INSTALLATION GUIDE

COMPACT

TECHNICAL INFORMATION

External Dimensions:

W300xD515xH600mm

Capacity Bean Hopper:

1x1200gr or 2x600gr

Capacity Instant Canisters:

1x2.3L or 2x1.6L

Noise Emission: <70dB

Weight: 38kg

The Primo Compact is designed

to process whole coffee beans,

powder that is suitable for

automatic machines and fresh

milk where a milk system is fitted:

Parts Included:

Primo Compact Machine

Drip Tray and Grid

Waste Bin (inside machine)

Cleaning Container

Power Cable

Westomatic Hose set

Grinder Wrench

Canister Labels

Keys

Safety Instructions

Check the contents:

NB: The machine will have been set up to your specifications and tested at Westomatic

HQ prior to install. All parts have been assembled on the machine. The QR code inside

the machine gives access to the We:Support pages with technical information.

Important:

Ensure genuine Westomatic

water hoses are used, fitted

with a water cut-off

Ensure the power supply has

a capacity of at least 2.5W.

Ensure the surface has a

capacity of at least 50kg

Water supply requirements:

Water Pressure: 0.2 - 1.0MPa

(2-8 Bar)

Westomatic strongly recommend

using a water filter to prevent

scale build up in the parts - if this

happens the warranty becomes

void.

Flow Rate: >1L/Min

Water Temperature: <25°C

Ensure the

protective

plastic is

removed from

the spalsh back

Once in place -

Level the machine

Min Clearances:

Rear: 50mm

Above:180mm

Connect water

filter to main

water - set filter

to hardness of

local area

Place grill into

drip tray

Connect water

filter to Primo -

ensure new

hoses are used

Slide drip tray

into machine

Place the cup tray

grill onto tray and

firmly push down

to clip into place

Connect Primo

to an earthed

power socket

Westomatic will

have taken your

set up

specifications and

attached labels

These

correspond

with the

ingredient

choice canisters

Switch the Primo

Compact on -

switch located

below instant

canisters

Machine is set

up and ready to

configure

INSTALL WASTE TO BASE DRAIN

The Primo Drain Hose WVS

PN:

A screw driver

Combination Pliers

There is the option to have

plumbed drainage from the drip

tray to waste water drain:

Required Items:

NB: The machine must be

situation within close proximity

of a waste water drain - and

there needs to be height

differential to ensure the water

flows freely into the drain.

Remove the drip

tray from the

machine

Use the

screwdriver to

punch the

perforated hole at

back of drip tray

open the drain

hose outlet on

the back pf the

Primo Compact

Connect the

drain hose...

Using the

combination

pliers...

to the drio tray

connection

under the

machine

Feed the drain

hose to the waste

water outlet

Refit the drip tray

and check for any

leaks - tighten

connections if

necessary

Machine is

ready to use

INSTALL MILK FRIDGE

External Dimensions Fridge:

W230xD420xH455mm

External Dimensions Total:

W530xD515xH600mm

Capacity Milk Fridge:

4litres/8pints fresh milk

Noise Emission: <70dB

Weight: 19kg (Total: 57kg)

The milk fridge is designed to

work in combination with the

Primo Compact:
