Wine Guardian SS025 Technisches Dokument

Ducted Split

Wine Cellar Cooling Systems

Installation, Operation and Maintenance Guide

SS025, SS050, SS088, SS200

Manufactured by:

Syracuse, NY

Wine Guardian reserves the right, without notice, to make changes to this document at its sole discretion.

Please visit our web site for the most current version of the Wine Guardian manual and other literature.

Wine Guardian is a registered trademark (2,972,262) of Air Innovations, Inc.

Edition 10/2012

TABLE OF CONTENTS

Directory of Terms...........................................................................................................5

Illustrations......................................................................................................................6

Receiving, Inspecting and Unpacking the Wine Guardian Unit .......................................7

Review the Packing Slip to Verify

........................................................................................ 7

Check the fan coil unit for:

.................................................................................................... 7

Check the condensing unit for................................................................................................ 7

General Description.........................................................................................................8

The Wine Guardian Ducted Split System Contains ................................................................ 8

Wine Guardian Fan Coil Unit.................................................................................................. 9

Electrical Controls.................................................................................................................. 9

Condensing Unit .................................................................................................................... 9

Accessories and Optional Equipment

.................................................................................10

Heating Coils.........................................................................................................................10

Duct Collars and Flexible Ducts ............................................................................................10

Extended Compressor Warranty...........................................................................................10

Low Ambient Option..............................................................................................................10

Condensate Pump ................................................................................................................10

Humidifier..............................................................................................................................10

Overview of the Wine Guardian fan coil ................................................................................11

Ducted split systems specifications sheet .............................................................................13

Wiring Diagram for 1/4-Ton and 1/2-Ton Units......................................................................14

Wiring Diagram for 1-Ton Unit...............................................................................................15

Wiring Diagram for 2-Ton Unit...............................................................................................16

24-Volt Contactor Detail Sheet..............................................................................................17

Safety............................................................................................................................18

Safety Message Conventions

.............................................................................................18

Danger..................................................................................................................................18

Warning ................................................................................................................................18

Caution .................................................................................................................................18

Lockout/Tagout Procedure

..................................................................................................19

Safety Considerations...........................................................................................................19

Safety Hazards .....................................................................................................................19

Electrical Hazards.................................................................................................................19

Electrical Shock Hazards ......................................................................................................19

Hot Parts Hazards.................................................................................................................19

Moving Parts Hazards...........................................................................................................19

Equipment Safety Interlocks..................................................................................................20

Main Power Switch................................................................................................................20

Installation.....................................................................................................................22

Pre-installation Test ..............................................................................................................22

To test the condensing unit: .................................................................................................22

Air Flow Diagram ..................................................................................................................22

Planning the Installation................................................................................................24

Addressing Items in the Planning Process ............................................................................24

Performing a Pre-installation Check......................................................................................24

Installing the Fan Coil Unit ............................................................................................25

Floor Mounting......................................................................................................................25

Wall Mounting.......................................................................................................................25

Ceiling Mounting ...................................................................................................................26

Typical Mounting Arrangements

.........................................................................................26

Handling and Installation.......................................................................................................26

Floor Mount...........................................................................................................................26

Rod Mount ............................................................................................................................27

Shelf Mount...........................................................................................................................27

Optional ductwork connection on same wall .......................................................................27

Installing the Ductwork and Grilles................................................................................28

Duct Collars ..........................................................................................................................28

Location of Supply and Return Grilles...................................................................................28

General Duct Recommendation............................................................................................29

Reducing Noise from the Unit ...............................................................................................29

Installing the Condensate Drain Connection.................................................................30

Installing the Drain Line.........................................................................................................30

Priming the Drain Trap..........................................................................................................30

Wiring the Fan Coil Unit for Power................................................................................31

Installing the Condensing Unit.......................................................................................32

Installation of Interconnecting Refrigerant Lines (Suction and Liquid) ...................................32

Split System Interconnecting Line Sizing Chart.....................................................................33

Sample Piping Configurations...............................................................................................34

Leak Checking and Evacuation Process...............................................................................35

Wiring....................................................................................................................................35

Refrigerant Charging.............................................................................................................36

Determining the amount of charge........................................................................................36

Procedures for Charging System with Head Pressure Control ..............................................37

Superheat.............................................................................................................................38

Sub-Cooling..........................................................................................................................38

Split System Operations Chart..............................................................................................39

Installing the Remote interface controller and Communication Cable...........................40

Mounting the Remote Interface Controller.............................................................................40

Installing the Wine Guardian Remote Sensor ...............................................................42

