Western Digital WDH1Q10000 - Studio Edition Bedienungsanleitung

Formatted for Mac, the My Book Studio Edition II treads

lightly on the earth and carries big performance for creative

professionals.

•The speed you need –Lightning-fast FireWire®800 combined

with RAID 0 (Striped) yields the speed you need for smooth

video editing, rendering complex 3D objects or special effects,

and saving huge blocks of data in record time.

•Cooler, quieter, eco-friendlier –Designed to use only

WD’s GreenPower™ drives, this system uses about 30% less

energy * than standardsystems and runs quietly because it

doesn’t need a fan.

•Formatted for Mac – Works with Apple’s Time MachineTM

software. Includes software and instructions for reformatting to

Windows®.

My Book

Studio Edition™II

Formatted for Macintosh

Quad interface

RAID enabled

Fast, Green,

and Mac®Ready

Uses high-speed

FireWire 800 and

eSATA connections.

Pre-configured to

RAID 0 (Striped).

Cooler. Quieter.

Eco-friendlier.

User servicable.

Automatic backup

software.

Capacity gauge shows

available storage space.

Dual-drive Storage System

After the lights, the camera

and the action, it’s all about

the data.

–JeffKillian

Videographer

*Tests based on comparison between a 1 TB dual-drive system using 7200 RPM drives and a 1 TB dual-drive system using WD’s GreenPower drives.

Interfaces

FireWire 800 eSATA

FireWire 400 USB 2.0

Dimensions

Height: 6.54 in (166 mm)

Width: 3.87 in (98 mm)

Depth: 6.06 in (154 mm)

Weight: 5.2 lb (2.63 kg)

System Compatibility

Mac OS X 10.4.10+, 10.5.2

Windows Vista/XP/2000

Compatibility may vary depending on user’s

hardware configuration and operating system.

Capacities and Model Numbers

1TB WDH2Q10000

2TB WDH2Q20000

Limited Warranty

5years1

Kit Contents

Dual-drive storage system

FireWire 800 cable

FireWire 800 to 400 cable

USB cable

AC adapter

SoftwareCD

Quick Install Guide

Product Specifications

Pre-configured to RAID 0 (Striped)

Configurable to RAID 1 (Mirrored)

Data transfer rate:

FireWire 800 Mb/s (maximum)

eSATA 3Gb/s (maximum)

USB 480 Mb/s (maximum)

AC input voltage 100-240V

AC input frequency 47-63 Hz

Temperature:

Operating 5°Cto 35°C

41 F to 95 F

Non-operating -20°C to 65°C

-4 F to 149 F

1The termof the limited warranty may varyby region.

Visit support.wdc.com/warranty for details.

Western Digital, WD, the WD logo, Put Your Life On It and My Book are registered trademarks in the U.S. and other countries; Studio Edition and GreenPower are trademarks of

Western Digital Technologies, Inc. Other marks may be mentioned herein that belong to other companies. Pictures shown may vary from actual product. Not all products may be

available in all regions of the world. All product and packaging specifications subject to change without notice. The term of your limited warranty is for 5-years, unless otherwise

required by law. Please visit our web site at support.wdc.com/warranty for the detailed terms and conditions of our limited warranty.

One gigabyte (GB) = one billion bytes. One terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on

operating environment. RAID 0 (Striped) accesses the full capacity of the drives. RAID 1 (Mirrored) accesses half of the total capacity for data protection.

Herearesome examples of how much you can store.

4178-705012 A00 Apr 2008

Photos

Hours

Songs

1TB 2TB

284,000 571,000

76 150

250,000 500,000

up to up to

or or

oror

Examples of the number of photos, songs, videos and any other files that can be stored on a hard drive are provided for

illustrative purposes only. These numbers reflect a dual drive storage system using the full capacity (RAID 0). Your results will

vary based on file size and format, settings, features, software and other factors.

My Book Studio Edition II

Dual-drive Storage System

Automatic backup software – Back up important projects to multiple

destinations including file servers, portable drives and My Book. Set it

and forget it; every time you save a change it’s automatically backed

up.

User serviceable – Want to upgrade a drive? Simply open the case

and replace the existing drive – no screwdriver needed.

Capacity gauge –See at a glance how much space is available on

your storage system.
