TECHNICAL EDUCATION

JOB AID 4317332

KAC-30

36″ & 48″ ISLAND

AND WALL CANOPY

RANGE HOODS

- ii -

WHIRLPOOL CORPORATION assumes no responsibility for any repairs made

on our products by anyone other than Authorized ervice Technicians.

FORWARD

This Job Aid, KitchenAid “36″ and 48″ Island And Wall Canopy Range Hoods,” (Part No. 4317332),

provides the technician with information on servicing the Island And Wall Canopy Range Hoods.

It is to be used as a training Job Aid and ervice Manual. For specific information on the model being

serviced, refer to the “Use and Care Guide” provided with the hood.

The Wiring Diagrams used in this Job Aid are typical and should be used for training purposes only.

Always use the Wiring Diagram supplied with the product when servicing the unit.

GOALS AND OBJECTIVES

The goal of this Job Aid is to provide detailed information that will enable the service technician to

properly diagnose malfunctions and repair the KitchenAid Island And Wall Canopy Range Hoods.

The objectives of this Job Aid are to:

• Understand and follow proper safety precautions.

• uccessfully troubleshoot and diagnose malfunctions.

• uccessfully perform necessary repairs.

• uccessfully return the range hood to its proper operational status.

- iii -

TABLE OF CONTENTS

Page

GENERAL............................................................................................................................... 1-1

Important afety Information ............................................................................................. 1-1

KitchenAid Model & erial Number Designations.............................................................. 1-2

Model & erial Number Label Location ............................................................................. 1-3

pecifications..................................................................................................................... 1-4

KitchenAid Range Hood Warranty ..................................................................................... 1-7

CO PONENT ACCESS ......................................................................................................... 2-1

Wall Hood Component Locations ...................................................................................... 2-1

Removing A lide witch, The Indicator Lamp, & The Blower Motor ................................ 2-2

Removing A Halogen Lamp ocket ................................................................................... 2-5

Island Hood Component Locations.................................................................................... 2-6

Removing The Ballast Transformer ................................................................................... 2-7

Removing The Control Board ............................................................................................ 2-8

Removing The Blower Motor ........................................................................................... 2-10

CO PONENT TESTING ........................................................................................................ 3-1

Blower Motor...................................................................................................................... 3-1

Ballast Transformer ........................................................................................................... 3-1

2- & 3-Position lide witches ........................................................................................... 3-2

peed (Variable) Control ................................................................................................... 3-2

WIRING DIAGRA S .............................................................................................................. 4-1

Island Hood........................................................................................................................ 4-1

Wall Hood .......................................................................................................................... 4-2

- iv -

— NOTES —

1-1

ELECTRICAL SHOCK HAZARD

Disconnect power before servicing.

Rep ace a pane s before operating.

Fai ure to do so cou d resu t in death or

e ectrica shock.

Important safety messages have been pro-

vided in this Job Aid. Always read and obey all

safety messages.

GENERAL

IMPORTANT SAFETY INFORMATION

Your safety and the safety of others is very important.

This is the safety alert symbol.

This symbol alerts you to haz-

ards that can kill or hurt you

and others.

All safety messages will be preceded by the

safety alert symbol and the word “WARNING.

All safety messages will identify the hazard, tell

you how to reduce the chance of injury, and tell

you what can happen if the instructions are not

followed.

WARNING

1-2

KITCHENAID MODEL & SERIAL NUMBER DESIGNATIONS

MODEL NUMBER

SERIAL NUMBER

SERIAL NUMBER F J J 4 6 02453

MANUFACTURING SITE

YEAR OF PRODUCTION

J = 1999, K = 2000, L = 2001, M = 2002

WEEK OF PRODUCTION

46TH WEEK

PRODUCT SEQUENCE NUMBER

MODEL NUMBER K WC U 3 8 0 J S S 0

INTERNATIONAL SALES IND.

