INSTRUCTIONS FOR USE

TUMBLE DRYER

IMPORTANT: PLEASE READ THESE

INSTRUCTIONS THOROUGHLY BEFORE USING

THIS APPLIANCE. KEEP THEM IN A SAFE PLACE FOR

FUTURE REFERENCE.

IMPORTANT USER INFORMATION

–This tumble dryer is intended for NORMAL DOMESTIC

USE ONLY.

-Adequate ventilation must be provided to avoid back flow of

gases into the room from appliances burning other fuels.

Including open fires.

-Exhaust air must not be discharged into a flue which is used

for exhausting fumes from appliances burning gas or other

fuel.

–Please note it is not recommended that the dryer is placed

directly next to ovens or cookers as the performance of the

dryer may be affected.

–A carpet must not obstruct the ventilation openings in the

base of the dryer.

–Do not stack the tumble dryer on top of other appliances

without the correct stacking kit.

–Any electrical work required to install the appliance should

be carried out by a qualified person.

–It is important to clean the lint filter after each drying cycle

or the restrictions to airflow will extend drying times and

could cause the safety cut-out to trip.

–Under no circumstances should anything other than the

recommended articles be placed in the tumble dryer.

–The tumble dryer should be serviced by an appointed service

organisation and only genuine parts used.

–It is dangerous to alter or modify the product in any way

other than fitting authorized accessories.

–We recommend that the appliance is unplugged each time

after use.It should always be disconnected from the electricity

supply or long periods (i.e.weekends, holidays etc.)

–The rear of the dryer gets quite hot during use. Position the

dryer so that the back is not accessible while in operation, but

ensure that the sides have a space available to allow airflow.

–The special mains cable and plug assembly must only be

replaced with a genuine part from the manufacturer or our

appointed service agent.

It is important to clean fluff from the window of the dryer and

around the door seal after each drying cycle. Failure to do so

could result in water leaking.

- This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning use

of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children

without supervision. Children of less than 3 years should be

kept away unless continuously supervised.

WARNING: Never stop a tumble dryer before the end of a

drying cycle unless all items are quickly removed and spread

out so that heat is dissipated.

Remove all objects from pockets such as lighters and matches.

DO NOT use a two-way adaptor, or extension lead. The dryer

must be connected to its own socket.

DO NOT block the air inlets at the front, base, rear and side of

your dryer.

DO NOT allow fluff to accumulate around the tumble dryer.

Risk of fire

DO NOT exceed the recommended maximum load.

DO NOT dry unwashed items in the tumble dryer

DO NOT place articles in the dryer if anything other than a

water solution has been used in the cleaning process.

DO NOT attempt to dry dripping wet articles.

DO NOT use the tumble dryer if you suspect that it is

damaged in any way. Under no circumstances should you

attempt to repair the appliance yourself. Repairs carried out by

inexperienced persons may cause serious injury. Consult your

local appointed service engineer and insist on genuine spare

parts.

INSTALLATION

Position the tumble dryer so that the plug remains accessible after installation. Do not block the vent at the front or

base of the dryer, as this will impair the working of the machine. This appliance must not be installed behind a

lockable door, a sliding door or a door with hinges on the opposite side to that of the tumble dryer.

TUMBLE DRYER VENTING

Your tumble dryer will release warm, damp air in one of three ways.

1) EXTENDABLE REAR VENTING - A long flexible vent hose is built into the dryer

and can be extended from the large opening at the rear of the machine

2) FIXED REAR VENTING - Venting is through the large opening at the bottom of

the rear panel. A separate extendible vent hose can be attached if desired.

3) FRONT VENTING - This is a special type of dryer which vents through a grille on the

plinth. The opening on the rear panel is blanked off during manufacturing.

Rear vented dryers can be used without a vent hose but not in a confined space. Rear vented machines must

have a vent hose if they are installed under a work surface. To minimise condensation it is preferable to vent

through a vent to outside. This may be through an open door or window. The best solution is to connect the vent

hose to a permanent connection through a wall or a single glazed window.

This is particularly recommended for small, cool rooms. A kit for this purpose is available as an accessory.

