Whirlpool ET16AK Bedienungsanleitung

GGUUIIDDEE

R frid rator-Fr z rs, Ic mak rs, Dishwash rs, Built-in Ov ns and Surfac Units, Rang s, Microwav Ov ns, Trash Compactors, Room Air Condion rs, D humidif rs

No-Frost

R frig rator-

Fr z r

Mod l ET16AK

Us AndCar

Cont nts

Whirlpool Use and Care Guide–No-Frost Refrigerator-Freezer–Model ET16AK

Safety First ..........................................................................................1

Safety Alert Definitions ..................................................................1

Installation............................................................................................3

Install It Properly ............................................................................3

evel It ...........................................................................................3

Remove Sales abels .....................................................................4

Clean It ...........................................................................................4

Plug It In .........................................................................................4

Using Your Refrigerator...................................................................5

Parts and Features............................................................................2

Set The Controls .............................................................................5

Power Saving Control ....................................................................5

Change The Control Settings ..........................................................6

Control Setting Troubleshooting Chart ..........................................6

Move The Meat Pan and Cover ......................................................7

Remove Crispers and Crisper Cover ..............................................7

Change The ight Bulb .................................................................8

Adjust The Refrigerator Shelves ....................................................8

Remove and Adjust The Freezer Shelf ..............................................................8

Energy Saving Tips ........................................................................9

Sounds You May Hear ....................................................................9

Vacation and Moving Care............................................................10

Ice Cube Trays .............................................................................11

Optional Automatic Ice Maker .....................................................11

Food Storage Guide .......................................................................12

Proper Storage–Fresh Food ..........................................................12

Proper Storage–Meat ....................................................................12

Proper Storage–Frozen Food .......................................................13

Cleaning Your Refrigerator .......................................................14

Cleaning Chart ..............................................................................14

Whirlpool Refrigerator Warranty.............................................16

Troubleshooting .............................................................17

Before Calling For Assistance ......................................................17

Service Contacts21

If You Need Assistance .................................................................21

If You Need Service.......................................................................21

If You Have a Problem...................................................................21

Whirlpool Use and Care Guide–No-Frost Refrigerator-Freezer–Model ET16AK

Saf ty First

IMPORTANT

Rul s for Saf Installaon and Op raon

Before doing anything else, please read these rules for safe installation and operation.

1. To ensure safety from entrapment and suffocation, unused refrigerators must have the door removed.

2. Please read the enclosed safety booklet from the Association of Home Appliance Manufacturers.

3. When prepping refrigerator for long vacations, tape rubber or wood blocks to doors and out of reach of

children.

4. Make sure refrigerator is installed and leveled on a floor that will hold the weight.

5. Refrigerator must be plugged in properly. Refer to “Recommended Grounding Method” instructions (Page 4).

6. Determine the refrigerator will fit the area installing.

7. Do not install near an oven, radiator, or other heat source.

8. Do not use an extension cord. Use a receptacle which cannot be turned off with a switch or pull chain.

9. Use refrigerator only for jobs expected of home refrigerators.

10. Always maintain refrigerator according to instructions (Page 5).

11. Refrigerator is not for outdoor use.

12. Do not install refrigerator where the room temperature is less than 55º F (13º C).

13.. Do not use rubbing alcohol or flammable or toxic solvents to remove labels.

15. Refrigerator usage is to be limited to those with a working knowledge of the appliance.

16. Keep refrigerator empty until it reaches the proper temperature for food storage.

17. Do not remove any permanent instruction labels inside refrigerator.

18. Do not remove the Tech Sheet fastened under the refrigerator at the front.

19. Before removing lightbulb, unplug or disconnect refrigerator.

20. Be aware that the glass shelving is heavy when moving it.

21. Turn refrigerator control off, unplug refrigerator, and take out all removable parts prior to cleaning.

22. Store fresh and frozen foods as instructions outline.

23. When moving the refrigerator, remove all food from refrigerator first.

24. Clean refrigerator, as instructions outlined, prior to first use.

Your saf ty and th saf ty of oth rs is v ry important.

