Whirlpool ADG1900 Bedienungsanleitung

5019 396 91700

Quick Reference Guide Before using the dishwasher, read

the user and installation instructions!

GB

Whirlpool is a registered trademark of Whirlpool USA

1) Reference programme for energy label in compliance with EN 50242 regulations.

2) Refer to “User Instructions”.

NOTE: Wash times can vary depending on the incoming water temperature, ambient conditions, type of dish load and whether the drawer has been opened during the wash.

Wash times are only APPROXIMATE on the Electronic display and based on 20°C incoming water.

Programme chart Eco Option

button Detergent 2) Consumption using

one drawer

(single drawer)

Consumption using

two drawers

(double drawer)

Programmes Loading Instructions 1. Prewash

compartment 2. Main wash

compartment Litres kWh Minutes Litres kWh Minutes

Intensive 70°C Heavily soiled pots, pans & dishes. - X X 15.0 0.97 130 30.0 1.94 130

Intensive Eco 60°C Heavily soiled every day dishes. X X X 12.5 0.76 125 25.0 1.48 125

Normal 65°C Dishes with normal soils for optimum

wash & dry performance. - X X 12.0 0.81 111 24.0 1.57 111

Normal Eco 1) 50°C Normal soiled dishes for optimum energy use. X X X 12.0 0.67 180 24.0 1.30 180

Rapid 50°C Lightly soiled dishes. - - X 7.5 0.47 56 15.0 0.89 56

Rapid Eco 45°C Lightly soiled non greasy dishes. X - X 7.5 0.34 42 15.0 0.66 42

Delicate 55°C Lightly soiled and heat-sensitive crockery

such as crystal ware. - - X 10.0 0.62 96 20.0 1.22 96

Delicate Eco 45°C Non greasy, lightly soiled & heat sensitive

crockery such as crystal ware. X - X 10.0 0.46 91 20.0 0.89 91

Pre-Rinse cold To prevent odours & soil drying on dishes. - - - 3.0 0.03 12 6.0 0.05 12

3gb91700.fm Page 1 Thursday, September 5, 2002 10:07 AM

Black process 45.0° 100.0 LPI

5019 396 91700

Whirlpool is a registered trademark of Whirlpool USA

The s are tested to EN50242 standards for both wash and dry performance.

The following are loading pattern diagrams, detergent quantities and rinse aid quantities used

for the .

DISHWASHER STANDARDS TEST

Wash Programme Normal Eco

Detergent Quantities 2.5 g (pre wash) per drawer

12.5 g (main wash) per drawer

Water Softener Setting Adjust the water softener to match the water

hardness.

Refer to the water softener and option adjustment

mode section of the User Guide.

Maximum Place Setting Double drawer: 12

Single drawer: 6

Accessories to be used in the

Dishwasher Standards Test Basket, drain filter access panel, mega rack, plate

insert, cutlery basket, cup racks and cup shelves.

To install The Cup Support Assembly Loading Particulars For The Cups

Note

The front cup support assembly

is longer than the rear.

Recommended Loading Pattern - double drawer

Top drawer Bottom drawer

Recommended Loading Pattern - single drawer

3gb91700.fm Page 2 Thursday, September 5, 2002 10:07 AM

Black process 45.0° 100.0 LPI