OR MARKETING CHANNEL

IF PRESENT

PRODUCT GROUP

K = KITCHENAID BRAND

PRODUCT IDENTIFICATION

IC = ISLAND HOOD

IV = ISLAND VENT

IR = ISLAND RETRACTABLE

WV = WALL VENT

PI = POWER INTERIOR

PE = POWER EXTERIOR

SV = SIDE VENT

WC = WALL CANOPY

MERCHANDISING SCHEME

D = DOWNDRAFT

U = UPDRAFT

CAPACITY / SIZE / SERIES / CONFIGURATION

1ST POSITION 2ND POSITION

0 = SIDE DOWNDRAFT 0 = 30″WIDE

1 = STANDARD UPDRAFT 5 = 500 CFM

2 = SLIDE-OUT UPDRAFT 6 = 36″ WIDE

3 = CANOPY 8 = 48″WIDE

8 = DOWNDRAFT 9 = 900 CFM

FEATURES

0 = STANDARD

1 = INTERIOR POWER

2 = EXTERNAL POWER

5 = ELECTRONIC CONTROLS

YEAR OF INTRODUCTION

H = 1999

J = 2000

K = 2001

COLOR CODE

WT = WHITE

BT = BISCUIT

SS = BRUSHED STAINLESS STEEL

ENGINEERING CHANGE (0, 1, 2, ETC.)

1-3

MODEL & SERIAL NUMBER LABEL LOCATION

The Model/Serial Number label locations are shown below.

Mode & Seria Number Location

(Wa Range Hood)

Mode & Seria Number Location

(Is and Range Hood)

1-4

SPECIFICATIONS

Is and Hoods

Model Number KICU265H SS, WT, BT KICU285H SS, WT, BT

Dimensions/Specifications

Overall Width (in) 35 3/8" 47 1/4"

Overall Depth (in) 23 5/8" 23 5/8"

Canopy Height (in) 10 1/4" 10 1/4"

Chimney Height (in) 24 5/8" to 34 3/4" 24 5/8" to 34 3/4"

Weight

Net Weight (lbs) 77 8 4

Shipping Weight (lbs) 82 90

Ratings

120v AC Yes Yes

Circuit Amps 15 AMP 15 AMP

Exterior

Hood Exterior

Type/Configuration Canopy-Updraft Canopy-Updraft

Size (Inches) 36 Inches 48 Inches

Color Stainless Stainless

Grease Filters 3 Heavy Duty (DW Safe) 3 Heavy Duty (DW Safe)

CFM 600 600

Sones 6.5 6.5

Light 2 Fluorescent Bulbs 2 Fluorescent Bulbs

Brand Logo Location KitchenAid KitchenAid

Controls

On/Off Yes Yes

Variable Speed Yes Yes

Auto Off No No

Interior

Ducting Convertible with kit Convertible with kit

Dimension 3 1/4" x 10" 3 1/4" x 10"

Accessories

Backsplash

Backsplash Kit Part/Description

Ductless Operation Kit Part/Description 4378625/Stainless 4378625/Stainless

Chimney Extension Kit

Wire Rack Kit Part/Description

Wire Rack Hanger Kit Part/Description

Utensil Bar-15 Inch Sides Kit 4378619 4378619

Utensil Bar-Back

Miscellaneous

Product Literature

Installation Instructions Part/Comment 4360369 4360369

Job Aid Part/Comment 4317332 4317332

Use & Care Guide Part/Comment 4360369/English; 4360370/French 4360369/English; 4360370/French

Wiring Diagram Part/Comment In Use and Care Guide In Use and Care Guide

Other

Agency Approvals UL,CUL UL,CUL

Warranty

Full (Months) 12 12

Power System Motor 48 Mo 48 Mo

1-5

Wa Hoods

Model Number KWCU205H SS, WT, BT KWCU265H SS, WT, BT KWCU285H SS, WT, BT

Dimensions/Specifications

Overall Width (in) 29 7/8" 35 3/8" 47 1/4"

Overall Depth (in) 19 1/4" 19 1/4" 19 1/4"

Canopy Height (in) 9 1/2" 9 1/2" 9 1/2"

Chimney Height (in) 23" to 42" 23" to 42" 23" to 42"

