Instructions for use

AMW 470

www.whirlpool.com

AMW 481

AMW 480 AMW 485

INSTALLATION

PRIOR TO CONNECTING

Check that the voltage on the rating plate

corresponds to the voltage in your home.

Do not remove the microwave inlet

protection plates located on the side of the

oven cavity wall. They prevent grease & food

particles from entering the microwave inlet

channels.

Ensure the oven cavity is empty before

mounting.

Ensure that the appliance is not damaged.

Check that the oven door closes ﬁrmly against

the door support and that the internal door

seal is not damaged. Empty the oven and clean

the interior with a soft, damp cloth.

Do not operate this appliance if it has

a damaged mains cord or plug, if it is not

working properly, or if it has been damaged

or dropped. Do not immerse the mains cord

or plug in water. Keep the cord away from hot

surfaces. Electrical shock, ﬁre or other hazards

may result.

This product should not be mounted at a

height lower than 850 mm above ﬂoor level.

AFTER CONNECTING

The oven can be operated only if the oven

door is ﬁrmly closed.

The earthing of this appliance is compulsory.

The manufacturer will accept no responsibility

for injury to persons, animals or damage to

objects arising from the non-observance of this

requirement.

In the case of a permanent connection, the

appliance should be installed by a qualiﬁed

technician.

Important!

A permanent connection requires the

installation of a separating device. The

separating device must have an omnipolar

contact opening of more than 3 mm including

LS switches, safety valves and relays. The

separating device must be connected directly

to the terminal.

The manufacturers are not liable for any

problems caused by the user’s failure to

observe these instructions.

Follow the supplied separate mounting instructions

when installing the appliance.

WARNING!

:Only allow children to use the oven with adult

supervision after adequate instructions have

been given so that the child is able to use the

oven in a safe way and understands the hazards

of improper use.

The appliance is not intended for

use by young children or inﬁrm

persons without supervision.

Young children should be

supervised to ensure that they do

not play with the appliance.

If your oven have a combination mode, children

should only use the oven under adult supervision

due to the temperatures generated.

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

Do not heat, or use ﬂammable materials

in or near the oven. Fumes can create a ﬁre

hazard or explosion.

Do not use corrosive chemicals or vapors in

this appliance. This type of oven is speciﬁcally

designed to heat or cook food. It is not

designed for industrial or laboratory use.

Do not use your microwave oven for drying

textiles, paper, spices, herbs, wood, ﬂowers,

fruit or other combustible materials. Fire could

result.

If material inside / outside the oven should

ignite, keep oven door closed and turn the

oven oﬀ. Disconnect the power cord or shut oﬀ

power at the fuse or circuit breaker panel.

Do not over-cook food. Fire could result.

Do not leave the oven unattended, especially

when using paper, plastic or other combustible

materials in the cooking process. Paper can

char or burn and some plastics can melt if used

when heating foods.

WARNING!

Do not use your microwave oven for heating

anything in airtight sealed

containers. The pressure increases

and may cause damage when

opening or may explode.

WARNING!

The door seals and the door seal areas must

be regularly inspected for damage. If these

areas are damaged the appliance should not be

operated until it has been repaired by a trained

service technician.

EGGS

Do not use your microwave

oven for cooking or reheating

whole eggs with or without

shell since they may explode

even after microwave heating has ended.

PRECAUTIONS

GENERAL

This appliance is designed for domestic use

only!

The appliance should not be operated without

food in the oven when using microwaves.

Operation in this manner is likely to damage the

appliance.

If you practice operating the oven, put a

glass of water inside. The water will absorb the

microwave energy and the oven will not be

damaged.

Do not use the cavity for any storage

purposes.

Do not remove the microwave inlet

protection plates located on the side of the

oven cavity wall. They prevent grease & food

particles from entering the microwave inlet

channels.

LIQUIDS

E.g. beverages or water in your

microwave oven, overheating

the liquid beyond boiling point

can occur without evidence

of bubbling. This could result in a sudden boil

over of the hot liquid.

To prevent this possibility the following steps

should be taken:

1. Avoid using straight-sided containers with

narrow necks.

2. Stir the liquid before placing the container

in the oven and let the teaspoon remain

in the container.

3. After heating, allow standing for a short

time, stirring again before carefully

removing the container from the oven.

Remove wire twist-ties from

paper or plastic bags before placing

bag in the oven.

DEEP-FRYING

Do not use your microwave

oven for deep-frying, because

the oil temperature cannot be

controlled.

Use hot pads or oven mitts to prevent burns,

when touching containers, oven parts, and pan

after cooking.

CAREFUL

Always refer to a microwave cookbook (not

included) for details. Especially, if cooking or

reheating food that contains alcohol.

After heating baby food or

liquids in a baby bottle or in

a baby food jar, always stir

and check the temperature

before serving. This will ensure that the heat

is evenly distributed and the risk of scalding

or burns can be avoided.

Ensure the Lid and the Teat is removed

before heating!

GLASS TURNTABLE

Use the Glass turntable with

all cooking methods. It collects

the dripping juices and food

particles that otherwise would

stain and soil the interior of the oven.

* Place the Glass turntable on the turntable

support.

ACCESSORIES

GENERAL

There are a number of accessories available

on the market. Before you buy, ensure they are

suitable for microwave use.

Ensure that the utensils you use are oven

proof and allow microwaves to pass through

them before cooking.

When you put food and accessories in the

microwave oven, ensure that they do not come

in contact with the interior of the oven. This is

especially important with accessories made

of metal or metal parts.

If accessories containing metal comes in

contact with the oven interior, while the oven

is in operation, sparking can occur and the

oven could be damaged.

Always ensure that the turntable is able to

turn freely before starting the oven.

Ensure that the utensils you use are oven

proof and allow microwaves to pass through

them before cooking.

TURNTABLE SUPPORT

Use the turntable support under

the Glass turntable. Never put any

other utensils on the turntable

support.

* Fit the turntable support in the oven.

CRISP HANDLE

Use the supplied special Crisp

handle to remove the hot Crisp plate

from the oven.

CRISP-PLATE

Place the food directly on the

Crisp-plate. Always use the Glass

turntable as support when using

the Crisp-plate.

Do not place any utensils on the

Crisp-plate since it will quickly

become very hot and is likely to

cause damage to the utensil.

The Crisp-plate may be preheated

before use (max. 3 min). Always use the Crisp

function when preheating the crisp-plate.

CLOCK

Keep the door open while setting the Clock.

This gives you 10 minutes to complete the

setting of the Clock. Otherwise, each step must

be accomplished within 60 seconds.

1. Press the Clock button (3 seconds) until the left-hand digit (hour’s) ﬂicker.

2. Press the +/- buttons to set the hours.

3. Press the Clock button again. (The two right hand digits (minutes) ﬂicker).

4. Press the +/- buttons to set the minutes.

5. Press the Clock button again.

The Clock is set and in operation.

Note: When the appliance is ﬁrst plugged in or after a power failure, the display is blank. If the

clock is not set, the display will remain blank until the cooking time is set.

Note: The Stop button may also be used to enter clock setting mode (press 3 seconds).

START PROTECTION / CHILD LOCK

This automatic safety function is activated

one minute after the oven has returned to

“stand by mode“.

PAUSE OR STOP COOKING

To pause cooking:

The cooking can be paused to check, turn or

stir the food by opening the door. The setting

will be maintained for 10 minutes.

To continue cooking:

Close the door and press the Start

button ONCE. The cooking is resumed

from where it was paused.

Pressing the Start button TWICE will increase

the time by 30 seconds.

If you don’t want to continue

cooking:

Remove the food, close the door and

press the STOP button

A beep will signal once a minute

for 10 minutes when the cooking is

ﬁnished. Press the STOP button or open the

door to cancel the signal.

Note: The oven will only hold the settings for

60 seconds if the door is opened and then

closed after the cooking is ﬁnished.

