Wetelecom WM-D200 Leitfaden

USB modem Wetelecom WM-D200

Installation and connection manual

MTS Connect 3G

• fast connecting to the Inernet network

• more mobility and freedom of movement

• maximum speed is to 3,1 Mbps

3G CDMA-450

ENG

TABLE OF CONTENTS

1. Welcome 3

1.1. The WM-D200 Package 3

1.2. Manufacturer Address 3

1.3. Important Notice 4

1.4. Safety Hazards 4

1.5. Limitation of Liability 6

2. Program Installation 7

2.1. Introduction 7

2.2. Minimum System Requirement 7

2.3. Insert RUIM Card 8

2.4. LED Status Indication 9

2.5. MTS Connect Installation and Uninstall (Windows® XP) 10

2.6. MTS Connect Installation and Uninstall (Windows® Vista/7) 16

3. Descriptions of the MTS Connect GUI 22

3.1. Launch the MTS Connect 22

3.2. Interface overview 22

4. Internet Services 24

4.1. Accessing the Internet 24

5. Settings and Information Query 25

5.1. Version Information 25

5.2. Unlocking the PIN 25

5.3. Enable/Disable PIN 25

5.4. Change PIN Code 26

5.5. Selecting Always On Top mode 26

5.6. Selecting a Pref Mode 26

5.7. Selecting a language 27

6. How to Mac OS 28

6.1. Drivers install 28

7. Product Specification 29

7.1. Technical Specification 29

ENG

1. WELCOME

Thank you for purchasing WeTelecom WM-D200 for МТS

CDMA Network!

Before installing the WM-D200, MTS Connect software

and drivers, review this user guide, which outlines the

features and functions of the WM-D200. This device

operates over the high-speed МТS networks in the

450MHz band anywhere!

1.1. THE WM-D200 PACKAGE

The МТS WM-D200 package includes USB Modem WM-

D200 with RUIM tray

1.2. MANUFACTURER ADDRESS

For customer service, contact at info@wetelecom.net.

Address : WeTelecom Co., Ltd. The’O Plus #1604

Sanbon-dong, Gunpo City, Kyunggi-do, KOREA

Phone : +82-70-8699-3873

ENG

1.3. IMPORTANT NOTICE

Due to the transmission and reception properties

of wireless communications, data can occasionally

be lost or delayed. This can be due to the variation

in radio signal strength that results from changes in the

characteristics of the radio transmission path. Although

data loss is rare, the environment where you operate

the WM-D200 may adversely affect communications.

Variations in radio signal strength are referred

to as fading. Fading is caused by several different

factors including signal reflection, the ionosphere, and

interference from other radio channels.

МТS or its partners will not be held responsible for

damages of any kind resulting from the delays or errors

in data transmitted or received with the WM-D200

device, or failure of the WM-D200 device to transmit

or receive such data.

1.4. SAFETY HAZARDS

Do not operate the WM-D200 device in an environment

that may be susceptible to radio interference resulting

in danger specifically;

1.4.1. Areas where prohibited by the law

Follow any special rules and regulations and obey all

signs and notices. Always turn off the host device and

remove the modem from the USB port when instructed

to do so, or when you suspect that it may cause

interference or danger.

ENG

1.4.2. Where explosive atmospheres may be present

• Do not operate the WM-D200 in any area where

a potentially explosive atmosphere may exist. Sparks

in such areas could cause an explosion or fire resulting

in bodily injury or even death. Be aware and comply with

all signs and instructions.

• Users are advised not to operate the WM-D200 while

at a refueling point or service station. Users are

reminded to observe restrictions on the use of radio

equipment in fuel depots (fuel storage and distribution

areas), chemical plants or where blasting operations are

in progress.

• Area with a potentially explosive atmosphere are often

but not always clearly marked. Potential locations can

include gas stations, below deck on boats, chemical

transfer or storage facilities, vehicles using liquefied

petroleum gas (such as propane or butane), areas where

the air contains chemicals or particles, such as grain,

dust or metal powders, and any other area where you

would normally be advised to turn off your vehicle

engine.

1.4.3. Near Medical and life support equipment

Do not operate the WM-D200 in any area where medical

equipment, life support equipment, or near any

equipment that may be susceptible to any form of radio

interference. In such areas, the host communications

device must be turned off. The WM-D200 may transmit

signals that could interfere with this equipment.

ENG

1.4.4. On an aircraft, either on the ground or airborne

Many airline regulations state that you must suspend

wireless operations before boarding an airplane. Please

ensure that the host device is turned off and the WM-

D200 is removed from the USB port prior to boarding

aircraft in order to comply with these regulations. The

WM-D200 can transmit signals that could interfere with

various onboard systems and controls.

1.4.5. While operating a vehicle

The driver or operator of any vehicle should not operate

a wireless data device while in control of a vehicle. Doing

so will detract from the driver or operator’s control and

operation of that vehicle. In some countries, operating

such communications device while in control of a vehicle

is an offense.

1.5. LIMITATION OF LIABILITY

The information contained in this document is subject

to change without notice and should not be construed

as a commitment by МТS.

ENG

2. PROGRAM INSTALLATION

2.1. INTRODUCTION

This section describes step-by-step method to install

WM-D200 USB MODEM and MTS Connect Software.

2.2. MINIMUM SYSTEM REQUIREMENT

2.2.1. PC Hardware

• Recommend to use PC/Notebook at speed of 300 MHz

or higher. Minimum 233 MHz speed required, Intel

Pentium/Celeron products, AMD K6/Athlon/Duron

products or compatible processors

• Recommend to use 128MB RAM or higher

• Minimum of 64MB memory is required, however, the

performance will be degraded and certain features will

be limited.

• At least 100 MB of free hard disk space is required.

• Motherboard or PCI card that supports USB.

• Video adaptor with Super VGA (800 × 600) or higher

resolution and Monitor

• CD-ROM or DVD Optical Drive

• Keyboard and Mouse

ENG

2.2.2. Operating System

• Windows® XP Home or Professional ( with Service Pack 2 )

• Windows® 2000 (with Service Pack 4 for optimal

performances)

• Windows® Vista

• Windows® 7

• Mac OS

Recommended parameters

Windows Update: Keep your computer up to date

2.3. INSERT RUIM CARD

• Insert RUIM card into Tray in proper direction as shown

below.

ENG

• Insert Tray into USB Modem. (Double check the position

of the tray.)

2.4. LED STATUS INDICATION

LED COLOR STATUS INFORMATION

Green + Red Internet Connection Status

Green + Blue System IDLE Status

Green only The modem is Powered on but there

is no service

ENG

2.5. MTS CONNECT INSTALLATION AND

UNINSTALL (WINDOWS® XP)

2.5.1. MTS Connect Installation (Automatic)

• Connect the modem to USB port. If USB DRIVER is not

present, Modem package Installer will run automatically.

Note:

If Modem package Installer doesn’t work automatically,

Execute RunPack.exe manually.

• Select the desire language as shown below.

• Press [OK] button to proceed. By pressing [Cancel]

button, the installation of MTS Connect program will

be aborted.
