Whirlpool RBS305PR Bedienungsanleitung

OVEN PARTS

For Models: RBS305PRB02, RBS305PRQ02, RBS305PRT02, RBS305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

05−08 Litho in U.S.A. (amd) (eeb) Part No. W10208661 Rev. A

30" BUILT−IN

ELECTRIC OVEN

SELF CLEAN

OVEN PARTS

For Models: RBS305PRB02, RBS305PRQ02, RBS305PRT02, RBS305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208661

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

8303647 Installation

Instructions

W10162170

Use & Care Guide

8301758 Tech Sheet

8304571 Installation/

Undercounter

Safer Cooking Tips

9762761 English

W10065852

French

8301928 Instructions

Microwave Trim

Kit

2 Trim, Side

Right

W10136093

Black

W10136094

White

W10136096

Biscuit

W10166950

Stainless

Left

W10136092

Black

W10136095

White

W10136097

Biscuit

W10166951

Stainless

3 Hinge Receiver

4455606 Right

4455605 Left

W10105790

Bumper, Door

5 Screw

3400832 Black

3400805 Zinc

7 8303099 Top Chassis

8 4448444 Grommet, Mounting

Rail

9 4452158 Tube, Vent

W10067870

Lens, Light

W10009930

Assembly, Oven

Light

12 4452166 Bulb, Light

W10130368

Frame, Front

15 4455382 Gasket, Door

16 4449809 Screw

17 4449040 Screw

18 4452152 Bracket, Mounting

19 4451478 Support, Insulation

21 Rail, Side

8303115 Right

8303116 Left

22 9760888 Latch, Motorized

23 4449154 Screw

25 4455641 Side, Chassis

W10161110

Back, Chassis

27 Liner, Oven

(Not serviceable)

W10131825

Sensor

33 9760677 Deflector, Vent

37 9759243 Thermostat

43 9759713 Base, Chassis

49 4448933 Retainer, Gasket

50 4451747 Cover, Back

53 4449845 Support, Bracket

55 Trim, Bottom

8303583 Black

8303584 White

8303585 Biscuit

8303582 Stainless

FOLLOWING PARTS

NOT ILLUSTRATED

INSULATION

4449316 Insulation, Wrap

4450365 Insulation, Back

OVEN DOOR PARTS

For Models: RBS305PRB02, RBS305PRQ02, RBS305PRT02, RBS305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208661

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 8303700 Door Liner

2 Hinge, Door

9760571 Right

9760572 Left

Stainless Only

Hinges

9760573 Right

9760574 Left

3 4449259 Glass, Inner

4 4451722 Insulation, Door

5 4457132 Retainer, Glass

6 4449743 Screw

7 9759225 Glass, Inner

8 4449809 Screw

9 4448520 Bumper, Door

12 Assembly, Door

Glass

8303330 Black

8303339 White

8303342 Biscuit

8303314 Stainless

13 Door Handle

8302813 Black

8302814 White

8302815 Biscuit

W10136473

Bracket, Handle

15 9759229 Bracket(2nd glass)

16 9759230 Bracket(3rd Glass)

17 8303811 Nameplate

19 4457103 Shield, Heat

4449809 Screw

20 4451040 Screw

21 8303878 Seal, Door Top

22 4457114 Shield, Heat

Bottom

24 9759228 Glass, Inner

INTERNAL OVEN PARTS

For Models: RBS305PRB02, RBS305PRQ02, RBS305PRT02, RBS305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208661

Illus. Part

No. No. DESCRIPTION

1 9760771 Element, Broil

2 4448717 Rack, Oven

3 9760766 Element,

Conventional Bake

4 4449154 Screw

CONTROL PANEL PARTS

For Models: RBS305PRB02, RBS305PRQ02, RBS305PRT02, RBS305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208661

Illus. Part

No. No. DESCRIPTION

1 Assembly, Control

Panel

8302848 Black

8302849 White

8302850 Biscuit

2 Membrane Switch

8304269 Black

8304270 White

8304271 Biscuit

3 8303885 Microcomputer

W10153086

Backer, Control

Panel

W10166944

Trim, Control

Panel (Stainless

Model Only)

TOP VENTING PARTS

For Models: RBS305PRB02, RBS305PRQ02, RBS305PRT02, RBS305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208661

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 4451759 Vent, Exhaust

2 4455178 Elbow, Vent Top

3 4457289 Blower

4 4451758 Block, Foam

5 4455177 Elbow, Vent Bottom

6 4449809 Screw

7 4449040 Screw

8 3400080 Screw

9 4450038 Screw

11 4449868 Block, Terminal

13 8303497 Vent, Control

Panel

14 Side, Control Top

4451597 Right

4451598 Left

15 9759135 Back, Control

16 4450551 Cover, Top Rear

17 4448664 Clamp

18 4452367 Cover, Top Front

19 8302143 Suppressor

OPTIONAL PARTS

For Models: RBS305PRB02, RBS305PRQ02, RBS305PRT02, RBS305PRS02

(Black) (Designer White) (Biscuit) (Stainless)

W10208661

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

PAINT, TOUCH−UP (1/2oz.)

72017 White

261869 Cord Brown

72032 Black

PAINT, SPRAY

350930 White

261900 Citrine White

830864 Black

ADHESIVE

591014 Adhesive

Loctite (1/3 oz.)

482338 Sealer, Silastic

(3 oz.)

SPLICING WIRES−−25FT.

LENGTH

242828 Wire (12 Ga.

150 c Black)

242820 Wire (14 Ga.

150 c Black)

242821 Wire (14 Ga.

150 c Blue)

242822 Wire (14 Ga.

150 c Brown)

242830 Wire (14 Ga.

200 c Brown)

242823 Wire (14 Ga.

150 c Green)

242824 Wire (14 Ga.

150 c Orange)

242825 Wire (14 Ga.

150 c Red)

242831 Wire (14 Ga.

200 c Red)

242827 Wire (14 Ga.

150 c Yellow)

WIRING HARNESS PARTS

8301400 Harness, Main

4450952 Conduit

4449809 Screw

4452400 Lead, Ground

Strap

4450800 Screw, Ground

7103P027−60

Nut, Terminal

Block

98997 Clip

4451761 Support, Wiring

4454842 Tie, Cable

Miscellaneous

W10106920

Screw, Install
