Wimius S26 Bedienungsanleitung

THE PROJECTOR

USER MANUAL

S26

English

Deutsch

Français

Español

Italiano

日本語

01-25

26-50

51-75

76-100

101-125

126-147

LANGUAGE

Foreword

Warnings

Precautions

Structural Diagram

Package Lists

Projector Specications

Multimedia Supported Files

Product Overview

Remote Control

Installation

Installing the Projector

How to clean the “ Black Spot”?

Projector Setting

Projection Distance&Size

Starting the Projector

Power On/Power Off

Language Setting

Keystone Correction & Focus & Digital Zoom

Signal Source & Multimedia Connection

Wireless Connection

Screen Mirroring ( For iOS System)

Screen Mirroring ( For Android System)

Bluetooth Connection

Main Menu Function

Factory Reset

System upgrade

Scheduled Shutdown

Power On Option

FAQ

Content

[email protected]

Foreword

Warnings

Dear Customer,

Luckily, your projector is already in your hands! Let's start enjoying the unique movie night with your family.

Please read this manual thoroughly before using the projector.

Do you have any questions on how it works? Are you satised with your projector? If you have any issues, send

email to [email protected], attaching your order number and the description of you issue. We will x your

issues as soon as possible.

Customers sometimes can meet some confusion when using the projector. Rather than trying to communicate

directly with us, many buyers instead just leave a comment on the product page. However, most negative comments

are caused by non-standardized use rather than a defect in the product itself. Actually, many problems can be

easily solved by setting, such as no signal, no sound, etc. We promise all the projectors have been carefully checked

and packaged before shipping. Therefore, if you have any questions, please contact us and give us an opportunity

to improve it. We guarantee that we will provide you with the most satisfactory solution.

Thanks for your understanding!

Best regards,

WiMiUS Brand Team

1. High brightness lamp! Please don’t look directly into the lamp.

2. Adjusting the contrast, brightness and focal length according to different input signals is the key to make the

picture clear; otherwise, the picture will be blurred;

3. There is high voltage inside the projector. Please don’t open the cover and touch the internal parts of the

machine.

[email protected]

Precautions

1. Clean

When cleaning this projector, please pull out the power cable. Use a wet cloth to clean, don’t use any detergent that

may damage the unit.

2. Accessory

Please use our recommended accessory. Or it will damage the projector.

3. Correct environment

Do not place the projector in a wet environment, like a damp basement or near the swimming pool, etc.

4. Ventilation

The ventilation is equipped for the projector to work stably. Do not put anything around the vents. Or it will cause

the projector to heat up.

5. Power

Please make sure the power is within the required power range.

6. Thunder

For thunder day, please unplug the power cable from the projector.

7. Repair

Due to high voltage inside, please do not open or try to repair the projector by yourself. Don't disassemble the

projector without our suggestion, otherwise, any warranty will be invalid. Seek help from an authorized agent or

qualied professionals when needed.

8. Keep away from heat device

Please make sure the projector is far away from any heat devices which will damage the projector.

[email protected]

Structural Diagram

Package Lists

Projector Specications

Projector x 1 Remote Control x 1 Power Cable x 1 AV Signal Cable x1 HDMI Cable x1

Portable Bag x1 User Manual x1 Cleaning Swab x2 Screwdriver x1

Model No.S26

Display Technology LCD Light Source LED

Resolution Native 1920x1080P Focus Manual

Installation Type Front/Rear/Ceiling/Desktop Aspect Ratio 16:9/4:3

Product Size 234×192×94mm Product Weight 1.6kg

Input Interface HDMI/USB/AV/3.5mm audio Output Interface Audio out

[email protected]

Multimedia Supported Files

Files Support Doesn't Support

Audio Format MP3, AAC, WAV, WMA, M4A, OGG,

FLAC Dolby AC3, DTS, DivX, VC1, RM, RMVB, FLV, etc

Image Format JPG, PNG, BMP, JPEG

Video Format MP4, MKV, WMV, 3GP, MPG, TP, TS,

F4V, DAT, FLV, TRP MSVC / CRAM , MP42, GMC, IV32, RLE, cvid, RV20,

DivX, RM, RMVB, VC1, FLV

File Format TXT, XLSX, DOCX, PPT

If play the above les, the projector still can’t work properly, please don’t hesitate to contact us via

[email protected].

Product Overview

23456 7 8

1. Arrow Keys /Conrm

2. Power

3. Back

4. Source

5. Earphone/3.5mm

Audio Out

6. Audio, Video Input

7. USB Input

8. HDMI Input

[email protected]

Remote Control

1. Power

2. Signal Source

3. Arrow keys

4. Menu

5. Home page

6. Volume+

7. Volume-

8. Mute

9. Flip

10. Conrm

11. Back

12. Previous

13. Next

310

411

1. Install 2 pieces of AAA batteries(not included) into the remote before using it. Do not combine new batteries with

old ones in remote controller, which can cause operation failure due to insufcient power supply.

2. When using the remote control, please make sure that the signal transmitter of the remote controller aims at

infrared signal of the projector.

3. When you are not using the remote controller for a long period. Please take out the batteries to prevent it from

leakage.

NOTE:

[email protected]

Installation

Installing the Projector

How to clean the “ Black Spot”?

Keep the projector vertical and towards the mid of projector screen, keep the projection image at on the screen.

The S26 has special clean door to help you clean the inner lens, it will greatly extend your use lifespan and

enhance the movie enjoyment!

1. To adjust the tilt base, unscrew the support rod at the bottom of the projector, see below picture.

2. For Ceiling mount, there are 4 holes at the bottom of the projector (M5*10mm). Please slowly unscrew the 4 black

rubbers, then you can nd the holes for ceiling mount, see below picture.

NOTE: The hanging bracket or ceiling mount stand is not packaged.

12 3

1. Support base thread Adjust the height of the projector

2. Rubber Pads/Holes Fix with M5x10mm Screws

3. Dusting Mouth Cover Dismantle it to clean the screen inside

Please Kindly Note: Any electrical appliances will automatically inhale dust during operation, so man dust falls

into the projector lens, it will have "Black dots" in the screen, it will make bad enjoyment to your use!

[email protected]

Tear off the bottom label, dismantle the Dusting Mouth Cover with a screwdriver(Included).

Method 1: Use the cold wind to blow the dusting mouth.

Method 2:(The most effective method): Use the cleaning swab (Included) to reach inside to clean the inner screen.

(We offer cleaning video!)

NOTE: Please contact our e-mail [email protected] for a video if you need detailed steps!

Projector Setting

Select Projection Mode to obtain a front and upward image:

Menu>Settings>Projection Image Setting>Projection Mode.

Press arrow key to select and press “OK” to conrm.