Mounting the Remote Sensor................................................................................................42

Joining the Communication Cable.................................................................................44

Changing Jumper Positions ..................................................................................................44

Standard Controller Functions.......................................................................................45

Inspection and Start Up Checklists ...............................................................................50

Receiving and Inspecting......................................................................................................50

Handling and Installing..........................................................................................................50

Starting-up the Unit...............................................................................................................50

Platform Mount......................................................................................................................50

Starting-up and Operating the Wine Guardian Split System .........................................51

Turn on the Unit....................................................................................................................51

Testing the Fan.....................................................................................................................51

Running the Unit

..................................................................................................................51

Cycling the Unit.....................................................................................................................52

Setting the Remote Interface Controller ................................................................................52

Regulating the Wine Cellar Temperature ..............................................................................52

Changing the Air Flow Direction............................................................................................52

Maintenance..................................................................................................................53

General

................................................................................................................................53

Cleaning the Condensate Drain System................................................................................54

Cleaning the Humidifier.........................................................................................................54

Heating Coil Option...............................................................................................................54

Maintenance Schedule

................................................................................................55

Monthly.................................................................................................................................55

Yearly....................................................................................................................................55

Troubleshooting

...........................................................................................................56

Typical start up problems

....................................................................................................56

Unit does not start up

..........................................................................................................56

Power switch light is on and the remote interface controller light is off ..................................56

Power switch light is on and the remote interface controller light is on ..................................56

Unit is operating and blows evaporator air

,........................................................................57

Cellar temperature too cold (below 51 degrees) when unit is running....................................57

Cellar temperature too cold (below 51 degrees) when unit is not running..............................57

Humidity too low or supply air is too cold, without optional humidifier....................................57

Humidity too low, without optional humidifier.........................................................................58

Humidity too low, with optional humidifier..............................................................................58

Humidity too high when unit is running but not cooling..........................................................58

Humidity too high when unit is not running............................................................................58

Humidity too high when unit is running and cooling...............................................................58

Unit operates but the power switch light is not ON ................................................................59

Unit is leaking water..............................................................................................................59

Unit is running properly, but the sound of the unit objectionable............................................59

High Pressure Switch has Shut the Unit Down

..................................................................60

Instructions to Reset High Pressure Switch

.......................................................................60

Advanced Troubleshooting............................................................................................61

Evaporator Coil is Freezing...................................................................................................61

High pressure switch keeps tripping......................................................................................61

Unit cycles on and off more than 8 times/hr...........................................................................61

High pitched or loud rubbing noise, clanking or vibration.......................................................61

Replacing the blowers...........................................................................................................61

Contact and Warranty Information ................................................................................62

Contact Information...............................................................................................................62

Warranty and Warranty Procedure

.....................................................................................62

Directory of Terms

Ambient Air –The surrounding area outside the wine cellar such as a room, basement, garage or

outdoors.

BTU/H –British thermal units/hour. A unit of measurement to describe the power of heating and

cooling system.

CFM –Cubic feet per minute. A unit of measurement for the amount of air handled by the fan.

Condensate / Condensation –The water formed out of the air when it is cooled below a certain

temperature (called dew point). Often referred to as “sweating” on pipes and cold surfaces. This water

collects at the bottom of the evaporator or cooling coil and drains out of the unit through the drain line.

Condensing Unit (Heat Rejection) –The condensing unit uses the compressor, condenser coil and

fan to remove heat from the refrigerant to the ambient air outside the wine cellar. The word condenser

refers to the condensation of the refrigerant from gas to liquid phase.

CSA/ETL –Canadian Standards Association/Edison Testing Laboratory (product compliance to

safety standards)

F –(Degrees) Fahrenheit

Fan Coil Unit (Evaporator Cooling) –The fan coil unit uses the cooling coil and the fan to remove

heat from the air inside the wine cellar to the refrigerant, cooling the air and condensing moisture out

of the air. The word evaporator refers to the evaporation of the refrigerant from liquid to gas phase in

the coil. The fan coil unit is ducted to or can be placed inside the wine cellar.

Flexible Duct –Round ducts with steel reinforced plastic liners, a layer of insulation and an outer

plastic layer used to convey the air from the unit to the wine cellar or ambient space.

Grille or Diffuser –Inlet or outlet plates to direct the airflow or protect the inside of the unit.

Heat Gain / Loss –The amount of cooling or heating expressed in watts transferred between the wine

cellar and the ambient space. The Wine Guardian must offset this heat/gain loss.

Inlet Air –The air returning from the wine room to the Wine Guardian fan coil.