Front venting machines must be converted to extendible rear venting before a permanent connection can be

made to the outside.

When using a vent hose, remember the following points:

The vent hose must be at least 10cm (4 ins) in diameter.

No more than three right-angled bends should be allowed when positioning the vent hose.

Do not distort or constrict the vent hose as this will reduce the airflow.

The vent hose must not be shared with other appliances, for example, a cooker hood outlet.

FINAL INSTALLATION

Push the filter into its operating position as shown in

the diagram. If you wish to change the side on which

your door opens, see the instructions on the back

page. Remove any dust by wiping the drum and door

with a damp cloth. Any initial smell of burning will

be caused by dust on the heater and will quickly

disappear.

THE CONTROLS

A. THE TIMER Select the required drying time based on the recommendations on the control panel.

B. HEAT SWITCH(ES) Select the required heat setting based on the recommendations on the control panel.

C. START BUTTON (IF FITTED) Press Start button after closing the door and selecting the required

drying time.

PREPARATION

Check care labels inside the garments.

CARE LABELS YOU MAY FIND ON YOUR FABRICS

Do not tumble dry woollen or wool mixture articles unless the article is labelled as being suitable .This should

avoid shrinkage.

Place delicate articles, e.g.tights, scarves, inside a pillowcase.

To avoid the need to iron easycare polyester/cotton items it is better to only dry small loads (i.e. half fill drum) It is

better to dry small and large articles together.

Fabric softeners, or similar products, should be used as specified by the fabric softener instructions. Do not

overload the dryer or dry large bulky items such as duvets or sleeping bags as it is important that the airflow

through the dryer is not obstructed.

The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are left at a

temperature that ensures that the items will not be damaged.

Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers,

turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being

dried in the tumble dryer.

Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and clothes or

pillows fitted with foam rubber pads should not be dried in the tumble dryer.

OPERATION

Open the door.

Load clothes loosely into the drum.

Load sheets first, starting with one corner.

Close the door.

Dry your hands.

Check that the timer is in the ‘0’position.

Plug in the machine.

Select correct heat position, (see programme chart on control panel for recommendations).

The standard cotton programme is suitable to dry normal wet cotton laundry. It is the most efficient programme in

terms of energy consumption for drying wet cotton laundry.

If your appliance is a reversing, small door opening a full load will typically take 115 minutes and will use

approximately 3.92kWh of electricity. A half load will typically take 66 minutes and will use approximately 2.08

kWh of electricity.

If your appliance is a uni-directional, small door opening a full load will typically take 110 minutes and will use

approximately 3.93kWh of electricity. A half load will typically take 65 minutes and will use approximately 2.08

kWh of electricity.

If your appliance is a reversing, large door opening a full load will typically take 130 minutes and will use

approximately 3.77kWh of electricity. A half load will typically take 80 minutes and will use approximately 2.12

kWh of electricity.

If your appliance is a uni-directional, large door opening a full load will typically take 130 minutes and will use

approximately 3.84kWh of electricity. A half load will typically take 75 minutes and will use approximately 2.09

kWh of electricity.

Set the timer to the required time setting (see programme chart on control panel for recommendations).

For energy labeling purposes (EN61121:2005) for a cotton dry load, use the maximum load weight for cotton and

set the timer to the recommended drying time for cotton dry as specified on the control panel.

Press the start button if fitted.

The drum will begin rotating. Reversing drum models will stop periodically to rotate in the reverse direction for a

short time.

Should the clothes become dry before the cycle has finished, or if an excessive programme time has been selected,

the drum will continue to rotate while the thermostat will automatically regulate the heater to reduce the risk of

over drying.

If the door is opened during a cycle the dryer will stop. To restart, close the door and press the start button (if

fitted).When drying large items such as sheets, we suggest you periodically stop the dryer to redistribute the load,

and restart it immediately afterwards

There is an automatic 12 minute cool down period at the end of every cycle, during which the heater is switched

off. This helps to minimize creasing, and must always be used fully to avoid the risk of fire.

NEVER SWITCH THE DRYER OFF AND LEAVE A HOT LOAD IN THE DRUM. RISK OF FIRE.