The door must be opened and closed e.g.

putting food into it, before the safety lock is

released. Else the display will show “door“.

1. Press the +/- buttons to set the desired length of the timer.

2. Press the power button repeatedly to set the power to 0 W.

3. Press the Start button.

TIMER

Use this function when you need a kitchen

timer to measure exact time for various

purposes such as cooking eggs, pasta or letting

the dough rise before baking etc.

An acoustic signal will be heard when the timer has ﬁnished to count down.

1. Press the +/- buttons to set the time.

2. Press the power button repeatedly to set the power.

3. Press the Start button.

COOK & REHEAT WITH MICROWAVES

Use this function for normal cooking and

reheating, such as vegetables, ﬁsh, potatoes

and meat.

Once the cooking process has been started:

The time can easily be increased in 30-second steps by pressing the Start button. Each press

increases the time with 30 seconds. You may also alter the time by pressing the +/- buttons to

increase or decrease the time.

Pressing the power button may also change the power level. The ﬁrst press will show you the

current power level. Press the power button repeatedly to change power level.

JET DEFROST

Use this function for defrosting Meat, Fish &

Poultry ONLY. For other foods such as Bread

& Fruit you should follow the procedure for

”How to cook and reheat with microwaves”and

choose 160 W when defrosting.

Jet Defrost should only be used if the net

weight is between 100 - 2000g.

1. Press the Jet Defrost button.

2. Press the + / - buttons to set the weight of

the food.

3. Press the Start button.

If the weight is lesser or greater than

recommended weight:

Follow the procedure for ”How to cook and

reheat with microwaves” and choose 160 W

when defrosting.

JET START

This function is used for quick reheating of

foods with a high water content such as; clear

soups, coﬀee or tea.

Press to automatically start with full microwave power level and the cooking time set to 30

seconds. Each additional press increases the time with 30 seconds. You may also alter the time by

pressing the +/- buttons to increase or decrease the time after the function has started.

Midway through the defrosting process the

oven stops and prompts you to“TURN” food.

— Open the door.

— Turn the food.

— Close the door and restart by pressing the

Jet Start button.

Au:If the food is warmer than deep-freeze

temperature (-18°C), choose lower weight of

the food.

If the food is colder than deep-freeze

temperature (-18°C), choose higher weight of

the food.

Note: the oven continues automatically after

2 min if the food hasn’t been turned. The

defrosting time will be longer in this case.

GRILL

Use this function to quickly give a pleasant

brown surface to the food.

1. Press the Grill button.

2. Press the +/- buttons to set the time.

3. Press the Start button.

Do not leave the oven door open for long periods when the Grill is in operation, as this will cause

a drop in temperature.

Note:

Pressing the Grill button during cooking switches the Grill element on and oﬀ. The timer will

continue to count down when the Grill element is turned oﬀ.

IMPORTANT!

Ensure that the utensils used are heat resistant and ovenproof before grilling with them.

Do not use plastic utensils when grilling. They will melt. Items of wood or paper are not suitable either.

GRILL & MICROWAVES

1. Press the Grill button.

2. Press the Power button to set the microwave

power.

3. Press the +/- buttons to set the time.

4. Press the Start button.

During operation you can switch the Grill element on/oﬀ by pressing the Grill button. The Max.

possible microwave power level when using the Grill is limited to a factory-preset level.

It is possible to switch the microwaves oﬀ by reducing the microwave power level to 0 W.

When 0 W is reached, the oven switches to Grill only mode.

Use this function to cook such foods as

Gratin’s, Lasagne, Poultry and Baked potatoes.

CRISP

Use this function to reheat and cook pizzas

and other dough based foods. It is also

good for frying bacon and eggs, sausages,

hamburgers etc.

1. Press the Crisp button.

2. Press the +/- buttons to set the time.

3. Press the Start button.

The oven automatically works with Microwaves and Grill in order to heat the Crisp-plate. This way

the Crisp-plate will rapidly reach its working temperature and begin to brown and crisp the food.