I.D. –Inside diameter

NEC –National Electrical Code

O.D. –Outside diameter

Psig Pounds –Force per square inch gauge

Recovery –The amount of cooling the unit does to return the cellar to its set point temperature after

some new heat load is introduced, such as people or new cases of warm wine entering the cellar.

Return Air - The air leaving the cellar and returning to the inlet of the fan coil. (See Inlet Air above)

TXV –Thermal expansion valve

VAC –Volts alternating current

SP –Static pressure. Unit of measurement (inches of water column) of the pressure of the air handled

by the fan.

Set Point –The desired temperature or humidity set on the remote interface controller or humidistat.

Supply Air - The air entering the wine cellar from the discharge of the fan coil.

Illustrations

Overview of the Wine Guardian fan coil..............................................................11

Refrigeration Illustration of the Wine Guardian fan coil .......................................11

Ducted split system specifications sheet.............................................................13

Wiring diagrams for ¼ and ½ ton units................................................................14

Wiring diagram for the 1-ton unit.........................................................................15

Wiring diagram for the 2-ton unit.........................................................................16

24-volt contactor detail sheet ..............................................................................17

Airflow diagram ...................................................................................................22

Mounting illustrations...........................................................................................24

Sample piping illustration .................................................................. .................34

Receiving, Inspecting and Unpacking the Wine Guardian Unit

NOTE: Wine Guardian units are factory assembled and tested prior to shipment. The

Wine Guardian Ducted Split System consists of two separate components, the Wine

Guardian fan coil and condensing unit. These ship from separate manufacturing

facilities and therefore may not arrive on the same date and time.

Each Wine Guardian component is shipped in a corrugated box. A shipment may include one or

more boxes containing accessories.

Lift at the designated handhold locations only or fully support from underneath.

Before opening, inspect the packing crates or boxes for obvious signs of damage or

mishandling.

Write any discrepancy or visual damage on the bill of lading before signing.

Inspect all equipment for any sign of damage caused during transit.

Report all visual or concealed damage to the carrier and file a claim immediately.

Thoroughly inspect the contents for any visible damage or loose parts.

Review the Packing Slip to Verify

Model number

Factory installed options

Unit accessories

If any items listed on the packingslip do not match your order information, contact the place of purchase

immediately.

Check the fan coil unit for:

An electrical power cord

A remote interface controller with communications cable plugged into side of unit

A drain line coming out of the unit

A 24 volt contactor and enclosure

One supply duct collar and one return duct collar

Check the condensing unit for:

Weather proof enclosure, top and sides

Installation, Operation and Maintenance manual

IMPORTANT

If this procedure is not followed, the shipping company may reject the claim and the

consignee may suffer the loss. Do not return the shipment to the factory.

General Description

View Fig. 1 and Fig. 2 on page 13 for details

The Wine Guardian cooling unit is a professional grade, American-manufactured, split two-piece

climate control unit designed specifically for the storage of wine at cellar temperatures. It is designed

for easy installation and operation. Wine Guardian uses digital electronic controls and R-134a

refrigerant. The entire Wine Guardian fan coil section is tested at the factory and the condensing unit is

shipped separately. All components are of a high quality standard commercial grade. The entire system

is approved by ETL according to UL 1995 and CSA safety standards. All wiring complies with NEC.

Each Wine Guardian fan coil section is furnished with a sealed, UL-approved power cord and plug.

The Wine Guardian Ducted Split System Contains

1. A Wine Guardian Fan Coil Unit with:

A thermal expansion valve to control the flow of refrigerant into the evaporator coil

A built in condensate drain trap. No external trap is required.

A removable control panel for ease of service

Supply duct collar

Return duct collar

Remote interface controller and control cable

2. A Condensing Unit with:

A filer dryer to keep the refrigerant clean and free of contaminants

A sight glass to observe the level of refrigerant

A manual reset high pressure switch on the discharge to protect the compressor from high

pressures.

Auto reset low pressure switch

24-volt contactor for control of fan coil unit

Crankcase heater

Low ambient refrigeration controls

Outdoor enclosure

IMPORTANT

Design and specifications are subject to change without notice

Wine Guardian Fan Coil Unit

The Wine Guardian fan coil unit meets its rated capacities for total BTU/H and CFM at design cellar

conditions and external static pressures. The fan coil unit is capable of rated CFM against the static

pressure imposed by recommended ductwork. The fan is a motorized impeller type, statically and

dynamically balanced, and uses permanently lubricated direct drive motors requiring no maintenance.

