INSTRUCTIONS FOR USE

AMW 705

INSTALLATION

PRIOR TO CONNECTING

ENSURE THAT THE APPLIANCE IS NOT DAMAGED. Check

that the oven door closes firmly against the

door support and that the internal door seal is

not damaged. Empty the oven and clean the

interior with a soft, damp cloth.

AFTER CONNECTING

THE EARTHING OF THIS APPLIANCE is compulsory. The

manufacturer will accept no responsibility for

injury to persons, animals or damage to ob-

jects arising from the non-observance of this

requirement.

The manufacturers are not liable for any

problems caused by the user’s failure to ob-

serve these instructions.

DONOT OPERATE THIS APPLIANCE if it has a damaged

mains cord or plug, if it is not working proper-

ly, or if it has been damaged or dropped. Do

not immerse the mains cord or plug in water.

Keep the cord away from hot surfaces. Electri-

cal shock, fire or other hazards may result.

DONOT REMOVE THE MICROWAVE INLET PROTECTION

PLATES located on the side

of the oven cavity wall.

They prevent grease & food

particles from entering the

microwave inlet channels.

ENSURE the oven cavity is

empty before mounting.

CHECK THAT THE VOLTAGE on the rating plate corre-

sponds to the voltage in your home.

THE OVEN CAN BE OPERATED ONLY if the oven door is

firmly closed.

MOUNTING THE APPLIANCE

FOLLOW THE SUPPLIED separate mounting in-

structions when installing the appliance.

IMPORTANT SAFETY INSTRUCTIONS

DONOT HEAT, OR USE FLAMMABLE MATERIALS in or

near the oven. Fumes can create a fire hazard

or explosion.

DONOT USE YOUR MICROWAVE oven for drying tex-

tiles, paper, spices, herbs, wood, flowers, fruit

or other combustible materials. Fire could re-

sult.

DONOT OVER-COOK FOOD. Fire could result.

DONOT LEAVE THE OVEN UNATTENDED, especially

when using paper, plastic or other combusti-

ble materials in the cooking process. Paper can

char or burn and some plastics can melt if used

when heating foods.

IFMATERIAL INSIDE / OUTSIDE THE OVEN SHOULD IGNITE

OR SMOKE IS OBSERVED, keep oven door closed and

turn the oven off. Disconnect the power cord

or shut off power at the fuse or circuit break-

er panel.

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

ONLY ALLOW CHILDREN to use the appliance under

adult supervision and after adequate instructions

have been given, so that the child is able to use

the appliance in a safe way and understands the

hazards of improper use.

THIS APPLIANCE IS NOT INTENDED FOR use by persons

(including children) with reduced physical, senso-

ry or mental capabilities, unless used under the

supervision of a person responsible for their safe-

ty.

DONOT USE YOUR MICROWAVE oven for heat-

ing anything in airtight sealed con-

tainers. The pressure increases

and may cause damage when

opening or may explode.

EGGS

DONOT USE YOUR MICROWAVE oven for cook-

ing or reheating whole eggs with or

without shell since they may

explode even after microwave

heating has ended.

THE DOOR SEALS AND THE DOOR SEAL AREAS must be reg-

ularly inspected for damage. If these areas are

damaged the appliance should not be operat-

ed until it has been repaired by a trained service

technician.

DONOT USE corrosive chemicals or vapors in this

appliance. This type of oven is specifically de-

signed to heat or cook food. It is not designed

for industrial or laboratory use.

GENERAL

THIS APPLIANCE IS DESIGNED FOR DOMESTIC USE ONLY!

THE APPLIANCE SHOULD NOT BE OPERATED without food

in the oven when using microwaves. Operation in

this manner is likely to damage the appliance.

IFYOU PRACTICE OPERATING the oven, put a glass

of water inside. The water will absorb the mi-

crowave energy and the oven will not be dam-

aged.

REMOVE WIRE TWIST-TIES from paper or

plastic bags before placing bag in

the oven.