It is not possible to change or switch, the Power level or Grill, on/oﬀ, when using the Crisp

function.

IMPORTANT!

Ensure that the Crisp-plate is correctly placed in the middle of the Glass turntable.

The oven and the crisp-plate become very hot when using this function.

Do not place the hot crisp-plate on any surface susceptible to heat.

Be careful, not to touch the ceiling beneath the Grill element.

Use oven mittens or the special Crisp handle supplied when removing the hot Crisp-plate.

Only use the supplied Crisp™plate with this function. Other available Crisp™plate

on the market will not give the correct result when using this function.

Andere Handbücher für AMW 470

Inhaltsverzeichnis

Andere Whirlpool Ofen Handbücher

Whirlpool

Whirlpool 501930001639 Bedienungsanleitung

Whirlpool

Whirlpool OMR35HR0X Bedienungsanleitung

Whirlpool

Whirlpool RB26OOXK Bedienungsanleitung

Whirlpool

Whirlpool RB270PXK Bedienungsanleitung

Whirlpool

Whirlpool BMZH 5900 IN Bedienungsanleitung

Whirlpool

Whirlpool SB100PER Bedienungsanleitung

Whirlpool

Whirlpool Gas Single And Double Built-In Oven Bedienungsanleitung

Whirlpool

Whirlpool AKP 288 Bedienungsanleitung

Whirlpool

Whirlpool W9OS24S1P Bedienungsanleitung

Whirlpool

Whirlpool AKG 659/01 IX Bedienungsanleitung

Whirlpool

Whirlpool SB100PEK1 Bedienungsanleitung

Whirlpool

Whirlpool RBD245PR Service-Handbuch

Whirlpool

Whirlpool PCCI 502161 Betriebsanleitung

Whirlpool

Whirlpool AKP 446/IX Betriebsanleitung

Whirlpool

Whirlpool AMW 545 Bedienungsanleitung

Whirlpool

Whirlpool AKZM 8920 Betriebsanleitung

Whirlpool

Whirlpool GGE350LWB Bedienungsanleitung

Whirlpool

Whirlpool YGSC278 Bedienungsanleitung

Whirlpool

Whirlpool AKP 605 IX Bedienungsanleitung

Whirlpool

Whirlpool W9I OM2 4S1 H Bedienungsanleitung

Whirlpool

Whirlpool AKP 738 Bedienungsanleitung

Whirlpool

Whirlpool AMW 4910/IX Bedienungsanleitung

Whirlpool

Whirlpool AKG 659/IX Bedienungsanleitung

Whirlpool

Whirlpool 6AKZ 186/IX Bedienungsanleitung

Beliebte Ofen Handbücher anderer Marken

Bosch

Bosch HVA531NS0 Bedienungsanleitung

Electrolux

Electrolux EOF6P46X Bedienungsanleitung

NEFF

NEFF B44S32 5GB Series Bedienungsanleitung

Combi

Combi BLODGETT BC142GDS Bedienungsanleitung

AEG

AEG COMPETENCE 311704300 Bedienungsanleitung

Falcon

Falcon DOMINATOR PLUS G3106 Series Benutzerhandbuch

Rational

Rational SCC WE 61G Bedienungsanleitung

Smeg

Smeg DOSPA38X Installations- und Betriebshandbuch

Electrolux

Electrolux air-o-convect 20 GN 2/1 Bedienungsanleitung

Miele

Miele HR 1954-2 Bedienungsanleitung

KHIND

KHIND OT50 Bedienungsanleitung

Henny Penny

Henny Penny Smoker Box Bedienungsanleitung

Lang

Lang ECOD-AP Bedienungsanleitung

AEG

AEG BEK455310M Bedienungsanleitung

Frigidaire

Frigidaire FNGE90JGR Bedienungsanleitung

Hotpoint

Hotpoint FE9 S831 JSH IX Bedienungsanleitung

GE Advantium SCB2000 Bedienungsanleitung

AEG

AEG DE401301DM Bedienungsanleitung