The Wine Guardian fan coil section operates as air passes through the cooling coil and is cooled by the

refrigerant inside the coil. This causes any excess humidity in the air to condense and be captured in

the drain pan and piped outside the unit. Air then enters the fan where it is pressurized and discharged

out of the unit through one of five openings. Optional heating coils are located between the cooling

coil and the fan. These coils heat the air to prevent low temperatures in the cellar.

All exterior framing of the Wine Guardian is powder coated 0.063 inch gauge aluminum to prevent

rust and corrosion. All coils are copper tubes, aluminum fins, with an electrocoating to protect against

premature corrosion. The unit uses an external drain to remove excess moisture and not reintroduce it

into the cellar or ambient space. Removable, multiple access doors are provided to facilitate cleaning

and maintenance, duct connections, and access to components and wiring. The fan coil has at least five

discharge outlets to facilitate custom installations.

Each unit is provided with a pre-wired and tested remote interface controller for remote mounting

within the wine cellar. The remote interface controller has multiple control functions for cooling,

heating and operation. It has a fully automatic mode to switch between heating and cooling.

Electrical Controls

Themainelectricalcontrolboardandcomponentsarelocatedonaseparatepanelaccessiblethroughasidedoor

panelorbyremovaloftheon/offpanelfromthesystemchassis.

All wiring is in accordance with the NEC.

Wires are numbered and color coded to match the wiring diagrams.

Electric power is supplied by a single factory-furnished cord and plug. All external controls are digital

and proprietary to Wine Guardian products. Only approved communication cable and Wine Guardian

controllers are suitable for proper system operation.

Condensing Unit

Compressors are rotary, self-lubricating, permanently sealed, hermetic reciprocating-type compressors,

with internal overload protection and capacitor start. They include a minimum of 20 months

manufacturer’s warranty and an optional five-year warranty. Compressors are mounted on rubber-in-

shear isolators to reduce noise and vibration. Additional features include a liquid line filter drier,

Sporlan Head Master Controls, a liquid line receiver and refrigerant sight glass. Each unit is housed in

a painted steel enclosure suitable for outdoor installation. The outdoor enclosure has adequate area for

ventilation and refrigerant piping penetrations.

IMPORTANT

The airexhaust from the condensing unit is hot and will be 25to 35 degrees F abovethe entering

temperature. The condensing units are rated for a maximum temperature of 115 degrees F. The

condensing units shouldbe installed in a well-ventilated area to ensureproperairflow across the

condenser coil and to limit short cycling.

Accessories and Optional Equipment

Heating Coils

An optional heating coil is built in and requires no additional power source. The electric

heating option is factory installed and includes primary and secondary over-temperature

protection devices per UL and NEC.

Duct Collars and Flexible Ducts

Ducting for the Wine Guardian is sold in kits by size for each unit. Each kit contains two

adapter collars, one 25 foot length of round flexible duct and two straps. The number of duct

kits needed depends on the wine cellar layout and application. The size of the kit depends on

the model Wine Guardian selected. Follow installation instructions carefully. Poorly or

incorrectly installed ducts can degrade the performance of your unit dramatically.

Extended Compressor Warranty

The Wine Guardian uses only the best commercially available compressors on the market.

However, since the compressor is the single most expensive component in the unit, it is

recommended that you purchase the extended warranty option.

Low Ambient Option –Standard on all Wine Guardian Ducted Split Systems

A factory-installed low ambient option is available that makes the Wine Guardian capable of

exposure to low ambient temperatures. This feature controls the condenser fan operation based

on head pressure and heats the compressor oil reservoir. The low ambient option is

recommended whenever the condenser section is exposed to air temperatures below 40

degrees F.

Condensate Pump

An optional Wine Guardian automatic condensate pump is available

to pump the water to a

remote sink, drain pipe or

outside. It requires aseparate120voltelectricaloutlet.

Humidifier

Another popular option for the Wine Guardian is a humidifier. The humidifier is available for

split system installation and can be retrofitted onto any existing Wine Guardian unit. Each

humidifier is furnished with a communication cable connection to plug into the side of the

Wine Guardian fan coil unit. It is then controlled by the same remote interface controller that

is used for the operation of the Wine Guardian unit. The humidifier mounts directly onto the

Wine Guardian unit and requires a water supply and drain for operation.

CAUTION

CAREFULLY FOLLOW THE INSTALLATION INSTRUCTIONS INCLUDED WITH THE HUMIDIFIER.

REFER TO THE INSTRUCTIONS CONTAINED INTHE BOX FORTHE HUMIDISTAT.