Weight

Net Weight (lbs) 4 5 52 59

Shipping Weight (lbs) 4 9 57 65

Ratings

120v AC Yes Yes Yes

Circuit Amps 15 AMP 15 AMP 15 AMP

Exterior

Hood Exterior

Type/Configuration Wall-Updraft Wall-Updraft Wall-Updraft

Size (Inches) 30 Inches 36 Inches 48 Inches

Color Stainless Stainless Stainless

Grease Filters 2 Heavy Duty (DW Safe) 3 Heavy Duty (DW Safe) 3 Heavy Duty (DW Safe)

CFM 600 600 600

Sones 6.5 6.5 6.5

Light 1 Fluorescent Bulb 1 Fluorescent Bulb 1 Fluorescent Bulb

Brand Logo Location KitchenAid KitchenAid KitchenAid

Controls

On/Off Yes Yes Yes

Variable Speed Yes Yes Yes

Auto Off No No No

Interior

Ducting Convertible with kit Convertible with kit Convertible with kit

Dimension 3 1/4" x 10" 3 1/4" x 10" 3 1/4" x 10"

Accessories

Backsplash

Backsplash Kit Part/Description 8171295/Stainless 4378615/Stainless 8171296/Stainless

Ductless Operation Kit Part/Description 4378621/Stainless 4378621/Stainless 4378621/Stainless

Chimney Extension Kit N / A N / A N / A

Wire Rack Kit Part/Description 8171297 4378616 8171298

Wire Rack Hanger Kit Part/Description 4378617 4378617 4378617

Utensil Bar-15 Inch Sides Kit 4378619 4378619 4378619

Utensil Bar-Back 8171299 4378618

Miscellaneous

Product Literature

Installation Instructions Part/Comment

Job Aid Part/Comment 4317332 4317332 4317332

Use & Care Guide Part/Comment 4360367/English;

4360368/French

4360367/English;

4360368/French

4360367/English;

4360368/French

Wiring Diagram Part/Comment In Use & Care Guide In Use & Care Guide In Use & Care Guide

Other

Agency Approvals UL,CUL UL,CUL UL,CUL

Warranty

Full (Months) 12 12 12

Power System Motor 48 Mo 48 Mo 48 Mo

1-6

Model Number KWCU380JSS KWCU360JSS

Size-Configuration 48" - Wall Canopy 36" - Wall Canopy

Feature Level/Series Professional Series Professional Series

Dimensions/Specifications

Exterior Dimensions

Overall Width (in) 4 8 " 36"

Overall Depth (in) 25" 2 5 "

Canopy Height (in) 18" 18"

Chimney Height (in) Accessory Accessory

Other Dimensions

Net Weight (lbs) 79 5 4

Shipping Weight (lbs) 116 8 4

Ratings

Electric Voltage/Phase/Frequency (Hz) 60 HZ 60 HZ

120v AC Yes Yes

Circuit Amps 15 15

Exterior

Hood Exterior

Type/Configuration Wall-Updraft Wall-Updraft

Size (Inches) 48 Inches 36 Inches

Color Stainless Stainless

Grease Filters Baffle Baffle

Power System Internal Internal

CFM 1200 600

Sones Maximum 6.5 Maximum 6.5

Light 4 Halogen Lights (12V 20 watt, Included) 3 Halogen Lights (12 V 20 watt, Included)

Warming Lamp No Heat Lamps No Heat Lamps

Control Area Under Canopy Under Canopy

Controls 3 Slide Switches 3 Slide Switches

Light On/Off Yes Yes

Blower On/Off Yes Yes

Variable Speed No No

Number of Speeds 3 3

Auto Off No No

Interior

Ducting Top or Rear Vented Top or Rear Vented

Dimension Rectangular 3 1/4" x 10" Rectangular 3 1/4" x 10"

Accessories

Backsplash Optional Optional

Backsplash Kit Part/Description 8284755/Stainless; telescopic, height

extends up to 39" high

8284756/Stainless; telescopic, height

extends up to 39"

Chimney Extension Kit Optional - 2 Choices Optional - 2 choices

Chimney Extension Kit Part/Description

8284752: 48"(W) x 12"(H) or 8284754:

24"(W) x 12" to 24"(H) (Height expands

to 8' - 9' ceilings)