ALWAYS CLEAN THE FILTER AFTER EACH USE. Failure to do so could cause the safety cut-out to

operate.

- Pull the filter upwards and away from the appliance.

- Remove any threads or fluff by hand or with a soft brush.

- Slide the filter back.

- Wash the filter occasionally in detergent solution using a soft brush to

remove small particles.

- If your filter becomes damaged, replace it to ensure no damage is caused to

the dryer.

CUSTOMER ADVICE – BEFORE CALLING FOR ASSISTANCE

If the clothes are not dry after normal drying time:

–Check that you used the correct heat setting.

–Check that you have not set the timer within a cool down period.

–Check that the lint filter has been cleaned. A blocked filter will restrict the airflow.

–Check that your dryer is heating - below the door to the left side, should feel warm to the touch after the first 10-

15 minutes of its programme.

Failure to heat may indicate the safety cut-out has operated. To reset, simply press the red button at the rear of the

machine. If it has operated then a sharp “click” will be heard.

This cut-out only operates if the airflow is severely restricted so make sure the filter is clean, the air inlets and

outlets at the side and back are not blocked, and that all other restrictions are removed before re-starting.

If the cut-out continues to operate after checking the above points, you should contact your service agent.

Check that the machine has the correct weight load in the drum before starting the appliance.

If your machine does not work check the following before calling a service engineer:-

- Check that there is a supply of electricity.

- Check that the door has been properly closed and the machine is switched on.

- Check the fuse in the moulded plug.

A call out charge will be applied for a service visit, if the call could have been

avoided by following these instructions.

ESSENTIAL CONTACT INFORMATION FOR “IN GUARANTEE” AND

“OUT OF GUARANTEE” REPAIRS.

If problems continue after checking the above points you should contact our service

agent. Please ensure that you have your serial number and model number to hand

when you make the call. To locate the serial number on your dryer, open the door and

look for a white label inside the door opening. This will indicate the appliance model

number along with the serial number.

APPROVED SERVICE AGENTS:

White Knight (Whirlpool) 0800 988 1323 (calls are free from landlines however calls from mobiles may be

charged at your network provider’s rates)

White Knight (0800 Repair): 0344 8797422 (Calls charged at basic rate).

Northern Ireland Only: (Service Network 2000) 028 90365222 (Daytime calls cost up to 14p plus 8p per minute

from BT lines Monday-Friday. Mobile and other providers’ charges may vary).

OPTIONAL EXTRAS

Front to Extendible Rear Venting Kit

To convert your dryer from front venting to extendible rear venting.

Vent Hose

Only available for fixed rear dryers. Leads the warm, damp air to outside.

Wall/Window Vent Kit - To make a permanent connection through a wall or window. Front venting dryers need

converting to rear venting before installing this kit (see ‘Front to Extendible Rear Venting Kit’ above). This kit is

not suitable for double glazed windows.

Stacking Kit - To enable your dryer to be secured onto the top of a front loading washing machine (to save floor

space).

The above items can be purchased as accessories for your tumble dryer from your supplier.

Instructions for stacking, if required, are supplied with the stacking kit.

TECHNICAL DATA

OVERALL DIMENSIONS:

Height: 85 cm

Width: 59.5 cm

Depth: 53 cm

MAXIMUM DRY WEIGHT LOADS:

Cotton 6kg

(For minimum creasing 2kg)

Delicates 6kg

For electrical ratings see plate on back of dryer.

For Model No. see serial plate inside door (needed when requesting service).

Room temperature range 5˚C to 30˚C. (Drying performance decreases as room temperature falls).

Your washing machine should have a spin speed of not less than 1000rpm for maximum efficiency.

THIS APPLIANCE MUST BE EARTHED

This label, positioned on the rear of your dryer, indicates the surface is hot

when in operation – avoid touching

CAUTION

HOT SURFACE

This appliance is marked according to the European Directive 2012/19/EU

on Waste Electrical and Electronic Equipment (WEEE).

This guideline is the frame of a European wide validity of return and

Recycling on Waste Electrical and Electronic Equipment.

