Safety Guidelines
Warning: This device must be operated with the original power supply, part number ADP-60CF A.
CAUTION: The power supply outlet should be located near the equipment and should be easily accessible.
Use a power cable that is properly grounded. Always use the appropriate AC cord that is certified for the
individual country. Some examples are listed below:
USA.................UL Switzerland ..... SEV
Canada.............CSA Britain ............. BASE/BS
Germany..........VDE Japan ............... Electric Appliance Control Act
IMPORTANT NOTICE CONCERNING POWER CORD SELECTION
The power cord set for this unit has been enclosed and has been selected according to the country of destination
and must be used to prevent electric shock. Use the following guidelines if it is necessary to replace the original
cord, or if it is not enclosed.
The female receptacle of the power cord must meet IEC-60320 requirements and should look like Figure A1
below:
Figure A1 Figure A2
For the United States and Canada
In the United States and Canada the male end of the plug is a NEMA5-15 style (Figure A2), UL Listed, and CSA
Labeled. For units that are mounted on a desk or table, type SVT or SJT power cords may be used. If the monitor
is placed on the floor, only SJT type cords may be used. The power cord must be selected according to the
current rating for your unit. Please consult the table below for the selection criteria for power cords used in the
United States and Canada.
Cord Type Size of Conductors in Cord Maximum Current Rating of Unit
SJT 18 AWG
16 AWG
14 AWG
10 Amps
12 Amps
12 Amps
SVT 18 AWG
17 AWG
10 Amps
12 Amps
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy, and may cause harmful interference to radio
communications if not installed and used in accordance with the instructions. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced technician for help.
FCC Warning:
To assure continued FCC compliance, the user must use a grounded power supply cord and the
provided shielded cables. Any unauthorized changes or modifications not expressly approved by
Westinghouse Digital could void the user's authority to operate this device.
5
