half-sine wave, measured in 2 ms duration and without

isolation.

Vibration

Operating Temperature and Humidity

Non-Operating Temperature and Humidity

Acoustics (Average) 3

Height 1.028 in (25.4 mm)

Length 5.787 in (147.0 mm)

Width 4.0 in (101.6 mm) ±0.01 in

Weight 3 1.61 lb (0.73 kg) ±10%

Operating (2 ms) 30G (write), 65G (read)

Non-operating (1 ms) 250G

Operating

Random 0.004 g2

/Hz (10 to 300 Hz)

0.008 g2

/Hz (300 to 500 Hz)

Linear 20–300 Hz, 0.75G (0 to peak)

Non-operating

Random 0.05 g2

/Hz (10 to 300 Hz)

0.01 g2

/Hz (300 to 500 Hz)

Linear 20–500 Hz, 4.0G (0 to peak)

Temperature 5°C to 55°C

Humidity 5–95% RH non-condensing

Thermal gradient 20°C/hour (maximum)

Temperature –40°C to 65°C

Humidity 5–95% RH non-condensing

Thermal gradient 30°C/hour

Idle mode 728 dBA

Performance seek mode834 dBA

Quiet seek mode 30 dBA

Performance Specifications

Average latency 4.2 ms

Buffer 16 MB

Cache

Read Adaptive

Write Yes

Data transfer rate

Buffer to host 3 Gb/s (maximum)

Buffer to disk398 MB/s (sustained)

Drive ready time 12.0 sec (average)

Error rate

(non-recoverable) <1 in 1015 bits read

LBA support Yes

MTBF41,200,000 hours

Rotational speed 7200 RPM

Seek time

Full stroke 21 ms (average)

Read 8.9 ms (average)

Track-to-Track 0.6 ms (average)

Limited warranty 5-year
