Willow WS90DFBL Bedienungsanleitung

Instruction manual

90cm Dual Fuel

Range Cooker

WS90DFBL

WS90DFSS

Contents

Safety Warnings............................................................................................................................ 4

Unpacking..................................................................................................................................... 7

Product Overview......................................................................................................................... 8

The Hob........................................................................................................................................................................8

Control Panel..............................................................................................................................................................8

Timer/Programmer Display...................................................................................................................................9

Oven...........................................................................................................................................................................10

Setting the Clock ........................................................................................................................ 11

Before Using the Hob ................................................................................................................. 12

Lighting the Hob......................................................................................................................... 12

Flame Failure Safety Feature ..................................................................................................... 13

If the Burner Does Not Light...................................................................................................... 13

If the Flame is Irregular .............................................................................................................. 13

Electricity Failure........................................................................................................................ 13

Cookware Guidelines ................................................................................................................. 14

Using the Oven ........................................................................................................................... 15

First Time Use of the Oven .................................................................................................................................15

Oven Controls ............................................................................................................................. 15

Right Oven Shelf Positions.................................................................................................................................16

Left Bottom Oven Shelf Positions....................................................................................................................16

Replacing the Anti-tilting Oven Shelf ............................................................................................................16

Preheating................................................................................................................................................................17

Cooking.....................................................................................................................................................................17

Baking Tips...............................................................................................................................................................17

Cooking with the Grill ................................................................................................................ 18

Grill Shelf Positions ...............................................................................................................................................19

Setting a Timer............................................................................................................................ 20

Cancelling the Buzzer sound.............................................................................................................................20

Setting a Cooking Timer............................................................................................................. 21

Setting a Cooking Timer with a Finish Time ............................................................................. 22

Using the Storage Compartment .............................................................................................. 24

Cleaning and Maintenance........................................................................................................ 25

Cleaning the Gas Hob................................................................................................................. 25

Burner Parts and Pan Supports ................................................................................................. 26

Replacing the Burners................................................................................................................ 26

Hob Controls ............................................................................................................................... 26

Cleaning Instructions ................................................................................................................. 27

Cleaning the Outside of the Cooker...............................................................................................................27

Cleaning the Oven Door Glass..........................................................................................................................27

Cleaning the Inside of Your Cooker.................................................................................................................28

Removing the Grill Door ............................................................................................................ 28

Hints and Tips ............................................................................................................................. 29

Removing the Door Glass .......................................................................................................... 30

Replacing the Oven Lamps ........................................................................................................ 30

Installation .................................................................................................................................. 31

Adjusting the Feet ...................................................................................................................... 32

Moving the Cooker ..................................................................................................................... 32

Stability Chain ............................................................................................................................ 32

Ventilation Requirements.......................................................................................................... 33

Gas Installation........................................................................................................................... 33

Installation and Service Regulations ........................................................................................ 33

Gas Connection........................................................................................................................... 34

Installation Relevant to Natural Gas ............................................................................................................... 34

Installation Relevant to Liquid Petroleum Gas (LPG)................................................................................ 34

To Connect the Gas Supply................................................................................................................................ 34

Replacement of Burner Injectors .............................................................................................. 35

To Replace the Hob Injectors ............................................................................................................................ 35

Adjusting the Reduced Flame Position ......................................................................................................... 35

Injector Size Table....................................................................................................................... 36

Electrical Connection ................................................................................................................. 37

Energy Saving Tips ..................................................................................................................... 38

Product Fiche and Specications .............................................................................................. 39

Product Support Information .................................................................................................... 41

Safety Warnings

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

• This appliance must be installed by a qualied Gas Safe registered

engineer. The manufacturer is not responsible for any damage caused

by incorrect installation.

• Check whether there is any damage to the appliance after you have

unpacked it. If any damage is found, do not use the appliance and

contact the store where you purchased it.

• This appliance is for indoor domestic use only.

• This appliance is for cooking purposes only. It must not be used for other

purposes, for example room heating.

• For disconnection from the mains supply you must have a switch with

a contact separation of at least 3.0 mm in all poles and rated 32 Amp that

provides full disconnection, this must be incorporated in the xed wiring

in accordance with the local wiring rules.

• If the mains cable gets damaged, it should be replaced by an authorized

service agent or qualied electrician in order to avoid a hazard.

• The cooker must be used in a well ventilated location and installed on

at / level surface.

• Only operate your appliance in a dry atmosphere.

• Keep the electrical cables of your other appliances away from hot areas;

do not let them touch the appliance.

• Ensure that the appliance is switched o at the mains supply switch

and allowed to completely cool down before cleaning, replacing the

oven lamp or performing any maintenance to avoid the possibility of an

electric shock or burns.

• The use of a gas cooking appliance results in the production of heat,

moisture and products of combustion in the room in which it is installed.

Ensure that the kitchen is well ventilated especially when the appliance

is in use. Keep natural ventilation holes open or install a mechanical

ventilation device (mechanical extractor hood).

• Prolonged intensive use of the appliance may call for additional ventilation,

for example opening of a window, or more eective ventilation, for

example increasing the level of mechanical ventilation where present.

• This appliance can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or

lack of experience and knowledge if they have been given supervision

or instruction concerning use of the appliance in a safe way and

understand the hazards involved.

• Cleaning and user maintenance shall not be made by children without

supervision.