DEEPFRYING

DONOT USE YOUR MICROWAVE oven for deep-frying,

because the oil temperature cannot be

controlled.

LIQUIDS

E.G. BEVERAGES OR WATER. Overheating the liquid

beyond boiling point can occur

without evidence of bubbling.

This could result in a sudden

boil over of the hot liquid.

To prevent this possibility the

following steps should be taken:

1. Avoid using straight-sided containers with

narrow necks.

2. Stir the liquid before placing the container

in the oven and let the teaspoon remain

in the container.

3. After heating, allow standing for a short

time, stirring again before carefully re-

moving the container from the oven.

CAREFUL

ALWAYS REFER to a microwave cookbook for de-

tails. Especially, if cooking or reheating food

that contains alcohol.

AFTER HEATING BABY FOOD or liquids in a

baby bottle or in a baby food

jar, always stir and check the

temperature before serving.

This will ensure that the heat is evenly distributed

and the risk of scalding or burns can be avoided.

Ensure the Lid and the Teat is removed be-

fore heating!

IMPORTANT PRECAUTIONS

USE HOT PADS OR OVEN MITTS to prevent burns,

when touching containers, oven parts, and

pan after cooking.

DONOT USE THE CAVITY for any storage purposes.

ACCESSORIES

GENERAL

IFACCESSORIES CONTAINING METAL comes in contact

with the oven interior, while the oven is in op-

eration, sparking can occur and the oven could

be damaged.

TURNTABLE SUPPORT

USE THE TURNTABLE SUPPORT under the

Glass turntable. Never put any oth-

er utensils on the turntable sup-

port.

Fit the turntable support in the oven.



GLASS TURNTABLE

USE THE GLASS TURNTABLE with all cooking meth-

ods. It collects the dripping juic-

es and food particles that other-

wise would stain and soil the in-

terior of the oven.

Place the Glass turntable on the turntable



support.

ENSURE THAT THE UTENSILS YOU USE are oven proof

and allow microwaves to

pass through them before

cooking.

WHEN YOU PUT FOOD AND ACCESSORIES in the micro-

wave oven, ensure that they do not come in

contact with the interior of the oven.

This is especially important with accesso-

ries made of metal or metal parts.

ALWAYS ENSURE that the turntable is able to turn

freely before starting the oven.

THERE ARE a number of accessories available on

the market. Before you buy, ensure they are

suitable for microwave use.

START PROTECTION / KEY LOCK

THIS AUTOMATIC SAFETY FUNCTION IS ACTIVATED ONE

MINUTE AFTER the oven has returned to

“stand by mode“. (The oven is in

“stand by” when the 24-hour clock is

displayed or if the clock has not been

set, when the display is blank).

THE DOOR MUST BE OPENED AND CLOSED e.g. putting

food into it, before the safety lock is released.

Else the display will show “DOOR”.

DONENESS (AUTO FUNCTIONS ONLY)

DONENESS IS AVAILABLE in most of the auto func-

tions. You have the possibility to personal-

ly control the end result through the Adjust

doneness feature. This feature enables you to

achieve higher or lower end temperature com-

pared to the default standard setting.

WHEN USING one of these functions the oven

chooses the default standard setting. This set-

ting normally gives you the best result. But if

the food you heated became too warm to eat

at once, you can easily adjust this before you

use that function the next time. NOTE:

THE DONENESS can only be set or altered during

the first 20 seconds of operation.

WHEN USING SOME OF THE AUTO FUNCTIONS the oven

may stop (depending on the chosen program

and food class) and prompt you to STIR FOOD

or TURN FOOD.

OF THE

UTOFUNCTION

STIR OR TURN FOOD (AUTO FUNCTIONS ONLY)

THIS IS DONE BY SELECTING ADONENESS LEVEL with the

+/- buttons right after you have pressed the

Start button.

NOTE: THE OVEN CONTINUES AUTOMATICALLY AFTER 1

MIN. if the food hasn’t been turned / stirred.

The heating time will be longer in this case.

