COOKTOP PARTS

For Model: RF110AXSQ0, RF110AXST0

(Designer White)(Designer Biscuit)

2−06 Litho in U.S.A. (lwp) Part No. 8188341

30" ELECTRIC FREESTANDING

STANDARD CLEAN RANGE

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

9762996 Instructions,

Installation

9763000 Owners Manual

9762974 Sheet, Tech

9762761 Safer Cooking Tips

Template,Anti−Tip

9757142 English/Spanish

9757143 English/French

2 Bowl, Drip

3195208 6" Chrome (3)

3195209 8" Chrome (1)

3 Cooktop

3186235 White

8273508 Biscuit

4 3195060 Hinge, Cooktop (2)

5 3196178 Screw

6 308605 Strain Relief

7 3195812 Rod, Support (2)

9 814399 Receptacle, Elmnt

10 3196154 Screw

11 Element, Surface

9761348 6" (3)

9761346 8" (1)

CONTROL PANEL PARTS

For Model: RF110AXSQ0, RF110AXST0

(Designer White)(Designer Biscuit)

8188341

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Endcap

W10009060

Left Hand Biscuit

W10009040

Left Hand White

W10009070

Right Hand Biscuit

W10009050

Right Hand White

2 9757609 Nameplate

3 Panel, Backguard

9762011 Biscuit

9762010 White

4 Switch, Infinite

3148953 Use W/ 8" Element

3148951 Use W/ 6" Element

6 9762215 Cntrl−Elec ROC60

7 9762095 Brkt−Mntg,Console

8 8523266 Indicator, Oven

9 3196166 Screw

10 3196200 Clip, Spring (2)

11 Knob (4)

9761963 Biscuit

9761962 White

13 3196068 Lens, Ind. (2)

14 Knob, Thermostat

9762525 Biscuit

9762526 White

15 8053912 Shield, Heat

17 8272473 Cover, Upper Rear

19 3196178 Screw

20 3400882 Screw

22 8273564 Clip

CHASSIS PARTS

For Model: RF110AXSQ0, RF110AXST0

(Designer White)(Designer Biscuit)

8188341

CHASSIS PARTS

For Model: RF110AXSQ0, RF110AXST0

(Designer White)(Designer Biscuit)

8188341

Illus. Part

No. No. DESCRIPTION

1 3169143 Vent Tube

2 3186144 Box, Burner

3 Panel, Side (2)

8053830 White−Textured

8272519 Biscuit−Textured

4 9757158 Thermostat

5 3186152 Seal, Oven Door

6 9757340 Element, Broil

7 9758541 Element, Bake

W10031780

Screw

9 9760407 Brkt, Mounting

10 9759785 Glide, Drawer Frnt

11 3196037 Foot, Front (2)

12 Frame, Front

(Not Serviced)

13 8054068 Tray, Insulation

14 3196576 Clip, Panel (6)

15 9760314 Rail, Base (2)

16 9761935 Foot, Rear (2)

17 9756355 Brkt−Thermostat

18 3195809 Bumper, Side (2)

19 3186116 Support, Oven (2)

20 3186034 Bracket, Service

21 9761958 Block, Terminal

112432 Nut (3)

22 8274034 Back, Main

23 3196566 Screw

24 9758283 Cover, Box

25 3196567 Screw

26 3196168 Screw

27 3196174 Screw

28 3196165 Screw

29 3196179 Screw

30 3196178 Screw

31 3400016 Screw

32 8273902 Sensor

34 3196172 Screw

35 3196169 Screw

INSULATION

8273263 Insulation, Wrap

8272611 Insulation, Back

DRAWER & BROILER PARTS

For Model: RF110AXSQ0, RF110AXST0

(Designer White)(Designer Biscuit)

8188341

Illus. Part

No. No. DESCRIPTION

1 3195710 Rack, Oven (2)

4 9761031 Drawer, Storage

5 9758200 Bracket, Drawer(2)

6 Rivet, Push (2)

3196814 White

3196815 Almond

7 Panel, Drawer Frnt

8053339 White

8272501 Biscuit

9 8053334 Glide, Drawer (2)

10 3196168 Screw

DOOR PARTS

For Model: RF110AXSQ0, RF110AXST0

(Designer White)(Designer Biscuit)

8188341

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

W10031790

Screw

3 9761342 Liner

4 8272618 Insulation, Door

W10031780

Screw

6 9761495 Hinge (2)

7 3196163 Screw

8 Panel, Steel

3195560 White

8273522 Biscuit

9 Spacer, Handle

3196143 White

8273879 Biscuit

10 Handle, Oven Door

3195263 White

8273506 Biscuit

11 Screw, Top

3196558 White

3196559 Almond

12 9761503 Brkt−Door

13 9761517 Clip−Door, Mntg

14 3196165 Screw

OPTIONAL PARTS

For Model: RF110AXSQ0, RF110AXST0

(Designer White)(Designer Biscuit)

8188341

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

Following Parts Not Illustrated

SPLICING WIRES−−25FT.

LENGTH

242828 Wire, Black

12 Ga. 150 c

8316781 Wire, Black

14 Ga. 150 c

242821 Wire, Blue

14 Ga. 150 c

242822 Wire, Brown

14 Ga. 150 c

242830 Wire, Brown

14 Ga. 200 c

242823 Wire, Green

14 Ga. 150 c

242824 Wire, Orange

14 Ga. 150 c

242825 Wire, Red

14 Ga. 150 c

242831 Wire, Red

14 Ga. 200 c

242827 Wire, Yellow

14 Ga. 150 c

REFINISHING MATERIAL

799832 Kit, Porcelain

Repair (White)

242756 Touch−Up

Self−Clean(1/2 Pt)

261582 Grease

INSULATION

261514 Insulation,

Fiberglass (1−1/2"

x 24" x 120")

240132 Insulation,

Fiberglass (2−1/2"

x 22" x 120")

PAINT, TOUCH−UP (1/2oz.)

72017 White

72107 Almond

511873 White Porcelain

(2 Oz.)

PAINT, PRESSURIZED SPRAY

(12 oz.)

350930 White

350956 Almond

285006 Superior Black

206922 Primer (White)

PAINT, BULK (1 qt.)

799344 White (Uncut)

978883 Almond (Uncut)

ACCESSORY PARTS

241430 Foil, Aluminum

Oven (18" x 25’)

3184478 Cleaner, Glass

4396923 Pan−Broiler

ANTI−TIP KIT

W10017440

Anti−Tip Kit

WIRING HARNESS PARTS

W10036240

Harness, Main

9761476 Harness, Cooktop

3196154 Screw, Grnd−Cktop

3196174 Screw, Grnd−Back

3196520 Clip, Wire Harness

311227 Wire, Ground

313660 Clip, Ground Wire

Miscellaneous

814381 Pin Kit−Dr Removal