Always r ad and ob y all saf ty m ssag s.

This is the safety alert symbol.

This symbol alerts user to potential hazards that could kill or hurt them and

others. All safety messages will follow the safety alert symbol and either the

word “DANGER” or “WARNING.”

Danger designates immenent death or very serious injury.

Warning designates serious injury.

All safety messages will describe the hazard, describe the consequences, and instruct you how to avoid it.

Caution designates minor injury or product damage.

CCAAUUTTIIOONN

Whirlpool Use and Care Guide–No-Frost Refrigerator-Freezer–Model ET16AK

Parts and F atur s

Prop r Disposal of R frig rator

Su ocaon Hazard. Refrigerator

entrapment can cause death. Remove

refrigerator doors prior to disposing.

Do the following prior to disposing of old refrigerator-freezer:

•Remove the doors (See Figure 2).

• eave shelves in place to keep children from climbing inside.

Parts and Features (Figure 1)

Proper Disposal of Refrigerator (Figure 2)

Whirlpool Use and Care Guide–No-Frost Refrigerator-Freezer–Model ET16AK

Installaon

1. INSTALL IT PROPERLY... 2. LEVEL IT...

To level your refrigerator, do the following:

(See Figure 4)

1. To raise front, turn each screw to the right.

2. To lower front, turn each screw to the left.

3. Check with a level at base of refrigerator.

To properly install, do the following:

(See Figure 3)

1. Allow 3 inches (7.5 cm) between overhead

cabinets and the refrigerator top.

2. Allow at least an inch (2.5 cm) between the

refrigerator condenser and the wall.

3. Allow 1/2 inch (1.25 cm) on each side of the

refrigerator for ease of installation.

4. If the refrigerator is to be against a wall, leave

enough space so the door can open completely.

Excessive Weight Hazard. Heavy

refrigerators can cause serious injury

or death. Use two or more people

when moving refrigerator.

Crash Hazard. Unstable ﬂoors can cause

refrigerator to fall on a person. Make

sure refrigerator is installed and leveled

on a ﬂoor that can hold the weight.

Level It (Figure 4)

Install It Properly (Figure 3)

Whirlpool Use and Care Guide–No-Frost Refrigerator-Freezer–Model ET16AK

RECOMMENDED GROUNDING METHOD

(See Figure 5)

A 115 Volt, 60 Hz., AC only 15 or 20 ampere fused and properly grounded electrical supply is required.

Plug into a grounded three-prong outlet. Do not remove ground prong, do not use an adapter, and do not use

an extension cord. It is recommended that a separate circuit serving only this appliance be provided.

See individual electrical requirements and grounding instruction sheet in your literature package.

5. PLUG IT IN...

Prior to first use, and after removing all the

packaging and sales labels, clean your refrigerator.

Refer to “Cleaning Your Refrigerator”

(Pages 14 and 15).

4. CLEAN IT...

Remove the Consumer Buy Guid label, tape, and any

inside labels before use.

To remove any remaining glue, do the following:

1. Rub briskly with thumb to make a ball and remove.

2. Soak area with dishwashing detergent solution

(1teaspoon detergent in 1 quart warm water) before

removing glue as described in step 1.

3. REMOVE SALES LABELS...

Explosion hazard. Ignion of rubbing

alcohol or inﬂammable or toxic solvents can

cause serious injury or death. Do not use

gasoline, carbon tetrachloride, etc. to clean

this product.

Installaon(Connu d...)

Electrical Shock Hazard. Electricity can

cause death or serious injury. Always make

sure wall receptacle and plug are grounded

before plugging in refrigerator.

NOTE: Do not remove any permanent instrucon labels

inside your refrigerator. Do not remove the Tech Sheet

fastened under the refrigerator at the front.

Plug It In (Figure 5)

Whirlpool Use and Care Guide–No-Frost Refrigerator-Freezer–Model ET16AK

Using Your R frig rator

SET THE CONTROLS...

