Whirlpool CEW9100VQ Bedienungsanleitung

To Locate a Distributor Near You, Please Visit www.whirlpoolcommerciallaundry.com/distributor, or call 1-800-NO-BELTS

Featuring Microprocessor Controls

WHIRLPOOL BRAND

COMMERCIAL DRYERS

PORCELAIN FINISH

Porcelain finish on top with

integrated backsplash, resists

chipping and scratching.

LARGE CAPACITY METERCASE

•Largercoinboxforreduced

collections.

•Acceptscoinslides,coindrops,card

readersandcanbesetupforOPL

non-coinuse.

LARGE 6.7 CU. FT.

DRUM CAPACITY

The increased capacity allows for large

loadsofclothestotumbleandspread

out,savingyouandyourcustomers

dryingtimeandexpense.

SIDE SWING REVERSIBLE

OPENING DOOR

•Extra-largeopening

•Seethroughdoorwindow

and screen

MICROPROCESSOR CONTROLS

•Timeremainingdisplay

•Frontcontrolsforease-of-use

•Debitcardcompatible

•TimeofDayPricing

AIRFLOW SYSTEM

Whirlpool®commercialdryersblower

systemincreasesairvelocity.This

increasesefficiency,heatingelement

life,andimprovesinstallation.Youcan

nowventupto100ft.with3elbows,

and1angledhoodforversatility.

4-WAY VENTING

4-Wayventingfromleftorrightside,

backorbottom.

LARGE LINT FILTER

Pull-out,84squareinchsteelmesh

lint filter.

1/3 HP MOTOR

1/3HPmotorwithoverloadprotection.

COMMERCIAL DRYER

*Call1-800-NO-BELTSforwarrantydetails

Machine accepts the Following Payment

Systems (not included):

- Coin Slide

- Retrofit Coin Drop

- Retrofit Card Reader

- OPL Non-Coin Money Acceptor

And Coin Box Covers

• Large6.7Cu.Ft.DrumCapacity

• FourRollerSuspensionwithPermanently

LubricatedBearings

• PushButtonControls

• LargeLintScreen(84Sq.In.)

• BlowerGuardReducesServiceCalls

• FrontControlPanel24°Angle

• Side-SwingReversibleDoor

• PorcelainFinishonTopwithBacksplash

ResistsChippingandScratching

• Front-ServiceAccessibility

• ElectricHeatingElementat

5600Watts240-Volt

• GasModelFeaturesa24KBTUBurner

• Motor:1/3-HPwithBuilt-InOverload

Protector;CentrifugalSwitchTurns

OffHeatingElementintheEventof

aBrokenBelt

• 

3 Year Limited Parts Only Warranty

• 

Money Acceptors Sold Separately

CEW9100VQ –

27” Electric Dryer with Metercase

CGW9100VQ –

27” Gas Dryer with Metercase

Shownwithoptionalpedestal,coindropandbox.

WhirlpoolCorporation•BentonHarbor,Michigan49022U.S.A. CWLL132

AA806045

COMMERCIAL DRYER SPECIFICATIONS

To Locate a Distributor Near You, Please Visit www.whirlpoolcommerciallaundry.com/distributor, or call 1-800-NO-BELTS

MAXIMUM EXHAUST DUCT LENGTH

PER NUMBER OF TURNS

Number Of

90° Turns

Rigid Metal Vent

  BoxHoodand AngledHood

  LouveredStyle Style

 0 135ft.(41.2m ) 129ft.(39.3m )

 1 125ft.(38.1m ) 119ft.(36.3m )

 2 115ft.(35.1m ) 109ft.(33.2m )

 3 106ft.(32.3m ) 100ft.(30.5m )

 4 98ft.(29.9m ) 92ft.( 28.0m )

Flexible Metal Vent

  BoxHoodand AngledHood

  LouveredStyle Style

 0 76ft.(23.2m ) 62ft.( 18.9m )

 1 71ft.(21.6m ) 57ft.( 17.4m )

 2 67ft.(20.4m ) 53ft.( 16.2m )

 3 65ft.(19.8m ) 51ft.( 15.6m )

 4 63ft.(19.2m ) 49ft.( 14.9m)

DRYER SPECIFICATIONS

MODEL CEW9100VQ/CGW9100VQ

MOTOR

Single-phase,thermoprotectedagainstoverload,

auto-reset

HP(kw) 1/3(.25)

CAPACITY

Cu.ft.(liters) 6.7(189.7)

DOOR OPENING DIAMETER

In.(mm) 18.25(463.5)

AIRFLOW

Gasmodels—cfm(cmm) 230(6.5)

Electricmodels—cfm(cmm) 215(6.1)

ELECTRICAL REQUIREMENTS

CEWmodel—voltage 240V/60Hz

CGWmodel—voltage 120V/60Hz

BREAKER/FUSE REQUIREMENTS

CEWmodel—amps 30

CGWmodel—amps 15

EXHAUST DUCT DIAMETER

In.(mm) 4(101.6)

ELECTRONIC BURNER IGNITION

CGWmodel •

HEATING ELEMENT RATING

CGWmodel—BTU/hr.(kcal/hr.) 24,000(6,048)

CEWmodel—ElectricHeatingElement-watts 5,600

GAS INLET

CGWmodel—in. 3/8N.P.T.

ADJUSTABLE LEVELING LEGS •

APPROXIMATE WEIGHT

Crated—lbs.(kg) 163(73.9)

Uncrated—lbs.(kg) 150(68)

DIMENSIONS

Width—in.(mm) 27(685.8)

Depth—in.(mm) 29(736.6)

Height—in.(mm) 44.80(1137.92)*

*Heightatmetercasetopdoesnotincludepedestal.

Seespecificinstructionsforproperinstallation.Becauseofcontinuousproductimprovement,

Whirlpoolreservestherighttochangespecificationswithoutnotice.

Powercordsonelectricmodelssoldseparately.

LPConversionKit#W10135245.

PedestalSingleBoxKit#WHP0400VW

PedestalPackof10Kit#WHP0401VW

Dimensions are for planning purposes only.

See Whirlpool® INSTALLATION INSTRUCTIONS for full details.

3 YEARS LIMITED PARTS

ONLY WARRANTY

Foraperiodfromthedateoforiginalpurchasethrough

thetimelistedabove,thedesignatedpartsthatfailin

normalcommercialusewillberepairedorreplacedfree

of charge for the part itself, with the owner paying all

othercosts,includinglabor,transportationandcustoms

duty.Chemicaldamageisexcludedfromallwarranty

coverage.Seecompletewarrantyfordetails.

Whirlpool® Extra-Large Capacity Dryer

MICROPROCESSOR CONTROLS