TOCONTINUE COOKING:

Open the door.

Stir or turn the food.

Close the door and restart by pressing the

Start button.

DONENESS

LEVEL EFFECT

HIGH +2 YIELDS HIGHEST END TEMPERATURE

HIGH +1 YIELDS HIGHER END TEMPERATURE

MED 0 DEFAULT STANDARD SETTING

LOW -1 YIELDS LOWER END TEMPERATURE

LOW -2 YIELDS LOWEST END TEMPERATURE

FOOD

qDINNER PLAT E (250g - 500g)

wSOU P (200g -

WHEN USING THE AUTO FUNCTIONS the oven needs

to know which food class it is to use to reach

proper results. The word FOOD and a food

class digit is displayed when you are choosing

a food class with the +/- buttons.

COOLING DOWN

WHEN AFUNCTION IS FINISHED, the oven may carry

out a cooling procedure. This is normal.

After this procedure the oven switches off au-

tomatically.

IFTHE TEMPERATURE IS HIGHER THAN 50°C, “HOT”

and the current cavity temperature is dis-

played. Be careful not to touch the cavity in-

side when removing food. Use oven mittens.

IFTHE TEMPERATURE IS LESS THAN 50°C, the 24 hour

clock is displayed.

PRESS THE BACK BUTTON to tem-

porarily view the 24 hour

clock when “HOT” is dis-

played.

THE COOLING PROCEDURE can be interrupted with-

out any harm to the oven by opening the door.

AUTO FUNCTION

the ovenneed

FOOD CLASSES (AUTO FUNCTIONS ONLY)

FOR FOOD NOT LISTED IN THE TABLES and if the

weight is lesser or greater than recommended

weights, you should follow the procedure for

”Cook & Reheat with microwaves”.

THE FOOD CLASSES are listed in the tables placed

with each Auto function.

CLOCK SETTING

KEEP THE DOOR OPEN WHILE SETTING THE

CLOCK. This gives you 5 minutes to

complete the setting of the Clock.

Otherwise, each step must be ac-

complished within 60 seconds.

WHEN THE APPLIANCE IS FIRST PLUGGED

IN it will ask you to set the Clock.

AFTER APOWER FAILURE the Clock will

flash and needs to be reset.

YOUR OVEN HAS a number of func-

tions which can be adjusted to

your personal taste.

CHANGING SETTINGS

qPRESS THE MANUAL BUTTON until Setting is shown.

wUSE THE +/- BUTTONS to choose one of the following settings to adjust.

Clock



Sound

ECO

Brightness

ePRESS THE STOP BUTTON TO EXIT the settings function and save

all your changes when you are done.

qPRESS THE OK BUTTON. (The left right hand digits (hours) flicker).

wPRESS THE +/- BUTTONS to set the hours.

ePRESS THE OK BUTTON. (The two right hand digits (minutes) flicker).

rPRESS THE +/- BUTTONS to set the minutes.

tPRESS THE OK BUTTON again to confirm the change.

THE CLOCK IS SET AND IN OPERATION.

IFYOU WISH TO REMOVE THE CLOCK from the display once it has been set,

simply enter the clock setting mode again and press the Stop but-

ton while the digits flicker.

SOUND SETTING

qPRESS THE OK BUTTON.

wPRESS THE +/- BUTTONS to turn the buzzer ON or OFF.

ePRESS THE OK BUTTON again to confirm the change.

ECO

qPRESS THE OK BUTTON.

wPRESS THE +/- BUTTONS to turn the ECO setting ON or OFF.

ePRESS THE OK BUTTON again to confirm the change.

WHEN ECO IS ON, the display will automatically turn off after a while

to save energy. It will automatically light up again when a button is

pressed or the door is opened. At cooking end cavity lamp switches

off after 30 seconds.

WHEN OFF IS SET, the display will not turn off and the 24 h clock will

always be visible. At cooking end cavity lamp switches off after 3

minutes.