NOTE: It may take several hours for the refrigerator to cool down completely. Allow it to reach desired coolness prior to

adding food to the refrigerator.

NOTE: A good way to determine if your refrigerator is set at the correct temperature is if ice cream is ﬁrm and the milk

and juice is cold enough for you.

You will find these controls inside your refrigerator (See Parts and Features, Page 2). After plugging in your

refrigerator for the first time, set the controls to these suggested temperatures to ensure the best food storage

results (See Figure 6).

Set Refrigerator

control to 3

Set Freezer

control to B

POWER SAVING CONTROL...

The Power Saving Control on the Control Console (see top of this page) operates electric heaters around the

door openings. These heaters help keep moisture from forming on the outside of the refrigerator. (See Figure 6)

CONTROL CONSOLE...

Use the

CONSUMES LESS ENERGY

seng when humidity is low.

Use the

REDUCES EXTERIOR MOISTURE

seng only if moisture forms on the

outside of the refrigerator

Control Console (Figure 6)

Whirlpool Use and Care Guide–No-Frost Refrigerator-Freezer–Model ET16AK

Using Your R frig rator (Connu d...)

CHANGE THE CONTROL SETTINGS...

Use the following guidelines when adjusting the temperatures in your refrigerator or freezer:

• Adjust the Refrigerator Control first.

• Wait at least 24 hours between adjustments.

• Then adjust the Freezer Control, if needed.

Deciding what settings to use is made easy by the chart below.

QUESTIONS?

Call your COOL-LI!E service assistance telephone number.

Continental U.S. .........................................800.253.1301

ichigan .....................................................800.632.2243

Alaska & Hawaii ........................................800.253.1121

CONDITION

If Refrigerator Section is TOO WARM

If Freezer Section is TOO WARM

If Refrigerator Section is TOO CO D

If ICE isn’t MADE FAST ENOUGH

If BOTH SECTIONS are TOO WARM

REASONS

Door opened often

arge amount of food added

Room temperature too warm

Door opened often

arge amount of food added

Very cold room temperature

(can’t cycle often enough)

Controls not set correctly for

your conditions

Heavy ice usage

Very cold room temperature

(can’t cycle often enough)

Door opened often

arge amount of food added

Very warm or very cold room

temperatures

RECOMMENDED

CONTROL SETTINGS

Refrigerator - 4

Freezer - C

Refrigerator - 3

Freezer - A

Refrigerator - 2

Freezer - B

Refrigerator - 3

Freezer - A

Refirgerator - 4

Freezer - B

CONTROL SETTINGS TROUBLESHOOTING CHART

Whirlpool Use and Care Guide–No-Frost Refrigerator-Freezer–Model ET16AK

Using Your R frig rator (Connu d...)

The meat pan is removable for cleaning and can also be moved to another shelf if desired.

To remove the meat pan and cover, do the following:

1. Slide meat pan out to stop.

2. ift the front of meat pan.

3. Slide pan the rest of the way out.

4. To remove cover, push up glass insert from bottom, then

lift out with both hands (See Figure 7).

5. ift cover frame straight up and out.

To replace the meat pan and cover, do the following:

1. To replace cover, fit notches in cover frame sides over cen-

ter shelf support.

2. ower cover frame into place.

3. ower glass insert into cover frame.

4. To replace pan, fit edges of pan into supports on cover.

5. Slide meat pan into place.

MOVE THE MEAT PAN AND COVER...

(See Figure 8)

To remove the crispers, do the following:

1. Slide crisper straight out to stop, lift front, and then,

slide the rest of the way out.

2. Slide crisper back out, lift front, and then, slide in to

stop.

To remove the cover, do the following:

1. Push up glass insert from bottom, and then, slide out

with both hands.

2. ift front of cover frame and remove cover support.

3. ift out cover frame by pulling up and out.

To replace the cover, do the following:

1. Fit back of cover into notch supports on wall of

refrigerator, then, lower front into place.