8284753: 36"(W) x 12"(H) or 8284754:

24"(W) x 12" to 24" (H) (Height expands

to 8' - 9' Ceilings)

Comment

Discharge Transition = 8284757:

Transitions from two 3 1/4" x 10" to One

10" Rnd (not for use w/chimney kit

8284754)

Miscellaneous

Product Literature

Installation Instructions Part/Comment 8284601 8284601

Use & Care Guide Part/Comment w/installation instructions, 8284601 w/installation instructions, 8284601

Job Aid 4317332 4317332

Other

Agency Approvals UL,CUL UL,CUL

Warranty

Full (Months) 12 12

Power System Motor 48 Mo 48 Mo

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Whirlpool Dunstabzugshaube Handbücher

Whirlpool

Whirlpool Amana UXW7324BSS Produktinformationsblatt

Whirlpool

Whirlpool WVW75UC6DS0 Produktinformationsblatt

Whirlpool

Whirlpool YUMV4084 Bedienungsanleitung

Whirlpool

Whirlpool UXT4230AD Produktinformationsblatt

Whirlpool

Whirlpool UXT5530AAS Bedienungsanleitung

Whirlpool

Whirlpool UXT2030AD Produktinformationsblatt

Whirlpool

Whirlpool UXI6536BSS Handbuch

Whirlpool

Whirlpool GZ7930XHS1 Bedienungsanleitung

Whirlpool

Whirlpool AKR 687 - EXTRACTOR OR FILTERING HOOD Bedienungsanleitung

Whirlpool

Whirlpool WHVA 62F LM K Bedienungsanleitung

Whirlpool

Whirlpool WVI75UC6DS0 Produktinformationsblatt

Whirlpool

Whirlpool UXT5230AYB0 Produktinformationsblatt

Whirlpool

Whirlpool 99043751B Produktinformationsblatt

Whirlpool

Whirlpool Cooker hoods Betriebsanleitung

Whirlpool

Whirlpool RH2630XJ Service-Handbuch

Whirlpool

Whirlpool WVW51UC6FS Handbuch

Whirlpool

Whirlpool RJH 3330-1 Bedienungsanleitung

Whirlpool

Whirlpool UXT4036ADB0 Produktinformationsblatt

Whirlpool

Whirlpool GXI6536DXS Produktinformationsblatt

Whirlpool

Whirlpool RH2030XJB3 Bedienungsanleitung

Whirlpool

Whirlpool UXT3030AYW0 Produktinformationsblatt

Whirlpool

Whirlpool AKR3100/IX Bedienungsanleitung

Whirlpool

Whirlpool 30" AND 36" (76.2 AND 91.4 CM) WALL-MOUNTCANOPY RANGE... Produktinformationsblatt

Whirlpool

Whirlpool 99044504A Produktinformationsblatt

Beliebte Dunstabzugshaube Handbücher anderer Marken

emmeti

emmeti RECUPA MED A-140 Leitfaden

Nibe

Nibe F135 Bedienungsanleitung

Kuppersberg

Kuppersberg INTRO 60 Montage- und Wartungsanleitung

Zephyr

Zephyr Spruce AK9834BS Installationsanleitung

Hisense

Hisense MH6INBG Bedienungsanleitung

Miele

Miele DA 1255 Bedienungsanleitung

Broan

Broan 46000 Bedienungsanleitung

GE Profile PV977 Originalbetriebsanleitung

FALMEC

FALMEC FFRIA24W5FS Bedienungsanleitung

Küppersbusch

Küppersbusch DX ISLA Bedienungsanleitung

ETNA

ETNA AV360RVS Bedienungsanleitung

JUNO

JUNO JDF603E6 Bedienungsanleitung

Miele

Miele DA 6708 D Bedienungsanleitung

Tricity Bendix

Tricity Bendix LE 150 Handbuch

AEG

AEG X68163BV1 Bedienungsanleitung

AEG

AEG 125 D Bedienungsanleitung

Smeg

Smeg KSEV97X Bedienungsanleitung

Nibe

Nibe S Series Benutzerhandbuch
