Western Digital WDXML400UE - Passport 40 GB External Hard... Montageanleitung

CAPACITIES

ORDER NUMBERS

SOFTWARE

INTERFACE

Portable Storage

WD Passport

Portable Hard Drives

USB Powered

Sync & Encrypt Software

Rugged Design

™

USB 2.0 and 1.1

60 to 120 GB

WDXML600UExx

WDXML800UExx

WDXML1000UExx

WDXML1200UExx

Note: Not all products

may be available in all

regions of the world.

High-speed, easy-to-use, reliable add-on storage — the portable headquarters for your digital

life. Simply plug in your WD Passport Portable Hard Drive to back up and save your valuable

digital files.

Product Features

!Easy to use — simply plug it in and go.

!Maximum protection from data loss with a rugged, protective case, and highly shock-tolerant

WD 2.5-inch hard drive.

!Small and light. Elegant, energy-absorbing, soft-touch case provides easy handling.

!USB-powered. No separate power supply needed for most systems.*

!Cool-running hard drive and specially designed case make this a cool, safe place for your data.

!Ultra quiet.

!Fast, 5400 RPM performance.

!Power-conserving design preserves notebook battery life.

!Protected by Data Lifeguard™.

!Safety tested — one of the few external drives with certification to meet all applicable safety

requirements.

!WD Sync — synchronization and encryption software that lets you securely take your data

with you, edit files, read e-mail, view photos on any PC, and sync your changes to your home

or office computer.

Applications

!Add storage instantly for all your business files, music, video, and games.

!Back up your existing notebook hard drive for extra data safety.

!Easily share files between computers.

!Turn any PC into your own protected workspace with WD Sync synchronization and

encryption software (included).

Compatibility

Kit Contents

!WD Passport Portable USB Drive

!22-inch USB 2.0 certified interface cable

!Quick Install Guide

*An external power adapter may be required for the few laptops with limited bus power.

Windows®Macintosh®

!Available USB port !Available USB port

!Windows 98SE/Me/2000/XP !Mac®OS 9.2.2 or Mac OS X 10.2.8 or later

WD Sync™

WD Passport

Portable HardDrives

Performance Specifications

Product Dimensions

Buffer 2 MB

Data transfer rate1Up to 480 Mb/sec

Rotational speed 5400 RPM

Read seek time 12.0 ms (average)

Height 0.83 in (21.1 mm) ± 0.10

Length 5.68 in (144.3 mm) ± 0.10

Width 3.51 in (89.1 mm) ± 0.10

Weight 0.6125 lb. (0.2778 kg)

Packaging Specifications

Retail UPC Codes

Clamshell English Metric

Retail package size 9.812 in 9.25 in 3.0 in 249.23 mm 234.95 mm 76.2 mm

Retail package weight 1.00 lb 0.45 kg

Master carton size 10.313 in 9.598 in 10.6 in 261.95 mm 243.79 mm 269.24 mm

Master carton weight 4.25 lb 1.93 kg

Packages per master carton 4 4

Master cartons per pallet 72 72

Box English Metric

Retail package size 7.5 in 6.125 in 3.125 in 190.5 mm 155.57 mm 79.38 mm

Retail package weight 0.90 lbs 0.41 kg

Master carton size 12.5 in 7.063 in 8.35 in 317.5 mm 179.4 mm 212.09 mm

Master carton weight 4.3 lbs 1.95 kg

Packages per master carton 4 4

Master cartons per pallet 100 100

UNITED STATES CANADA EUROPE/MIDDLE EAST/AFRICA

Capacity2Order Number UPC Code Order Number UPC Code Order Number UPC Code

60 GB WDXML600UETN 7 18037 11183 4 WDXML600UETQ 7 18037 11186 5 WDXML600UETE 7 18037 11184 1

80 GB WDXML800UETN 7 18037 11192 6 WDXML800UETQ 7 18037 11195 7 WDXML800UETE 7 18037 11193 3

100 GB WDXML1000UETN 7 18037 11718 8 WDXML1000UETQ 7 18037 11722 5 WDXML1000UETE 7 18037 11719 5

120 GB WDXML1200UETN 7 18037 11411 8 WDXML1200UETQ 7 18037 11724 9 WDXML1200UETE 7 18037 11716 4

××××

Environmental Specifications

External Power Specifications (optional)

Operating temperature 5°C to 40°C

Non-operating temperature –20°C to 65°C

AC input voltage 5.0 VDC, 1.0A

The WD Promise

WD understands the importance of the information you save to your hard

drive and we are committed to protecting that data with exceptionally reliable

products, advanced data protection technology, and superior customer support.

No one does more to safeguard your data than WD.

For service and literature:

support.wdc.com

www.westerndigital.com

Western Digital and WD are registered

trademarks; and the WD logo,

WD Passport, WD Sync, and Data

Lifeguard are trademarks of Western

Digital Technologies, Inc. Other marks

may be mentioned herein that belong to

other companies. Product specifications

subject to change without notice.

Western Digital

20511 Lake Forest Drive

Lake Forest, California 92630

U.S.A.

2879-001126-A05 Jun 2006

800.ASK.4WDC North America

949.672.7199 Spanish

+800.6008.6008 Asia Pacific

+31.20.4467651 EMEA

1A USB 2.0 host and USB 2.0 certified cable are required to obtain Hi-Speed USB performance.

21 gigabyte (GB)=1 billion bytes. Total accessible capacity varies depending on operating environment.