2. Replace cover support with the long tab towards the front.

3. Slide back of glass insert into place, then lower front.

REMOVE CRISPERS AND CRISPER COVER...

NOTE: If the support needs adjustment, turn base right to raise, or le to lower.

Cov r

<– Support

Low r –>

Meat Pan and Cover(Figure 7)

Remove Crispers and Crisper Cover (Figure 8)

Whirlpool Use and Care Guide–No-Frost Refrigerator-Freezer–Model ET16AK

To change your refrigerator light bulb, do the following:

1. Reach behind Control Console to find bulb.

2. Unscrew bulb.

3. Screw a 40-watt appliance bulb in to socket (See Figure 9).

CHANGE THE LIGHT BULB...

Using Your R frig rator (Connu d...)

Electrical Shock Hazard. Electricity can

cause death or serious injury. Always

make sure wall receptacle and plug are

grounded prior to plugging in refrigerator.

To adjust the shelving, do the following:

1. First, remove the food from shelf.

2. Slide shelf straight out to stop.

3. ift front (See Figure 10).

4. Slide the rest of the way out.

To replace the shelving, do the following:

1. Fit back of shelf on top of guides with wire stops on the bottom of guides.

2. ift front, slide shelf in until it clears guide stops.

ADJUST THE REFRIGERATOR SHELVES...

Sh lf guid

Sh lf Stop

Guid Stop

To remove the shelf, do the following:

1. ift front slightly.

2. ift back off supports.

3. Replace in reverse order.

To adjust the shelf, do the following:

1. Remove food from shelf.

2. Remove shelf

3. Remove supports by sliding upwards (See Figure 11).

4. Replace supports on desired level.

5. Replace shelf.

REMOVE AND ADJUST THE FREEZER SHELF...

Sh lf Support

Change The Light Bulb (Figure 9)

Adjust The Refrigerator Shelves (Figure 10)

Remove And Adjust The Freezer Shelf (Figure 11)

Andere Handbücher für ET16AK

Inhaltsverzeichnis

Andere Whirlpool Kühlschrank Handbücher

Whirlpool

Whirlpool WRQA59CNKZ Bedienungsanleitung

Whirlpool

Whirlpool WRS571CIHV Bedienungsanleitung

Whirlpool

Whirlpool Roper RS25AQXKQ00 Bedienungsanleitung

Whirlpool

Whirlpool ET8WTKXKB09 Bedienungsanleitung

Whirlpool

Whirlpool GI6FDRXXB Montageanleitung

Whirlpool

Whirlpool WRS322FDAB00 Bedienungsanleitung

Whirlpool

Whirlpool WRX988SIBM Bedienungsanleitung

Whirlpool

Whirlpool WUR50X24HZ Bedienungsanleitung

Whirlpool

Whirlpool MULLION EVAPORATOR DESIGN Bedienungsanleitung

Whirlpool

Whirlpool ED25DQXDB06 Bedienungsanleitung

Whirlpool

Whirlpool GC3SHEXNB15 Bedienungsanleitung

Whirlpool

Whirlpool GB2FHDXWB Montageanleitung

Whirlpool

Whirlpool W55VM 1100 W Bedienungsanleitung

Whirlpool

Whirlpool ER2MHKXPL01 Bedienungsanleitung

Whirlpool

Whirlpool W10193172A Bedienungsanleitung

Whirlpool

Whirlpool GZ25FSRXY Stücklistenhandbuch

Whirlpool

Whirlpool ET1MHKXMB06 Bedienungsanleitung

Whirlpool

Whirlpool 2188771 Bedienungsanleitung

Whirlpool

Whirlpool WRT371SZBW00 Bedienungsanleitung

Whirlpool

Whirlpool WH40S1E Bedienungsanleitung

Whirlpool

Whirlpool ET20NK Bedienungsanleitung

Whirlpool

Whirlpool ET16EP Bedienungsanleitung

Whirlpool

Whirlpool ED2VHGXMB01 Bedienungsanleitung

Whirlpool

Whirlpool WHR46TS1E Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