• Children should be supervised to ensure that they do not play with

the appliance.

• During use the appliance becomes hot. Care should be taken to avoid

touching the parts inside the oven or the hob burners/pan stands.

• The appliance and its accessible parts may become hot during use.

Young children should be kept away.

• Unattended cooking on a hob with fat or oil can be dangerous and may

result in re. NEVER try to extinguish a re with water, but switch o the

appliance and then cover the ame e.g. with a lid or a re blanket.

• Danger of re: Do not store items on the cooking surfaces.

• When the hob is hot never touch any parts that get hot. Allow the hob to

cool before touching these parts.

• When the oven is hot never touch the oven glass or any other parts that

get hot. Allow the oven to cool before touching these parts.

• Do not use harsh abrasives cleaners or sharp metal scrapers to clean the

oven door glass since they can scratch the surface, which may result in

the glass shattering.

• Before starting to use your appliance, keep curtains, tulle, paper or

ammable materials away from your appliance.

• Do not keep combustible or ammable things in, on or near the appliance.

• Do not use steam cleaners for cleaning the appliance.

• Do not rest any items on the open door and do not let children climb on

or stand on it.

• Take care when handling parts with glass, knocks, chips, heavy handling

and dropping could cause the glass to shatter.

• The glass doors use toughened glass and are designed to break into

many‘nugget’ size pieces if it breaks. These pieces will still have sharp

edges, please handle broken glass with care.

• The appliance is not intended to be operated by means of an external

timer or separate remote-control system.

• This appliance is not designed to be used with hob guards. Use of

inappropriate hob guards can cause accidents.

• The inside surface of storage compartment may be hot during use. Care

should be taken to avoid touching inside surfaces.

• To prevent the appliance tipping, the stabilizing

bracket must be installed.

Unpacking

Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to local

regulations.

The following items are included:

Oven Shelf × 2

Thank you on the purchase of your new Dual Fuel Range Cooker.

You must read this manual in order to fully understand how to operate it correctly.

This unit MUST be installed by a competent and registered engineer (Gas Safe in the UK).

Please allow the installer to view the installation section of this manual.

Read all the safety warnings carefully before use and keep this manual for future reference.

* All images are for indication only; please refer to your individual unit for actual item.

LPG Conversion Kit:

LPG Nozzle × 5

Pan Support (Left/Middle/Right) × 3 Grill Pan set x 1

100 mm Burner Ring × 1

100 mm Burner Cap × 1

75 mm Burner Ring × 2

75 mm Burner Cap × 2

55 mm Burner Ring × 1 Multi Ring Burner Ring × 1

55 mm Burner Cap × 1 67 mm & 135 mm Multi

Ring Burner Cap × 1

Control Panel

1. Oven Thermostat indicator

2. Oven Temperature Control

3. Oven Programme Control

4. 3 button Digital Timer

5. Front left Hob Control

6. Back Left Hob Control

7. Middle Multi Ring Hob Control

8. Back Right Hob Control

9. Front Right Hob Control

123456789

* All images are for indication only; please refer to your individual unit for actual item.

Product Overview

6 8 10

The Hob

1. Standard Burner (75 mm)

2. Multi Ring Burner (middle 60mm, outer 130mm)

3. Small Burner (55 mm)

4. Large Burner (100 mm)

1 3

Timer/Programmer Display

1 2

1. Auto Cook Symbol

2. Manual Cook Symbol

3. Time Display

4. Timer Symbol

5. + Button

6. Option Button

7. - Button

Oven

1. Control Panel

2. Hob Controls

3. Wire grill tray

4. Deep Grill Tray **

5. Oven Door

6. Oven Handle

7. Lower Cabinet Door

8. Plastic Legs

9. Oven Lamp

10. Grill

The inside surface of storage compartment may be hot during use. Care should be taken to avoid

touching inside surfaces.

NOTE: your model may have a different number of shelves to illistration.

** Not included with this model

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Willow Kocher Handbücher

Willow

Willow WSE50W Bedienungsanleitung

Beliebte Kocher Handbücher anderer Marken

Modena

Modena FC 7645 SGM Betriebsanleitung

Electrolux

Electrolux Insight EKG6049 Bedienungsanleitung

Stanley

Stanley Donard 60 Bedienungsanleitung

Bartscher

Bartscher 201TC Bedienungsanleitung

Parkinson Cowan

Parkinson Cowan 50 GR/BU Bedienungsanleitung

Siemens

Siemens HK9P00020U Bedienungsanleitung

Creda

Creda S150E Leitfaden

Creda

Creda HB48309 Bedienungsanleitung

Bosch

Bosch HCE743220F Bedienungsanleitung

Tricity Bendix

Tricity Bendix SE545P Bedienungsanleitung

NEFF

NEFF E1461A2/01 Bedienungsanleitung

Zanussi

Zanussi ZCM 700 X Bedienungsanleitung

Smeg

Smeg SNL61MA9 Bedienungsanleitung

RiverGrille

RiverGrille TF2002501-RG Bedienungsanleitung

Vollrath

Vollrath 69504F Bedienungsanleitung

Tricity Bendix

Tricity Bendix CSIE500 Bedienungsanleitung

AEG

AEG Competence 5731 V Bedienungsanleitung

Euromaid

Euromaid ES60 Bedienungsanleitung
