C342 / C343 USER MANUAL

User Manual：C34 series

Issue Date：2016/11/24

Version 2.1

C34 USER MANUAL

- 2 -

Declaration

The content of this manual is subject to change without prior notice and cannot be

altered without written permission obtained from Wincode Technology Co., Ltd

(hereinafter referred to as “Wincode”). No part of this manual may be reproduced or

transmitted in any form by any means. This manual includes the installation instruction

and detailed description of possible questions in the operation. Wincode has reserved

the right to improve product including technology, components, software and

hardware.

The Copyright of this manual is belonged to Wincode

Ver2.0, November. 2016.

Printed in Taiwan

Trademark

Our registered trademark:

Compliances

CE Class B

FCC Part 15, Class B

CCC, CB

Comply with RoHS regulation

C34 USER MANUAL

- 3 -

Safety Instructions

Please read the following instructions carefully.

1. Install printer on the flat and stable place. To avoid printer exposed in the

high temperature or high humidity or polluted place.

2. Do not disassemble the printer and adapter under any circumstances.

3. Please check the voltage before printer is connected with power outlet; If

printer is deemed to idle for a long time, please pull out the power cord to

avoid voltage instability to cause printer damage.

4. If printer gets water or conductive material, please shut off the power

immediately to ensure the safety of personnel and equipment.

5. To avoid printer to start printing while there is no label paper installed;

otherwise the print head and platen roller would be damaged.

6. The print head is a thermal part, please do not touch it or its peripherals

during printing or after printing.

7. Shut down the printer when connecting or disconnecting interfaces to avoid

any damage happened.

8. Please choose designated adapter model of Wincode to connect printer

accordingly.

C34 USER MANUAL

- 4 -

Contents

1. Product Introduction...............................................................................................- 5 -

2. Getting Started ........................................................................................................- 6 -

2.1 Unpacking and checking...................................................................................- 6 -

2.2 Appearance .......................................................................................................- 7 -

3. Setup ........................................................................................................................- 9 -

3.1 Setting up the printer .......................................................................................- 9 -

4. Ribbon Loading......................................................................................................- 10 -

4.1. Ribbon Installation Path.............................................................................- 14 -

5. Label Loading.........................................................................................................- 15 -

5.1 Label installation path................................................................................- 17 -

6. LED indicators and button explanation ...............................................................- 18 -

7. WinLabel tool suite ...............................................................................................- 20 -

7.1 WinLabel program includes the below icons ...............................................- 20 -

7.2 Software “WinLabel” installation ..................................................................- 21 -

7.3 Driver installation............................................................................................- 21 -

7.4 Update settings and update check................................................................- 22 -

7.5 Driver Setup.....................................................................................................- 23 -

7.5.1 Page Setup....................................................................................................- 23 -

7.5.2 Media Settings .............................................................................................- 23 -

7.5.3 Calibration ....................................................................................................- 25 -

7.5.4 Options .........................................................................................................- 25 -

7.5.5 Tools ..............................................................................................................- 26 -

7.5.6 About：WinLabel driver version ...............................................................- 27 -

7.6 Printer Utility ...................................................................................................- 28 -

7.7 Settings page in the Printer Utility ................................................................- 31 -

8. Maintenance..........................................................................................................- 34 -

9. Appendix – C34 series specification ....................................................................- 35 -

C34 USER MANUAL

- 5 -

1.Product Introduction

Thank you for purchasing Wincode’s C34 series label printer, this desktop label printer

with reasonable price has reliable quality to provide user highly-efficient printing

performance. The C34 series printer not only can print label in text or graphic formats,

but owns basic function and convenient operation interface.

In addition, C34 series label printer with elegant bright black enclosure has cover open

buffer design to avoid hand clamped in operation; The maximum 5” outside diameter

label loading space; It is also equipped 32 bit processor with highly efficient relevant

configurations to make printing action smoothly and clearly so it can be applied in the

different fields such as retailing, health care, manufacturing, logistics, warehousing

and so on.

The bundled label design program as “WinLabel” provides completed label design

tools and barcode resource for user to design ideal label format; Free database

function can be connected with Excel, Access, Text file…etc and get required

information in the specified positon of label. Standalone function can support

advanced models C34 series to produce standalone format label.

C34 USER MANUAL

- 6 -

2.Getting Started

2.1 Unpacking and checking

Unpacking the package, and refer to the below packing list to check whether any part

is damaged or missing in transit. If this incident has been happened, please contact

with local dealer or distributor for further assistance.

Label Printer CD Disc Quick Installation Guide

USB Cable Adapter Power Cord

Ribbon Supply Spindle Empty Paper Core (1” core)

Ribbon Take-up Spindle

C34 USER MANUAL

- 7 -

2.2 Appearance

(Figure 1: Front View)

(Figure 2: Rear View)

C34 USER MANUAL

- 8 -

(Figure 3: Inside View)

C34 USER MANUAL

- 9 -

3.Setup

3.1 Setting up the printer

1.) Place the printer on the flat surface.

2.) Make sure the power switch is OFF.

3.) Choose corresponding cable (RS232 or USB 2.0) to connect printer with computer.

4.) Plug the DC power cord into the power slot and plug the AC power cord into a

socket on the wall.

Note: Power Cord instruction

1. To use 100-125 Voltage, please choose minimum rating power cord. (125V, 10A)

2. To use 200-240 Voltage, please choose minimum rating power cord. (250V, 10-

16A)

3. Please select the power cord length less than 2 meter.

4. Power cord is connected with adapter and have to plug in the jack as

ICE-320-C13 as right figure.

Country/ Area

North

America/Taiwan

Europe

China

Power cord

Voltage and

Electricity Spec.

125V, 10A

SVT 18AWG

250V,10A

H05VV-F

250V,10A

RVV H05VV-F

Plug (Refers to the

local plug standard)

125V, 10A

250V, 16A

250V, 10A

C34 USER MANUAL

- 10 -

4.Ribbon Loading

1. Open the ribbon cover and top cover; Install an empty paper core onto the

ribbon take-up spindle; Install a ribbon onto the ribbon supply spindle.