CHANGING SETTINGS

USE THIS FUNCTION when you need

a kitchen timer to measure exact

time for various purposes such

as cooking eggs or letting the

dough rise before baking etc.

KITCHEN TIMER

qPRESS THE +/- BUTTONS to set the desired length of the timer.

wPRESS THE OK BUTTON.

ANACOUSTIC SIGNAL will be heard when the timer has finished to

count down.

PRESSING THE STOP BUTTON before the timer has finished will reset the

timer to zero.

CHANGING SETTINGS

BRIGHTNESS

qPRESS THE OK BUTTON.

wPRESS THE +/- BUTTONS to set the level of brightness suitable to your preference.

ePRESS THE OK BUTTON again to confirm your selection.

Inhaltsverzeichnis

Andere Whirlpool Mikrowellenofen Handbücher

Whirlpool

Whirlpool JT 355 WHITE Bedienungsanleitung

Whirlpool

Whirlpool JT 379 Bedienungsanleitung

Whirlpool

Whirlpool COMPACT EASYTRONIC MWD240 Bedienungsanleitung

Whirlpool

Whirlpool KM-24 Bedienungsanleitung

Whirlpool

Whirlpool GH7208XRS3 Bedienungsanleitung

Whirlpool

Whirlpool GT4175 Bedienungsanleitung

Whirlpool

Whirlpool MH3184XPB5 Bedienungsanleitung

Whirlpool

Whirlpool GH8155XM Bedienungsanleitung

Whirlpool

Whirlpool YGH7155XHS1 Bedienungsanleitung

Whirlpool

Whirlpool W11553924A Bedienungsanleitung

Whirlpool

Whirlpool MWl500XS Bedienungsanleitung

Whirlpool

Whirlpool AMW 585 IX Bedienungsanleitung

Whirlpool

Whirlpool 6MT 744/WH Bedienungsanleitung

Whirlpool

Whirlpool UDT518SAHP Bedienungsanleitung

Whirlpool

Whirlpool MH1150XMQ3 Bedienungsanleitung

Whirlpool

Whirlpool MAX 35 WH Bedienungsanleitung

Whirlpool

Whirlpool MT1110SK Bedienungsanleitung

Whirlpool

Whirlpool WMC10007AWCYBER Bedienungsanleitung

Whirlpool

Whirlpool WMH76719CH Bedienungsanleitung

Whirlpool

Whirlpool UMC5225GZ Bedienungsanleitung

Whirlpool

Whirlpool W10545083A Bedienungsanleitung

Whirlpool

Whirlpool GMC275PRS Bedienungsanleitung

Whirlpool

Whirlpool AMW 230 Bedienungsanleitung

Whirlpool

Whirlpool MW B00 Bedienungsanleitung

Beliebte Mikrowellenofen Handbücher anderer Marken

Daewoo

Daewoo KOG-574R0S Bedienungsanleitung

LG MH7040SS Bedienungsanleitung

Sharp

Sharp R-895(AL)M Bedienungsanleitung

Dometic

Dometic DOTRM13W Bedienungsanleitung

Sanyo

Sanyo EM-X680 Bedienungsanleitung

Sharp

Sharp R-393M Bedienungsanleitung

KitchenAid

KitchenAid KMCX4510 Montageanleitung

Smeg

Smeg S45MCX1 Bedienungsanleitung

Russell Hobbs

Russell Hobbs RHM2044 Bedienungsanleitung

Sunbeam

Sunbeam SMW759 Bedienungsanleitung

Gallet

Gallet FMOE230S Bedienungsanleitung

Bosch

Bosch CEG732X.1B Bedienungsanleitung

Dometic

Dometic Roadmate 230 Bedienungsanleitung

Samsung

Samsung SJ0396W Bedienungsanleitung

Sanyo

Sanyo EM-P494WS Bedienungsanleitung

Sharp

Sharp R-240 Bedienungsanleitung

Electrolux

Electrolux EMS2840 Bedienungsanleitung

Daewoo

Daewoo KOC-984T2S13 Bedienungsanleitung