LAV SDO Rev

Suppliers name or trade mark WHITE KNIGHT

Model identifier 437, 434, 447, 512, 514, 517, 432, 513, 44B, 44A, 449,

44C - TYPE

Rated capacity at full load 6kg

Appliance type Air Vented

Energy efficiency class C

Energy consumption of the appliance* 459kWh

The figures above is based on 160 drying cycles of the standard cotton programme at full and partial load and the

consumption of the low-power modes. Actual energy consumption per cycle will depend on how the appliance is used.

Automatic/non-automatic Non-automatic

EU Ecolabel N/A

Edry 3.92kWh

Edry½ 2.08kWh

Egdry N/A

Egdry½ N/A

Egdry,a N/A

Egdry½,a N/A

Off mode power (Po) 0W

Left on mode power (Pl) 0W

Duration of left-on mode N/A

The standard cotton programme used at full and partial load is the standard drying programme to which the information in

the label and the fiche relates. This programme is suitable for drying normal wet cotton laundry. It is the most efficient

programme in terms of energy consumption for cotton.

Tt86mins

Tdry 115mins

Tdry½ 66mins

Condensing efficiency class N/A

CtN/A

Cdry N/A

Cdry½ N/A

Sound power level 62dBA

Built in/not built in Model 432 is intended on being built in. All other

models are not intended on being built in.

Andere Handbücher für 437

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere White Knight Trockner Handbücher

White Knight

White Knight 0312 44A 15330 - 44AS Bedienungsanleitung

White Knight

White Knight CL372 Bedienungsanleitung

White Knight

White Knight eco 43a the low carbon Kurzanleitung

White Knight

White Knight 76AS Bedienungsanleitung

White Knight

White Knight C38AW Bedienungsanleitung

White Knight

White Knight ECO 83A Kurzanleitung

White Knight

White Knight B96G8W Bedienungsanleitung

White Knight

White Knight CL42 Bedienungsanleitung

White Knight

White Knight 0312 44A 15100-44AW Bedienungsanleitung

White Knight

White Knight C37AW-S Bedienungsanleitung

White Knight

White Knight eco 86A Bedienungsanleitung

White Knight

White Knight 0312 44C 15001 - C45CWUK Bedienungsanleitung

White Knight

White Knight CL767 Bedienungsanleitung

White Knight

White Knight 93AW Bedienungsanleitung

White Knight

White Knight CONDENSER TUMBLE DRYERS Bedienungsanleitung

White Knight

White Knight eco 86A Bedienungsanleitung

White Knight

White Knight C77AS Bedienungsanleitung

White Knight

White Knight C37AW Bedienungsanleitung

White Knight

White Knight TUMBLE DRYERS Bedienungsanleitung

White Knight

White Knight 44AW Bedienungsanleitung

White Knight

White Knight C831WV Bedienungsanleitung

White Knight

White Knight C36AW Bedienungsanleitung

White Knight

White Knight C372WV Bedienungsanleitung

White Knight

White Knight CL43 Bedienungsanleitung

Beliebte Trockner Handbücher anderer Marken

Bosch

Bosch WTA79200GB Bedienungsanleitung

Amana

Amana W10233410A Bedienungsanleitung

Miele

Miele TWH 780 WP Bedienungsanleitung

Asko

Asko T760 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Bedienungsanleitung

Bosch

Bosch Logixx 10 WTB76556GB Technisches Datenblatt

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Bedienungsanleitung

Electrolux

Electrolux EW2H328R2 Bedienungsanleitung

Beko

Beko DS8433RX1M Bedienungsanleitung

Dawlance

Dawlance Spinner DS 6000 C Bedienungsanleitung

Electrolux

Electrolux TP5080TW Bedienungsanleitung

AEG

AEG TR838P4OB Bedienungsanleitung

Indesit

Indesit IDV 75 Bedienungsanleitung

Infiniton

Infiniton SD-DG85C Bedienungsanleitung

BOMANN

BOMANN WT 5019 Bedienungsanleitung

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Bedienungsanleitung

Asko

Asko T793C Bedienungsanleitung

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Bedienungsanleitung
