CABINET PARTS
1
For Model: 8W8TXDWFXT00
(Biscuit)
10−11 Litho In U.S.A. (mat) (eeb) Part No. W10459022 Rev.A
REFRIGERATOR
CABINET PARTS
2
For Model: 8W8TXDWFXT00
(Biscuit)
W10459022
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10344152
Service &
Wiring Sheet
Use & Care Guide
W10335269
(English)
W10388619
(Chinese)
W10411909
Energy Guide
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
677969 Do−It−Yourself
Manual, Ref./ Fzr.
2 2261963 Hinge Butt, Top
3
W10142530
Roller, Front
4 487576 Washer
5 2264132 Cover, Unit
6
W10133299
Leveler
7 489442 Screw
8 2266506 Spacer, Back
9 2166086 Hinge, Center
10 2166043 Shim, Hinge
Center
11 489497 Screw
12 2325482 Hinge Butt,
Bottom
13 2325483 Hinge−Pin,
Bottom
14 487576 Washer
15 2201567 Shim, Bottom
Hinge
16 Hole Plug (6)
2200924 Biscuit
17 Corner Filler
2202282 Biscuit
18 489341 Washer
19 Rail, Center
(Not Serviced)
20 Cabinet (Not a
Serviceable Part)
DOOR PARTS
3
For Model: 8W8TXDWFXT00
(Biscuit)
W10459022
DOOR PARTS
4
For Model: 8W8TXDWFXT00
(Biscuit)
W10459022
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(Includes
Illus. 9,12,
14 & 24)
W10329720
Biscuit
2 2264478 Cover, Utility
3 8281206 Screw
4 2156003 Trim, Endcap
5 Handle,
Refrigerator
2221946T Biscuit
6 489357 Screw
7 2264477 Utility
Compartment
8 8281206 Screw
9 Door Gasket,
Magnetic
W10190032
Mist Beige
10 Screw Cover
2202819T Biscuit
11 2262218 Nameplate
12 939101 Screw Anchor
13
W10234241
Trim, Door Shelf
14 2262054 Thimble
16 Freezer Door
W10329721
Biscuit
(Includes
Illus. 14,18 & 24)
17 Hole Plug,
Handle
2200936 Biscuit
18 Door Gasket,
Magnetic
W10190031
Mist Beige
19 2189202 Bracket, Door Stop
20 488921 Screw
21 Hole Plug
2212649 Biscuit
22 2266727 Trim, Door
24 Handle, Freezer
2215015 Biscuit
25 2265126 Bin
26 2328217 Trivet
27 2258681W Shim, Door Stop
LINER PARTS
5
For Model: 8W8TXDWFXT00
(Biscuit)
W10459022
LINER PARTS
6
For Model: 8W8TXDWFXT00
(Biscuit)
W10459022
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 939962 Rivet
3 2183061 Cover, Air Diffuser
4 2303825 Adaptive Defrost
Control
5 489174 Screw
6 488693 Screw
7 2265572 Wire Assembly
Control Box
8 2162085 Socket, Light
9
W10180172
Fan Support
Bracket
10 2197405 Fan Mounting
Bracket
11 2169141 Fan Blade
12
W10338475
Control Box
13 2325701 Thermostat
14 489399 Screw
15 1118680 Thermostat Tube
Barrier
16
W10244012
Cover, Evaporator
17 2311792 Light Bulb
18 9791702 Light Shield
19 1118894 Rocker Arm
Switch
20 2217784 Cover, Hole
21
W10183127
Wiring, Freezer
(Includes Item 32)
22 2202885 Control Knob
23 9790408 Air Tower
24 2197052 Hood And Foil
Assembly
25 2261978 Cover, Air Return
26 2221992 Air Diffuser
Assembly
28 2264462 Grommet, Motor
29 489478 Screw
30 2315539 Evaporator Fan
Motor
31 2262178 Screw
32 2266066 Defrost, BI−Metal
33
W10337823
Tube, Barrier
(2nd)
UNIT PARTS
7
For Model: 8W8TXDWFXT00
(Biscuit)
W10459022
UNIT PARTS
8
For Model: 8W8TXDWFXT00
(Biscuit)
W10459022
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1
W10222450
Support Plate,
Compressor
2 489442 Screw
3 2264597 Condenser
4 2176942 Heater, Defrost
5 2264835 Clip, Condenser
6 8533859 Screw
7 2319224 Heat Shield
8 2263628 Clip, Combo
9 2264278 Tube, Drain
10
W10358308
Scroll, Fan
11 2188874 Motor, Condensor
12 2264278 Clip, Harness
13 24364001 Clip, Compressor
14 Grommet
2264447 Production
2264447 Service
16 939054 Clip, Wire
17 2150304 Roller
18 2264756 Axle, Rivet
19 2262191 Wedge, Evaporator
20 2263920 Evaporator Assy.
21
W10151680
Wire Assy, Unit
22
W10197428
Start− Device
Combination
(Start Relay and
Overload)
23 2262192 Wedge, Evaporator
24 2264129 Fan Blade
25 2264841 Screw
26 2266360 Shield,Electrical
28
W10200250
Compressor
(Includes Items
14, 22, 29 & 32)
29 Drier
W10190413
Production
W10143759
Service
30 2263990 Strap
31 2264838 Sleeve
32 2264017 Capacitor
33 2263928 Evaporator Tray
35 2174739 Tube, Process
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
3.75 Ozs.
(R134A)
SHELF PARTS
9
For Model: 8W8TXDWFXT00
(Biscuit)
W10459022
Illus. Part
No. No. DESCRIPTION
1 9790379 Cover, Meat Pan
2
W10142522
Shelf (2)
3 2222031 Crisper, Cover
4 2263086 Crisper Pan
5 2262441 Glass, Crisper
6 2183273 Pan, Meat
7
W10142525
Shelf, Wire
8 2212446 Body, Humidity
9 2176222 Slide, Humidity
OPTIONAL PARTS
10
For Model: 8W8TXDWFXT00
(Biscuit)
W10459022
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
x 2−5/8")
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4" x 108")
876305 Kit, Insulation
(14 Pcs.
3" x 24" x 48")
876370 Kit, Insulation
(2 Pcs.
3" x 24 " x 48")
876029 Kit, Foam Slab
(30" x 32−1/2" x
1−1/2")
505587 Sealer, Mastic
(1 Qt.)
511873 Touch−Up, White
Porcelain (2 Oz.)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
799832 Kit, Porcelain
Repair (White)
503695 Cork Sealer
(1/4 Pound)
Customer Touch−Up Material
350942 Primer, White
(12 Oz. Spray Can)
350939 Enamel, Black
(12 Oz. Spray Can)
350930 Enamel, White
(12 Oz. Spray Can)
4392901 Enamel, Biscuit
(12 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−Up Kit
(Black)
4392899 Brush Touch−Up Kit
(Biscuit)
Refinishing Material
799344 Enamel, White
(1 Qt. Uncut)
799340 Enamel, Black
(1 Qt. Uncut)
4392900 Enamel, Biscuit
(1 Qt. Uncut)
833938 Kit, Terminal
Connector
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
TORX SCREW WRENCH
1117510 Torx Key
FIELD INSTALLABLE
ICE MAKER
2155469A ECKMF94
